Whitehall F-260-S User manual

6900-204-001_REV_B
Revised: 08-11-2020
User Manual
Full-Immersion Models
F-260-S, F-270-S, F-300-S, F-425-S
P.O. Box 3527  City of Industry, CA 91744-0527 U.S.A.
800-782-7706
 626-968-6681  www.whitehallmfg.com
F-260-S F-425-S

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
2
The information in this manual is proprietary and confidential to Whitehall Manufacturing, a
division of Acorn Engineering and a member of Morris Group International. Any
reproduction, dissemination or distribution of this document in whole or in part without prior
written authorization of Whitehall Manufacturing is strictly prohibited. While every effort has
been made to ensure the accuracy of information provided in this document, please note
the information is subject to change without notice.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
3
Contents
Symbols................................................................................................................................................ 4 
Warnings .............................................................................................................................................. 5 
Intended Use ........................................................................................................................................ 7 
Contraindications ................................................................................................................................. 7 
User Skills ............................................................................................................................................ 8 
Device Description ............................................................................................................................... 8 
Accessories .......................................................................................................................................... 9 
Facility Requirements ........................................................................................................................ 10 
Rough-In for F-260-S .................................................................................................................... 11 
Rough-In for F-270-S .................................................................................................................... 12 
Rough-In for F-300-S .................................................................................................................... 13 
Rough-In for F-425-S .................................................................................................................... 14 
Instructions ......................................................................................................................................... 15 
Installing Carriage Assemblies ...................................................................................................... 15 
Installing Turbine(s)....................................................................................................................... 17 
Installing Thermometer .................................................................................................................. 17 
Installing Headrest ......................................................................................................................... 17 
Operating Instructions .................................................................................................................... 18 
Draining Instructions ..................................................................................................................... 18 
Thermometer Calibration Instructions ........................................................................................... 19 
Disinfecting and Cleaning Instructions .......................................................................................... 20 
Turbine Maintenance ..................................................................................................................... 21 
Troubleshooting ............................................................................................................................. 21 
Classification...................................................................................................................................... 23 
Specifications ..................................................................................................................................... 23 

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
4
WARNING
READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE OPERATING THE WHIRLPOOL
Failure to follow the instructions in this manual could result in Whirlpool damage and/or bodily injury
Symbols
Waste Electrical and Electronic Equipment (WEEE)
Indicates that the product must not be disposed of with regular waste. It is the user’s responsibility to dispose
of waste equipment according to local laws. For information about where to drop off the waste equipment for
recycling, contact your local waste collection authority.
General Warning or Caution
Indicates personal injury or damage to the equipment is possible
Electric Shock
Indicates a hazard arising from dangerous voltage. Any mishandling could result in irreparable damage to
the equipment and/or personal injury or death.
Warning; Crushing of hands
To warn of a closing motion of mechanical parts of equipment
Refer To Manual (Instructions for Use)
Indicates that user manual shall be referred to before performing any installation, operation or maintenance
Alternating Current
Indicates alternating current is present
Manufacturer
Indicates manufacturer of device
Manufacture Date
Indicates manufacture date of device
Authorized representative in the European Community
Indicates the authorized representative in the European Community

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
5
Warnings
Treatments:
 Whirlpools are intended for use by a medical professional only, e.g., Physiotherapist,
Physical Therapist, Rehabilitation Therapist, Athletic Trainers, Podiatrist
 During treatment, stay with patient at all times.
 The maximum allowable patient mass is 135 kg (298 lbs)
 Ensure water in tub is no greater than 43.3ºC (110ºF). Higher temperatures may result
in injury to patient.
 Treatment should terminate if the patient experiences dizziness, light-headedness,
shortness of breath, or nausea
 To avoid patient cross-infection, drain and clean hydrotherapy equipment after each
patient’s use, and disinfect equipment surfaces and components by using an EPA-
registered product in accordance with the manufacturer’s instructions
Operation:
 Use of this equipment adjacent to or stacked with other equipment should be avoided
because it could result in improper operation. If such use is necessary, this equipment
and the other equipment should be observed to verify that they are operating normally.
 Use of accessories and cables other than those specified or provided by the
manufacturer of this equipment could result in increased electromagnetic emissions or
decreased electromagnetic immunity of this equipment and result in improper operation
 Use only Whitehall-approved items on the Whirlpool
 Portable RF communications equipment (including peripherals such as antenna cables
and external antennas) should be used no closer than 30 cm (12 inches) to any part of
the Whirlpool, including cables specified by the manufacturer. Otherwise, degradation
of the performance of this equipment could result.
 If there is visible damage to the Whirlpool or packaging upon receipt, report this
damage to shipping company and Whitehall. Do not use the Whirlpool if damage to it
is suspected.
 Operate with the bottom of the turbine submerged in at least 15.2 cm (6 inches) of
water
 Keep hair and loose items (gown straps, gauze, etc.) out of the tub. These items can
be pulled into the pump and cause injury or damage to the turbine.
 Use the Whirlpool only for the purpose described in this manual
 Position the Whirlpool so that the power cord is easily accessible.
 To avoid damage to the thermometer, do not drop the thermometer or expose it to
temperatures above 60°C (140°F)

