Wildgame Innovations Terra 8 User manual

Infrared Digital Scouting Camera
User’s Manual Model # TR8i1-7

Camera Unit 2 - Bungee Cords
User Manual
page 1
Includes

RESOLUTION
FLASH
FLASH RANGE
SENSOR
SENSOR RANGE
IMAGE FORMAT
MEMORY
IMAGE RESOLUTION
POWER SUPPLY
BATTERY LIFE
HOUSING
MOUNTING
MAX: 8 MP
21 pc High Intensity Infrared LED’s
up to 60 feet
Passive Infrared Sensor (PIR) Motion and Heat
up to 60 feet
JPEG - Digital Stills/ AVI-Digital Video
up to 32GB SD Card (not included and required)
Class 4 and above recommended
8 MP
8 AA batteries (not included and required)
Alkaline recommended
Estimated up to 1 year or 30,000 photos
Weather resistant with rubber gaskets
2 Bungee cords - included
page 2
Features

Installing Batteries
1. Open the door at the bottom of the
camera by unlatching the locking
tab.
2. With the camera facing open, open
the battery compartment cover by
sliding the latch to the left.
page 3
3. With the bottom of the camera to-
wards you, Make sure to insert the
batteries into the camera with the
positive ends towards you where
marked positive and the negative
ends towards you where marked
negative.
NOTE:
Do not mix old and new batteries. Do
not mix alkaline, standard (carbon-
zinc) or rechargable (ni-cad, ni-mh,
etc) batteries.

page 4
4. Close battery compartment cover.
To latch the cover simply pull the
latch slightly to the left as you close
the battery compartment cover.
IMPORTANT:
Make sure the camera is powered off
before removing or installing an SD card.
If you are using an SD card from other
cameras, please make sure to format the
SD card in your computer prior to use in
your camera. New cards are ok to use
straight from the package.
5. Load SD memory card (up to 32GB
not included) into the SD card slot
with the connectors facing up.

page 4
4. Close battery compartment cover.
To latch the cover simply pull the
latch slightly to the left as you close
the battery compartment cover.
IMPORTANT:
Make sure the camera is powered off
before removing or installing an SD card.
If you are using an SD card from other
cameras, please make sure to format the
SD card in your computer prior to use in
your camera. New cards are ok to use
straight from the package.
5. Load SD memory card (up to 32GB
not included) into the SD card slot
with the connectors facing up.

page 5
1. To turn the unit ON press and re-
lease the power button.
2. Check the battery level icon
to ensure the batteries just
installed contain the proper
charge level. If so, you are ok to
proceed with camera use.
Time/Date
Still Video
AM
Photos
Power On Test Mode
1. LCD Ready Mode: The camera will
automatically enter Ready Mode if a
button is not pressed for greater than
30 seconds.
2. LED Status Light: During the first
30 seconds of the LCD Ready Mode,
the red light will illuminate when a
PIR event is triggered. After the LCD
turns off, the red light will blink 2-3
seconds when photo is taken. After
2 minutes, all indicator lights will
turn off until a button is pressed.

page 5
1. To turn the unit ON press and re-
lease the power button.
2. Check the battery level icon
to ensure the batteries just
installed contain the proper
charge level. If so, you are ok to
proceed with camera use.
Time/Date
Still Video
AM
Photos
Power On Test Mode
1. LCD Ready Mode: The camera will
automatically enter Ready Mode if a
button is not pressed for greater than
30 seconds.
2. LED Status Light: During the first
30 seconds of the LCD Ready Mode,
the red light will illuminate when a
PIR event is triggered. After the LCD
turns off, the red light will blink 2-3
seconds when photo is taken. After
2 minutes, all indicator lights will
turn off until a button is pressed.

page 6
1. To change date and time, start by
pressing and releasing the enter
navigation button to set the hour.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the hour is set, repeat
steps 1 and 2 to set the minutes.
Time/Date
Still Video
AM
Photos
Time/Date
Still Video
AM
Photos
Power Save Setting Time
1. After 30 seconds without any buttons
being pushed, the LCD will turn off
and camera enters into Power Save
or Ready Mode.
2.The LCD screen can be awakened by
pressing the Power button briefly.
Note: The LCD will not “wake up”
when camera is writing to memory.

