Whyte 5 Series User manual

5 WIRE TAPS & SPLITTERS
INSTRUCTION MANUAL
www.whytetechnologies.com
MODELS:
WT51-10
WT51-20
WT52-10
WT52-20
WT53-10
WT53-20
WS52-05
Whyte



Example 5 wire

Example 5 wire

Safety
Guarantee


3
3
4
4
5
5
6
7
CONTENTS
www.whytetechnologies.com
2
GENERAL DESCRIPTION
Whyte Series 5 Taps & Spliers are a range of 5 wire passive devices that
distribute IF and Terrestrial Signals. The range includes 1 way, 2 way and
3 way Taps with either 10dB or 20dB tap-os and a 2 way Splier with
2 x 4dB tap-os.
For ease of installaon, each Tap & Splier comes complete with colour
coded 600mm F-type leads which enables the Mulswitch to be
posioned either side of the Tap as well as vercally or horizontally to
suit the available space. The Tap outputs are located on the top of the
unit to make installaon and servicing easier. A Green LED indicates the
presence of power on the HL and HH trunk lines.
TECHNICAL DESCRIPTION
Whyte Series 5 Taps and Spliers are DC passing on all IF Trunk Lines.
The HL and HH Tap Lines are DC passing whilst the VL, VH and Terrestrial
Tap Lines are isolated. An Auxiliary 18V Input is provided on all Taps and
Spliers which enables a Whyte Power Supply Unit to be conveniently
connected anywhere on the system. The Auxiliary Input injects 18V DC
on to the HH and HL trunk lines upwards and downwards.
Whyte Series 5 Taps and spliers can be coupled together to create a
multude of 5 wire spliers with various combinaons of outputs and
tap losses as can be seen below.
3
www.whytetechnologies.com


SAFETY
Whyte Series 5 Taps and Spli ers are intended for indoor use only. Do
not install the Taps and Spli ers in damp, humid, hot or dusty areas.
Always earth bond the Taps and Spli ers using the earth bonding lug to
a suitable earth bonding point, using min 4mm diameter earth cable.
Do not remove the cover of the Taps & Spli ers or disassemble them as
this will invalidate the guarantee.
GUARANTEE
All Whyte products are guaranteed for a period of 4 years from the
date of purchase against defects. Within this guarantee period, Whyte
Technologies will repair or replace the faulty product. In the unlikely
event, please return any faulty products to your dealer. The Guarantee
will be deemed as void if the serial number on the product is removed,
damaged or illegible. The Guarantee excludes defects caused by incorrect
use, accidental damage, disassembly, water/ re/lightning damage or lack
of ven la on.
www.whytetechnologies.com
4 5
www.whytetechnologies.com
EXAMPLE 5 WIRE