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
6
 No parts shall be serviced or maintained while in use with a patient
 To avoid the risk of electric shock, this equipment must only be connected to a supply
mains with protective earth
 Connect the power cord to a Ground Fault Circuit Interrupter (GFCI) medical grade
receptacle
 No parts of the Whirlpool, including the power supply cord, are repairable or
replaceable by service personnel
 No modification of the Whirlpool is allowed
 To protect stainless steel surfaces, use soft water (i.e., water with low concentrations of
ions and in particular low in ions of calcium and magnesium) in the tub.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
7
IntendedUse
Whitehall Whirlpools are intended to facilitate hydrotherapy. Tub size, water temperature,
and water circulation requirements are determined by the medical professional treating the
patient.
Whirlpools are intended for use in professional healthcare and supervised athletic training
facilities only.
Muscle or joint pain are the typical indications for hydrotherapy, and Whirlpools can be
used for any part of the body below the neck. Suitability of treatment is determined by the
medical professional treating the patient.
Contraindications
Patient Groups in which hydrotherapy is contraindicated:
ꞏ Active infection anywhere in the body
ꞏ Open wounds*
ꞏ Loss of temperature sensation
ꞏ Hydrophobia
ꞏ Heat or cold intolerance
ꞏ Poor balance
ꞏ Kidney failure
*Burn patients are an exception. Work with the consent of a physician in these cases.
Safety & Effectiveness has not been established in patients:
ꞏ With Cancer: Caution is advised when treating patients with cancer. It is best to
work with the consent of a physician.
ꞏ Who Hemorrhage: Caution is advised when treating a patient who has a tendency
to hemorrhage. Applications of heat and cold which cause vasodilation, which
increases the possibility of hemorrhage.
ꞏ Who are Pregnant: Caution is advised when treating someone who is pregnant.
Consult the patient’s healthcare provider with any questions or concerns you may
have.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
8
UserSkills
The medical professional using the Whirlpool must have the following skills:
 The ability to assist the patient
 Knowledge of hydrotherapy protocols
 To have read and understood this manual
 To have become familiar with the Whirlpool before using it with a patient

DeviceDescription
The Whirlpool consists of a welded stainless steel tub for holding water and one or two
turbine assemblies. For the Whirlpool with one turbine (F-260-S), the turbine is mounted to
the side of the tub. For Whirlpools with two turbines (F-270-S, F-300-S, F-425-S), the
turbines are mounted to a track, allowing each turbine to be moved independently around
the tub. The interior of the tub and tub rim are considered Type B Applied Parts, since they
are likely to be touched by the patient.
The turbine assembly is a motor-operated centrifugal pump that circulates the water. The
pump position can be adjusted up or down to change the position of the water outlet, then
locked with a handle. The tub is supported by legs. Water is drained by opening the drain
valve to a fixed drain.
Water temperature may be adjusted by the operator depending on the desired treatment.
A thermometer mounted to the side of the tube is included with the Whirlpool. The
Whirlpool does not control water temperature.
The patient can enter the tub or be placed in the tub and is fully immersed in the water to
the neck. A vinyl headrest is provided for the patient.


WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
9
Accessories
The following accessory is available:
# Description Instructions
HR Vinyl Headrest Mount headrest tube in mount on tub
and clamp in place with knob. For
maintenance, see Disinfecting and
Cleaning Instructions.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
10
FacilityRequirements
The following are needed prior to using your Whirlpool:
 Clean water source for filling tub. For burn patients with open wounds, follow the
physician’s recommendation for water quality.
 Drain plumbed per Figure 1, Figure 2, Figure 3, or Figure 4, installed by licensed
plumber
 Medical-grade GFCI receptacle(s) located per Figure 1, Figure 2, Figure 3, or
Figure 4, installed by licensed electrician
 Environmental conditions within those specified in the Specification section of this
manual
NOTE: The emissions characteristics of this equipment make it suitable for use in
industrial areas and hospitals (CISPR 11 class A). If it is used in a residential environment
(for which CISPR 11 class B is normally required) this equipment might not offer adequate
protection to radio-frequency communication services. The user might need to take
mitigation measures, such as relocating or re-orienting the equipment.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
11
Figure 1: F-260-S Rough-In Diagram. Numbers in parentheses are in mm.
① Mains input (medical grade GFCI)* ⑦ Filler spout
② 31.8mm (1-¼ inch) outer diameter twin
overflow assemblies
⑧76.2mm (3 inch) butterfly valve, 76.2mm (3
inch) outer diamete
r
tailpiece
③ Height-adjustable tub supporting legs ⑨ Turbine assembly
④ Headrest raising and lowering assembly ⑩ Removable grid strainer
⑤ 31.8mm (1-¼ inch) NPT x plain end pipe tube
filler connection ⑪ Thermometer
⑥ Drain valve lever handle * Custome
r
provided
Rough-In
for F-260-S
1207 mm
(
47.5 in
)
114 mm
(
4.5 in
)
152 mm
(
6.0 in
)
2286 mm
(
90 in
)
2413 mm
(
95 in
)
1175 mm
(46.25 in)
TUB FILLER
1178 mm
(46.38 in)
OVERFLOW
914 mm
(
36 in
)
1041 mm
(
41 in
)
197 mm
(7.75 in)
REF
229 mm
(9.0 in)
REF
86 mm
(3.38 in)
REF
813 mm
(32 in)
254 mm
(10 in)
559 mm
(22 in)
191 mm
7.5
381 mm
(15 in)

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
12
Figure 2: F-270-S Rough-In Diagram
① Mains input (medical grade GFCI)* ⑦ Drain valve lever handle
② 31.8mm (1-¼ inch) outer diameter twin overflow
assemblies ⑧ Filler spout
③ 63.5 mm (2-½ inch) rail, all around perimeter ⑨ 76.2 mm (3 inch) butterfly valve, 76.2
mm (3 inch) outer diamete
r
tailpiece
④ Height-adjustable tub supporting legs ⑩ Turbine and carriage assembly
⑤ Headrest raising and lowering assembly ⑪ Removable grid strainer
⑥ 31.8mm (1-¼ inch) NPT x plain end pipe tube filler
connection ⑫Thermometer
* Custome
r
provided
Adjust leg length as indicated below to allow for proper drainage (assumes level floor):
Leg Set Leg Length, cm (inches)
5 25.4 (10.00)
4 28.0 (10.625)
3 28.6 (11.25)
2 30.2 (11.875)
1 31.1 (12.25)
Rough-In
for F-270-S
1219 mm
(
48 in
)
380 mm
(
15 in
)
194 mm
(
7.625 in
)
2362 mm
(
93 in
)
2067 mm
(
81.375 in
)
492 mm
(
19.375 in
)
1625 mm
(
64.0 in
)
987 mm
(
38.875 in
)
546 mm
(
21.5 in
)
864 mm
(
34.0 in
)
35.0 mm
(1.375 in)
REF
127 mm
(5.0 in)
REF
186 mm
(6.625 in)
REF
102 mm
(
4.0 in
)
159 mm
(
6.25 in
)
178 mm
(
7.0 in
)

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
13
Figure 3: F-300-S Rough-In Diagram
① Mains input (medical grade GFCI)* ⑦ Drain valve lever handle
② 31.8 mm (1-¼ in) outer diameter twin overflow
assemblies ⑧ Filler spout
③ 63.5 mm (2-½ in) rail, all around perimeter ⑨ 76.2 mm (3.0 in) butterfly valve, 76.2
mm (3 in) outer diamete
r
tailpiece
④ Height-adjustable tub supporting legs ⑩ Turbine and carriage assembly
⑤ Headrest raising and lowering assembly ⑪ Removable grid strainer
⑥ 31.8 mm (1-¼ in) NPT x plain end pipe tube filler
connection ⑫Thermometer
* Custome
r
provided
Rough-In
for F-300-S
2260 mm
(
89.0 in
)
2134 mm
(
84.0 in
)
835 mm
(
32.875 in
)
416 mm
(
16.375 in
)
457 mm
(
18.0 in
)
1143 mm
(
45.0 in
)
1270 mm
(
50.0 in
)
559 mm
(
22.0 in
)
813 mm
(
32.0 in
)
133 mm
(5.25 in)
REF
1100 mm
(43.25 in)
REF
86 mm
(3.375 in)
REF
102 mm
(4.0 in)
368 mm
(14.5 in)
267 mm
(12.0 in)
TYP.
129 mm
(9.0 in)
REF

