Operation Manual
50982- CET-80000
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificant-
ly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.

© by WilTec Wildanger Technik GmbH Seite 13
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
The information contained in this document is subject to change without prior notice. No part of this
document can be copied or duplicated in another form without the prior written consent of WilTec Wil-
danger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
___________________________________________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [e-mail]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury by means of fire or
electric shock we urge that our clients take some basic safety precautions when using this
device. Please read the operation instructions carefully and make sure you have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the corre-
sponding mains voltage on the type plate. If you have any doubts about the connection being ground-
ed, have it checked by a qualified professional. Never use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised inter-
vention the 2-year warranty is no longer valid! Keep these operation instructions safe.

© by WilTec Wildanger Technik GmbH Seite 14
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
UN PACKING
Notify your dealer immediately if there are external damage.
SAFETY INSTRUCTIONS
1> For your own safety, please contact an electrical specialist in case of questions
and problems.
2> Do not connect the power supply when the all parts are not installed.
3> Plug in the pump only to a power receptacle with ground contact. This type of out-
let must have been set up according to the respective national directives (VDE.
EN……IEC etc.) Insure that the PE conductor extend all the way to the pump.
4> Make sure the voltage in the pump is the same with the actual power supply.
5> Electrical installations on garden ponds must correspond to the international and
national installation directives.
6> Only operate the pump if no one is in the water.
7> Do not carry or pull the pump by the connecting cord.avoid the cable over heat,
greasy or touch acute angle.
8> The pump may not be operated if the cable or the casing are defective.
9> Never displace any liquids other than water.
10> Attention: the pump will automatically stop working if overload or run without wa-
ter.
11> The controller is not water-proof design, so put it in a dry and ventilated place.
USING APPLICATIONS
Apply to ponds, rockery, bourne, aquarium tanks and seafood tanks.
FEATURE
1> Multi-function intelligent control, can adjust flow and power.
2> The new electronic frequency conversion technology, energy saving 60%
3> Centrifugal impeller design, improve the H-max and output.
4> Super silence, cab be used both in fresh and sea water.
5> Novel design and generous, rotary handle, easy to carry.
6> Rotary footings, can work both vertical or horizontal.
7> Ceramic shaft, wear resistance, no rust.
8> Long service life, no copper element
9> The outlet realize multistage over, suitable for a variety of pipe diameter connec-
tion.
10> Separation of electric drive, more safe and stable.
11> The external aluminum alloy radiator of the controller can dispatch heat well .
12> With anti-blocking and anti-idling function ( immediately cut off power automati-
cally if impeller blocked, immediately cut off power automatically if pump run idling)

© by WilTec Wildanger Technik GmbH Seite 15
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
13> With abnormal alarm function. This pump can warn you of various abnormal
problems in time.
INSTALLATION
1> Notify your dealer immediately if there are external damages.
2> Compare the Voltage and frequency of your electrical circuit with the data on the
model plate, these data must agree.
3> Connect the pipeline if needed. (Attention: the piping system shall not have bub-
ble.) Hose connection diagram is as follows.
This product have variety of outlets, you can select according to the size. Loosen the
nut in clockwise direction, connect the hose, Tighten the nut in anti-clockwise direc-
tion.
4> Attention: the pump must installed below the water level 20cm at least, the sur-
face must firm and horizontal.
5> Do not place the pump directly in the ponds floor that have mud, place it on a
raised surface.
6> Connect the pump with the controller of four core wire (PIC 1), lock the nut as
shown in PIC 2

