Wilfa COOL 9 CONNECTED User manual

EN ·Instruction manual NL ·Instructies
NO ·Bruksanvisning PL ·Instrukcje
SE ·Bruksanvisning FR ·Instructions
DK ·Betjeningsvejledning IT ·Manuale di istruzioni
FI ·Käyttöohje ES ·Manual de instrucciones
DE ·Anleitung
COOL 9 CONNECTED
AIR CONDITIONER

NO
SE
DK
FI
EN
NL
PL
FR
IT
ES
DE
LES ALLE ANVISNINGER FØR BRUK
LÄS IGENOM ALLA INSTRUKTIONER INNAN PRODUKTEN ANVÄNDS
LÆS ALLE VEJLEDNINGER INDEN BRUG
LUE OHJEET HUOLELLISESTI ENNEN KÄYTTÖÄ
READ ALL INSTRUCTIONS BEFORE USE
LEES VÓÓR GEBRUIK ALLE INSTRUCTIES
PRZED UŻYCIEM ZAPOZNAĆ SIĘ ZE WSZYSTKIMI ZALECENIAMI
PRENEZ CONNAISSANCE DE TOUTES LES INSTRUCTIONS AVANT UTILISATION
LEGGERE TUTTE LE ISTRUZIONI PRIMA DELL’USO
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
LESEN SIE DIE ANLEITUNG VOR DEM GEBRAUCH GRÜNDLICH DURCH

2
EN
INSTRUCTION MANUAL ·AIR CONDITIONER

3
EN
AIR CONDITIONER ·COOL 9 CONNECTED
CONTENTS
4 IMPORTANT SAFETY INSTRUCTIONS
6 EXCEPTION CLAUSES
7 THE REFRIGERANT
9 OPERATION ENVIROMENT
12 PRODUCT OVERVIEW – MAIN UNIT
14 PRODUCT OVERVIEW – CONTROL PANEL
16 PRODUCT OVERVIEW – REMOTE CONTROL
17 PRODUCT OVERVIEW – REMOTE CONTROL DISPLAY
19 REPLACEMENT OF BATTERIES
20 CLEANING AND MAINTENANCE
21 CHECKS
21 LONG-TIME STORAGE
21 NOTICE FOR RECOVERY
22 TROUBLESHOOTING
24 ERROR CODE
25 INSTALLATION
32 GUARANTEE
33 PRODUCT SPECIFICATIONS
33 SUPPORT AND SPARE PARTS
33 RECYCLABILITY

4
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
IMPORTANT SAFETY INSTRUCTIONS
• Read this instruction manual thoroughly before
use and save it for future reference. It is also
available at our website; wilfa.com.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
• Cleaning and user maintenance shall not be made
by children without supervision. Children shall not
play with the appliance.
• Before operation, please conrm whether power
specication complies with that on nameplate.
• Before cleaning or maintaining the air conditioner,
please turn off air conditioner and pull out the
power plug.
• Make sure the power cord hasn’t been pressed by
hard objects.
• Do not pull or drag the power cord to pull out the
power plug or move the air conditioner.
• Do not insert or pull out the power plug with wet
hands.

5
EN
AIR CONDITIONER ·COOL 9 CONNECTED
• Please use the grounded power. Make sure the
grounding is reliable.
• If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualied person in order to avoid a
hazard.
• If abnormal condition occurs (e.g. burned smell),
please disconnect power at once and then contact
local dealer.
• When nobody is taking care of the unit, please turn
it off and remove the power plug or disconnect
power.
• Do not splash or pour water on air conditioner.
Otherwise, it may cause short circuit or damage
to air conditioner.
• If drainage hose is used, ambient temperature
can’t be lower than 0ºC. Otherwise, it will cause
water leakage to air conditioner.
• Prohibit operating heating equipment around the
air conditioner.
• Prohibit operating the unit in the bathroom or
laundry room.
• Far away from re source, inammable and
explosive objects.

6
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
• Children and disabled people are not allowed to
use the unit without supervision.
• Keep children from playing or climbing on the air
conditioner.
• Do not put or hang dripping objects above the air
conditioner.
• Do not repair or disassemble the air conditioner
by yourself.
• Prohibit inserting any objects into the air
conditioner.
• Do not use an extension cord.
• Do not put sundries into the air duct. If sundries get
into the air duct, please contact the professionals
to deal with it.
EXCEPTION CLAUSES
Supplier will bear no responsibilities when personal
injury or property loss is caused by the following
reasons:
1. Damage the product due to improper use or
misuse of the product.
2. Alter, change, maintain or use the product
with other equipment without abiding by the
instruction manual of manufacturer.

