Windsor Saber Glide SGE28 Specifications

MODELS
:
SGE28 SGE36 SGE32 SGEO32
10052480 10052500 10052490 10052520
AFTER SN: 1000136404
86037550 09/28/12
PRV NO. 980193
AE
SCRUBBER
IPX4
Operating Instructions (ENG)
Bedienungsanleitung (GER)
Istruzioni operative (ITA)
Manuel d’utilisation (FRE)
Read these instructions before using the machine
Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen
Leggere attentamente le presenti istruzioni prima di azionare la macchina
Lire ce manuel avant d’utiliser la machine

MACHINE DATA LOG/OVERVIEW
GLIDE 86037550 05/10/11
2
For the name and address of your dealer contact: Windsor Industries
YOUR DEALER
Name: __________________________________________________________________________________________________
Address: _______________________________________________________________________________________________
Phone Number: _________________________________________________________________________________________
MODEL _______________________________________
DATE OF PURCHASE __________________________
SERIAL NUMBER ______________________________
SALES REPRESENTATIVE # _____________________
DEALER NAME ________________________________
OPERATIONS GUIDE NUMBER ___________________
PUBLISHED __________________________________________
OVERVIEW
The Saber Glide is a battery powered, ride-on, hard floor scrubber intended for commercial use.
The appliance applies a cleaning solution onto a hard floor, scrubs the floor with brushes or pads,
and then vacuums the soiled water back into the recovery tank.
Warranty Registration
Thank you for purchasing a Windsor product. Warranty registration is quick and easy.
Your registration will allow us to serve you better over the lifetime of the product.
To register your product go to:
www.windsorind.com/WarrantyRegistration.aspx
For customer assistance:
1-800-444-7654

TABLE OF CONTENTS
GLIDE 86037550 06/30/12
3
Machine Data Log/Overview................................2
Table of Contents.................................................3
HOW TO USE THIS MANUAL
How to use this Manual........................................1-1
SAFETY
Important Safety Instructions ...............................2-1
Hazard Intensity Level..........................................2-2
Safety Label Location...........................................2-3
OPERATIONS
Technical Specifications.......................................3-1
How the Machine Works. .....................................3-3
Components.........................................................3-4
Controls ................................................................3-5
Machine Operation............................................ 3-14
Pre-Run Machine Inspection ......................... 3-14
Starting Machine. ........................................... 3-14
Filling the Solution Tank................................. 3-14
Scrubbing. ...................................................... 3-14
Emergency Stop Procedures ......................... 3-15
Emptying & Cleaning Tanks........................... 3-16
MAINTENANCE
Maintenance............................................ ............4-1
Batteries. ..............................................................4-2
Battery Maintenance. ...........................................4-2
Checking Battery Specific Gravity.....................4-2
Charging the Batteries. .....................................4-3
Changing Batteries............................................ 4-4
Battery Connections..........................................4-4
Battery Tray Drain Hose....................................4-4
Squeegee.............................................................4-5
Adjusting Pitch ..................................................4-5
Replace/Rotate Rear Squeegee Blade.............4-6
Removing Squeegee Assembly........................4-6
Replace/Rotate Front Squeegee Blade ............4-6
Side Squeegee..................................................4-7
Replace/Rotate Side Squeegee Blades............4-7
Adjusting the Side Squeegee Deflection...........4-7
Scrub Brush Replacement ...................................4-8
Brake ....................................................................4-9
Steering Chain Tensioner ....................................4-9
Vacuum Motor................................................... 4-10
Brush Motor....................................................... 4-11
Traction Motor ................................................... 4-12
Fuse .................................................................. 4-12
Circuit Breakers................................................. 4-12
Squeegee Actuator ........................................... 4-13
Scrub Deck Actuator ......................................... 4-14
Transporting Machine ....................................... 4-15
Jacking Machine ............................................... 4-16
Service Schedule. ............................................. 4-17
Machine Troubleshooting.................................. 4-18
GROUP PARTS LIST
Brake- From SN. ..................................................5-1
Brake- To SN........................................................5-3
Circuit Breaker......................................................5-5
Control Panel........................................................5-7
Decal. ...................................................................5-9
Front Bumper & Floor........................................ 5-11
Fwd/Rev Pedal .................................................. 5-13
Scrub Brush/Driver ............................................ 5-15
Scrub Deck-28 in Disk....................................... 5-17
Scrub Deck Side Squeegee-28 in Disk............. 5-19
Scrub Deck Lift-28 & 32 in................................. 5-21
Scrub Deck-32 in............................................... 5-23
Scrub Deck Side Squeegee-32 in ..................... 5-25
Scrub Deck-36 in Main ...................................... 5-27
Scrub Deck-36 in Retractable ........................... 5-29
Scrub Deck Side Squeegee-36 in ..................... 5-31
Scrub Deck Lift-36 in ......................................... 5-33
Seat & Side Cover............................................. 5-35
Solution Delivery ............................................... 5-37
Squeegee-28 in & 36 in..................................... 5-39
Squeegee –32 in ............................................... 5-41
Squeegee Lift .................................................... 5-43
Steering-Upper .................................................. 5-45
Steering-Lower .................................................. 5-47
Tank .................................................................. 5-49
Tank Cover........................................................ 5-51
Vacuum ............................................................. 5-53
Wheel & Frame ................................................. 5-55
Wheel Motor ...................................................... 5-57
Wiring-Battery.................................................... 5-59
Wiring-Main Harness......................................... 5-61
Wiring-Main Harness Connection ..................... 5-63
Wiring-Control Panel Group .............................. 5-65
Wiring-Drive Motor ............................................ 5-67
Wiring Diagram.................................................. 5-69
Suggested Spare Parts ..................................... 5-70
Accessory Pump-Option.................................... 5-71
Back-Up Alarm-Option ...................................... 5-73
Dual Vacuum Motor-Option............................... 5-75
Warning Light-Option ........................................ 5-77
EC Declaration of Conformity............................ 5-79
Serial Numbers.................................................. 5-82
Warranty

