widos RSR 630 User manual

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
Headquarters: D 71254 Ditzingen Heimerdingen Country court Stuttgart HRB 200973 Managing director: Dieter Dommer, Jürgen Dommer
Working Instructions
Translation
Saw blade for radial cuts RSR 630
Keep for further use!

Kunststoffschweißtechnik
Product identification
29.03.2011 Working instructions WIDOS RSR 630 Page 2 of 27
Type: Band saw RSR 630
Serial number / year of construction: see type label
Customer entries
Inventory no.:
Location:
Order of spare parts and after sales ser ice
Address of manufacturer WIDOS
Wilhelm Dommer Söhne GmbH
Einsteinstr. 5
D 71254 Ditzingen Heimerdingen
Phone: ++49 7152 / 99 39 0
Fax: ++49 7152 / 99 39 40
[email protected]
http://www.widos.de
Address of the Subsidiary Companies:
WIDOS GmbH WIDOS
An der Wiesenmühle 15 Wilhelm Dommer Söhne AG
St. Gallerstr. 93
D 09224 Grüna / Sachsen CH – 9201 Gossau
Phone: ++49 3 71 8 15 73 0 Phone: ++41 71 388 89 79
Fax: ++49 3 71 8 15 73 20 Fax: ++41 71 388 89 73

Kunststoffschweißtechnik
Introduction
29.03.2011 Working instructions WIDOS RSR 630 Page 3 of 27
Purpose of the document
These working instructions give you information about all important questions which refer to
the construction and the safe working of your machine.
Just as we are, you are obliged to engage in these working instructions, as well.
Not only to run your machine economically but also to avoid damages and injuries.
Should questions arise, contact our service team in the factory or in our subsidiary companies.
We will help you with pleasure.
According to our interest to continuously improve our products and working instructions, we
kindly ask you to inform us about problems and defects which occur in exercise.
Thank you.
Structure of the working instructions
This manual is arranged in chapters which belong to the different using phases of the
machine.
Due to this structure, the searched information can be easily found.
3/29/2011 WIDOS
W. Dommer Söhne GmbH
Einsteinstraße 5
D 71254 Ditzingen Heimerdingen
All rights reserved.
Reprinting only allowed with permission of the corporation.
Any changes are subject to technical innovations.

Kunststoffschweißtechnik
Contents
29.03.2011 Working instructions WIDOS RSR 630 Page 4 of 27
1. DESCRIPTION OF THE PRODUCT ..............................................................................6
1.1. Usage and purpose-oriented use ........................................................................................6
1.2. Safety measures....................................................................................................................6
1.3. Conformity .............................................................................................................................6
1.4. Designation of the product ..................................................................................................7
1.4.1. Technical data ................................................................................................................7
1.4.2. Electrical data.................................................................................................................7
1.5. Equipment and accessories.................................................................................................7
1.6. Wear parts list .......................................................................................................................7
2. SAFETY RULES ............................................................................................................ 8
2.1. Explanation of the symbols and indications......................................................................8
2.2. Obligations of the owner......................................................................................................9
2.3. Obligations of the operator..................................................................................................9
2.4. Measures of organization.....................................................................................................9
2.5. Information about safety precautions.................................................................................9
2.6. Instructions for the staff.......................................................................................................9
2.7. Dangers while handling the machine................................................................................10
2.8. General safety indications .................................................................................................10
2.9. Specific dangers .................................................................................................................11
2.9.1. Danger of cutting or catching clothes ...........................................................................11
2.9.2. Danger of stumbling over electric wire .........................................................................11
2.9.3. Danger of being injured by chips / oddments ...............................................................11
2.9.4. Risk of injury of noise ...................................................................................................11
2.10. Maintenance and inspection, repair..................................................................................11
2.11. Remaining risks ..................................................................................................................11
2.12. Warranty and liability..........................................................................................................12
3. FUNCTIONAL DESCRIPTION..................................................................................... 13
4. OPERATING AND INDICATING ELEMENTS.............................................................. 14
4.1. Machine o er iew ...............................................................................................................14
4.1.1. Fuse in switch case ......................................................................................................15
4.2. Saw blade guidance and saw blade co er .......................................................................16
4.3. How to adjust the sawing radius .......................................................................................17
4.3.1. How to adjust the angle for branch pipe 45° and 60° ...................................................17
4.4. Vacuum (option)..................................................................................................................18
5. STARTING AND OPERATING..................................................................................... 19
5.1. Starting.................................................................................................................................19
5.2. How to clamp the pipes......................................................................................................20