7
EN
AIR CONDITIONER ·COOL 9 CONNECTED
3. After verication, the defect of product is directly
caused by corrosive gas.
4. After verication, defects are due to improper
operation during transportation of product.
5. Operate, repair, maintain the unit without abiding
by instruction manual or related regulations.
6. After verication, the problem or dispute is caused
by the quality specication or performance of
parts and components that produced by other
manufacturers.
7. The damage is caused by natural calamities, bad
using environment or force majeure.
Appliance lled with ammable gas
R290.
Before installing and using the
appliance, read the manual rst.
THE REFRIGERANT
• To realize the function of the air conditioner unit,
a special refrigerant circulates in the system. The
used refrigerant is the uoride R290, which is
specially cleaned.

8
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
• The refrigerant is ammable and inodorous.
Furthermore, it can lead to explosion under
certain conditions.
• Compared to common refrigerants, R290 is a
non-polluting refrigerant with no harm to the
ozonosphere. The inuence upon the greenhouse
effect is also lower. R290 has got very good
thermodynamic features which lead to a high
energy efciency. The units therefore need a less
lling.
• Please refer to the nameplate for the charging
quantity of R290.
WARNING
• Appliance lled with ammable gas R290.
• Appliance shall be installed, operated and stored
in a room with a oor area larger than 11m2.
• The appliance shall be stored in a room without
continuously operating ignition sources (for
example: open ames, an operating gas appliance
or an operating electric heater.)
• The appliance shall be stored in a well-ventilated
area where the room size corresponds to the room
area as specied for operation.
• The appliance shall be stored to prevent
mechanical damage from occurring.

9
EN
AIR CONDITIONER ·COOL 9 CONNECTED
• Ducts connected to an appliance shall not contain
an ignition source.
• Keep any required ventilation openings clear of
obstruction.
• Do not pierce or burn.
• Be aware that refrigerants may not contain an
odour.
• Do not use means to accelerate the defrosting
processortoclean,otherthanthoserecommended
by the manufacturer.
• Servicingshallbeperformedonlyasrecommended
by the manufacturer.
• Should repair be necessary, contact your nearest
authorized Service Centre.
• Any repairs carried out by unqualied personnel
may be dangerous.
• Compliance with national gas regulations shall be
observed.
OPERATION ENVIROMENT
• The air conditioner must be operated within the
temperature range: 16°C ~ 35°C.
• The appliance is for indoor use only.

10
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
• The appliance must be positioned so that the
plug is accessible.
• This air conditioner is for domestic, non-
commercial use only.
• Reserved space around the air conditioner should
be 30cm at least.
• Do not operate the air conditioner at humid
environment.
• Please keep air inlet and air outlet clean, no
obstacles.
• During operation, close doors and windows to
improve cooling effect.
• Please put the air conditioner at smooth and at
ground for operation to avoid noise and vibration.
• This air conditioner is equipped with castors.
Castors should slide at smooth and at ground.
• Prohibitincliningorturningovertheairconditioner.
If there’s abnormity, please disconnect power
immediately and contact dealer.
• Avoid direct sunshine.

11
EN
AIR CONDITIONER ·COOL 9 CONNECTED

12
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
PRODUCT OVERVIEW – MAIN UNIT
1. Controller panel
2. Horizontal louver
3. Vertical louver
4. Castor
5. Wire-xing hook
6. Plug of power cord
7. Filter
8. Air inlet
9. Joint
10. Heat discharge pipe
11. Rear clip
1
2
3
4
7
8
9
10
5
6
11

13
EN
AIR CONDITIONER ·COOL 9 CONNECTED
USE
To change air direction:
1. Up/Down air ow direction:
– Hold the horizontal louvers and adjust the air ow directions.
– Do not adjust the horizontal louvers to the lowest or the highest position
in the COOL or DRY mode with the fan speed set too low for an extended
period of time, Condensation may form on the louvers.
2. Left/right air ow direction. Hold the vertical louver and adjust the air ow
direction.
Caution:
• Do not adjust the vertical louvers to the extreme left or right in the COOL
or DRY mode with the fan speed set too low for an extended period.
Condensation may form on the louvers.
OPERATION TEST
• Press on/off button on the remote controller to start the unit.
• Press mode button to select auto, cooling, drying or fan function, and check if
the unit operates normally.
• If ambient temperature is below 16°C the unit cannot operate in cooling
mode.

14
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
PRODUCT OVERVIEW – CONTROL PANEL
1. ON/OFF button
2. +/- button
3. Mode button
4. Fan button
5. Timer button
6. Wi- button
7. Display
8. Cool mode indicator
9. Dry mode indicator
10. Fan mode indicator
11. Fan speed indicator
1
2
3
4
6
7 8
9
5
10
11
USE
• After connecting the air conditioner to the power supply, it will sound a beep.
After that, you can operate the air conditioner by the control panel.
• Under ON status, after each pressing of the button on control panel, the air
conditioner will give out a sound. Meanwhile, corresponding indicator on
control panel will be bright.

