WilTec CTF-2800 User manual

© by WilTec Wildanger Technik GmbH Seite 10
http://www.wiltec.info
Operating Instruction
Pond Pumps and Fountain Pumps
CTF
-
2800
-
50286
CTF- 3800 - 50287
CTF- 4800 - 50288
CTF- 5800 - 50289
CTF- 5000 - 50290
CTF- 6000 - 50291
CTF
-
7000
-
50292
CTF- 8000 - 50293
CTF-10000 - 50294
CTF-12000 - 50295
CTF-14000 - 50296
CTF-16000 - 50297
Similar illustrations – may vary depending on the version
Vor Inbetriebnahme Bedienungsanleitung und Sicherheitshinweise lesen und beachten
Read and follow the operating instructions and safety information before using for the first time.
Avant la mise en service, lisez le mode d’emploi et les consignes de sécurité et respectez-les.
Subject to technical changes!
Due to further developments, illustrations, functioning steps and technical data may differ slightly.
Documentation Updates
If you have any suggestions for the improvement or in case you have noticed irregularities, please
contact us.

© by WilTec Wildanger Technik GmbH Seite 11
http://www.wiltec.info
The information contained in this document may change without prior notice at any time. No part of
this document may be copied without the prior written consent of WilTec Wildanger Technik GmbH or
reproduced in any other form. WilTec Technic GmbH assumes no liability for any errors in this manual
or the connection diagrams.
Although WilTec Technik GmbH has made their best efforts to ensure that this manual is complete,
accurate and up to date, errors can not be ruled out. As for problems with this manual, please fill out
this form and send it back to us.
FAX-Note (+++49 2403 55592-15),
From: ________________________________________
Name: ________________
Company:_____________________
Phone/Fax:__________________
II would like to report the following error:
Customer Service Wiltec Wildanger Technik GmbH
e-mail: [e-mail]
Phone:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury by fire or electric shock,
we kindly ask you to take same basic safety precautions into account when using this device. Please
read these operating instructions thoroughly and make sure that you have understood them. Always
use a grounded power supply with the correct voltage. The corresponding mains voltage is indicated
on the nameplate. In case you are unsure whether the connection is grounded, have it checked by a
qualified technician. Never make use of a damaged power cord.
Do not open this device in damp or wet surroundings or if you are wet yourself and protect it from di-
rect sunlight. Install the device in a safe place so that no one can step or fall on the cord. Provide for
an adequate air cooling and avoid heat accumulation. Before cleaning the device pull the power plug
and simply use a damp cloth. Avoid the use of cleaning agents and ensure that no liquid enters the
device. The interior of this device does not contain any parts that have to be maintained by you. Leave
the maintenance, adjustment and repair to qualified personnel. In the case of foreign intervention, the
2-years´ warranty period expires! Keep this manual in a safe place.

© by WilTec Wildanger Technik GmbH Seite 12
http://www.wiltec.info
Security notes:
ATTENTION:
In stagnant waters, garden ponds and swimming ponds and the surrounding areas the device can only
be used with a residual current circuit breaker and a triggering nominal current up to 30 mA (according
VDE 0100 part 702 and 738).
The device is not for use in swimming pools, any kind of paddle ponds and the like that are used by
humans during the operation of the device. Operating the device during the stay of humans in the
danger zone is not permitted. Ask your electrician!
The device must not be used by persons (including children) with reduced physical, sensory or mental
capabilities and/or lack of experience or knowledge, unless they are instructed by a person responsi-
ble for their safety or given instruction how to use the device.
ATTENTION:
 Perform a visual inspection before each use of the device. Do not use the device if the safety
equipment is damaged or worn. Never override the safety equipment.
 Only use the device for the purpose as specified in this manual.
 You are held responsible for the safety in the work area.
 If the power cord or the plug is damaged by external influences, the cord must not be re-
paired.! The cord must be replaced with a new one. This operation must be carried out only by
a qualified electrician.
 The Voltage of 230 AC volts as indicated on the device´s nameplate has to be according to
the mains voltage.
 Never lift, transport or fix the device by using the power cord as a means for this purpose.
 Make sure that the electrical connectors are located in a flood-safe area and that they are pro-
tected from moisture.
 Pull the power plug before working on the device.
 The device must not be exposed to a direct stream of water or rain.
 As for the compliance with local safety and installation regulations the user is held responsible
(as the case may be, ask an electrician).
 Consequential damage due to flooding caused by faults of the device is to be prevented by
the user who takes the appropriate measures therefor.
 In case of a failure, the device may only be repaired by a qualified electrician or by the WilTec
customer service.
 The device must never run dry or be operated with the suction tube fully closed.
 The device must not be used for the operation of swimming pools.
 The device must not be installed in the portable water cycle.

