WIKA LSD-30 User manual

Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
GB
D
F
E
Füllstandsschalter Typ LSD-30
Level switch model LSD-30
Level switch model LSD-30
Commutateur de niveau type LSD-30
Interruptor de nivel modelo LSD-30

2 WIKA operating instructions level switch model LSD-30
GB
D
F
E
11613033.01 01/2012 GB/D/F/E
© 2012 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA® is a registered trademark in various countries.
WIKA® ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d'emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta posterior!
Operating instructions model LSD-30 Page 3 - 28
Betriebsanleitung Typ LSD-30 Seite 29 - 54
Mode d'emploi type LSD-30 Page 55 - 78
Manual de instrucciones modelo LSD-30 Página 79 - 103

3WIKA operating instructions level switch model LSD-30
GB
1. General information 4
2. Safety 6
3. Specications 9
4. Design and function 15
5. Transport, packaging and storage 15
6. Commissioning, operation 16
7. Maintenance and cleaning 24
8. Faults 24
9. Dismounting, return and disposal 26
Appendix 1: EC Declaration of conformity model LSD-30 27
11613033.01 01/2012 GB/D/F/E
Contents
Contents
Declarations of conformity can be found online at www.wika.com.

4 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
1. General information
■
The level switch described in the operating instructions has been designed and manufactured using
state-of-the-art technology. All components are subject to stringent quality and environmental criteria
during production. Our management systems are certied to ISO 9001 and ISO 14001.
■
These operating instructions contain important information on handling the instrument. Working
safely requires that all safety instructions and work instructions are observed.
■
Observe the relevant local accident prevention regulations and general safety regulations for the
instrument's range of use.
■
The operating instructions are part of the product and must be kept in the immediate vicinity of the
instrument and readily accessible to skilled personnel at any time.
■
Skilled personnel must have carefully read and understood the operating instructions, prior to begin-
ning any work.
■
The manufacturer's liability is void in the case of any damage caused by using the product contrary
to its intended use, non-compliance with these operating instructions, assignment of insuciently
qualied skilled personnel or unauthorised modications to the instrument.
■
The general terms and conditions contained in the sales documentation shall apply.
■
Subject to technical modications.
■
Further information:
- Internet address: www.wika.com / www.wika.de
- Relevant data sheet: LM 40.01
- Application consultant: Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
1. General information

5WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
Explanation of symbols
WARNING!
... indicates a potentially dangerous situation which can result in serious injury or death if not
avoided.
CAUTION!
... indicates a potentially dangerous situation which can result in light injuries or damage to
the equipment or the environment if not avoided.
Information
… points out useful tips, recommendations and information for ecient and trouble-free
operation.
CAUTION!
... indicates a potentially dangerous situation that can result in burns, caused by hot
surfaces or liquids, if not avoided.
Abbreviations
U+Positive power terminal
U- Reference potential
S+Analogue output
SP1 Switch point 1
SP2 Switch point 2
MBA Start of measuring range
MBE End of measuring range
1. General information

6 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
2. Safety
WARNING!
Before installation, commissioning and operation, ensure that the appropriate level switch
has been selected in terms of measuring range, design and specic measuring conditions.
Non-observance can result in serious injury and/or damage to the equipment.
WARNING!
Observe the working conditions in accordance with Chapter 3 "Specications".
Further important safety instructions can be found in the individual chapters of these
operating instructions.
2.1 Intended use
The level switch is used to convert a level into an electrical signal indoors and outdoors.
The level switch has been designed and built solely for the intended use described here, and may only
be used accordingly.
The technical specications contained in these operating instructions must be observed. Improper
handling or operation of the level switch outside of its technical specications requires the instrument to
be taken out of service immediately and inspected by an authorised WIKA service engineer.
The manufacturer shall not be liable for claims of any type based on operation contrary to the intended
use.
2. Safety

7WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
2.2 Personnel qualication
WARNING!
Risk of injury if qualication is insucient!
Improper handling can result in considerable injury and damage to equipment.
The activities described in these operating instructions may only be carried out by skilled
personnel who have the qualications described below.
Skilled personnel
Skilled personnel are understood to be personnel who, based on their technical training, knowledge
of measurement and control technology and on their experience and knowledge of country-specic
regulations, current standards and directives, are capable of carrying out the work described and
independently recognising potential hazards.
Special operating conditions require further appropriate knowledge, e.g. of aggressive media.
2.3 Special hazards
WARNING!
For hazardous media, in addition to all standard regulations, the appropriate existing codes
or regulations must also be followed.
WARNING!
Residual media in dismounted level switches can result in a risk to persons, the
environment and equipment.
Take sucient precautionary measures.
CAUTION!
Operate the level switch only at a minimum distance of 1 m from electromagnetic elds.
2. Safety

8 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
2.4 Labelling / safety marks
Product label
2. Safety
Power supply
P# Product no.
S# Serial no.
Analogue signal
Switching output 1
Switching output 2
If the serial number becomes illegible (e.g. due to mechanical damage or overpainting), traceability will
no longer be possible.
Explanation of symbols
General danger symbol
CE, Communauté Européenne
Instruments bearing this mark comply with the relevant European directives.
Maximum working pressure

9WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3. Specications
3. Specications
3.1 Measuring ranges
for parallel process connections
Probe length F 250 370 410 520 730
mm 189 309 349 459 669
inch 7.44 12.17 13.74 18.07 26.34
for tapered process connections
Probe length F 250 370 410 520 730
mm 205 325 365 475 685
inch 8.07 12.80 14.37 18.70 26.93
Insertion lengths see "Insertion lengths in mm"
Specic gravity range of the medium
≥ 0.7 g/cm3
3.2 Display
14-segment LED, red, 4-digit, character size 9 mm
Display can be turned electronically through 180°
Update
200 ms

10 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3. Specications
3.3 Output signal
Switching output 1 Switching output 2 Analogue signal
PNP - 4 ... 20 mA
PNP - DC 0 ... 10 V
PNP PNP -
PNP PNP 4 ... 20 mA
PNP PNP DC 0 ... 10 V
Alternatively also available with NPN rather than PNP switching output.
Oset adjustment (display)
max. +1,500 mm
Scaling (display and analogue signal)
Zero point: max. +25 % of span
Final value: max. -25 % of span
Analogue signal
Load
■
Current output: ≤ 500 Ω
■
Voltage output: > 10 kΩ
Switching output
Switching point 1 and 2 are individually adjustable
Function
■
Normally open and
normally closed: freely adjustable
■
Window and hysteresis: freely adjustable
Switching voltage: Power supply – 1 V
Switching current: max. 250 mA per
switching output
Response time: < 200 ms
Adjustment accuracy: 2.5 mm steps

11WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3. Specications
3.4 Voltage supply
Power supply
DC 15 ... 35 V
Current consumption
max. 100 mA
Total current consumption
max. 600 mA (incl. switching current)
3.5 Measuring element
Resistance measuring chain with reed switches and float
Resolution
< 6 mm
Response time
< 700 ms
Maximum working pressure
3 bar
Media compatibility
Test following ISO 7620, section 6, table 1
Medium Standard
Mineral oil HLP per DIN 51524
Aqueous solution HFC per VDMA 24317
Organic ester HFD-U per VDMA 24317
Triglyceride (rape oil) HETG per VDMA 24568
Synthetic ester HEES per VDMA 24568
Polyglycols HEPG per VDMA 24568

F M
250 189
370 309
410 349
520 459
730 669
F M
250 205
370 325
410 365
520 475
730 684
Parallel thread Tapered thread
12 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
Insertion lengths in mm
Legend:
F = probe length
M = max. measuring range
3.6 Accuracy (electronics)
Switching and indication accuracy at room temperature
1% of span (display ±1 digit)
Analogue signal
≤ ± 0.5 % of span
Legend:
F = probe length
M = max. measuring range
3. Specications

13WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3. Specications
3.7 Reference conditions
Temperature: 15 ... 25 °C
Atmospheric pressure: 950 ... 1,050 mbar
Humidity: 45 ... 75 % relative
Nominal position: Process connection lower mount (LM)
Power supply: DC 24 V
Load: see "Output signal"
3.8 Operating conditions
Temperatures and humidity
Permissible medium temperature: -20 ... +80 °C
Ambient temperature: -20 ... +80 °C
Storage temperature: -20 ... +80 °C
Permissible humidity: 45 ... 75 % relative
Mechanics
Mounting position: vertical
3.9 Materials
Wetted parts
Level sensor: Stainless steel 316Ti
Float: see „Media compatibility“
Non-wetted parts
Case: Stainless steel 304
Keyboard TPE-E
Display window: PC
Display head: PC+ABS-Blend

14 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
3.10 Approvals, directives and certicates
CE conformity
EMC directive: 2004/108/EC, EN 61326-2-3 emission (group 1, class B) and interference immunity
(industrial application)
RoHS conformity: Yes
3.11 Electrical connections
Connections
Circular connector M12 x 1, 4-pin
Circular connector M12 x 1, 5-pin (only for version with SP1, SP2 and S+)
Ingress protection
IP 65 and IP 67
The stated ingress protection (per IEC 60529) only applies when plugged in using mating connectors that have the appropriate ingress
protection.
Electrical safety
Short-circuit resistance: S+ / SP1 / SP2 vs. U-
Reverse polarity protection: U+ vs. U-
Insulation voltage: DC 500 V
Overvoltage protection: DC 40 V
For further specications see WIKA data sheet LM 40.01 and the order documentation.
3. Specications

15WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
4. Design and function
4.1 Description
A oat with an internal magnet, which moves up and down at the guide tube, has an eect on the reed
measuring chain built into the guide tube (reed contacts + resistors). By means of the resistance value
of the measuring chain the ll level can be determined and converted into an electrical signal.
Via the electronics this electrical signal can be linked to various switching functions.
4.2 Scope of delivery
Cross-check the scope of delivery with the delivery note.
5. Transport, packaging and storage
5.1 Transport
Check the instrument for any damage that may have been caused by transport.
Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Handle the level switch with care when removing it from the packaging. The measuring element must
not be exposed to high mechanical loads.
Keep the packaging as it will provide optimum protection during transport (e.g. change in installation site,
sending for repair).
5.3 Storage
Permissible conditions at the place of storage:
Storage temperature: -20 ... +80 °C
WARNING!
Before storing the level switch (following operation), remove any residual media. This is of
particular importance if the medium is hazardous to health, e.g. caustic, toxic, carcinogenic,
radioactive, etc..
4. Design and function / 5. Transport, packaging and storage

16 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
6. Commissioning, operation
6.1 Operating conditions
The medium to be measured must not be heavily soiled or contain coarse particles.
The level switch is not suitable for crystallising media. If the measuring element comes into contact
with a crystallising medium, the measuring element must be pulled out and cleaned immediately (see
chapter 7.2 "Cleaning").
6.2 Mounting
■
Do not expose the measuring element to high mechanical loads.
■
Do not expose the oat to any impact loads.
■
The sealing faces at the instrument always have to be clean.
■
Only ever screw in, or unscrew, the instrument via the spanner
ats. Never use the case as a working surface.
■
The correct torque depends on the dimensions of the pressure
connection and the gasket used (form/material).
■
When screwing in, do not cross the threads.
■
For information on tapped holes and welding sockets, see Techni-
cal Information IN 00.14 at www.wika.de.
■
The instrument must be earthed via the process connection!
6. Commissioning, operation
Spanner ats
Measuring
element
Float

17WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
Seal
Correct sealing of the process connections with parallel threads at the sealing
face  must be made using suitable at gaskets, sealing rings or WIKA prole
sealings. The sealing of tapered threads (e.g. NPT threads) is made by providing
the thread with additional sealing material such as, for example, PTFE tape (EN
837-2).
For further information on seals see WIKA data sheet AC 09.08 or under www.wika.com.
Pin assignment
6. Commissioning, operation

Circular connector M12 x 1, 4-pin
Assignment
U+ U- S+ SP1 SP2
13242
Circular connector M12 x 1, 5-pin
Assignment
U+ U- S+ SP1 SP2
13542

18 WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
6.2 Operating modes
System start
■
Display is fully activated for 2 seconds.
■
When the level switch is powered up within the range of the hysteresis, the output switch is set to "not
active" by default.
Display mode
Normal operation, display of the level
Programming mode
Setting the parameters
6.3 Keys and functions
The level switch has two operating modes, the display mode and the programming mode. The selected
operating mode determines the respective function of the key.
Jumping into the programming mode
Keep the "MENU" key pressed for approx. 5 seconds. If the password is set to ≠ 0000, a
password will be requested rst-hand. If authentication is successful, then it enters the
programming mode, otherwise it reverts to display mode.
6. Commissioning, operation
Returning to the display mode
Simultaneous pressing of both keys.

19WIKA operating instructions level switch model LSD-30
GB
11613033.01 01/2012 GB/D/F/E
6. Commissioning, operation
4-digit LED display
■
Display of the level
■
Display menu item
■
Display parameter
Status switching output 1
Status switching output 2 (optional)
Display mode
▶Short press
Display of the unit
▶Long press
Display of the set parameters see
chapter 6.4 "Parameters"
Programming mode
▶Short press
Menu up
Parameter value up (step-wise)
▶Long press
Menu up
Parameter value up (fast)
Display mode
▶Short press
Display of the unit
▶Long press
Jumping into the programming mode
Programming mode
▶Short press
Menu up
Parameter value up (step-wise)
▶Long press
Menu up
Parameter value up (fast)
Display mode
▶Short press
Display of the unit
Programming mode
▶Short press
Select menu item
Conrmation of the input

20 WIKA operating instructions level switch model LSD-30
GB
Parameter Description
SP1/SP2 Hysteresis function: Switch point switching output (1 or 2)
FH1/FH2 Window function: Window high switching output (1 or 2)
RP1/RP2 Hysteresis function: Reset point switching output (1 or 2)
FL1/FL2 Window function: Window low switch output (1 or 2)
EF Extended programming functions
RES Return the set parameter to the factory settings
DS1/DS2 Switch delay time, which must occur without interruption before any electrical signal change occurs
(SP1 or SP2)
DR1/DR2 Switch delay time, which must occur without interruption before any electrical signal change occurs
(RP1 or RP2)
OU1 Switching function switching output (1 or 2)
OU2 HNO = hysteresis function, normally open
HNC = hysteresis function, normally closed
FNO = window function, normally open
FNC = window function, normally closed
UNIT Changing units
SETR
Measuring range scaling (analogue output)
"4 mA" or "0 V" determines at which level the output signal is to be 4 mA or 0 V.
"20 mA" or "10 V" determines at which level the output signal is to be 20 mA or 10 V.
OFS Oset adjustment by 1,500 mm maximum (distance between start of measuring range and tank
bottom). Not possible with unit "%".
DISM Display value in display mode
ACT = actual level; LOW, HIGH = minimum, maximum level value OFF = display o;
SP1/FH1 = function switch point 1, RP1/FL1 = function reset point 1,
SP2/FH2 = function switch point 2, RP2/FL2 = function reset point 2,
DISR Rotate display indicator by 180°
RHL Clear the Min- and Max-value memories
PAS Password input, 0000 = no password, password input digit by digit
TAG Input of a 16-gure alphanumeric measuring point number
11613033.01 01/2012 GB/D/F/E
6. Commissioning, operation
6.4 Parameters