HOW TO USE THIS MANUAL
GLIDE 86037550 11/05/08
1-1
This manual contains the following sections:
- HOW TO USE THIS MANUAL
- SAFETY
- OPERATIONS
- MAINTENANCE
- PARTS LIST
The HOW TO USE THIS MANUAL section will tell
you how to find important information for ordering
correct repair parts.
Parts may be ordered from authorized Windsor
dealers. When placing an order for parts, the
machine model and machine serial number are
important. Refer to the MACHINE DATA box which
is filled out during the installation of your machine.
The MACHINE DATA box is located on the inside of
the front cover of this manual.
The model and serial number of your machine are
located to the front of the battery compartment for
the machine.
The SAFETY section contains important information
regarding hazard or unsafe practices of the
machine. Levels of hazards are identified that could
result in product or personal injury, or severe injury
resulting in death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains preventive
maintenance to keep the machine and its
components in good working condition. They are
listed in this general order:
- Batteries
- Scrub Brushes
- Adjusting Squeegee
- Service Schedule
- Machine Troubleshooting
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts
lists include a number of columns of information:
- REF – column refers to the reference
number on the parts illustration.
- PART NO. – column lists the part
number for the part.
- PRV NO. – reference number
- QTY – column lists the quantity of the
part used in that area of the machine.
- DESCRIPTION – column is a brief
description of the part.
- SERIAL NO. FROM – If this column has
an (*) and a Reference number, see the
SERIAL NUMBERS page in the back of
your manual. If column has two asterisk
(**), call manufacturer for serial number.
The serial number indicates the first
machine the part number is applicable
to. The main illustration shows the most
current design of the machine. When a
boxed illustration is shown, it displays
the older design.
-NOTES – column for information not
noted by the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement
parts numbers needed for ordering future parts.
NOTE: The number on the lower left corner of the
front cover is the part number for this manual.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
DEALER NAME ______________________________
OPERATIONS GUIDE NUMBER __________________
PUBLISHED ________________________________
Copyright 2002 Windsor Industries, Printed in USA

