Whyte 9 Series User manual

9 WIRE SPLITTER
INSTRUCTION MANUAL
www.whytetechnologies.com
WS92-05

Safety
Precauons
Guarantee
General Descripon
Technical Descripon
Example Conguaron
Specicaons
3
3
3
4
5
6
7
CONTENTS
www.whytetechnologies.com
2www.whytetechnologies.com 3
Whyte
SAFETY
Whyte Launch Ampliers are intended for indoor use only. Do not install the
amplier in damp, humid, hot or dusty areas.
Switch o and remove the power supply when making connecons to the
Launch Amplier to avoid damaging the unit.
Always earth bond the Launch Amplier using the earth bonding lug to a suitable
earth bonding point using min 4mm diameter earth cable.
Do not remove the cover of the Launch Amplier or disassemble it as this will
invalidate the guarantee.
PRECAUTIONS
To ensure trouble free operaon:
Do not remove the cover of the mulswitch or disassemble it as this will invalidate
the guarantee.
The female F connectors on this unit were designed for use with '100' type
coaxial cable with a centre core diameter of 1mm². When using larger CT125
or CT167 cables, you must ensure that suitable F connectors with reducing
pins are used otherwise damage to the unit will occur which will invalidate the
guarantee.
Do not over ghten the F connectors (nger ght only).
GUARANTEE
All Whyte products are guaranteed for a period of 4 years from the date of
purchase.

www.whytetechnologies.com
4www.whytetechnologies.com 5
The Whyte Series 9 Splier is a passive device designed to be used with
the Whyte Series 9 IRS Mulswitch Range. The WS92-05 Splier comes
with 9 F-type Couplers for quick & easy inseron in to a cascade of Series
9 Mulswitches.
GENERAL DESCRIPTION TECHNICAL DESCRIPTION
The Whyte™ Series 9 Splier is DC passing through all SAT Inputs and Outputs.
Whilst the WS92-05 Splier does not require power to funcon (passive device),
it has an Auxiliary 18V Input, which enables a Whyte™ Power Supply Unit to be
connected thus serving as a convenient DC injector. The Auxiliary Input injects
18V DC on to the HH and HL trunk lines upwards and downwards.
A Green LED indicates the presence of power on the HL and HH Trunk Lines.
The Whyte™ Series 9 range is compact due to the zig-zag layout of the Input
and Output Terminals. Therefore, an F Connector Tool (F Connector Screwdriver)
should be used to connect the input and output cables. Do not over ghten
the F connectors (nger ght only). Each Series 9 Splier comes complete
with 9 F Type Couplers to enable quick and easy interconnecon to Series 9
Mulswitches and Ampliers.
Whyte

Whyte
Whyte
www.whytetechnologies.com www.whytetechnologies.com
67
Whyte
SPECIFICATIONSEXAMPLE CONFIGURATION