page 6
1. To change date and time, start by
pressing and releasing the enter
navigation button to set the hour.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the hour is set, repeat
steps 1 and 2 to set the minutes.
Time/Date
Still Video
AM
Photos
Time/Date
Still Video
AM
Photos
Power Save Setting Time
1. After 30 seconds without any buttons
being pushed, the LCD will turn off
and camera enters into Power Save
or Ready Mode.
2.The LCD screen can be awakened by
pressing the Power button briefly.
Note: The LCD will not “wake up”
when camera is writing to memory.

page 7
1. Press the enter navigation but-
ton after setting the minute to
change the Date.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the Month is set, repeat
steps 1 and 2 to set the Day and
Year.
1. Press and release the enter navi-
gation button to choose Photos.
The number displayed is the num-
ber of photos on your SD card. This
is not a programmable mode for
the camera.
Time/Date
Still Video
Photos
M
D D
M
Time/Date
Still Video
Photos
M
D D
M
Time/Date
Still Video
Photos
Setting Date Photos

page 7
1. Press the enter navigation but-
ton after setting the minute to
change the Date.
2.Press the + or - navigation button
to go up or down in sequence.
3.When the Month is set, repeat
steps 1 and 2 to set the Day and
Year.
1. Press and release the enter navi-
gation button to choose Photos.
The number displayed is the num-
ber of photos on your SD card. This
is not a programmable mode for
the camera.
Time/Date
Still Video
Photos
M
D D
M
Time/Date
Still Video
Photos
M
D D
M
Time/Date
Still Video
Photos
Setting Date Photos

1. Press the enter navigation button
while Image is selected. The high-
lighted option will be blinking.
2.Press the + or - navigation but-
ton to move to different options.
Press the enter navigation button
to save the setting.
page 8
Time/Date
Still Video
Photos
AM
Time/Date
Still Video
Photos
AM
1. To turn the unit off, first wake up
the LCD screen and then depress
and hold the power button until
the LCD turns off.
Time/Date
Still Video
Photos
AM
Image Power Off

1. Press the enter navigation button
while Image is selected. The high-
lighted option will be blinking.
2.Press the + or - navigation but-
ton to move to different options.
Press the enter navigation button
to save the setting.
page 8
Time/Date
Still Video
Photos
AM
Time/Date
Still Video
Photos
AM
1. To turn the unit off, first wake up
the LCD screen and then depress
and hold the power button until
the LCD turns off.
Time/Date
Still Video
Photos
AM
Image Power Off

Pictures Display:
A- Time
B- Date
C- Moon Phase
D- Photo Count
A B C D
1. When mounting to a tree, first latch
the 2 bungee cords through the
mounting holes on the left or right
side of the camera. Then, stretch
the cords around the tree and latch
the other ends of the bungee cords
through the mounting holes on the
opposite side of the camera.
page 9
Image Stamp Mounting

Pictures Display:
A- Time
B- Date
C- Moon Phase
D- Photo Count
A B C D
1. When mounting to a tree, first latch
the 2 bungee cords through the
mounting holes on the left or right
side of the camera. Then, stretch
the cords around the tree and latch
the other ends of the bungee cords
through the mounting holes on the
opposite side of the camera.
page 9
Image Stamp Mounting

The directions as contained herein assume that you are using a Microsoft operat-
ing system and not Linux or a Mac-based operating system. Even said, there may
be slight variations in your process based on the specific version of the operation
system that you are using as well as the predefined user preference for each
computer. The below listed steps are to serve as a guideline and may have to be
slightly modified based on the specific operating system and preference as on
your personal computer.
TIPS:
Recommended distance from target area is 25-30 feet for optimal imaging
quality.
To improve the quality of your images, try not to mount the unit facing the rising
or the setting sun in order to avoid direct sunlight into the camera lens.
If mounting to a feeder unit or dusty environment, be sure to clean the cam-
era lens cover, incandescent flash cover, and the PIR sensor cover on a regular
basis.
Periodically check the mounting of the camera to insure it is not loose.
Make sure that you securely latch the door closed each and every time you use
the unit, as the moisture seal will not be activated unless closed properly.
Check batteries frequently to insure no corrosive build-up, as this may cause
harm to the camera.
page 10
Important

