BAT KT7 (USA/Canada)
BAT KT8 (International)
Chargers for Pocketalker 2.0
QUICK SETUP GUIDE
BAT KT7 (U.S.A. and Canada)
BAT KT8 (International)
MAN 200C

Safety Warnings
1. To prevent injury,never charge the unit in enclosed
spaces such as handbags, cases, or other closed
storage bags.
2.To prevent injury, unplug this device during lightning
storms, or when charging is complete and the device
is unused for long periods of time.
3. To prevent injury, use correct AC adapter for country
of use.
4. To prevent injury, use only the power supply provided
by Williams AV. Other power supplies may have
similar specifications, but may not be equivalent. Use
of an unapproved power supply may leave the device
partially or completely inoperable, and will void the
warranty.
5.To prevent injury, protect the power cord from
being walked on or pinched, particularly at plugs,
receptacles, and near the power jack on the unit.
Product Description
The BAT KT7 and BAT KT8 are designed for charging the
Williams AV Pocketalker 2.0 when used with NiMH
batteries.
The BAT KT7 is the USA and Canada version with U.S.
prongs.
The BAT KT8 is the International version supplied with
prong adapters for the UK, Europe, and Australia. It is CE
compliant and meets the requirements of Europe’s Medical
Device Directive.
WARNING!
USE THIS CHARGER WITH NiMH RECHARGEABLE BATTERIES
ONLY - Williams AV P/N BAT 022 (or equivalent) AAA size NiMH, 1.2
VDC Rechargeable batteries).

Preparing the BAT KT7 charger for use
1. While holding the power supply, pry out the prongs with
a finger.
1. Pry prongs out
2. Continue pulling until the prongs stop.
2. Pull until it stops

Preparing the BAT KT8 charger for use
Choose the prong adapter for your country of use.
1. Place the prong adapter on the power supply as shown,
sliding it down (right) as far as possible.
1. Insert prongs
2. Pivot the adapter up/to the left until it clicks into place.
2. Pivot to left
“click”
To remove the adapter:
1. Push down and pull back on the tab as shown.
2. With the tab pulled back, pivot the adapter to the right.
1. Pull back 2. Pivot right

3. Once the adapter is free, release the tab.
3. Release
Charging the Pocketalker
WARNING!
BEFORE CONNECTING THE CHARGER TO THE POCKETALKER,
MAKE SURE THE POCKETALKER HAS NiMH RECHARGEABLE
BATTERIES INSTALLED NOT ALKALINE.
1. Open the Pocketalker battery compartment and set the
battery switch to the NiMH position (Figure 1).
Figure 1: Battery Compartment
+
–
+–
A650
Battery type switch
AAA Batteries
(note polarity)
NiMH
Alkaline
2. Insert two AAA NiMH batteries. Be sure to follow
correct polarity (Figure 1).

3. Connect the USB Cable using Figures 2 or 3 depending
on which charger is used:
a. Plug the USB “A” (larger rectangular) plug into the
USB port of the power supply. Do not force it; if it
doesn’t slide in easily, it could be upside down. If it is,
rotate it 180 degrees and try again.
b. Plug the USB “Micro-B” (smaller) connector into the
charging port on the Pocketalker.
4. Follow the instructions in the previous section
“Preparing the charger for use”.
5. Plug the power supply into an AC wall outlet (Figure 2
or 3).
-The charging indicator on the Pocketalker will blink slowly
while the batteries are being charged, then stay on when
the batteries are fully charged.
-It will take approximately 16 hours to fully charge the batteries.
Figure 2: BAT KT7 Charging Connection
A652
USB
Micro-B
Charging
Port
USB Micro-B
Plug (small)
USB A Plug
(large)
USB A
Port
PockeTalker 2.0 USB charging cord
Charging Indicator
Power Supply
US
Prongs
plug into
wall outlet

Figure 3: BAT KT8 Charging Connection
A651
USB “Micro-B”
Port
USB “Micro-B”
Plug (small)
USB “A”
Plug (large)
USB “A”
Port plug into
wall outlet
Charging Indicator
PockeTalker 2.0 Power Supply
Adapter for
country of use
installed
USB charging cord
Power Supply Specifications
Weight 0.4 lbs
Input 100-240 VAC, 50-60 Hz, 0.5-0.3 A
Output 5 VDC, 2.0 A
Warranty
The BAT KT7 and BAT KT8 are covered by a 90 day
warranty.
Customer Service
If you experience diculty with your system, call Toll-Free for
Customer Assistance:
1-800-328-6190 (U.S.A.) or
[phone] (Outside the U.S.A.)
If it is necessary to return the system for service, your Customer
Service Representative will give you a Return Authorization Number
(RA) and shipping instructions.

EU Authorized Representative:
Emergo Europe
Prinsessegracht 20
2514 AP The Hague
The Netherlands
©2019 Williams AV LLC MAN 200C
[e-mail] / www.williamsav.com
800-843-3544 / INTL: [phone]