GLIDE 86037550 01/09/07 2-1
IMPORTANT SAFETY INSTRUCTIONS
When using an battery powered appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer’s recommended components and
attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is not suitable for picking up hazardous dust.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
Disconnect battery before cleaning or servicing.
Before the machine is discarded, the batteries must be removed and properly disposed of.
Make sure all warning and caution labels are legible and properly attached to the machine.
During operation, attention shall be paid to other persons, especially children.
Before use all covers and doors shall be put in the positions specified in the instructions.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
Only chemicals recommended by the manufacturer shall be used.
This appliance has been designed for use with the brushes specified by the manufacturer. The fitting
of other brushes may affect its safety.
SAVE THESE INSTRUCTIONS
!
WARNING:

HAZARD INTENSITY LEVEL
GLIDE 86037550 01/09/07
2-2
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR
SAFETY. The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property
damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate
all safety devices on the machine. Please take the necessary steps to train the machine operating
personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use Windsor approved replacement parts.
Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep
solution tank in raised position when charging. Keep sparks and flames away from the batteries.
Do not smoke around batteries.
Disconnect batteries before working on machine. Only qualified personnel should work inside
machine. Always wear eye protection and protective clothing when working on or near batteries.
Avoid skin contact with the acid contained in the batteries.
Never allow metal to lie across battery tops.
!WARNING
!WARNING
!WARNING
!WARNING
!CAUTION

SAFETY LABEL LOCATION
GLIDE 86037550 01/09/07 2-3
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become
illegible, promptly replace them.
SAFETY DECAL
86252530
PRV NO. 81494
BATTERY CAUTION
86252520
PRV NO. 80885
HORN DECAL
86248210
PRV NO. 81349
PINCH POINT WARNING
86243830
PRV NO. 500663
CIRCUIT BREAKER
86244130
PRV. NO 500859 - 28 IN & 32 IN
86244140
PRV NO. 500861 – 36 IN
PINCH POINT WARNING
86243830
PRV NO. 500663 (2)
* 36 IN MODEL ONLY

TECHNICAL SPECIFICATIONS
GLIDE 86037550 06/26/12
3-1
ITEM DIMENSION/CAPACITY
Nominal power 2.9 kW
Rated Voltage 36 Volts DC
Rated Amperage 80 amps (28in & 32in)
95 amps (36in)
Batteries 6 x 6 Volt 250-335 AH @20 hr. rate
Scrub Brush Motors 2 x 1.0 HP (746 W) 28in & 32in
3 x 1.0 HP (746 W) 36in
Vacuum Motor(s) 1 x .75 HP (560 W) Standard, second motor
optional
Propelling Motor 1.3 HP (1000 W)
Mass (GVW) 1810 lbs (820 kg) 28in & 32in
1840 lbs (835kg) 36in
Weight empty without batteries 790 lbs (360 kg) 28in & 32in
825 lbs (375 kg) 36in
Solution Control Gravity feed, fully variable with automatic
shut off in neutral
Solution tank capacity 30 gal (115 L)
Recovery tank capacity 30 gal (115 L)
Scrub brush diameter for 28 in. (71 cm) disk scrub head 14 inch (35.5 cm)
Scrub brush diameter for 32 in. (81 cm) disk scrub head 16 inch (40.6 cm)
Scrub brush diameter for 36 in. (91 cm) disk scrub head 12 inch (30.5 cm)
Scrub brush pressure 0-225 lbs (0-1000N) 28in & 32in
0-150 lbs (0-667N) 36in
Scrub brush speed 300 rpm
Tires – Front
– Rear
11.8 in. (30.0cm) Solid Polyurethane
12 in. (30.5 cm) Solid Scrubber Compound
Foundation Pressure 108 lbs./in²(745 kPa)
Maximum Speed 4.1 miles/hour (6.5 Km/hour)
Frame Construction Powder coated steel
Brakes Mechanical band with hand lock parking
brake
Minimum aisle u-turn width with 28 in. (71 cm), 32 in. (81
cm) or 36 in. (91 cm) disk scrub head
66 inches (168 cm)
Maximum rated climb and descent angle 7.5 degrees

