Wilbur Curtis Company G4CBHS User manual

READ AND SAVE THESE INSTRUCTIONS
NOTICE TO INSTALLER: Please leave this booklet with the machine.
G4 High Volume Combo Brewers
022317A
FC3 - G4CBHS/G4CBHT, FRONT COVER F-10002 revA
USER’S GUIDE

CONTENTS CL3
.H\)HDWXUHV6SHFLÀFDWLRQV6\VWHP5HTXLUHPHQWV................................................................................................FS3
,PSRUWDQW6DIHJXDUGV............................................................................................................................................... IS2
,QVWDOODWLRQ,QVWUXFWLRQV*HQHUDO...............................................................................................................................II2
,QVWDOODWLRQ,QVWUXFWLRQV/HYHOLQJ:DWHU6XSSO\(OHFWULFDO......................................................................................II8
2SHUDWLQJ,QVWUXFWLRQV ..............................................................................................................................................OI2
&OHDQLQJ,QVWUXFWLRQV%UHZHU .................................................................................................................................CI1
&OHDQLQJ,QVWUXFWLRQV7KHUPDO&RIIHH6HUYHU ........................................................................................................CI5
&OHDQLQJ,QVWUXFWLRQV7HD'LVSHQVHU .....................................................................................................................CI6
3URJUDPPLQJ*XLGH ............................................................................................................................................... 3*
5RXJK,Q'UDZLQJ................................................................................................................................................... 5'
,OOXVWUDWHG3DUWV5HFRPPHQGHG3DUWV0DLQ&KDVVLV............................................................................................. IP3
,OOXVWUDWHG3DUWV5HFRPPHQGHG3DUWV7DQN$VVHPEO\6LQJOH............................................................................ IP19
,OOXVWUDWHG3DUWV5HFRPPHQGHG3DUWV7DQN$VVHPEO\7ZLQ .............................................................................. IP20
(OHFWULFDO6FKHPDWLF*&%+6..............................................................................................................................ES7
(OHFWULFDO6FKHPDWLF*&%+7 ..............................................................................................................................ES8
7URXEOHVKRRWLQJ*XLGH ............................................................................................................................................7*
7URXEOHVKRRWLQJ*XLGH ............................................................................................................................................7*
7URXEOHVKRRWLQJ*XLGH ..........................................................................................................................................7*
(UURU&RGHV .............................................................................................................................................................EC1
3URGXFW:DUUDQW\....................................................................................................................................................3:
Contact Information
Wilbur Curtis Co., Inc.
6913 Acco Street | Montebello, CA 90640 US
Phone: [phone] | Toll Free: 800-421-6150
Email: [email protected] | Web: www.wilburcurtis.com
'PSUIFMBUFTUTQFDJmDBUJPOTBOEJOGPSNBUJPOHPUPXXXXJMCVSDVSUJTDPN
5PMM'SFF].POEBZ'SJEBZA.M.- 4:00 P.M.PT
Email: [email protected]
%VFUPDPOUJOVFEQSPEVDUJNQSPWFNFOUUIFQSPEVDUTJMMVTUSBUFEQIPUPHSBQIFEJOUIJTHVJEFNBZWBSZTMJHIUMZGSPNUIFBDUVBMQSPEVDU
($#)4($#)5$0/5&/54-*45ø /$

KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS3
Key Features
• Multiple Beverage Options – Allows you to brew Coffee, Iced Coffee and Iced Tea from one model.
• Generation Four (G4) Digital Control Module – Large, 4.3” touchscreen. Icon-driven interface streamlines
operation. Provides precise control of all critical brewing functions.
• On-Screen Instructions – Provides fast, intuitive training; reduces service calls.
• Built-in Self Diagnostic System – Includes real-time feedback of the brewing process and energy saving mode.
• Industry’s most effective mineral tolerant design.
• Encapsulated control boards – Protect against steam, water and impact.
6SHFLÀFDWLRQV6HOHFWHG0RGHOV
(OHFWULFDO6XSSO\5HTXLUHPHQWV
02'(/ '(6&5,37,21 3+$6( 92/76 $036 +($7,1*&21),* :,5( :$776 +(57= *$/+5
*&%+6 Single, Combo High Volume Brewer 1 PH 110/220 V 15.0/12.7 A 2 X 1600 W 2W/3W + G 1800/2800 W 50/60 Hz 12.0
*&%+7 Twin, Combo High Volume Brewer 1 PH 220 V 23.0/34.0 A 3 X 2500 W 3W + G 5100/7500 W 50/60 Hz 21.0
'LPHQVLRQV :DWHU6XSSO\5HTXLUHPHQWV
02'(/ +(,*+7 :,'7+ '(37+ 6+,3:(,*+7 6+,3&8%( :$7(5&211(&725 :$7(535(6685( 0,1)/2:5$7(
*&%+6 36.71” 10.07” 22.82” 47.0 lbs 9.27 cu ft µÁDUH
20 - 90 psi 1.0 gpm
*&%+7 36.71” 18.11” 22.82” 76.0 lbs 16.04 cu ft µÁDUH 20 - 90 psi 2.0 gpm
G4CBHS/G4CBHT, KEY FEATURES/SPECS/SYSTEM REQUIREMENTS 092016A
• Brew Temperature = 200°F
• Minimum Brew Temperature = 195°F
• Water Bypass (coffee) = On LARGE and MEDIUM
brew only
Following are the factory default settings for the combination brewer:
• Brew Volume (coffee) = Large-Medium-Small
• Brew Volume (tea) = Large-Small
• Energy Save Mode = Off