Kunststoffschweißtechnik
Contents
29.03.2011 Working instructions WIDOS RSR 630 Page 5 of 27
5.3. How to cut radiuses............................................................................................................21
5.4. How to cut angled radiuses ...............................................................................................21
6. MAINTENANCE / STORAGE / TRANSPORT.............................................................. 22
6.1. In general .............................................................................................................................22
6.2. Storage.................................................................................................................................22
6.3. How to remo e the cutting chips from the saw arm .......................................................22
6.4. How to set and tension the saw blade..............................................................................23
6.5. How to adjust the saw blade..............................................................................................24
6.6. Disposal ...............................................................................................................................24
7. ELECTRIC DIAGRAMS ............................................................................................... 25
8. DECLARATION OF CONFORMITY............................................................................. 27

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
29.03.2011 Working instructions WIDOS RSR 630 Page 6 of 27
1. Description of the product
This chapter gives important basic information about the product and its prescribed use.
All technical details of the machine are put together as a general arrangement.
1.1. Usage and purpose-oriented use
The WIDOS band saw RSR 630 is special machinery for cutting plastic pipes up to Ø 630 mm,
and cutting radiuses up to 600 mm, in the way described as follows.
The purpose oriented use includes also that a sufficiently dimensioned, operational suction
plant is connected to the machine.
All use going beyond is not purpose-oriented.
The described plastic band saw may only be operated, maintained and repaired by persons
who are trained and informed about the dangers.
The machine is a workshop machine and not suitable for operation in hazardous locations.
It is forbidden to cut wood and sheets made out of wood (e.g. pressboard).
The manufacturer is not responsible for any damages caused by inexpert handling or
operation.
For personal injuries, material and immaterial damages resulting herefrom, only the user is
responsible!
Also part of the purpose oriented use is
• respecting all the indications of the working instructions and
• performing the inspection and maintenance work.
1.2. Safety measures
In case of wrong use, wrong operation or wrong maintenance, the machine itself or products
standing nearby can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thoroughly read and the corresponding safety
regulations must be necessarily adhered to.
1.3. Conformity
The machine corresponds in its construction to the valid recommendations of the European
Community as well as to the according European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.

Kunststoffschweißtechnik
Description of product Chapter 1
29.03.2011 Working instructions WIDOS RSR 630 Page 7 of 27
1.4. Designation of the product
The product is designated by a type label at the basic mounting.
It contains the type, the serial number and the year of construction of the machine.
1.4.1. Technical data
Thickness of saw blade: 0.65 mm
Width of saw blade: 13 mm
Length of saw blade: 6295 mm
Total height: appr. 2710 mm
Total depth: appr. 2435 mm
Total width: appr. 2080 mm
Length of the pipe supports: 700 mm
Max. diameter of pipes: 630 mm
Max. cutting radius 600 mm
Weight: appr. 610 kg
1.4.2. Electrical data
Voltage 400V AC
Feeding CEE 16 A
Power 1,5 kW
Frequency 50 Hz
Current: 3,7 A
1.5. Equipment and accessories
Pieces Denomination
1 Key for doors (saw blade guidance and switch cupboard); hand out the key to
authorized persons only
1 each Fork wrench size: 19 / 22 / 24
1 Allan key with T grip sizes 6
2 Saw blade 6295x13x0.65 mm / 4 ZpZ, K
1.6. Wear parts list
Pieces/
Mach.
Name Article-No.
1 Saw blade 6295x13x0.65 mm / 4 6 ZpZ, S 5406302
1 Drive wheel D400 (in exchange) 5442105
2 Deflection pulley D400 (in exchange) 5442104
2 Roller for saw blade guidance 6002 2 Z (rear) on request
4 Roller for saw blade guidance 6201 2 Z (sidewards) on request
For article numbers and single parts, please contact the WIDOS company.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
29.03.2011 Working instructions WIDOS RSR 630 Page 8 of 27
2. Safety rules
The base for the safe handling and the fault free operation of this machine is the knowledge of
the basic safety indications and rules.
• These working instructions contain the most important indications to run the machine
safely.
• The safety indications are to be followed by all persons working with the machine.
2.1. Explanation of the symbols and indications
In the working instructions, following denominations and signs are used for dangers:
This symbol means a possible danger for the life and the health of persons.
• The disrespect of these indications may have heavy consequences for the
health.
This symbol means a possible dangerous situation.
• The disrespect of these indications may cause light injuries or damages
on goods.
This symbol means a possible dangerous situation by moving parts of the
machine
• The disrespect of these indications may cause heavy crushing of parts of
the body resp. damages of parts of the machine.
This symbol means a possible risk of injury by noises exceeding 80 dB (A).
• Ear protection is obligatory
This symbol gives important indications for the proper use of the machine.
• The disrespect of these indications may conduct to malfunctions and
damages on the machine or on goods in the surrounding.
Under this symbol you get user tips and particularly useful information.
• It is a help for using all the functions on your machine in an optimal way
and helps you to make the job easier.
T h e r e g u l a t i o n s f o r t h e p r e e n t i o n o f a c c i d e n t s a r e a l i d ( U V V ) .