TECHNICAL SPECIFICATIONS
GLIDE 86037550 01/09/07 3-2
ITEM MEASURE
Height 1 51 inches (130 cm)
Height 2 56.6 inches (144 cm)
Length 63.5 inches (161 cm)
Width without squeegee and scrub head 31 inches (79 cm)
Width of squeegee 33 inches (84 cm)
Width of scrub path for 28 in. (71 cm) 28 inches (71 cm)
Width of scrub path for 32 in. (81 cm) 32 inches (81 cm)
Width of scrub path for 36 in. (91 cm) 28-36 inches (71-91 cm)
The weighted root mean square acceleration at the
operator’s arms was measured to be below 2.5m/s2 .
This was a tri-axial, third-octave-band measurement
made during normal operation on a composite tile
floor. The measurement and related calculations were
made in accordance with ANSI S3.34-1986.
SPECIAL NOTES:
The sound pressure level at the operator’s ear was
measured to be 72.3 dBA. This was a nearfield, broad-
band measurement taken in a typical industrial
environment on a tile floor. This appliance contains no
possible source of impact noise. The instantaneous
sound pressure level is below 63 Pa.
WIDTH LENGTH
HEIGHT 2
HEIGHT 1

HOW THE MACHINE WORKS
GLIDE 86037550 01/09/07
3-3
The Saber Glide is a battery powered, self-
propelled, hard floor scrubber intended for
commercial use. The appliance applies a
cleaning solution onto a hard floor, scrubs the
floor with brushes, and then vacuums the soiled
water back into the recovery tank.
The machine's primary systems are the solution
system, scrub system, recovery system, and
operator control system.
The function of the solution system is to store
cleaning solution and deliver it to the scrub
system. The solution system consists of the
solution tank, strainer, valve and controls. The
solution tank stores cleaning solution (water and
detergent) until it is delivered to the scrub system.
The strainer protects the valve from debris. The
valve is a solenoid type valve, which controls the
delivery of cleaning solution to the scrub system.
The valve automatically prevents solution flow
unless the scrub brushes are turned on and the
machine is being propelled. The solution control
switch controls the amount of cleaning solution
delivered to the scrub system by controlling the
amount of time the valve is open.
The function of the scrub system is to scrub the
floor.
The 28 in. and 32 in. disk scrub systems consists
of two rotary type disk scrub brushes, motors,
scrub deck skirt, lift actuator and controls. The
brushes scrub the floor as the motors drive the
brushes. The brush drive hubs allow the scrub
brushes to follow irregularities and changes in the
floor without loosing contact with the floor. The
scrub deck skirts and side squeegees control the
cleaning solution on the floor so that the
squeegee can pick it up. The one touch switch
controls the motors and lift actuator to turn the
motors on and lower the deck, or turn the motors
off and raise the deck. The brush pressure switch
controls the down pressure on the scrub deck.
The 36 in. disk scrub system consists of three
rotary type disk scrub brushes, motors, scrub
deck skirts, lift actuator, shift actuator and
controls. The brushes scrub the floor as the
motors drive the brushes. The brush drive hubs
allow the scrub brushes to follow irregularities and
changes in the floor without loosing contact with
the floor. The scrub deck skirts and side
squeegees control the cleaning solution on the
floor so that the squeegee can pick it up. The one
touch switch controls the motors and lift actuator
to turn the motors on and lower the deck, or turn
the motors off and raise the deck. The brush
pressure switch controls the down pressure on
the scrub deck. The scrub deck shift switch
controls the position of the retractable scrub deck.
The function of the recovery system is to vacuum
the soiled water back into the recovery tank. The
recovery system consists of the squeegee,
vacuum motor, filter, recovery tank and controls.
The squeegee wipes the dirty solution off the floor
as the machine moves forward. The vacuum
motor provides suction to draw the dirty solution
off the floor and into the recovery tank. The filter
protects the vacuum fan from debris and foam.
The recovery tank stores the dirty solution.
The float switch in the tank activates the recovery
tank full indicator, shuts off the scrub motors and
solution flow, raises the scrub deck then
squeegee, and shuts off vacuum motor.
The function of the operator control system is to
control the direction and speed of the machine.
The directional control system consists of the
direction/speed control pedal, steering wheel,
brake pedal, propel controller, and drive wheel.
The direction/speed pedal signals forward or
reverse direction and speed. The controller
interprets signals from the direction/speed pedal
to command the drive wheel to propel or slow the
machine. The steering wheel points the drive
wheel in the direction desired by the operator. The
brake can be used to hold the machine on slopes.

