Wilo Control SC-Fire Electric User manual

Wilo-Control SC-Fire Electric
Pioneering for You
2 541 365-Ed.01 / 2014-02-Wilo
de Einbau- und Betriebsanleitung
en Installation and operating instructions
fr Notice de montage et de mise en service
nl Inbouw- en bedieningsvoorschriften

Fig. 1:
SPRINKLER PUMP MOTOR SUPPLY.
NOT TO BE SWICHED OFF
IN THE EVENT OF FIRE
I ON
0 OFF
1
2
**

3
1
6
7
5
4

Fig. 2:
231546
10
9
7 8

English
26 WILO SE 01/2014
Captions
Fig. 1 Switchgear set-up
1Menu selection and parameter input
2Main switch: for switching the switchgear 
on/off
3Fusible cut-outs
4Transformer: 
3-phase pump current measurement
5Contactors/contactor combinations
6Base board: printed circuit board with micro-
controller
7Measurement board: 
converting current and voltage values
** Note regarding the main switch:
Power supply for the sprinkler pump motor.
DO NOT SWITCH OFF IN THE EVENT OF A FIRE!
Fig. 2 Switchgear display elements
1LED (green): Operational standby
2LED (green): Pump operation
3LED (yellow): False start
4LED (white): Sprinkler request
5LED (white): Float switch request
6LED (yellow): Collective fault
7LED (green) and button: Manual start
8LED (red) and button: Manual stop
9Button: Lamp test
10 Button: Acknowledgement of error messages

English
Installation and operating instructions Wilo SC-Fire Electric 27
Installation and operating instructions
1 General
1.1 About this document
The language of the original operating instruc-
tions is German. All other languages of these
instructions are translations of the original oper-
ating instructions.
These installation and operating instructions are
an integral part of the product. They must be kept
readily available at the place where the product is
installed. Strict adherence to these instructions is
a precondition for the proper use and correct
operation of the product.
These installation and operating instructions cor-
respond to the relevant version of the product and
the underlying safety regulations and standards
valid at the time of going to print.
EC declaration of conformity:
A copy of the EC declaration of conformity is a
component of these operating instructions.
If a technical modification is made on the designs
named there without our agreement or the decla-
rations made in the installation and operating
instructions on product/personnel safety are not
observed, this declaration loses its validity.
2Safety
These operating instructions contain basic infor-
mation which must be adhered to during installa-
tion, operation and maintenance. For this reason,
these operating instructions must, without fail, be
read by the service technician and the responsible
specialist/operator before installation and com-
missioning.
It is not only the general safety instructions listed
under the main point “safety” that must be
adhered to but also the special safety instructions
with danger symbols included under the following
main points.
2.1 Indication of instructions in the operating
instructions
Symbols:
General danger symbol
Danger due to electrical voltage
NOTE
Signal words:
DANGER!
Acutely dangerous situation.
Non-observance results in death or the most
serious of injuries.
WARNING!
The user can suffer (serious) injuries. ’Warning’
implies that (serious) injury to persons is proba-
ble if this information is disregarded.
CAUTION!
There is a risk of damaging the pump/unit. ’Cau-
tion’ implies that damage to the product is likely
if this information is disregarded.
NOTE:
Useful information on handling the product. It
draws attention to possible problems.
Information that appears directly on the product,
such as:
• Direction of rotation arrow,
• Identification for connections,
• Rating plate,
• Warning sticker,
must be strictly complied with and kept in legible
condition.
2.2 Personnel qualifications
The installation, operating and maintenance per-
sonnel must have the appropriate qualifications
for this work. Area of responsibility, terms of ref-
erence and monitoring of the personnel are to be
ensured by the operator. Ifthe personnel are not in
possession of the necessary knowledge, they are
to be trained and instructed. This can be accom-
plished if necessary by the manufacturer of the
product at the request of the operator.
2.3 Danger in the event of non-observance of the
safety instructions
Non-observance of the safety instructions can
result in risk of injury to persons and damage to
the environment and the product/unit. Non-
observance of the safety instructions results in
the loss of any claims to damages.
In detail, non-observance can, for example, result
in the following risks:
• Danger to persons from electrical, mechanical and
bacteriological influences
• Damage to the environment due to leakage of
hazardous materials
• Property damage
• Failure of important product/unit functions
• Failure of required maintenance and repair proce-
dures
2.4 Safety consciousness on the job
The safety instructions included in these installa-
tion and operating instructions, the existing
national regulations for accident prevention
together with any internal working, operating and
safety regulations of the operator are to be com-
plied with.
2.5 Safety instructions for the operator
This appliance is not intended for use by persons
(including children) with reduced physical,sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.