Kunststoffschweißtechnik
Safety rules Chapter 2
29.03.2011 Working instructions WIDOS RSR 630 Page 9 of 27
2.2. Obligations of the owner
The owner is obliged only to let persons work at the machine who
• know about basic safety and accident prevention rules and are instructed in the handling of
the machine, as well as who
• have read and understood the safety chapter of this manual and certify this by their
signature.
The safety-conscious working of the staff has to be checked in regular intervals.
2.3. Obligations of the operator
All persons who are to work at the machine are obliged before working:
• to follow the basic safety and accident protection rules.
• to have read and understood the safety chapter and the warnings in this manual and to
confirm by their signature that they have well understood them.
• to inform themselves about the functions of the machine before using it.
2.4. Measures of organization
• All equipment required for personal safety is to be provided by the owner.
• All available safety equipment is to be inspected regularly.
2.5. Information about safety precautions
• The working instructions have to be permanently kept at the place of use of the saw. They
are to be at the operator's disposal at any time and without much effort.
• In addition to the manual, the common valid and the local accident protection rules and
regulations for the environmental protection must be available and followed.
• All safety and danger indications on the machine have to be in a clear readable condition.
• Every time the machine changes hands or is being rent to third persons, the working
instructions are to be sent along with and their importance is to be emphasized.
2.6. Instructions for the staff
• Only skilled and trained persons are allowed to work at the saw.
• It must be clearly defined who is responsible for transport, mounting and dismounting,
starting the operation, setting and tooling, operation, maintenance and inspection, repair
and dismounting.
• A person who is being trained may only work at the machine under supervision of an
experienced person.

Kunststoffschweißtechnik
Safety rules Chapter 2
29.03.2011 Working instructions WIDOS RSR 630 Page 10 of 27
2.7. Dangers while handling the machine
The band saw WIDOS RSR 630 is constructed according to the latest technical standard and
the acknowledged technical safety rules.
However, dangers for the operator or other persons standing nearby may occur. Also material
damages are possible.
The machine may only be operated:
• according to the purpose oriented usage
• in safety technical impeccable status
Disturbances which may affect the safety of the machine must be cleared immediately.
2.8. General safety indications
• A working area without obstacles around the machine and a non slip and plane floor are of
basic importance for a safe operation.
• The working area must be well lightened and free of waste (cuttings, residues).
• Before starting the operation, make sure that the saw blade is tightened properly and that
the band guidance is adjusted correctly, as well as that the door situated over the saw
blade guidance is closed.
• During the operation, wear tight clothes only.
• Keep the handles dry and free from oil and grease.
• Wear safety glasses during the cutting operation.
• Do not wear rings, bracelets etc.
• Protect long hair by means of a sufficient headgear.
• During work, the pipe must be clamped firmly.
• Do ne er remove reminders as long as the saw is working.
• In case of irregular running behaviour of the saw blade, switch off the saw immediately and
check the saw blade for correct course, correct tension and possible fractures.
• Replace dull or badly set saw blades by orderly installed saw blades.
• Before elimination of any disturbances, and before any repair or maintenance work, switch
off the saw and disconnect in any case the mains plug.
Only skilled persons are allowed to work at electrical appliances.
• The electrical equipment of the machine has to be checked regularly. Loose
connections and damaged cables have to be replaced or repaired
immediately.
• Protect the machine from wetness and humidity.