COMPONENTS
GLIDE 86037550 01/09/07 3-4
1. Control panel
2. Front cover
3. Side cover
4. Tank
5. Recovery tank cover
6. Recovery tank dome
7. Recovery tank drain hose
1
2
4
3
11
5
6
8
9
10
12 13
7
8. Scrub head
9. Scrub head side squeegee
10. Solution tank drain hose
11. Solution tank cover
12. Squeegee
13. Vacuum motor

CONTROLS
GLIDE 86037550 01/09/07
3-5
1 2
3
4
5
6
7
11
14
15
12
21
17
13
20
18
20
19
16
21
10
9
8

CONTROLS
GLIDE 86037550 01/09/07 3-6
1. Key switch
2. Emergency stop button
3. One touch switch
4. Brush pressure switch
5. Solution control switch
6. Vacuum/squeegee switch
7. Display toggle switch
• Information Screen 1
• Information Screen 2
• Hour meter
• Fault codes and special icons
• Battery meter
8. Scrub Deck Shift Switch (36in only)
9. Recycle switch (optional)
10.Recycle indicator light (optional)
11.Headlight switch (optional)
12.Brake pedal
13.Parking brake lever
14.Directional control pedal and speed
reduction feature.
15.Steering wheel
16.Steering tilt lever
17.Horn button
18.Seat adjustment grab bar
19.Squeegee camber adjustment knob
20.Squeegee deflection adjustment knob
21.Side squeegee deflection adjustment knob
1. KEY SWITCH
Controls the power for the machine functions. To turn the machine power on, rotate key clockwise. When the
key is turned on the battery symbol will flash for 12 seconds while the system runs self-diagnostics and
returns scrub deck and squeegee to raised position, if necessary. The controller will not respond to other
commands until this routine is complete. To turn the machine power off, rotate key counterclockwise.
2. EMERGENCY STOP BUTTON
This safety feature is designed to cut all power to the machine at any time. To shut the machine power off,
push the Emergency Stop switch. To reset the machine, rotate the switch clockwise.
INFORMATION DISPLAY
INFORMATION DISPLAY

CONTROLS
GLIDE 86037550 01/09/07
3-7
3. ONE TOUCH SWITCH
This switch controls the scrub brushes and vacuum all in one touch.
To start scrubbing, press the one touch switch. The brush drive motors will turn on, the scrub deck will lower
to the "light scrub" position, the solution will flow at “two bars” rate, the squeegee will lower and the vacuum
will turn on. The information display window will show which functions are operating. If the direction control
pedal is in the neutral position for more than two seconds the brushes and solution flow will stop. If the one
touch switch is activated without brushes installed, the brush motors will stop, the scrub deck will rise, and the
brush pressure indicator will display error code 9000. To stop scrubbing, press the one touch switch. The
brush drive motors will turn off, the scrub deck will raise the solution flow will stop, the squeegee will raise
after a 15 second delay, and the vacuum motor will turn off. This delay is to clear the vacuum hose of
recovered solution.
4. BRUSH PRESSURE SWITCH
This switch controls the amount of brush pressure to the floor. There are 5 different pressure settings. To
decrease the amount of down pressure, press the top of the brush pressure switch (-). To increase the
amount of down pressure, press the bottom of the brush pressure switch (+). The information display screen
will show the amount of pressure.
NOTE: Press switch and hold momentarily each time to change brush pressure.
INFORMATION DISPLAY
INFORMATION DISPLAY
LESS PRESSURE MORE PRESSURE