IMPORTANT SAFEGUARDS IS2
Symbols
This is the safety alert symbol. It is used to alert you to potential physical injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING - Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION - Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE - Indicates a situation which, if not avoided, could result in property damage.
IMPORTANT - Provides information and tips for proper operation.
SANITATION REQUIREMENTS
Important Safeguards/Conventions
WARNING:
• Make sure that this brewer is installed and grounded according to the INSTALLATION INSTRUCTIONS
CZRVBMJmFEQFSTPOOFMCFGPSFBUUFNQUJOHUPVTFJU'BJMVSFUPGPMMPXUIF*/45"--"5*0/*/4536$5*0/4
could result in personal injury or void the warranty.
• This appliance is designed for commercial use. Any service other than cleaning and preventive
maintenance should be performed by an authorized Wilbur Curtis service technician.
• 5PSFEVDFUIFSJTLPGmSFPSFMFDUSJDTIPDL%0/05PQFOUIFTFSWJDFQBOFMT5IFSFBSFOPVTFS
serviceable parts inside.
• Keep hands, arms and other items away from hot surfaces of the brewer during operation.
• Clean the brewer and any dispensers completelyCFGPSFVTJOHUIFNGPSUIFmSTUUJNFBTBDDPSEJOHUP
the CLEANING INSTRUCTIONS. Clean them regularly as instructed in the CLEANING INSTRUCTIONS.
• Use this appliance only for its intended use, brewing hot and/or cold beverages.
$0''&&5&"#3&8&34*.1035"/54"'&(6"3%44:.#0-4 "

INSTALLATION INSTRUCTIONS II2
Installation Instructions
Installation Requirements
• A secure surface capable of supporting the weight of the brewer.
• For brewers without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet
UIFFMFDUSJDBMTQFDJmDBUJPOTGPSUIFCSFXFS*GZPVIBWFRVFTUJPOTBCPVUUIFDPSSFDUDBCMFTJ[FBOEMFOHUI
DPOTVMUBRVBMJmFEJOTUBMMFS*GUIFCSFXFSXJMMCFIBSEXJSFEUPBKVODUJPOCPYUIFQPXFSDBCMFNVTUCFMPOH
enoughTPUIBUUIFCSFXFSDBOCFNPWFEGPSDMFBOJOHVOEFSOFBUI
• "HSPVOEFEFMFDUSJDBMDPOOFDUJPOUPBOFMFDUSJDBMDJSDVJUUIBUNFFUTUIFFMFDUSJDBMTQFDJmDBUJPOTPGUIFCSFXFS
(see SPECIFICATIONS5IFDJSDVJUNVTUCFQSPUFDUFECZUIFBQQSPQSJBUFTJ[FEDJSDVJUCSFBLFS*GZPVBSFOPU
DFSUBJOUIBUUIFFYJTUJOHDJSDVJUNFFUTUIFSFRVJSFNFOUTGPSZPVSCSFXFSDPOTVMUBMJDFOTFEFMFDUSJDJBO
• "XBUFSmMUSBUJPOTZTUFNJTSFRVJSFEUPNBJOUBJOUSPVCMFGSFFPQFSBUJPO8JMCVS$VSUJT$P*ODSFDPNNFOETB
8JMCVS$VSUJTBQQSPWFEXBUFSmMUFS7JTJUwww.wilburcurtis.comUPTFFUIFGVMMMJOFPG8JMCVS$VSUJTBQQSPWFE
XBUFSmMUFST
• 1PUBCMFXBUFSTVQQMZMJOFDPOOFDUJPOGSPNUIFXBUFSmMUFSDBQBCMFPGTVQQMZJOHUIFNJOJNVNnPXSBUFSFRVJSFE
CZUIFTQFDJmDBUJPOT5IFXBUFSTVQQMZMJOFNVTUCFBCMFUPDPOOFDUUPUIFnBSFmUUJOHPOUIFCBDLPGUIF
brewer. See the SPECIFICATIONS section for the correct size. The water line should also be capable of being
DPOUSPMMFECZBTIVUPGGWBMWF%POPUDPOOFDUUIFXBUFSMJOFUPBTBEEMFWBMWF
/4'*OUFSOBUJPOBMSFRVJSFTUIFGPMMPXJOHXBUFSDPOOFDUJPO
1 "RVJDLEJTDPOOFDUPSBEEJUJPOBMDPJMFEUVCJOHBUMFBTUUXPUJNFTUIFEFQUIPGUIFCSFXFSJTSFRVJSFE
 TPUIBUJUDBOCFNPWFEGPSDMFBOJOHVOEFSOFBUI
2 5IJTFRVJQNFOUJTUPCFJOTUBMMFEXJUIBEFRVBUFCBDLnPXQSPUFDUJPOUPDPNQMZXJUIBQQMJDBCMF
federal, state and local codes.
 8BUFSQJQFDPOOFDUJPOTBOEmYUVSFTEJSFDUMZDPOOFDUFEUPBQPUBCMFXBUFSTVQQMZTIBMMCFTJ[FE
installed and maintained in accordance with federal, state and local codes.
WARNING:*OTUBMMBUJPOJTUPCFQFSGPSNFEPOMZCZBRVBMJmFEJOTUBMMFS
WARNING: *NQSPQFS FMFDUSJDBM DPOOFDUJPO NBZ SFTVMU JO BO FMFDUSJD TIPDL IB[BSE 5IJT CSFXFS NVTU CF
properly grounded.
NOTICE:%0/05DPOOFDUUIJTCSFXFSUPBIPUXBUFSTVQQMZ5IFXBUFSJOMFUWBMWFJTOPUSBUFEGPSIPUXBUFS
%POPUFYDFFEUIFNBYJNVNXBUFSQSFTTVSFTUBUFEJOUIFSPECIFICATIONS section.
IMPORTANT:0CTFSWFBMMHPWFSOJOHDPEFTBOEPSEJOBODFT
#3&8&34(&/&3*$*/45"--"5*0/*/4536$5*0/4 "
5IF*OUFSOBUJPOBM1MVNCJOH$PEFPGUIF*OUFSOBUJPOBM$PEF$PVODJMBOEUIF'PPEBOE%SVH"ENJOJTUSBUJPO
'%"'PPE$PEFNBOVBMEJSFDUUIBUUIJTFRVJQNFOUNVTUCFJOTUBMMFEXJUIBEFRVBUFCBDLnPXQSFWFOUJPO
in compliance with federal, state and local codes. For units installed outside of the U.S.A., make sure that
the installation is in compliance with the applicable plumbing/sanitation code for your area.