28 WILO SE 01/2014
English
If hot or cold components on the product/the unit
lead to hazards, local measures must be taken to
guard them against touching.
Guards protecting against touching moving com-
ponents (such as the coupling) must not be
removed whilst the product is in operation.
Leakages (e.g. from the shaft seals) of hazardous
fluids (which are explosive, toxic or hot) must be
led away so that no danger to persons or to the
environment arises. National statutory provisions
are to be complied with.
• Highly flammable materials are always to be kept
at a safe distance from the product.
• Danger from electrical current must be eliminated.
Local directives or general directives [e.g. IEC, VDE
etc.] and instructions from local energy supply
companies must be adhered to.
2.6 Safety instructions for installation and
maintenance work
The operator must ensure that all installation and
maintenance work is carried out by authorised and
qualified personnel, who are sufficiently informed
from their own detailed study of the operating
instructions.
Work on the product/unit must only be carried out
when at a standstill. It is mandatory that the pro-
cedure described in the installation and operating
instructions for shutting down the product/unit
be complied with.
Immediately on conclusion of the work, all safety
and protective devices must be put back in posi-
tion and/or recommissioned.
2.7 Unauthorised modification and manufacture of
spare parts
Unauthorised modification and manufacture of
spare parts will impair the safety of the product/
personnel and will make void the manufacturer’s
declarations regarding safety.
Modifications to the product are only permissible
after consultation with the manufacturer. Original
spare parts and accessories authorised by the
manufacturer ensure safety. The use of other
parts will absolve us of liability for consequential
events.
2.8 Improper use
The operating safety of the supplied product is
only guaranteed for conventional use in accord-
ance with Section 4 of the operating instructions.
The limit values must on no account fall under or
exceed those specified in the catalogue/data
sheet.
3 Transport and interim storage
Immediately after receiving the product:
• Check product for transport damage.
• In the event of damage in transit, take the neces-
sary steps with the forwarding agent within the
respective time limits.
CAUTION! Risk of property damage!
Incorrect transport and interim storage can
cause property damage.
• The switchgear is to be protected against mois-
ture and mechanical damage.
• It must not be exposed to temperatures outside
the range of -10°C to +50°C.
4 Application (intended use)
The SC Fire pump switchgear is used to control an
individual electric pump in automatic sprinkler
systems, in accordance with EN 12845.
The device is used in residential and office build-
ings, hospitals, hotels, administrative and indus-
trial buildings.
The pump is used in conjunction with suitable sig-
nal transmitters and it is switched on according to
the pressure or on and off according to the level.
The intended use includes complying with these
instructions.
Any other use is considered to be outside the
intended use.