© by WilTec Wildanger Technik GmbH Seite 13
http://www.wiltec.info
WARNING:
Read all safety warnings and instructions. Any failure due to disrespect of the safety instructions may
result in electric shock, fire and / or serious injury.
Keep all warnings and instructions for the future.
Resistance
During continuous operation, the maximum temperature of the liquid to deliver should not exceed
+35°C.
The delivery of aggressive liquids (such as acids, alkalis, silo seepage, etc.) as well as liquids contain-
ing abrasive materials (sand etc.) is to be avoided.
Electrical connection
 The electrical connection is made to a grounded socket 230 V ~ 50 Hz. Hedging at least 6 amps.
 By an integrated thermal motor protection, the engine is protected from overload and blockage.
Mains connection
The acquired pond pump is already equipped with a grounded socket. The pump is intended for a
connection to a grounded socket with 230 V ~ 50 Hz. Make sure that the socket is adequately secured
and in a good condition. Run the pump plug into the socket. The pump is ready for operation.
Note:
Installation
8. Check out whether the mains voltage corresponds with the specifications on the nameplate.
9. Do not place the pump directly in the pond mud but on a stone in order to make sure that no mud
is drawn in.
10. Check the delivery head (maximum depth). This information can be likewise found the nameplate.
11. The pump is installed as follows: either in a fixed position with a fixed tubing or in a fixed position
with flexible tubing.
12. Route the cord in a protected way in order to avoid the possibility of damage.
13. Connect the pump to the power supply.
14. As long as being connected to the power supply the pump keeps its operation.
Commissioning
Having read the afore-mentioned instructions carefully, you may operate the pump under the following
conditions:
 Check out whether the pressure line is attached properly.
 Make sure that the electrical connection is 230V~50Hz.
 Make sure that the socket is in a proper condition.
 Make sure that there is never any contact between humidity or water with the mains connection.
 Install the pump below the water surface.
 Make sure that the pump never runs dry.
 Never operate the pump without a filter basket. The filter basket protects the pump from coarse
dirt that may lead the pump to get clogged.
 Never install the pump in the pond mud.

© by WilTec Wildanger Technik GmbH Seite 14
http://www.wiltec.info
Overload protection
The pump disposes of an integrated overload protection. After being switched of by the overheating
protection, the pump has to cool down for a while before re-operation. If it does not start re-operating
by itself the following checks are to be performed:
Could the pump cool down sufficiently after the switch-off by the overheating protection
Is there a sufficient water supply? > Improve water supply!
Is there any dirt in the pump housing? > Cleaning as below mentioned!
Hose or tube clogged? > Clean!
Hose bend or to long? > Check, replace, cut it!
Model Voltage
Perfo
r-
mance
Maximum
Flow Rate
Maximum
Delivery head
Connection
(inch) Cord length
CTF
-
2800
AC 220-240V/50Hz
10W
3000 l/h
2 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
3800
20W
3600 l/h
2.8 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
4800
30W
4500 l/h
4 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
5800
40W
5200 l/h
4.8 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
5000
30W
5000 l/h
3.3 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
6000
40W
6000 l/h
4.2 m
1“ – 1 ¼“ –1½“
10 m
CTF
-
7000
50W
7000 l/h
4.6 m
1“ – 1 ¼“ –1½“-2“
10 m
CTF
-
8000
70W
8000 l/h
5.6 m
1“ – 1 ¼“ –1½“-2“
10 m
CTF
-
10000
80W
10000 l/h
6 m
1“ – 1 ¼“ –1½“-2“
10 m
CTF
-
12000
100W
12000 l/h
6.5 m
1“ – 1 ¼“ –1½“-2“
10 m
CTF
-
14000
120W
14000 l/h
7 m
1“ – 1 ¼“ –1½“-2“
10 m
CTF
-
16000
140W
16000 l/h
7.5 m
1“ – 1 ¼“ –1½“-2“
10 m
Maintenance
The pond motor pump is a proven quality product subjected to strict final instructions.
However, in order to ensure a long durability and a continuous operation, we recommend a regular
control and and care.
To ensure the proper operation of the pump it is indispensable to clean it regularly. We advise a
weekly cleaning. Kindly remove the pump housing and clean the pump with a smooth brush in running
water. Remove any residue found on the pump shaft.
Winter storage
5. Remove the pump from the water and disconnect it from the power supply.
6. Clean the pump as afore mentioned.
7. Check the pump with regard to damage, such as cracks or cuts in the housing.
8. Kindly store the pump under frost-free conditions, if possible in a container filled with water.