Installation
Leveling
1 Position the brewer on the counter top. Level it left to
right and front to back by turning the bottom of the
legs.
Connect the Water Supply
2 Flush the water supply line prior to installation to
QVSHFBJSBOEEFCSJTGSPNUIFXBUFSmMUFSBOEUVCJOH
3 $POOFDUUIFXBUFSTVQQMZMJOFUPUIFnBSFmUUJOHPO
the back of the brewer. Leave the water supply valve
closed until the power is connected.
Connect the Brewer Wiring
Brewers Without A Cord Set Attached
4 Remove the screws that hold the front cover in place
and remove the cover.
5 Loosen the strain relief on the back of the brewer.
6 On dual voltage units being operated at 220 Volts
(nominal) disconnect the existing power cable from
the terminal block and remove.
7 Feed the 220 Volt power cable into the brewer.
8 On dual voltage units being operated at 220 Volts,
disconnect and cap the jumper wire between the “C”
and “N” terminals on the terminal block.
9 Connect the wires on the power cable to the terminal
block inside the brewer.
10 Tighten the strain relief and replace the front cover.
11 Connect the power cable wires to the terminals in the
junction box. See the ELECTRICAL SCHEMATIC for
the power supply requirements.
INSTALLATION INSTRUCTIONS II8
DECANTER/DISPENSER BREWERS, INSTALLATION INSTRUCTIONS 080516NC
WARNING: Use the leveling legs to level the
brewer only. Do not use them to adjust brewer
height. Do not extend them higher than necessary.
Front
panel
WARNING: Turn off power to the junction box at
the circuit breaker panel before connecting the
power cable to the brewer.
Terminal
block

Brewers With A Cord Set Attached
12 Connect the power cord to the appropriate electrical
outlet.
Connect the Bag-in-Box (BIB) Sweetener -
Units Equipped for Brewing Sweet Tea Only
13 Connect two Bag-in-Box (BIB) sweeteners to the
brewer sweetener supply hoses as instructed in the
OPERATING INSTRUCTIONS section. Connecting two
bags allows the brewer to continue operating if one
bag runs out.
Power Up the Brewer
14 Turn on the water supply valve.
15 Make sure that the circuit breaker supplying power to
the unit is on.
16 Turn the toggle switch on the back of the brewer to the
0/QPTJUJPO5IFXBUFSUBOLXJMMTUBSUUPmMM8IJMFUIF
UBOLJTmMMJOHJOTQFDUUIFXBUFSTVQQMZMJOFGPSMFBLT
17 When the water in the tank rises to the correct level, the
heating elements will turn on automatically. Depending
on the incoming water temperature and the electrical
TQFDJmDBUJPOTUIFXBUFSUBOLUZQJDBMMZSFRVJSFTUP
minutes to reach the factory set operating temperature.
When the water has heated, Ready to brew will be
displayed on the LCD screen.
18 Perform a brew cycle of a least 12 ounces to purge
any remaining air from the system. See OPERATING
INSTRUCTIONS. During the initial brew cycle and
XIFOFWFSUIFmMUFSJTSFQMBDFEZPVNBZIFBSUIF
TPVOETPGBJSCFJOHQVSHFEGSPNUIFmMUFSUVCJOHBOE
water tank.
INSTALLATION INSTRUCTIONS II8
DECANTER/DISPENSER BREWERS, INSTALLATION INSTRUCTIONS 080516NC
Connect the Brewer Wiring (cont.)
WARNING: Connect the power cord to the
appropriate type and size electrical outlet. If the
electrical outlet is not compatible with the power
cord, have it upgraded by a licensed electrician. Do
not modify the power plug. Do not use an extension
cord. Do not use a power cord/plug that is damaged.
IMPORTANT: When operating the brewer at
higher elevations, reduce the operating
temperature by 2°F for each 1000 feet of
elevation. See PROGRAMMING GUIDE.