English
Installation and operating instructions Wilo SC-Fire Electric 29
5Productinformation
5.1 Type key
Example:
WW = Wilo
CTRL Control
SC Smart Control = control unit
FF = fire fighting purposes
1x Number of pumps
7.7 A Maximum rated motor current [A]
T4 T = 3 phases; 4 = 400 V
DOL
SD
Direct online (direct starting)
Star delta (star-delta starting)
FM
BM
Frame mounted (on a base frame)
Base mounted (free-standing cabinet)
ND3
ND4
New Design switchbox 400 x 1300 x 250 mm
New Design switchbox 400 x 950 x 250 mm
ESwitchgear for electric pump
5.2 Technical data (standard version)
Mains supply voltage [V]: 3~400 V (L1, L2, L3, PE)
Frequency [Hz]: 50/60 Hz
Control voltage [V]: 230 VAC; 24 VDC
Max. current consumption [A]: See rating plate
Protection class: IP 54
Max. fuse protection on mains side [A]: See wiring diagram
Ambient temperature [°C]: 0 to +40°C
Electrical safety: Degree of contamination II
Alarm/signalling contact 250 VAC, 1 A
5.3 Scope of delivery
•Switchgear
•Wiringdiagram
• Installation and operating instructions
• Test report acc. to EN 60204-1
5.4 Accessories
6 Description and function
6.1 Description of the product (Fig. 1)
6.1.1 Function description
The switchgear is used to control an individual
electric pump in sprinkler systems, in accordance
with EN 12845. The pump can be switched on and
off by the control depending on the pressure. The
system’s operating statuses, such as standby,
pump operation, fault etc., are displayed visually
by LEDs on the door and operating parameters
such as current or voltage values are shown on the
display. The system is operated using the rotary
knob and the buttons in the door.
Potential-free contacts are available for forward-
ing run or fault signals messages to the building
management system.
6.1.2 Set-up of the switchgear (Fig. 1)
The set-up of the switchgear depends on the
capacity of the pump to be connected. It consists
of the following main components:
• Main switch: Switches the switchgear on/off
(Fig. 1, item 2)
• Human-machine interface (HMI): signal lamps or
display for indicating the operating status (e.g.
standby, fault, and rated pump current), rotary
knob and buttons for menu selection, parameter
input and operation (Fig. 1, item 1)
• Base board: printed circuit board with microcon-
troller (Fig. 1, item 6)
• Measurement board: converting current and volt-
age values (Fig. 1, item 7)
• Transformer: 3-phase pump current measure-
ment (Fig. 1, item 4)
• Fuse protection for drives: fusing for the pump
motor by means of fusible cut-outs (Fig. 1, item 3)
• Contactors/contactor combinations: contactors
for switching on the pumps (Fig. 1, item 5)