15
EN
AIR CONDITIONER ·COOL 9 CONNECTED
1ON/OFF button
Pressing this button will turn on or turn off the air conditioner.
2+/- button
Under cooling mode, press “+” or “-” button to increase or decrease the
temperature by 1°C (°F). Set temperature range is 16°C~30°C Under drying or
fan mode, this button is invalid.
3Mode button
Press this button and the mode will circulate according to below sequence:
Cool-> Dry-> Fan
• Cool: Under this mode, cooling mode indicator is bright. The display shows
set temperature. Temperature setting range is 16-30 degrees Celsius.
• Dry: Under this mode, drying mode indicator is bright.
• Fan: Under this mode, the air conditioner only blow fan. Fan indicator is bright.
4Fan button
Press this button and the fan speed will circulate as “low speed-medium speed-
high speed-auto fan-low speed”
5Timer button
• Press timer button to enter timer setting mode.
• Under this mode, press “ + “ or “ - “ button to adjust the timer.
• The timer will increase or decrease 0.5 hour by pressing “ + “ or “ - “ within
10 hours.
Exceeding 10 hours, the timer will increase or decrease 1 hour when pressing
“+” or “-“. After setting the timer, the display shows the temperature if there’s
no operation for 5s. If timer function is started up, the upper indicator will keep
the display status. Under timer mode, press timer button again to cancel timer
mode.
6 Wi- button
• Press “WiFi“ button to turn on WiFi function, “WiFi“ icon will be displayed on
the remote controller: Hold “WiFi“ button for 5s to turn off WiFi function and
“WiFi“ icon will disappear.
• Under off status, press “MODE” and “WiFi“ buttons simultaneously for 1s,
WiFi module will restore factory settings.

16
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
PRODUCT OVERVIEW – REMOTE CONTROL
1 2
34
7
8
5
69
1. ON/OFF button
2. Mode button
3. +/- button
4. Swing button (not available)
5. Fan button
6. Sleep button
7. Timer button
8. Health button (not available)
9. WiFi button
FAN
AUTO
OPER
Fan Swing
ModeOn/Off
Sleep Timer
Health WiFi
FAN
AUTO
OPER

17
EN
AIR CONDITIONER ·COOL 9 CONNECTED
FAN
AUTO
OPER
Fan Swing
ModeOn/Off
Sleep Timer
Health WiFi
FAN
AUTO
OPER
I feel function
Turbo mode
Send signal
Health function
Light function
8°C heating function
TIMER ON /TIMER OFF
Set temperature
Child lock
Up & down swing
Set fan speed
Auto mode
Cool mode
Dry mode
Fan mode
Heat mode
Sleep mode
Set temp.
Outdoor ambient temp.
Indoor ambient temp.
Operation mode
Temperature display type
PRODUCT OVERVIEW – REMOTE CONTROL DISPLAY
Ventilation operation
Set time
NOTE:
This is a general use remote controller, and some functions, as described are
non-functioning.
USE
1ON/OFF button
Press this button to turn on the unit. Press this button again to turn off the unit.
2Mode button
Press this button and the mode will circulate according to below sequence:
Auto -> Cool -> Dry-> Fan-> Heat
• Auto: During auto the unit will automatically adjust the settings. The set
temperature cannot be changed.
• Cool: Under this mode, air conditioner operates under cooling mode. Cooling
indicator will be on. Press “Fan Speed” button to adjust the fan speed.
• Dry: Under this mode, the unit runs in low fan speed for dehumidication and
the corresponding indicator is on. The fan speed cannot be adjusted.
• Fan: Under this mode, air conditioner will not cool or heat, only blow wind. Fan
indicator will be on. Press “Fan Speed” button to adjust the fan speed.
• Heat: Not available

18
EN
INSTRUCTION MANUAL ·AIR CONDITIONER
3+/- button
• Pressing “+” or “-” button once will increase or decrease set temperature by
1°C (°F). Hold “+” or “-” button for 2s, set temperature on remote controller
will change quickly.
• Release the button after your required set temperature is reached.
Under timer setting status, after each pressing of “+” or “-” button, time will
increase or decrease 0.5h. Hold “+” or “-” button and the time on the display
will change quickly.
4Swing button
Not available for this unit.
5Fan button
This button sets the fan speed. The sequence goes from auto, 1, 2, 3, and back
to auto.
6Sleep button
Press this button to turn the sleep mode on. This function maintains the most
comfortable temperature for you.
7Timer button
• Press this button once and the characters of HOUR ON (OFF) will ash.
• Meanwhile, press “+” button or “-” button to adjust timer setting (time will
change quickly if holding “+” or “-” button). Time range is 0.5~24hours.
• Press this button again to conrm timer setting and the characters of HOUR
ON (OFF) will stop ashing.
If the characters are ashing but you haven’t press timer button, timer setting
status will be stopped after 5s. If timer is conrmed, press this button again to
cancel timer.
8Health button
Not available for this unit.
9 Wi- button
• Press “WiFi“ button to turn on WiFi function, “WiFi“ icon will be displayed on
the remote controller: Hold “WiFi“ button for 5s to turn off WiFi function and
“WiFi“ icon will disappear.
• Under off status, press “MODE” and “WiFi“ buttons simultaneously for 1s,
WiFi module will restore factory settings.