OPERATING INSTRUCTIONS OI2
Brewing Instructions
The G4 Combo Brewer is factory preset for optimal performance.
($#)4($#)501&3"5*/(*/4536$5*0/4ø /$
 Remove the lid from
an empty coffee or tea
dispenser and position it
on the brew deck. Center it
under the brew basket.
3 Select the brew basket
labeled for the type of
beverage being brewed (hot
coffee, iced coffee or iced tea)
BOEJOTFSUBDMFBOQBQFSmMUFS
Fill with the proper amount of
coffee or leaf tea. Level the
DPGGFFUFBJOUIFmMUFS
4 4MJEFUIFmMMFECSFXCBTLFU
into the brew rails under the
control panel. Slide it all the
way back until it stops.
5 )PMEZPVSmOHFSPOUIF
appropriate brew icon. As
soon as you hear the click
of the brew valve, lift your
mOHFS#SFXJOHXJMMCFHJO
The brewer will brew coffee or tea based on the settings programmed into the universal control module (UCM). To
change the settings, see the PROGRAMMING GUIDE.
 The brewer should be ON.
$POmSNUIJTBUUIFSFBSUPHHMF
switch. “Ready to brew”
should be on the display.
WARNING - TO AVOID SCALDING, AVOID SPLASHING. Keep body parts clear of the brewer during
brewing. Do not remove the brew basket while “Brewing” appears on the display.
WARNING - DO NOT refrigerate unused tea overnight for later consumption.
 If a keypad appears on
the display, the brew code
feature is enabled (default
is off). Brewing will start
immediately after you enter
the brew code. See the
PROGRAMMING GUIDE to
set up/disable the brew code.

NOTICE - Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives.
5IFTFQSPEVDUTQSPNPUFDPSSPTJPOBOEXJMMEBNBHFUIFmOJTIFT USE OF THESE PRODUCTS WILL VOID
THE WARRANTY.
CLEANING INSTRUCTIONS CI1
Cleaning The Brewer - Daily
BREWERS - GENERIC, CLEANING INSTRUCTIONS 080416B
WARNING: HOT SURFACES - To avoid injury, allow the brewer and dispenser(s) to cool before cleaning.
The brewer should be OFF.5VSOUIFCSFXFSPGGCZnJQQJOHUIFSFBSUPHHMFTXJUDIUPUIF0''QPTJUJPO
1 Remove the dispenser(s). Wipe exterior brewer surfaces with a damp cloth to remove spills and debris.
2 Remove the brew basket(s) and clean them in a mild detergent solution. Use a soft bristled brush for hard to
clean areas. Rinse with clean water, then dry.
3 Wipe the spray head area with a cloth soaked in a mild detergent solution. Rinse with a cloth soaked with
clean water removing any residual detergent. Use a clean, soft cloth to dry.
4 Dump out the drip tray(s) (if applicable). Rinse with clean water, then dry with a soft, clean cloth.
Cleaning The Brewer - Weekly
The brewer should be OFF.5VSOUIFCSFXFSPGGCZnJQQJOHUIFSFBSUPHHMFTXJUDIUPUIF0''QPTJUJPO
1 Remove the spray head(s), unscrewing counterclockwise from the dome plate.
2 Thoroughly clean and rinse the dome plate area.
3 Clean the brew basket rails with a brush soaked with a mild detergent solution. Rinse the area with a cloth
soaked with clean water, removing any residual detergent.
4 Dry the area with a soft, clean cloth.
5 Reattach the spray head(s).
WARNING: DO NOT immerse the brewer in water or any other liquid.

Cleaning the 1.0 Gallon or 1.5 Gallon Thermal Dispensers (Daily)
To clean, prepare a mild solution of detergent and warm water. Remove the ThermoPro dispenser from the brewer
and rinse.
1 Remove the lid from the dispenser. Clean it with a spiral brush and detergent solution. Rinse and dry.
2 Clean the dispenser. Wipe the exterior surfaces with a damp cloth to remove spills and debris. Fill the liner with a
mild detergent solution. Take a sponge brush and scrub out the stainless steel liner. Thoroughly rinse with clean,
warm water and dry.
3 Sanitize the interior of the dispenser using a commercial sanitizer suitable for food grade applications. Sanitize
according to the directions on the package.
4 Clean the faucet. Unscrew the handle/bonnet assembly from the top of the faucet and remove it. Inspect the seat
cup for wear. Replace the seat cup if it is damaged. Clean the faucet parts with the detergent solution. To avoid
damage, DO NOT use a brush to clean the faucet or the inside of the dispenser shank (outlet). Rinse, dry
and assemble the handle/bonnet. Hand tighten the handle/bonnet onto the top of the faucet.
5 Clean the sight gauge (some versions). If the sight gauge has a cover, pull it up and off to remove. Remove the
glass tube by unscrewing the cap. Clean the glass tube with a gauge brush soaked with detergent solution.
Rinse and dry. Clean the two washers, rinse and dry. Reassemble and hand tighten the cap.
CLEANING INSTRUCTIONS CI5
("--0/5)&3."-%*41&/4&3$-&"/*/(*/4536$5*0/4ø "
Faucet
Assembly
TXSG Series TLCG Series
Seat cup
Handle
Bonnet
Cap
Washer
Glass tube
Washer
Faucet
Assembly
Seat cup
Handle
Cover
Bonnet
Cap
Glass tube
WARNING: DO NOT immerse thermal dispensers in water or any other liquid. Do not place the ThermoPro
dispenser in a dishwasher. Placing the ThermoPro dispenser in a dishwasher will void the warranty.