30 WILO SE 01/2014
English
6.2 Function and operation
DANGER! Risk of fatal injury!
When working on the open switchgear, there’s a
danger of electric shock from touching the live
components.
This work must only be carried out by qualified
personnel!
NOTE:
After connecting the switchgear to the supply
voltage, as well as after every mains interruption,
the switchgear returns to the operating mode set
before the power interruption.
6.2.1 Switchgear operating modes (Fig. 2)
Switching the switchgear on/off
After connection to the mains supply, the switch-
gear can be switched on or off using the main
switch. Once the main switch has been switched
on, the system is ready for operation after a few
seconds (the start phase). If the supply voltage is
within the set parameters, standby is indicated by
the signal lamp (Fig. 2, item 1) lighting up green.
Pump request
If the pressure drops below the set target pressure
at least one of the two pressure switches, the sig-
nal lamp lights up (Fig. 2, item 4). After a configur-
able delay period (see menu 1.2.5.1) (LED flashes),
the connected pump is activated. The signal lamp
(Fig. 2, item 2) lights up green, indicating that the
pump is in operation.
Once the pressure reaches or exceeds the target
pressure, the signal lamp (Fig. 2, item 4) goes out
again but the pump remains activated. The pump
has to be switched off manually. The signal lamp
(Fig. 2, item 2) then goes out.
Priming device
If the level of the pump priming tank falls below 
2/3, the float switch closes and the signal lamp
(Fig. 2, item 5) lights up white. After a configur-
able delay time (see menu 1.2.5.2) (LED flashes),
the pump activates and the signal lamp (Fig. 2,
item 2) lights up green. Once the pump priming
tank is full and the float switch opens again, the
signal lamp goes out (Fig. 2, item 5) and the pump
either switches off again automatically or it has to
be deactivated manually (see menu 5.2.2.0).
The signal lamp (Fig. 2, item 2) then goes out.
Voltage monitoring
To improve operational reliability, the mains
power supply is monitored continuously. To do
this, the correct supply voltage has to be set in
menu 1.2.1.1. The voltage is monitored individu-
ally between all three live wires. If no pump is run-
ning (standby), the voltage in the display switches
alternately between all three conductors. When
the supply voltage exceeds or drops below the
configurable tolerances (see menu 5.4.1.0 and
5.4.2.0), the signal lamp (Fig. 2, item 1) goes out
after a configurable delay (see menu 1.2.5.3) and
the collective fault signal (Fig. 2, item 6) lights up
yellow. If a fault occurs, the pump nevertheless
starts or continues running. Once the voltage is
back within the tolerance range, the fault is self-
acknowledging. The signal lamp (Fig. 2, item 6)
goes out and the signal lamp (Fig. 2, item 1) lights
up green again.
Current monitoring
The pump current is monitored while the pump is
in operation. To do this, the correct rated current
for the pump has to be set in menu 1.2.1.2. The
current is monitored individually in all three con-
ductors. If the pump is running, the pump current
in the display switches alternately between all
three conductors. The signal lamp (Fig. 2, item 2)
lights up green once the pump current reaches a
configurable minimum threshold (see menu
5.4.3.0). When the pump current exceeds or drops
below the configurable tolerances (see menu
5.4.3.0 and 5.4.4.0), the signal lamp (Fig. 2, item 6)
lights up after a configurable delay (see menu
1.2.5.5). If a fault occurs, the pump nevertheless
starts or continues running. Once the pump cur-
rent is back within the tolerance range, the fault
can be acknowledged. The signal lamp (Fig. 2,
item 6) goes out.
Monitoring hydraulic false start
Once the pump has started, the hydraulic output is
monitored by a pressure switch on the pump. If
the pump does not build up any pressure after the
configurable period of time (see menu1.2.2.2) and
the pressure switch on the pump remains open,
the signal lamps (Fig. 2, item 6) and (Fig. 2, item 3)
light up. If the pump is running, the relevant pres-
sure has been reached and the pump pressure
switch is closed accordingly, the fault can be
acknowledged. The signal lamps (Fig. 2, item 6)
and (Fig. 2, item 3) go out and the signal lamp
(Fig. 2, item 2) lights up green.
Monitoring electric false start
Once the pump has started, the pump’s electric
output is monitored for a configurable period of
time after the start (see menu 1.2.2.1). To do this,
the correct pump output has to be set in menu
1.2.1.3. If the configurable minimum threshold (see
menu 5.4.5.0) is not reached within the monitoring
period, the signal lamps (Fig. 2, item 6) and (Fig. 2,
item 3) light up after a configurable delay period
(see menu 1.2.5.4) plus the time for the star/delta
changeover (see menu 1.2.5.6). If the pump is run-
ning and the relevant pump output has been
reached, the fault can be acknowledged. The signal
lamps (Fig. 2, item 6) and (Fig. 2, item 3) go out and
the signal lamp (Fig. 2, item 2) lights up green.
Logic reversal of the collective fault signal (SSM)
The required logic of the SSM can be set in menu
5.5.2.0. In this case, it is possible to select
between negative logic (falling edge in case of a
fault = “fall”) or positive logic (rising edge in case
of a fault = “raise”).

English
Installation and operating instructions Wilo SC-Fire Electric 31
6.2.2 Operation of the switchgear
Operating elements
•Main switch on/off (lockable in “Off” position)
•TheLCD shows the operating statuses of the
pump and the settings menu. The menu selection
and parameter input are performed using the
operating knob. Turn the knob to change values
or to scroll through a menu level; press it in order
to select and confirm:
Information appears on the display as shown in
the sample illustration below:
4
4
1
2
3
5
Item Description
1Menu number
2Value display
3Units display
4Standard symbols
5Graphic symbols
The following graphic symbols are used:
Symbol Function/description Availability
Go back (brief press: one menu level; long press: main screen) all
EASY menu all
EXPERT menu all
Meaning: Service not logged in
Meaning: Display value – no entry possible
all
Service menu all
Parameter all
Information all
Fault all
Reset fault all
Alarm settings all