Kunststoffschweißtechnik
Safety rules Chapter 2
29.03.2011 Working instructions WIDOS RSR 630 Page 11 of 27
2.9. Specific dangers
2.9.1. Danger of cutting or catching clothes
You can cut yourself during sawing or when exchanging the saw blade!
• Before starting the cutting operation, take care that no person is standing in
the operating, swiveling or cutting area.
• Always wear safety gloves when exchanging the saw blade.
2.9.2. Danger of stumbling o er electric wire
Make sure that no person has to step over the wire. Lay the wire in such a way
that the danger is kept to a minimum. Do not squeeze, buckle etc. the wires.
2.9.3. Danger of being injured by chips / oddments
• Wear safety glasses during cutting.
• Adjust saw blade covering onto the pipe diameter.
• Ne er remove oddments as long as the saw is running.
2.9.4. Risk of injury of noise
Noises exceeding 80 dB (A) may occur; during planing it is obligatory to wear ear
protection!
2.10. Maintenance and inspection, repair
All maintenance and repair work has to be basically performed with the machine in
off position.
During this, the machine has to be secured against unauthorized switching on.
2.11. Remaining risks
Even at purpose oriented use and even if following all the relevant safety instructions, the
following risks are remaining due to the construction conditional on the purpose of operation of
the machine:
• Injuries caused by parts of the work pieces which are squirting away.

Kunststoffschweißtechnik
Safety rules Chapter 2
29.03.2011 Working instructions WIDOS RSR 630 Page 12 of 27
2.12. Warranty and liability
Fundamentally our "General Sales and Delivery Conditions" are valid.
They are at the owner's disposal latest when signing the contract.
Guarantee and liability demands referring to personal injuries or damages on objects are
excluded if they are caused by one or several of the following reasons:
• Not using the machine according to the prescriptions;
• Inexpert transport, mounting, starting, operating, and maintenance of the machine;
• Running the machine with defective or not orderly mounted safety appliances;
• Ignoring the information given in this manual;
• Structural modifications on the machine without permission;
• Unsatisfactory checking of parts of the machine which are worn out;
• Repairs performed in an inexpert way;
• In case of catastrophes and force majeure.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
29.03.2011 Working instructions WIDOS RSR 630 Page 13 of 27
3. Functional description
B a s i c a l l y , t h e i n t e r n a t i o n a l a n d n a t i o n a l p r o c e s s g u i d e l i n e s a r e t o b e
f o l l o w e d .
Set the saw to the desired radius and secure it by clamping.
Lay the pipe on the pipe support and clamp it (check the distance to the saw blade!).
When the cutting operation is finished, switch off the saw blade motor and cut the radius by
moving the swiveling plate.
Unclamp the pipe.

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
29.03.2011 Working instructions WIDOS RSR 630 Page 14 of 27
4. Operating and indicating elements
4.1. Machine o er iew
No. Name / unction
1 Saw arm
2 Saw blade guidance
3 Handgrip with button, the button starts the drive motor
4 Lever to move the swiveling plate
5 Clamping lever to set the radius
6 Prism to support the pipe
7 Swivel plate to cut radiuses
8 Deflection pulley with set screws
9 Protective device for saw blade
10 Saw blade
11 Deflection pulley with set screws and eccentric for saw blade tension
12 Switching case with fuse
13 Drive motor for saw blade
14 Leveling foot (4 pieces) to adjust the machine
1
6
4
5
3
2
8
11
9
14
7
13
12
10

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
29.03.2011 Working instructions WIDOS RSR 630 Page 15 of 27
4.1.1. Fuse in switch case
The motor protective is located within the switch
case F40, 2,8 – 4A.
It is the overloading protection for the drive motor.
In case the motor protective has been triggered,
clear the cause of the overloading and reactivate
the fuse afterwards.
Motor protective 2,8 4A

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
29.03.2011 Working instructions WIDOS RSR 630 Page 16 of 27
4.2. Saw blade guidance and saw blade co er
The saw blade guidance is mounted to the saw blade
cover. The saw blade cover should be adjusted in
such a way that the lower edge is somewhat above
the pipe to be cut.
• Keep hold of the saw blade guiding, detach the
hexagon socket screw and shift the saw blade
guiding to the requested height.
• Fix the saw blade cover by the hexagon socket
screw again.
(Saw blade guidance upper side)
The saw blade runs through the identical saw blade guidings upside and downside.
It is lead through the two rollers and supported to the backside by the larger roller on one side.
The roller with eccentric can be adjusted. It is adjusted correctly if both rollers can still be
turned somewhat towards each other and if the saw blade runs even.
For setting the guidance, release the left hand counter nut by means of fork wrench size 24.
Now the eccentric is turned with hexagon socket wrench size 6 until the rollers have the
desired distance.
Secure the eccentric again by means of the counter nut
Saw blade guidance upper side
Saw blade
Saw blade cover
Rollers for guidance left and right
Supporting roller
Counter nut
Eccentric
Hexagon head screw