Method 1: Remove SD card and use card
reader
A. First, remove the SD Card from the cam-
era unit itself by pressing on it to where it
automatically ejects.
B. Next, insert the SD card into your SD
card reader.
C. Once inserted into your computer it may
automatically launch “AutoPlay”, a window
recognizing a new Secure Digital Storage
Device (the SD Card).
D. If so, it should list several options for
the next steps (not limited to the following):
1. Picture Options
a. Import pictures
b. View pictures
c. Copy Disc
d. Transfer pictures
2. General Options
a. Open folder to view files
E. Select the method from the list provided
that best suits your requirements. If the se-
lection is made to “View pictures”, you can
then view the images located on the SD Card
and manipulate them as needed.
F. If your computer does not automatically
launch the AutoPlay window recognizing the
Removable Disk (the SD Card), then you will
need to go to the “Start Menu” at the bottom
left of your screen and select “Computer”.
The summary view will then be illustrated
on the right hand side of the window where
by the “Devices with Removable Storage”
will be listed. The computer will recognize
the reader as “Secure Digital Storage De-
vice”. Please select “Secure Digital Storage
Device” from this menu (or double click on
the graphical icon).
G. This will then direct you into the SD Card
file folder. Images are in the MEDIA folder.
H. Once open, you will then see all of the
photo files that are located on the SD Card.
Select each image individually to view. The
default viewing browser for your computer
will then automatically launch.
I. Repeat for viewing all or other photos.
J. If you determine that you want to delete
the image, select the image by placing your
cursor on it and clicking your mouse only
once. Right click on your mouse and select
delete. This will delete the image perma-
nently, so be absolutely sure you want to do
this before selecting delete.
page 11
Retrieving Images (SD Card Reader)

page 12
Format SD Card
Having trouble with your SD card? Try this.
1. Connect the SD card to your computer. If
your computer has an SD card slot you can insert the SD card directly into the port.
NOTE: If you are using a MicroSD card, you will need an adapter to allow it to fit into
standard SD card ports. If your computer does not have an SD card port built-in, you can
use an external USB card reader that plugs into any USB port
on your computer.
2. Click the Start or Windows menu and select Computer (Windows Vista/7) or My
Computer (Windows XP). For Windows 8 users, type “computer” and click the Computer
icon in the Apps search results.
3. Right-click the drive letter associated with your memory device, then select “Format”
4. Ensure FAT32 is selected under “File System”
5. Ensure ”Quick Format” is checked
6. Click “Start”
SDXC cards are not supported.

page 13
DISCLAIMERS
WGI Innovations, LTD is not responsible for damage, expense or injury caused by the unauthorized use of,
alterations to, improper connection of and abuse or neglect of the WGI Innovations™ products.
WARRANTY
For the warranty to be in effect, visit our website and register your product at www.wildgameinnovations.com.
Follow the onscreen directions to complete the process.
WGI Innovations, LTD will replace all workmanship defects free of charge for ONE (1) YEAR after the date of
purchase as long as your warranty is in effect.
This warranty DOES NOT COVER damage, expense or injury caused by unauthorized repairs, alterations, improper
connection, shipping, abuse, theft, accident, neglect or collateral loss.
When returning product(s) for service you MUST obtain a Return Merchandise Authorization (RMA) number from
WGI Innovations, LTD. Please include name, UPS address (No P.O. Box), telephone number, RMA number and
a complete description of the problem on all enclosed correspondence. When possible, pack product carefully
in original carton. Customers are responsible for any shipping cost to WGI Innovations™. WGI Innovations™ will
pay the shipping cost of replacement product to the customer. We are not responsible for damage incurred in
returning items for repair.
For product service send to:
WGI Innovations™
602 Fountain Parkway
Grand Prairie, TX 75050
[phone]
www.wildgameinnovations.com
Thank you for your purchase!
CUSTOMER SERVICE
WGI Innovations, LTD. stands behind every product we manufacture for a one year product workmanship warranty
and a strong commitment to customer service. If you are in need of customer service for missing parts or need
assistance with the operation or assembly of your product, we encourage you to call one of our customer service
representatives and let us assist you with your WGI Innovations™ product.
DISCLAIMER
WGI Innovations, LTD reserves the right to make changes to product features, functionality and physical design at
its sole discretion. As a result, such changes may not be reected in this version of the manual.
Warranty