CLEANING INSTRUCTIONS CI6
5&"%*41&/4&3$-&"/*/(*/4536$5*0/4ø "
Cleaning the Tea Dispenser (Daily)
Cleaning the Container
 Prepare a mild solution of detergent and warm water.
Remove the dispenser from the brewer and remove the
lid. Rinse.
2 Wash - Wipe the exterior surfaces with a sponge and
the detergent solution to remove spills and debris. Use
the detergent solution and a soft bristled brush to wash
the inside of the container.
3 Rinse - Rinse with clean, warm water.
4 Sanitize* - Sanitize the interior of the dispenser using a
commercial sanitizer suitable for food grade applications.
Sanitize according to the directions on the package.
* If a three compartment sink large enough to submerge
the dispenser is not available, swab, brush or pressure
spray the sanitizing solution according to the directions
on the package.
5 Air Dry - Turn the container upside down and allow to
air dry.
Cleaning the Faucet Parts, Lid and Drip Tray
 Disassemble the faucet - Unscrew the faucet assembly
from the dispenser. Then, unscrew the handle/bonnet
assembly from the top of the faucet and remove. Inspect
the seat cup for wear. Replace the seat cup if it is
damaged.
2 Wash - Wash the lid, drip tray and faucet parts with the
detergent solution.
3 Rinse - Thoroughly rinse all parts with clean, warm
water.
4 Sanitize - After rinsing, place the faucet parts in the sink
to be sanitized. Immerse them in a commercial sanitizer
suitable for food grade applications. Sanitize according
to the directions on the package.
5 Air Dry - Allow all parts to thoroughly air dry.
6 Reassemble - When dry, reassemble the handle/bonnet.
Hand tighten the handle/bonnet onto the top of the faucet
assembly. Hand-tighten the faucet assembly onto the
dispenser outlet.
Seat cup
Faucet
Handle
Bonnet

PROGRAMMING GUIDE PG1
Touchscreen Control Module
The touchscreen turns on whenever power is provided to the brewer and the rear toggle switch is on. The symbol
buttons on the screen control operation and programming. Pressing the on-screen symbols and buttons with
ZPVSmOHFSUJQBDUJWBUFTUIFWBSJPVTGVODUJPOT5IFEFGBVMUTDSFFOBTXFMMBTBEEJUJPOBMDPOUSPMCVUUPOTBSFTIPXO
CFMPX5IFDPOmHVSBUJPOPGUIFEFGBVMUTDSFFOWBSJFTEFQFOEJOHPOUIFCSFXFSNPEFM
2 The ACCESS CODE screen will appear. The
EFGBVMUQBTTDPEFJT0ODFUIFDPEFJT
FOUFSFEQSFTT0,5IF."*/.&/6TDSFFOXJMM
appear. The access code can be reset in the
$POUSPM4FUUJOHTTVCNFOVVOEFS1BTTXPSET
Status lights
Brew Buttons
Curtis logoHome Undo Scroll
left/right
Return to
previous
Control symbols - all
symbols may not be
present at the same
time
Entering Programming Mode
 5BQUIFXIJUF$VSUJTMPHPPOUIFUPVDITDSFFOmWFUJNFTUPFOUFSQSPHSBNNJOHNPEFTFFEJBHSBNBCPWF
 5IF."*/.&/6TDSFFODPOUBJOTBTFSJFTPGTVC
menu icons. The icons vary based on the model
TFMFDUFEVOEFSUIF.PEFM4FMFDUTVCNFOV'PS
UIFCSFXFSUPPQFSBUFQSPQFSMZUIFNPEFMTFMFDUFE
must match the model series on the brewer model
OVNCFSMBCFMBGmYFEUPUIFPVUTJEFPGUIFNBDIJOF
(130(3"..*/((6*%&ø #

PROGRAMMING GUIDE PG1
SELECTIONS FOR
COFFEE BREWER MODELS
SELECTIONS FOR
TEA BREWER MODELS
SELECTIONS FOR
COMBO BREWER
MODELS
Coffee
Gemini
Gemini IF
ThermoPro
Milano
Omega
Gourmet Std
Light Roast
Dark Roast
High Yield
Filter Pack
Decaf
Custom Recipe*
Model Select Control Settings Brew Settings
Recipes
Tea
Model Select Control Settings Brew Settings Settings Summary
Recipes
Combo
Model Select Control Settings Coffee
Brew Settings
Tea
Brew Settings Settings Summary Exit
Exit
Settings Summary Exit
Tea Recipes Coffee Recipes
Temperature
Warmer Settings*
Quality Timer
Energy Savings
Sounds
Diagnostics
Display Settings
Preventative Maintenance
Brew Counter
Passwords
Master Reset
Regional Settings
Filter Pre-Wet*
Custom Recipes
Chemex
V60
Kalita
Brew Basket
Custom Recipes
Thermo Pro 1G Single
Twin
Single
Twin
One Batch
Two Batch
Three Batch
One Batch
Two Batch
Three Batch
See Brew
Settings
One Batch
One Batch
Two Batch
Seraphim Single
Twin Paper Cup
Gold Cup
By Volume/Time
Pre/Pulse
Bypass
Drip Out
Flow Calibration
Tea/IC-1Batch
Tea/IC-2Batch
Tea/IC-3Batch
Tea/IC-4Batch
Tea-Sweet
Dual-Dilution
Dual-Sweet
Standard-Purple
Standard-Gray
Standard-Amber
Tropical-Purple
Tropical-Gray
76/308-Purple
76/308-Gray
Temperature
Quality Timer
Energy Savings
Sounds
Diagnostics
Display Settings
Preventative Maintenance
Brew Counter
Passwords
Master Reset
Regional Settings
Full Only
Full & Half
By Volume/Time
Dilution by Volume/Time
Dilution Delay/Stir/Fast-Brew
Pulses
Drip-Out
Sweetener*
Combo
Combo/IC
Combo-Sweet
Standard-Purple
Standard-Gray
Standard-Amber
Tropical-Purple
Tropical-Gray
76/308-Purple
76/308-Gray
Standard-Amber
Tropical-Amber
76/308-Amber
Standard-Purple
Standard-Amber
Gourmet Std
Light Roast
Dark Roast
High Yield
Filter Pack
Decaf
Temperature
Quality Timer
Energy Savings
Sounds
Diagnostics
Display Settings
Preventative Maintenance
Brew Counter
Passwords
Master Reset
Regional Settings
Full Only
Full & Half
Combo HV
Combo HV/IC
Single
Twin
By Volume/Time
Dilution by Volume/Time
Dilution Delay/Stir/Fast-Brew
Pulses
Drip-Out
Sweetener*
By Volume/Time
Pre/Pulse
Bypass*
Drip-Out
Pulses
Sprayhead Types
Flow Calibration
Batch Size
Sprayhead Types
Flow Calibration
Single*
Twin
Ceramic Cup
Paper Cup
Filter pack
One Batch
Two Batch
Three Batch
Programming
4IPXOCFMPXBSFUIFWBSJPVTQSPHSBNNJOHPQUJPOTBWBJMBCMFJOUIFQSPHSBNNJOH."*/.&/65IFJDPOTUIBU
BQQFBSWBSZCBTFEPOUIFCSFXFSNPEFMTFMFDUFEVOEFS.PEFM4FMFDU
'FBUVSFOPUBWBJMBCMFPOTPNFNPEFMT
(130(3"..*/((6*%&ø #