EXAMPLE 5 WIRE

WT52-10
+
WS52-05
WT52-10
+
WT52-10
2x Outputs

2x Outputs

1x Outputs

2x Outputs


www.whytetechnologies.com
67
SPECIFICATIONS
www.whytetechnologies.com
2.5A Power Supply Unit
Short Circuit & Overload Protection
Model: WPSU - 2.5A
Input: 110- 240VAC 50/60Hz
Output: 18V 2.5A
TERR: Freq Range 47~790 MHz Trunk Loss 2dB Tap Loss 20dB
SAT: Freq Range 950~2150 MHz Trunk Loss 3dB Tap Loss 20dB
T
A
P
2
T
A
P
1
WT52-20
5 Wire 2 Way
Tap - 20dB
DC IN 18V
T
A
P
2
T
A
P
1
Whyte
HL VH HH
TERR
VL
HHVH
HL
VL TERR
HL VH HH
TERR
VL
WT51-10
5 Wire 1 Way Tap - 10dB
TERR: Freq Range 47~790 MHz Trunk Loss 2dB Tap Loss 10dB
SAT: Freq Range 950~2150 MHz Trunk Loss 2dB Tap Loss 10dB
T
A
P
DC IN 18V
Whyte
HHVH
HL
VL TERR
WT52-10
5 Wire 2 Way
Tap - 10dB
TERR: Freq Range 47~790 MHz Trunk Loss 2dB Tap Loss 10dB
SAT: Freq Range 950~2150 MHz Trunk Loss 3dB Tap Loss 10dB
T
A
P
2
T
A
P
1
DC IN 18V
Whyte
HL VH HH
TERR
VL
HHVH
HL
VL TERR
TERR: Freq Range 47~790 MHz Trunk Loss 2dB Tap Loss 20dB
SAT: Freq Range 950~2150 MHz Trunk Loss 3dB Tap Loss 20dB
T
A
P
2
T
A
P
1
WT52-20
5 Wire 2 Way
Tap - 20dB
DC IN 18V
T
A
P
2
T
A
P
1
Whyte
HL VH HH
TERR
VL
HHVH
HL
VL TERR
EXAMPLE APPLICATION
Model
WT51-10
WT51-20
WT52-10
WT52-20
WT53-10
WT53-20
WS52-05
Frequency
SAT
950-
2150MHz
950-
2150MHz
950-
2150MHz
950-
2150MHz
950-
2150MHz
950-
2150MHz
950-
2150MHz
TERR
87-
790MHz
87-
790MHz
87-
790MHz
87-
790MHz
87-
790MHz
87-
790MHz
87-
790MHz
Inputs (F-Type Connector)
4 SAT + 1
TERR
4 SAT + 1
TERR
4 SAT + 1
TERR
4 SAT + 1
TERR
4 SAT + 1
TERR
4 SAT + 1
TERR
4 SAT + 1
TERR
Outputs (F-Type Connector)
2x 4 SAT +
2x 1 TERR
2x 4 SAT +
2x 1 TERR
3x 4 SAT +
3x 1 TERR
3x 4 SAT +
3x 1 TERR
4x 4 SAT +
4x 1 TERR
4x 4 SAT +
4x 1 TERR
2x 4 SAT +
2x 1 TERR
DC Input (Injection of DC applied to:)
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
HL + HH
Trunk/Tap
DC Pass Trunk to Tap
SAT
HL + HH
HL + HH
HL + HH
HL + HH
HL + HH
HL + HH
HL + HH
TERR
NO
NO
NO
NO
NO
NO
NO
DC Pass Trunk to Trunk
SAT
YES
YES
YES
YES
YES
YES
~
TERR
NO
NO
NO
NO
NO
NO
~
Trunk Through Loss
SAT
2dB±1dB
2dB±1dB
3dB±1dB
3dB±1dB
3dB±1dB
3dB±1dB
~
TERR
2dB±1dB
2dB±1dB
2dB±1dB
2dB±1dB
2dB±1dB
2dB±1dB
~
Tap Loss
SAT
10dB
20dB
10dB
20dB
10dB
20dB
2dB±1dB
TERR
10dB
20dB
10dB
20dB
10dB
20dB
2dB±1dB
Fixed Slope Taps (SAT)
4dB
4dB
4dB
4dB
4dB
4dB
4dB
Isolation
>40dB
>40dB
>40dB
>40dB
>40dB
>40dB
>40dB
Max Current Pass (Trunk/Trunk Trunk/Tap)
2A 2A 2A 2A 2A 2A 2A
Earth Lug (F-Type connector with clamp)
Up to
6mm² core
Up to
6mm² core
Up to
6mm² core
Up to
6mm² core
Up to
6mm² core
Up to
6mm² core
Up to
6mm² core
Dimensions (mm)
156 x 136 x
43
156 x 136
x43
156 x 136 x
43
156 x 136 x
43
156 x 136 x
43
156 x 136 x
43
156 x 136 x
43
Weight
385g
385g
425g
425g
462g
464g
385g