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
14
Figure 4: F-425-S Rough-In Diagram
① Mains input (medical grade GFCI)* ⑦ Drain valve lever handle
② 31.8 mm (1-¼ in) outer dia. twin overflow assemblies ⑧ Filler spout
③ 63.5 mm (2-½ in) rail, all around perimeter ⑨ 76.2 mm (3 in) butterfly valve, 76.2
mm (3 in) outer diameter tailpiece
④ Height-adjustable tub supporting legs
⑤ Headrest raising and lowering assembly ⑩ Turbine and carriage assembly
⑥ 31.8 mm (1-¼ in) NPT x plain end pipe tube filler
connection
⑪ Removable grid strainer
⑫Thermometer
* Custome
r
provided
Adjust leg length as indicated below to allow for proper drainage (assumes level floor):
Leg Set Leg Length, cm
(inches)
5 25.4 (10.00)
4 28.0 (10.625)
3 28.6 (11.25)
2 30.2 (11.875)
1 31.1 (12.25)
Rough-In
for F-425-S
2689 mm
(105.875 in)
2267 mm
(89.25 in)
194 mm
(7.625 in)
1467 mm
(57.75 in)
419 mm
(16.5 in)
TYP
1073 mm
(42.25 in)
337 mm
(13.25 in)
1950 mm
(76.75 in)
546 mm
(21.5 in)
364 mm
(34.0 in)
38 mm
(1.5 in)
REF
127 mm
(5.0 in)
REF
168 mm
(6.625 in)
102 mm
(4.0 in)
159 mm
(6.25 in)
178 mm
(7.0 in)
REF

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
15
Instructions
Installing Carriage Assemblies
Figure 5: Installing Carriage Assemblies (F-270/300/425-S only)
NOTE: It is recommended that 2 people mount the carriage assemblies onto the tub.
The auto-counterbalancer and carriage assembly are designed for installation on the
upper and lower tub rails. After installation, the assembly will move freely around the tub
until locked in desired position.
1. At the top of the carriage assembly (1) there are two sets of upper guide rail bearing
assemblies (2). Each consists of one single roller bearing with an eccentric shaft (3)
and one double roller bearing (4). Remove both single roller bearings (3) before
mounting carriage assembly (1) onto tub.
2. Place carriage assembly (1) on tub by positioning the lower guide rail bearing (5) onto
the lower guide rail (6).
3. While holding carriage assembly (1) in place onto the upper guide rail (7), re-insert
single roller bearings (2). Do not tighten completely as adjustments will be required.
4. With carriage assembly (1) resting on upper guide rail (7), adjust single roller bearings
(2) to provide 1/8” (3.2mm) clearance between inner tub wall (8) and roller bearing (2).

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
16
Secure into position by tightening bearing bolt (9). Move carriage assembly (1) around
tub and readjust if necessary.
5. Engage friction lock (10) by rotating the lock handle (11) counterclockwise.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
17
Installing Turbine(s)
NOTE: It is recommended that 2 people mount the turbine
assembly(ies) onto the tub.
For F-260-S (Figure 6),
1. Loosen handle (8) then lower turbine support rod (4) into
tube (3). Tighten handle (8) when turbine is at desired
height.
2. Turn the pressure control valve handle (5) fully clockwise,
then fully counterclockwise to completely lubricate the
plunger assembly.
3. Turn the turbine power switch (6) off.
4. Plug in the turbine assembly into the medical grade GFCI
outlet.
For F-270/300/425-S (Figure 7),
1. Loosen set screw (3) and slide motor support casting (2) onto
tube (4) then tighten set screw (3).
2. Plug turbine power cords into carriage assembly outlets.
3. Turn the pressure control valve handle (5) fully clockwise, then
fully counterclockwise to completely lubricate the plunger
assembly.
4. Turn the turbine power switch (6) off for each turbine.
5. Plug carriage assembly power cords into medical-grade GFCI
outlet.
Installing Thermometer
(Figure 9) Insert sensing rod (3) through upper
bracket (1) and into lower bracket (4), then
tighten screw (2).
Installing Headrest
(Figure 8) Loosen handle (4), insert headrest
rod (2) into raising and lower assembly (3) and
tighten handle (4).
F
igure 6: Installing turbine on F-260-S
F
igure 7: Installing turbine on F-270/300/425-S
F
igure 8: Installing headrest
F
igure 9: Installing thermometer

