Whittier Wood 2002AEGACa User manual

P.O. Box 2827
Eugene, OR 97402 USA
Production Code:
06/14
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
•Before you begin your project, completely read the Assembly Instructions.
•Store this item: 1- in its box; 2- in a dry place; 3- in temperatures that
range from 40°F to 90°F (not on a cold and possibly damp cement floor.)
•Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
WARNING
Notice to California Customers
California Prop 65 requires consumer goods to be labeled if any one of
850+ different chemicals or substances, including wood dust, is present
even in trace amounts. Drilling, sawing, sanding or machining wood
products generates wood dust, a substance known to the State of
California to cause cancer. Warning: This product contains a chemical
or substance known to the State of California to cause cancer, birth
defects or other reproductive harm. California Health and Safety Code
Section 25249.6
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
CALL US FIRST! Do not return this item to the store
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: [phone]
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
AEGAC = Glazed Antique Cherry finish; AEGSP = Glazed Spice finish;
AECAF = Caffè finish
48"W McKenzie Alder Bookcase
Door Kit
Assembly Instructions
Model #
2002AEGACa;
2002AEGSPa;
2002AECAFa

Page 2 — 2002AEGACa_AEGSPa_AECAFa — 06/14
2002AEGACa; 2002AEGSPa; 2002AECAFa
48"W McKenzie Alder Bookcase Door Kit — Parts List
Please identify the parts and check that quantities received match those on this list.
If you need to replace a part, refer to the following letter and model number.
Part Description Quantity
A Door 4
BDoor Knob 4
Ca #8 x 1-1/2" Machine Screw Tuscan 4
D Side Panel Hinge 4
G Vertical Panel Hinge 4
E Hinge Plate 8
F Pad 4
H Washer 8

Tool Required: Phillips Screwdriver
Page 3 — 2002AEGACa_AEGSPa_AECAFa — 06/14
Assembly Instructions
2. Snap the handle of the Hinge (D or G) down on to each of the Hinge Plates (E or E/H) as seen
in Figures 2 and 2a.
1. Add washers to four of the eight Hinge Plates (E). You will attach the Vertical Divider Hinges (G) to
these Hinge Plates (E)/Washers (H) assemblies. See Figures 1a, 1b and 1c.
E or E/H D or G
Fig. 2 Fig. 2a
Fig. 1a Fig. 1cFig. 1b
2002AEGACa; 2002AEGSPa; 2002AECAFa
48"W McKenzie Alder Bookcase Door Kit

Page 4 — 2002AEGACa_AEGSPa_AECAFa — 06/14
3.
Fig. 3
Fig. 3a
A
Lay two Doors (A) face down on a clean, protected surface. There are predrilled holes in the doors as
shown in Figure 3. This is where you will be inserting the hinge part of the assembly. Insert the Side Panel
Hinge (D) assembly that has the plastic knobs into the predrilled holes in the bottoms and tops of the Doors
(A). See Figures 3 and 3a. You must place both Side Panel Hinges (D) into the Doors before you
attach the doors to the bookcase.
Lay the other two Doors (A) face down on a clean, protected surface. There are predrilled holes in the
doors as shown in Figure 4. This is where you will be inserting the hinge part of the assembly. Insert the
Vertical Divider Hinge (G) assembly that has the plastic knobs into the pre-drilled holes in the bottoms and
tops of the Doors (A). See Figures 4 and 4a. You must place both Vertical Divider Hinges (G) into
the Doors prior to attaching to bookcase.
E
D
4.
Fig. 4
Fig. 4a
A
E/H
G

6.
Page 5 — 2002AEGACa_AEGSPa_AECAFa — 06/14
Side adjustment
Depth adjustment
To move the door towards the side panel/vertical divider, rotate screw ‘2’ counter-clockwise.
To move it away, rotate screw ‘2’ clockwise.
Loosen screw ‘1’ and adjust door. Re-tighten screw.
Height adjustment Loosen screws ‘3’ and adjust door. Re-tighten screws.
Fig. 6
1
2
3
3
The door may need to be adjusted so that all the spaces between the doors and unit sides are
equal. To make those adjustments, follow the instructions below. See Figure 6.
Fig. 5 Fig. 5a Center Shelf Fig. 5b
Side Panel
5. Attach the door with the Side Panel Hinges (D) to the side panels of the bookcase (see Fig. 5b)
by inserting the screws in the Hinge Plate (E) into the second and third holes up from the bottom of
the bookcase unit. See Figure 5. Attach the second Side Panel Hinge assembly to the same
door/bookcase by inserting screws ino the third and fourth predrilled holes down from the top of the
fixed centered shelf. See Figure 5a. Repeat the steps for other side.
Attach doors with Vertical Divider Hinges (G) and Washers (H) to each side of the vertical divider of
the bookcase in the same manner.
Bottom
Vertical
Divider
Fixed
Center
Shelf

7. Attach the Knobs (B) to the Doors (A) with #8x1-1/2 " Machine Screws Tuscan (Ca). See Figure 7.
Door
Ca
B
8. Attach a Pad (F) to the back of each door where it comes in contact with the adjustable shelf.
F x 4
B x 4
Fig. 7
Page 6 — 2002AEGACa_AEGSPa_AECAFa — 06/14
Ca x 4