CONTROLS
GLIDE 86037550 01/09/07 3-8
Indicates vac motor is running
5. SOLUTION CONTROL SWITCH
This switch controls the amount of solution flow to the scrub deck. There are 7 different flow settings. To
increase the solution flow, press the solution control switch (+). To decrease solution flow, press the top of
the switch (-). If the brush motors are turned off or the direction control pedal is in neutral, the flow is
automatically interrupted until the motors are turned on again, or the drive pedal is moved forward or reverse.
This feature prevents unintentional draining of the solution tank and allows the operator to adjust the solution
flow to the scrub deck without resetting each time the scrubbing operation is interrupted. If recycling option is
installed, this switch controls the amount of solution flow to the scrub deck by controlling the speed of the
pump.
NOTE:Press switch and hold momentarily each time to change solution flow.
6. VACUUM/SQUEEGEE SWITCH
This switch independently controls the vacuum motor and squeegee position. To start the vacuum motor and
lower the squeegee to the floor, press the bottom of the switch. To raise the squeegee and turn off the
vacuum motor, press the top of the switch. The squeegee will raise after a 15 second delay, and the vacuum
motor will turn off 15 seconds later, in order to clear vacuum hose of recovered solution.
INFORMATION DISPLAY
LESS SOLUTION MORE SOLUTION
INFORMATION DISPLAY

CONTROLS
GLIDE 86037550 01/09/07
3-9
Records the entire time that the key is on.
Records the time spent with the brushes running and
gives true brush motor time.
Brush Run Time:
Key ON Hours:
Traction Motor Time:
7. DISPLAY TOGGLE SWITCH
The display toggle switch allows you to change the information display screen. Two screens are
available.
• INFORMATION DISPLAY –SCREEN 1
• The hour meter is viewed on screen 2 of the information display. Hours are displayed for key ON
time, brush run time, and traction motor time.
• INFORMATION DISPLAY –SCREEN 2
Records the time spent propelling the machine and gives
true traction motor time.
• Fault codes/icon will appear on either display screen when the controller detects a problem within the electrical
system. The codes/icons are used to assist users as well as service technicians in identifying and correcting
problems. See troubleshooting section for more information on fault codes. The machine must be keyed off, then
on again, to clear fault code after repair.
• Icon appears if throttle is depressed when the key is turned on. To correct, lift foot off of throttle. If this does
not clear the icon, the throttle may be damaged and should be checked by a qualified service technician.

CONTROLS
GLIDE 86037550 01/09/07 3-10
• The float switch is located inside the recovery tank. The purpose of the float switch is to notify the user that
the recovery tank is full. When the float switch is activated, the scrub brush motors and solution flow will stop,
the scrub deck will raise, the squeegee will rise after 60 seconds, and the vacuum motor will turn off 10
seconds later.
• The battery meter can be viewed at the left side of either information screen 1 or information screen 2. The
level of battery charge is indicated by the horizontal bars in the battery meter box. When the batteries require
charging, the icon will flash and a battery inhibit icon will appear on the right side of either information screen.
Scrub and solution functions that are running when the battery inhibit icon appears will be automatically shut
off. It is not possible to restart scrub functions while the battery inhibit is displayed. The controller reserves
enough battery charge to allow pick-up of residual water and transport back to a charging station.
8. SCRUB DECK SHIFT SWITCH (36 IN ONLY)
• This switch controls the position of the retractable scrub deck. To extend the scrub deck, press and hold the
top of the switch. To retract the scrub deck, press and hold the bottom of the switch.