32 WILO SE 01/2014
English
Pump all
Setpoints all
Actual value all
Sensor signal all
Sensor measurement range Electrical equipment
Delay time all
Operating mode/application all
Stand-by all
Operating data all
Switchgear data:
Controller type; ID number; software/firmware
all
Operating hours all
Pump’s operating hours all
Switchgear’s switching cycles all
Pump’s switching cycles all
Communication all
Output parameters all
SSM parameter all
Set motor speed Diesel
Symbol Function/description Availability

English
Installation and operating instructions Wilo SC-Fire Electric 33
Starting time per start attempt Diesel
Pause between start attempts Diesel
Fuel Diesel
Battery A Diesel
Battery B Diesel
Sprinkler (pressure switch) all
Pump priming tank (float switch) all
Heating Diesel
Engine oil Diesel
Motor temperature thermostat Diesel
Cooling water (temperature) Diesel
Belt break Diesel
False start Electrical equipment
Pressure Electrical equipment
Mains power supply Electrical equipment
Voltmeter all
Ampere meter all
Star-delta switching Electrical equipment
Symbol Function/description Availability

34 WILO SE 01/2014
English
Menu structure: The menu structure of the control system has
4 levels.
Freely configurable fault signal all
Fault input all
Start attempts counter Diesel
Duration all
Power meter Electrical equipment
Communication parameters all
Modbus all
BACnet all
Factory setting all
Resetting the settings to the factory settings all
Alarm counter all
Maintenance interval all
Reset all
Motor speed Diesel
Set motor speed Diesel
Minimum speed for “motor in operation” Diesel
Reset starting counter Diesel
Symbol Function/description Availability

English
Installation and operating instructions Wilo SC-Fire Electric 35
Navigation in the individual menus as well as the
parameter input are described in the following
example (selecting the transformer):

36 WILO SE 01/2014
English
Refer to the following table for a description of the
individual menu items:
Menu
no./
Display Description Parameter range
Factory setting
The main screen shows the status of the system.
The display continuously switches between the
voltages of the live wires.
When the motor is running, the present pump cur-
rent in all three live wires is shown alternately on
the display.
The EASY menu allows you to make settings for
the supply voltage, rated pump current and the
pump’s performance.
The EXPERT menu contains other settings that
can be used for a detailed setting of the switch-
gear.
The parameter menu for all settings that influence
operation.
The setting menu for the electrical parameters of
the connected pump.
Setting the supply voltage. 400

English
Installation and operating instructions Wilo SC-Fire Electric 37
Setting the rated pump current. 0.1..7.8..5000
Setting the pump motor’s output. 1..4..250
The setting menu for the monitoring operations
periods.
Setting the duration for monitoring of the pump’s
electric output (electric false start).
0..70..120
Setting the duration for monitoring of the pump’s
hydraulic output (hydraulic false start).
0..70..120
The setting menu for the delays.
Start delay when pressure switch trips 1..10
Start delay when float switch trips 1..10
Menu
no./
Display Description Parameter range
Factory setting

38 WILO SE 01/2014
English
Delay in event of error message from voltage
monitoring
0..1..10
Delay for “electric false start” error message 0..1..20
Delay in event of error message from current
monitoring
0..1..20
Star-delta changeover time 0..5..60
Buffer time between deactivation of star contac-
tor and activation of delta contactor
0.00..0.05..1.0
Communication
Display of currently activated fieldbus OFF, Modbus, BAC-
net, GSM
Pump menu
Menu
no./
Display Description Parameter range
Factory setting

English
Installation and operating instructions Wilo SC-Fire Electric 39
Drives on/off OFF, ON
Information
Current operating values
Voltage values
Voltage between conductors L1 and L2
Voltage between conductors L1 and L3
Voltage between conductors L2 and L3
Current values
Menu
no./
Display Description Parameter range
Factory setting

40 WILO SE 01/2014
English
Pump current in L1
Pump current in L2
Pump current in L3
Output values
Pump output L1
Pump output L2
Pump output L3
Status information
Menu
no./
Display Description Parameter range
Factory setting