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
29.03.2011 Working instructions WIDOS RSR 630 Page 17 of 27
4.3. How to adjust the sawing radius
• In order to adjust the radius, release
both clamping levers.
• Push the swiveling bow until the desired
radius is shown on the measuring tape.
• Fix the setting with the both clamping
lever.
4.3.1. How to adjust the angle for branch pipe 45° and 60°
In case of branch pipes with angle 45° or 60° having to be cut, the prism thus has to be
swiveled upwards.
For this purpose detach the two hexagon
head screws „1“ in the rear from prism and
support and unscrew the two hexagon head
screws „2“ in front.
Swivel the prism upwards and mount the
long fixings for angle 45° branch, the short
fixings for angle 60° between prism and
support and fix the hexagon head screws„2“
again.
Depending on the pipe size and angle it will
be necessary to shift the prism in order to
minimize the unsupported pipe overhang.
• For this purpose detach the hexagon
head screw „3“ and push the support with
the prism to the required position.
Clamping lever
Pointer for reading
Hexagon head screw „1“
Fixing for 45° / 60°
Support
Prism
Hexagon head screw „2“
Hexagon head screw „3“

Kunststoffschweißtechnik
Operating and indicating elements Chapter 4
29.03.2011 Working instructions WIDOS RSR 630 Page 18 of 27
4.4. Vacuum (option)
It is indispensable to exhaust the cutting chips. The guidings for the swiveling arm as well as
the saw blade guiding may become sluggish resp. get damaged by the cutting chips.
Example for a vacuum:
F.e. shift the vacuum hose from one of the vacuums (option) below the guard plate just in front
of the saw blade.
Necessarily secure the vacuum against shifting f.e. by vibration during the
cutting.
Always activate the vacuum during the cutting.
Vacuum hose
Guard plate

Kunststoffschweißtechnik
WIDOS Einsteinstr. 5 Phone ++49 (0)7152 / 9939 0
W. Dommer Söhne GmbH D 71254 Ditzingen Heimerdingen Fax ++49 (0)7152 / 9939 40
www.widos.de email: [e-mail]
29.03.2011 Working instructions WIDOS RSR 630 Page 19 of 27
5. Starting and operating
The instructions of this chapter are supposed to initiate in the operation of the machine and
lead during the appropriate starting of the machine.
This includes:
• the safe operation of the machine
• economic operation of the machine.
5.1. Starting
To start the operation, the radius band saw has to be adjusted by means of the leveling
screws in the machine feet in such a way that the swiveling bow is horizontal and the saw arm
is vertical.
• Connect the mains plug to the local power supply 400 V / 16 A / 50 Hz.
It is necessary to connect a vacuum plant (chapter: 4.4).
In situations of danger for man and machine immediately let loose the button
resp. pull the power plug!
Only cut tightly clamped pipes!
• Take care that no unauthorized person has access to the band saw.
• Protect the band saw from wetness and humidity!
The housing of the saw blade has to be cleaned regularly. For that purpose
switch off the saw.
Don’t saw without safety glasses and ear protection!
Replace the screw plug by the enclosed venting screw
before starting the band saw.
Do not throw away the screw plug, you need it again
when transporting the band saw.

Kunststoffschweißtechnik
Starting and operating Chapter 5
29.03.2011 Working instructions WIDOS RSR 630 Page 20 of 27
5.2. How to clamp the pipes
If the swiveling retainer is not at the left limit stop,
thus swivel it there.
Lay the pipe onto the prism and clamp it by the
clamping belt in near to saw cut.
Lay the clamping belt around the pipe and the
prism.
Lead the belt from the inside to the outside
through the aperture of the ratchet and tighten it.
Clamp the pipe firmly onto the prism by moving
several times the grip of the ratchet into direction
of the arrow.
The ratchet snaps in at both ends.
Attention! Do not deform pipes with thin walls.
The belt can be unclamped again by pulling the
safety gripper into direction of the ratchet grip.
Safety gripper
Ratchet grip