PROGRAMMING GUIDE PG1
USB - Easy Programming
5IFSFBSFUXPNFUIPETGPSDIBOHJOHUIFEFGBVMUTFUUJOHTPO(CSFXFST5IFTFUUJOHTDBO
CFQSPHSBNNFENBOVBMMZVTJOHUIFCSFXFSUPVDITDSFFOPSBVUPNBUJDBMMZVTJOHUIF64#
6OJWFSTBM4FSJBM#VTEBUBQPSUPOUIFTJEFPGUIFCSFXFS6TJOHUIF64#DPOOFDUJPOBOEB
nBTIESJWFFBTJMZSFQSPHSBNTUIFTFUUJOHTCZTJNQMZDPQZJOHEBUB
"nBTIESJWFDBODPQZBMMPGUIFTFUUJOHTGSPNPOFJEFOUJDBM(CSFXFSUPBOPUIFS%PJOHTPFMJNJOBUFTUIFOFFEUP
program each step individually using the touchscreen. This process also makes it easy to quickly standardize the
QSPHSBNTFUUJOHTPONVMUJQMF(CSFXFST
6TFBnBTIESJWFUIBUTVQQPSUT64#PSBCPWFBOEIBTBUZQF"64#DPOOFDUJPO5IFTUPSBHFDBQBDJUZNVTU
CF(#NJOJNVN
IMPORTANT:5IFnBTIESJWFNVTUCFcompletelyCMBOL&SBTFBOZFYJTUJOHmMFTPOUIFESJWFCFGPSF
TUBSUJOHUIFGPMMPXJOHQSPDFTT
Uploading the Software to the Flash Drive
 .BLFTVSFUIFCSFXFSJTPO$IFDLUPNBLFTVSFUIBUUIFCSFXFSZPVBSFDPQZJOHTFUUJOHTGSPNJTQSPHSBNNFE
as desired.
2 0QFOUIFDPWFSPOUIF64#QPSUBOEJOTFSUUIFDPOOFDUPSPOUIFFNQUZnBTIESJWF5IFQPSUJTMPDBUFEPOUIF
SJHIUTJEFQBOFMPGUIFCSFXFSOFBSUIFUPQ5IFVOJWFSTBMDPOUSPMNPEVMF6$.XJMMVQMPBEBMMPGUIFTFUVQ
EBUBPOUPUIFnBTIESJWF5IFZFMMPX-&%JDPOPOUIFUPQMFGUPGUIFUPVDITDSFFOXJMMMJHIUJOEJDBUJOHUIBUEBUBJT
USBOTGFSSJOH5IJTQSPDFTTXJMMPOMZUBLFBTFDPOEUPDPNQMFUF
Downloading the Software to the Brewer from the Flash Drive
 Select the (identical) brewer you wish to make program changes to. The brewer must be on.
2 1MVHUIFMPBEFEnBTIESJWFJOUPUIF64#QPSUPOUIFCSFXFS5IFEBUBDPQJFEGSPNUIFmSTUCSFXFSXJMM
BVUPNBUJDBMMZEPXOMPBEPWFSXSJUJOHBMMUIFTFUUJOHTUIBUXFSFPOUIFTFDPOECSFXFS
 5IFSFE-&%POUIFUPQMFGUPGUIFUPVDITDSFFOXJMMJOEJDBUFUIBUUIFEPXOMPBEJTJOQSPDFTT5IJTXJMMPOMZUBLF
a second.
 0ODFUIFEPXOMPBEJTDPNQMFUFUIF6$.XJMMSFCPPUTPUIBUUIFDIBOHFTUBLFFGGFDU
 3FNPWFUIFnBTIESJWF5IFEPXOMPBEJTDPNQMFUF5IFEBUBPOUIFnBTIESJWFDBODPOUJOVFUPCFEPXOMPBEFE
into as many identical brewers as needed.
USB File Transfer
5IJTTDSFFOXJMMCFQSFTFOUXIFOFWFSUIF64#nBTIESJWFJTJOTFSUFE
provided the brewer is not currently brewing.
5IFEFGBVMUBDUJPOJTi/P"DUJPOw5IF6$.XJMMBMXBZTDSFBUFBCBDLVQ
POUIFnBTIESJWFCFGPSFEPXOMPBEJOHTFUUJOHTSFDJQFTPSBTDSFFOTBWFS
*GBmSNXBSFVQEBUFJTQSFTFOUPOUIFnBTIESJWFUIFmSNXBSFVQEBUF
QSPDFEVSFXJMMCFTUBSUFECFGPSFUIFTDSFFOJTTIPXO
FILE TRANSFER
Settings/recipes
Present on USB
Screensaver
Not present on USB
Start
Upload
to USB
Download
from USB No Action
(130(3"..*/((6*%&ø #