© by WilTec Wildanger Technik GmbH Seite 16
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
CONTROLLER USE
The controller is consist of hook, panel, touch button, fixed foot.
1> Switch function
After the power is switched on, touch “START-STOP”, control the switch of pump.
Attention: please cut off the power if long time no use.
2> Adjust the gear.
Touch “DOWM” or “UP” to adjust pump gear. Consult the detailed performance data
as below.
Model Voltage Gear Power
(W) Output
(L/h) H-max (m) Flow rate
(1.5m)
50982
(CET-
8000)
110V~22V
50~60HZ
SP01 18 3500 1.6 500L
SP02 23 4000 1.9 1350L
SP03 28 4600 2.3 2000L
SP04 35 5000 2.7 2600L
SP05 42 5400 0.1 3200L
SP06 51 5800 3.5 3500L
SP07 60 6200 3.9 3800L
SP08 66 6700 4.5 4500L
SP09 73 7200 4.8 4800L
SP10 80 8000 5.4 5100L

© by WilTec Wildanger Technik GmbH Seite 17
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
3> Feeding function
Long press “UP” until the buzzer sound twice, you now in the state of delay start. You
have 10 minutes to feed the fish. Operation is the same if you want cancel this delay
start..
4> Lock / Unlock function
After you get the correct gear you want, you need press ”down” until the buzzer
sounds twice. You now in the state of locked. the unlock function is the same opera-
tion.
5> Automatic memory function
When the controller power off suddenly, it still have memory. The pump will automatic
recovery to a working state as before when power on.
6> Alarm function
The pump will immediately cut off power automatically if pump run idling. Then re-
start automatically to work again after 5 seconds. If still run idling the pump will auto-
matically power off again. After repeated five times the pump will power off until re-
connect the power. Meanwhile, the buzzer will sounds short time to make alarm.
The pump will immediately cut off power automatically if impeller blocked, and the
buzzer will sounds to make alarm until re-connect the power.
7> Code definition and troubleshooting.
Code
Definition Status Troubleshooting
P000 Power Normal /
SP00 Gear Normal /
FEE0
Delay start Normal /
ER05
Short-circuit current display Abnormal
check the controller
ER04
overheat flicker Abnormal
clean the pump
ER03
pump work without water Abnormal
check the pump if working without wa-
ter
ER02
pump block Abnormal
check the impeller if block
ER01
over/under voltage display Abnormal
check voltage

© by WilTec Wildanger Technik GmbH Seite 18
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
MAINTENANCE / CLEANING
Please clean the filter casing, impeller, rotor and shaft part regularly. Please cut off
the power when clean it:
①Turn and take off the filter casing as Pic 1 and Pic 2.
②Press the insurance clasp vertically as Pic 3, and take off the impeller cover as Pic
4.
③take off the rotor set as Pic 5, then you can clean or change.
④The installation position of the O-ring as Pic 6
If the pump is not used for a long time, please full out the pump, it is better to run the
pump in the clean water for a short time. And then rinse with clean water. Clean and
make sure the pump is dry, put it in a stable place.
If the temperature is below 0 degree, the water in the pump should be discharged
immediately. In order to prevent freezing damage of water pump.
TROUBLESHOOTING
Problem
Cause
Troubleshooting
pump do not run
No power supply Connect the power
Burning machine Change pump
Impeller stall Clean and re-link to power
Run without water Fill with water and re-link to power
Not connected with the controller
Re-link the controller
The controller is damaged Change the controller
Pump noise Dirty inside Clean pump
shaft break or wear change shaft
Pump water
shortage
Damage of the impeller change impeller
inlet and outlet obstruction clean the inlet and outlet
filter case obstruction clean filter case
low voltage adjust voltage

© by WilTec Wildanger Technik GmbH Seite 19
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
DRAWING
NO. NAME NO. NAME
1 Bottom foot 8 ceramic bearing
2 filter case 9 motor with cable
3 outlet 10 rear cover
4 seal circle 11 handle
5 impeller cover 12 rubber foot
6 rotor set 13 Gear box with cable
7 O-Ring

© by WilTec Wildanger Technik GmbH Seite 20
http://www.WilTec.de
http://www.aoyue.eu
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2002/96/EC) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equip-
ment. By contributing to the correct disposal of this
article you protect the environment and the health of
your fellow men. Environment and health are threat-
ened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