CONTROLS
GLIDE 86037550 01/09/07
3-11
9. RECYCLE SWITCH (OPTIONAL)
This switch controls the solution recycle pump. To start recycle pump, press the switch. A green light
above the circuit breakers will indicate that pump is on. The solution control switch will control the
speed of the pump and therefore the amount of solution flow to the scrub deck. Make sure there is an
adequate amount of water in recovery tank before starting recycle pump, and turn off recycle pump
when water level reaches filter. To stop the solution recycle pump, press the switch. The pump will
stop and the green indicator light will turn off, and the solenoid valve will resume control of solution
flow to the scrub deck.
10. RECYCLE INDICATOR LIGHT (OPTIONAL)
This light will turn on when the recycle pump is on, and turn off when the recycle pump is off.
11. HEADLIGHT SWITCH (OPTIONAL)
Turns on optional headlight for improved visibility in low light areas.

CONTROLS
GLIDE 86037550 01/09/07 3-12
12. BRAKE PEDAL
The brake pedal is located on the floor to the right side of the steering column pedestal. The pedal operates
the disc brake on the drive wheel. To slow or stop the vehicle, apply pressure to the brake pedal.
13. PARKING BRAKE LEVER
The black knob located on the right side of the steering column pedestal is used to set the parking brake. To
set the parking brake, fully depress the brake pedal and push the parking brake knob. To release the parking
brake, fully depress the brake pedal. Then release pressure on the brake pedal. The parking brake knob will
return it to its’ released position.
FOR SAFETY: Before leaving or servicing machine; stop on level surface, set parking brake, turn off
machine and remove key.
14. DIRECTIONAL CONTROL PEDAL AND SPEED REDUCTION FEATURE
This pedal controls the direction of travel and the speed of the vehicle. Slowly pressing the front of the pedal
causes the machine to travel forward. Pressing the rear of the pedal causes the vehicle to travel in reverse.
The vehicle speed can be controlled by varying the pressure on the front or rear of the pedal.
FOR SAFETY: The vehicle can coast for a short distance after releasing the directional pedal.
Remove the foot from pedal and use brakes to slow or stop the machine.
SPEED REDUCTION FEATURE
Maximum speed of machine can be decreased to 80% of maximum by disconnecting wire 3 white from wire 16
white, located between controller and LCD display. Machine is set at 100% speed setting at factory.
FORWARD
REVERSE

CONTROLS
GLIDE 86037550 01/09/07
3-13
15. STEERING WHEEL
The steering wheel turns the front wheel causing the machine to change direction.
16. STEERING TILT LEVER
The steering tilt lever is located on the right side of the steering wheel. To engage the tilt adjustment,
pull on the lever and adjust the steering column to desired position. Release lever and allow it to lock
into desired position.
17. HORN BUTTON
The horn button is located on left side of the steering column. The horn is activated by pressing the
horn button.
18. SEAT ADJUSTMENT GRAB BAR
The seat adjustment grab bar is located in front of seat at the bottom. While in a standing position,
grasp the back of the seat and the seat adjustment grab bar and lift seat into the adjustment slot and
lower into one of the locking positions. Adjust the seat to the desired position.
19. SQUEEGEE CAMBER ADJUSTMENT KNOB
The squeegee camber adjustment knob is located at the center of the squeegee at the rear of the
machine. (See maintenance section for adjustment).
20. SQUEEGEE DEFECTION ADJUSTMENT KNOB
The squeegee deflection knobs are located at the rear of the machine, one on either side of the
squeegee assembly. (See maintenance section for adjustment).
21. SIDE SQUEEGEE DEFECTION ADJUSTMENT KNOB
Side squeegee adjustment knobs are located above the scrub deck. (See maintenance section for
adjustment).
Locking position
Adjustment slot