ROUGH-IN DRAWINGS RD3
9.11 in
23.1 cm
25.4 cm
10.00 in
25.6 cm
10.07in
36.71 in
93.2 cm
58.0 cm
22.82 in
20.84 in
52.9 cm
3.3 cm
61.7 cm
24.31 in
58.4 cm
22.99 in
1.29 in
23.65 in
60.1 cm
5.43 in
13.8 cm
45.7 cm
18.00 in
93.2 cm
36.71 in
85.7 cm
33.74 in
23.59 in
59.9 cm
20.84 in
52.9 cm
3.3 cm
58.0 cm
22.82 in
58.9 cm
23.18 in
61.5 cm
24.21 in
1.29 in
G4CBHT - G4 Twin High Volume Combo Brewer
G4CBHS - G4 Single High Volume Combo Brewer
($#)4($#)5306()*/%3"8*/(ø /$

ILLUSTRATED PARTS/RECOMMENDED PARTS IP3
G4CBHS/G4CBHT, ILLUSTRATED PARTS/RECOMMENDED PARTS 090616NC
Supplies and Accessories - All Models
CAB-1 - Cleaning BrushWC-29050 - Spray Head
Sold by the case
13
12
11
2
14
1
8
25
18
17
6
329
16
28
15
20
22
23
30
24
5
7
10
9
21
27
26
4
31
19
SEE SECTION IP25
G4CBHS - Main Chassis - Exploded View

ILLUSTRATED PARTS/RECOMMENDED PARTS IP3
G4CBHS/G4CBHT, ILLUSTRATED PARTS/RECOMMENDED PARTS 090616NC
ITEM # PART # DESCRIPTION
1 WC-58117 COVER, TOP ALPGT/D500GT/D60GT TLP/TCTS/CBS/
GEMSS
2 WC-61607 COVER, FRONT CBHVS
3 WC-8531 RAIL, BASE TCTD
4 WC-2977-101K KIT,SPRAYHEAD FITTING PLASTIC
5 WC-29044 SLEEVE, OVERFLOW ASSY GEN USE
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-37122 KIT, DUMP VALVE RIGHT
8 WC-844-101 VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
9 WC-895-105 VALVE, INLET DUAL 120V 10W 2 GPM X .5 GPM
10 WC-37255 KIT, DUAL VALVE WATER INLET
11 WC-3417 BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-3398 BREW CONE, ASSY STD TEA NON METAL W/BLU
SPLASH POCKET
13 WC-3422IC BREW CONE,ASSY W/SPLASH POCKET TAN STYLZD
HV ‘ICED COFFEE’
14 WC-66079 SPOUT ASSY , DILUTION PLASTIC
15 WC-43134 O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
ITEM # PART # DESCRIPTION
4 WC-2977-101K KIT,SPRAYHEAD FITTING PLASTIC
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-37122 KIT, DUMP VALVE RIGHT
8 WC-844-101 VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
10 WC-37255 KIT, DUAL VALVE WATER INLET
G4CBHS - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
16 WC-13463-102 HARNESS ASSY, COMPLETE G4CBHS
17 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
18 WC-10001 CONTROL MODULE, UPM 120/220V G4
19 WC-10008 UNIVERSAL HOST ADAPTER USB
20 WC-103 SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
RESISTIVE
21 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
22 WC-8559 RELAY, SOLID STATE 280V/40A W/HEAT SINK AND
QUICK DISCONNECTS
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
24 WC-5231 COMPOUND, SILICONE 5 OZ
25 WC-589-101 TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
26 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
27 WC-1200 CORD, 14/3 SJTO 6’ BLK W/PLUG
28 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
29 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
30 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
31 WC-43089 GASKET, 1.00OD X .625 I.D. X .030 THK WHITE EPDM
70 SHORE
ITEM # PART # DESCRIPTION
20 WC-103 SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
RESISTIVE
22 WC-8559 RELAY, SOLID STATE 280V/40A W/HEATSINK AND
QUICK DISCONNECTS
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
24 WC-5231 COMPOUND, SILICONE 5 OZ
G4CBHS - Main Chassis - Parts List

ILLUSTRATED PARTS/RECOMMENDED PARTS IP3
G4CBHS/G4CBHT, ILLUSTRATED PARTS/RECOMMENDED PARTS 090616NC
1
13
25
5
3
8
12
17
11
6
22
27
15
2
14
28
20
18
31
16
4
33
7
19
10
26
21
9
29
30
23
32
24
G4CBHT - Main Chassis - Exploded View
SEE SECTION IP26