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
18
Operating Instructions
Refer to warnings on page 5 before operating the Whirlpool.
1. Ensure power cord is plugged into medical-grade GFCI outlet.
2. Fill tub with water so that the bottom of turbine is at least 15.2 cm (6 inches) below
surface of water.
3. F-270/300/425-S only (Figure 5): To change the lateral position of the turbine:
WARNING: Do not place your hands on the tub railing as they could be injured by the
motion of the carriage assembly.
a. With both hands on the carriage assembly, turn handle clockwise (11) to unlock
carriage assembly from tub and slowly push the carriage assembly to the desired
location.
b. Lock the lateral position of the carriage assembly by turning handle
counterclockwise (11).
4. To change the vertical position of the turbine:
a. F-260-S (Figure 6):
i. Loosen handle (8) to unlock turbine.
ii. Slowly push down on the top of the motor support casting (2) until the bottom of
the turbine is at the desired location.
iii. Tighten handle (8) to lock in place.
b. F-270/300/425-S (Figure 7):
WARNING: Keep your hands on the motor support casting (2) during this operation.
Movement of the lifting mechanism in the carriage assembly (see Figure 5) could
cause injury.
i. Loosen handle (8) to unlock turbine.
ii. Slowly push down on the top of the motor support casting (2) until the bottom of
the turbine is at the desired location.
iii. Tighten handle (8) to lock in place.
Refer to Figure 5 and Figure 6 for the remaining steps:
5. Turn the pressure control valve handle (5) fully clockwise. This will generate maximum
water circulation.
6. Turn the turbine power switch (6) on.
7. Adjust pressure control valve handle (5) to change level of water circulation.
8. Turn the turbine power switch (6) off to stop water circulation.
9. To electrically isolate the Whirlpool from supply mains, simply unplug the Whirlpool at
the wall outlet, if required.
Draining Instructions
Refer to Figure 6 and Figure 7.
1. Turn the turbine power switch (6) off.
2. Turn drain handle (1) to empty tub.

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
19
Thermometer Calibration Instructions
1. Fill the tub so that the bottom of the thermometer tip is immersed
in at least 10.2 cm (4 inches) of water.
2. Place the stem tip of a calibrated thermometer next to the tip of
the Whirlpool thermometer.
3. Turn on the turbine assembly.
4. If the reading on the Whirlpool thermometer is not the same as
that of the calibrated thermometer, turn the external adjustment
screw (a) so that the Whirlpool thermometer reading is identical to
the calibrated thermometer.
5. Re-calibration shall be performed at least every 12 months or as
needed.
F
igure 10: Calibrating
the thermometer

WHITEHALL MANUFACTURING  P.O. BOX 3527  City of Industry, CA 91744-0527 U.S.A.
Phone [phone]  [phone]  Fax [phone]  https://www.whitehallmfg.com
20
Disinfecting and Cleaning Instructions
Important:
1. Do not use abrasive compounds or applicators such as metal brushes – they can
damage the whirlpool's appearance. Do not allow steel wool to come in contact with
stainless steel. Steel particles can embed into the stainless steel surface and create
rust.
2. Avoid cleaning or disinfecting products that contain strong acids or contain chlorine,
fluorine, bromine, or iodine, as these products can damage the protective chromium
oxide layer, resulting in corrosion and leaks. If such products are used on stainless
steel, keep the exposure brief (less than 15 minutes) and thoroughly rinse stainless
steel surfaces of all residue.
Recommended cleaning materials:
a. Sponge (natural or artificial)
b. Soft-bristle brush
c. Soft cloth (e.g. microfiber cloth)
The tub, thermometer, and turbine shall be disinfected and cleaned after each patient.
Disinfecting and Cleaning Tub and Thermometer
1. Drain the tub following the draining instructions above.
2. Verify that the turbine is off.
3. Remove any loose objects or debris that may be present in the Whirlpool tub.
To disinfect, use a stainless steel hard surface disinfectant per the manufacturer’s
instructions with one of the recommended cleaning materials above.
To clean, use a mild soap solution with one of the recommended cleaning materials
above.
Rinse thoroughly prior to use.
Disinfecting and Cleaning the Turbine
1. Drain the tub following the draining instructions above.
2. Raise turbine, place a large clean bucket in the tub and lower the bottom of the turbine
into the empty bucket.
3. Fill the bucket with water so the bottom of the turbine is at least 15.2 cm (6 inches)
below the surface of the water.
4. Add disinfectant solution to the water per manufacturer’s instructions.
5. Ensure the pressure control valve is in the open position.
6. Turn on the turbine for 5 seconds and turn it off. Wait 10 minutes.