G4CBHT - Main Chassis - Parts List
ILLUSTRATED PARTS/RECOMMENDED PARTS IP3
G4CBHT - Recommended Parts to Stock
G4CBHS/G4CBHT, ILLUSTRATED PARTS/RECOMMENDED PARTS 090616NC
ITEM # PART # DESCRIPTION
1 WC-5421 COVER, TOP SS GEM-12D GEM-612ILD, TL9002,
312IL
2 WC-61619 COVER, FRONT W/A CBHTV
3 WC-37121 KIT, DUMP VALVE LEFT
4 WC-2977-101K KIT, SPRAYHEAD FITTING PLASTIC
5 WC-29044 SLEEVE, OVERFLOW ASSY GEN USE
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-37122 KIT, DUMP VALVE RIGHT
8 WC-844-101 VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
9 WC-895-104 VALVE, INLET DUAL 120V 9W .53 GPM X .53 GPM
10 WC-37255 KIT, DUAL VALVE WATER INLET
11 WC-3417 BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-3398 BREW CONE, ASSY STD TEA NON METAL W/BLU
SPLASH POCKET
13 WC-3422 BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED HIGH VOLUME
14 WC-66079 SPOUT ASSY , DILUTION PLASTIC
15 WC-43134 O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
16 WC-53045 TUBE ASSY, FLEXIBLE 1/4 FLARE SS/STL X 28.” LG
NYLON BRAIDED
ITEM # PART # DESCRIPTION
3 WC-37121 KIT, DUMP VALVE LEFT
4 WC-2977-101K KIT, SPRAYHEAD FITTING PLASTIC
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-37122 KIT, DUMP VALVE RIGHT
8 WC-844-101 VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
10 WC-37255 KIT, DUAL VALVE WATER INLET
ITEM # PART # DESCRIPTION
17 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
18 WC-10001 CONTROL MODULE, UPM 120/220V G4
19 WC-10008 UNIVERSAL HOST ADAPTER USB
20 WC-102 SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
21 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
22 WC-8559 RELAY, SOLID STATE 280V/40A W/HEATSINK AND
QUICK DISCONNECTS
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
24 WC-5231 COMPOUND, SILICONE 5 OZ
25 WC-589-101 TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
26 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
27 WC-847 VALVE, INLET 2 GPM 120V 10W GEN USE BROWN
BODY
28 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
29 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
30 WC-13450-102 HARNESS ASSY, COMPLETE G4TP2T
31 WC-2705 TEE, 1/4 X 1/4 FLARE X 3/8 NPT PLATED
32 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
33 WC-43089 GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
ITEM # PART # DESCRIPTION
20 WC-102 SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22 WC-8559 RELAY, SOLID STATE 280V/40A W/HEATSINK AND
QUICK DISCONNECTS
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
24 WC-5231 COMPOUND, SILICONE 5 OZ

ILLUSTRATED PARTS/RECOMMENDED PARTS IP25
WC-62080 TANK ASSEMBLY, ILLUSTRATED PARTS/RECOMMENDED PARTS 090616NC
ITEM # PART # DESCRIPTION
1A WC-54290DV-102 TANK, ASSY CBHS/CBHS67144
1B WC-62080 TANK COMPLETE, CBHS/CBHS67144
2 WC-5853-102 COVER, TOP HEATING TANK GEN USE
3 WC-43062 GASKET, TANK LID
4 WC-5527K KIT, PROBE WATER LEVEL O-RING & NUT
5 WC-904-04 KIT,ELEMENT, HEATING 1.6KW120V W/ JAM NUT
& SILICONE O-RING
6 WC-1438-101 SENSOR, TEMPERATURE TANK
7 WC-4394 GUARD, SHOCK/HEATING ELEMENT FOR SIN-
GLE HEATING ELEMENT
ITEM # PART # DESCRIPTION
3 WC-43062 GASKET, TANK LID
4 WC-5527K KIT, PROBE WATER LEVEL O-RING & NUT
5 WC-904-04 KIT,ELEMENT, HEATING 1.6KW120V W/ JAM NUT &
SILICONE O-RING
6 WC-1438-101 SENSOR, TEMPERATURE TANK
8 WC-522 THERMOSTAT, HI LIMIT HEATER CONTROL DPST
277V 40A
WC-62080 - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
9 WC-37365 KIT, FITTING TANK INLET
10 WC-37266 KIT, FITTING TANK OVERFLOW
11 WC-37317 KIT, STRAIGHT FITTING & BUSHNG MM GEN USE
12 WC-43055 GUARD, SHOCK RESET THERMOSTAT (WC-522)
13 WC-37357 KIT, STRAIGHT PLASTIC FITTING AND BUSHING
12MM
ITEM # PART # DESCRIPTION
8 WC-522 THERMOSTAT, HI LIMIT HEATER CONTROL
DPST 277V 40A
9 WC-37365 KIT, FITTING TANK INLET
10 WC-37266 KIT, FITTING TANK OVERFLOW
11 WC-37317 KIT, STRAIGHT FITTING & BUSHNG 8MM GEN
USE
12 WC-43055 GUARD, SHOCK RESET THERMOSTAT (WC-522)
13 WC-37357 KIT, STRAIGHT PLASTIC FITTING AND BUSHING
12MM
WC-62080 - Tank Assembly
2
3
10
11
5
8
7
6
12
4
1A
1B
13
9
9
WC-62080 - Tank Assembly - Parts List
