Windsor Saber Compact SC20 User manual

Read these instructions before using the machine
Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen
MODELS: SC20 SCC20
10052190 10052230
SC20T SCC20T
10052200 10052240
SCX20T SCXC20T
10052370 10052420
Operating Instructions
Bedienungsanleitung
86038350 01/29/07
PRV NO. 98712
BA
WALK BEHIND SCRUBBER
IPX4

MACHINE DATA LOG/OVERVIEW
SABER (SC) 86038350 01/29/07
2
For the name and address of your dealer contact: Windsor Industries
YOUR DEALER
Name: __________________________________________________________________________________________________
Address: _______________________________________________________________________________________________
Phone Number: _________________________________________________________________________________________
OVERVIEW
The Saber Compact is a battery powered, hard floor scrubber intended for commercial use.
The appliance applies a cleaning solution onto a hard floor, scrubs the floor with a brush or
pad, and then vacuums the soiled water back into the recovery tank.
MODEL _______________________________________
DATE OF PURCHASE __________________________
SERIAL NUMBER ______________________________
SALES REPRESENTATIVE # _____________________
DEALER NAME ________________________________
OPERATIONS GUIDE NUMBER ___________________
PUBLISHED __________________________________________
Copyright 1995 Windsor Industries, Printed in USA

TABLE OF CONTENTS
SABER (SC) 86038350 01/29/07
3
Machine Data Log/Overview.........................2
Table of Contents..........................................3
HOW TO USE THIS MANUAL
How to use this Manual.................................1-1
SAFETY
Important Safety Instructions........................2-1
Hazard Intensity Level. .................................2-2
Safety Label Location. ..................................2-3
OPERATIONS
Technical Specifications. ..............................3-1
How the Machine Works...............................3-3
Components..................................................3-4
Controls.........................................................3-5
Machine Operation......................................3-10
Pre-Run Machine Inspection....................3-10
Starting Machine......................................3-10
Emergency Stop Procedures...................3-10
Filling the Solution Tank...........................3-10
Scrubbing.................................................3-10
Emptying & Cleaning Tanks.....................3-12
MAINTENANCE
Batteries........................................................4-1
Battery Maintenance..................................4-1
Checking Battery Specific Gravity..............4-2
Charging the Batteries. ..............................4-2
Changing Batteries. ...................................4-3
Battery Connections...................................4-3
Scrub Brushes. .............................................4-4
Types.........................................................4-4
Replacing or Installing Scrub Brushes.......4-4
Squeegee Blades..........................................4-6
Replace Squeegee Blade..........................4-6
Remove Squeegee Assembly....................4-6
Adjusting Deluxe Squeegee.......................4-6
Adjusting Squeegee Deflection..................4-7
Replacing Squeegee Blades......................4-7
Greasing Axles...........................................4-7
Service Schedule..........................................4-8
Machine Troubleshooting..............................4-9
GROUP PARTS LIST
Control Handle Group – Non-Traction..........5-1
Control Tower Group - Traction....................5-3
Decal Group..................................................5-5
Electrical Panel Group – Non-Traction.........5-7
Electrical Panel Group – Traction…………...5-9
Hour Meter……………………………………5-11
Recovery Tank Group................................. 5-13
Scrub Brush/Pad Driver Group .................. 5-15
Scrub Head Group – Non-Traction…………5-17
Scrub Head Group - Traction...................... 5-19
Scrub Head Lift Group – Non-Traction....... 5-21
Scrub Head Lift Group - Traction................ 5-23
Solution Tank Group – Non-Traction.......... 5-25
Solution Tank Group – Traction.................. 5-27
Squeegee Group ........................................ 5-29
Squeegee Lift Group................................... 5-31
Deluxe Squeegee Group............................ 5-33
Deluxe Squeegee Lift Group. ..................... 5-37
Vacuum Group............................................ 5-39
Wheels and Frame Group – Non-Traction.. 5-41
Wheels and Frame Group - Traction.......... 5-43
Onboard Charger........................................ 5-45
Wiring Group – Battery Cables................... 5-47
Wiring Group–Control Panel-Non-Traction 5-49
Wiring Group-Control Panel-Non-Traction
With Battery Charger.......................... 5-51
Wiring Group – Schematic – Non-Traction. 5-53
Wiring Group – Schematic – Non-Traction
Onboard Charging.............................. 5-55
Wiring Group – Schematic - Traction.......... 5-57
Wiring Group –Schematic – Traction and
Onboard Charging.............................. 5-59
Wiring Group – Control Panel - Traction..... 5-61
Wiring Group – Main Harness - Traction.... 5-63
Emergency Stop Option.............................. 5-65
Accessory Pump Option............................. 5-67
Suggested Spare Parts............................... 5-69
EC Declaration of Conformity..................... 5-70
Warranty..................................................... 5-71

HOW TO USE THIS MANUAL
SABER (SC) 86038350 01/29/07
1-1
This manual contains the following sections:
- HOW TO USE THIS MANUAL
- SAFETY
- OPERATIONS
- MAINTENANCE
- PARTS LIST
The HOW TO USE THIS MANUAL section will tell
you how to find important information for ordering
correct repair parts.
Parts may be ordered from authorized Windsor
dealers. When placing an order for parts, the
machine model and machine serial number are
important. Refer to the MACHINE DATA box which
is filled out during the installation of your machine.
The MACHINE DATA box is located on the inside of
the front cover of this manual.
The model and serial number of your machine is on
the front of the control tower.
The SAFETY section contains important information
regarding hazard or unsafe practices of the
machine. Levels of hazards are identified that could
result in product or personal injury, or severe injury
resulting in death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains preventive
maintenance to keep the machine and its
components in good working condition. They are
listed in this general order:
- Batteries
- Scrub Brushes
- Squeegee
- Service Schedule
- Machine Troubleshooting
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts
lists include a number of columns of information:
- REF – column refers to the reference
number on the parts illustration.
- PART NO. – column lists the part
number for the part.
- PRV NO. – reference number
- QTY – column lists the quantity of the
part used in that area of the machine.
- DESCRIPTION – column is a brief
description of the part.
- SERIAL NO. FROM – column indicates
the first machine the part number is
applicable to. When the machine design
has changed, this column will indicate
serial number of applicable machine.
The main illustration shows the most
current design of the machine. The
boxed illustrations show older designs.
-NOTES – column for information not
noted by the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement
parts numbers needed for ordering future parts.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
DEALER NAME ______________________________
OPERATIONS GUIDE NUMBER __________________
PUBLISHED ________________________________
Copyright 1995 Windsor Industries, Printed in USA

SABER (SC) 86038350 01/29/07 2-1
IMPORTANT SAFETY INSTRUCTIONS
When using an battery powered appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer’s recommended components and
attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is not suitable for picking up hazardous dust.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
Disconnect battery before cleaning or servicing.
Before the machine is discarded, the batteries must be removed and properly disposed of.
Make sure all warning and caution labels are legible and properly attached to the machine.
During operation, attention shall be paid to other persons, especially children.
Before use all covers and doors shall be put in the positions specified in the instructions.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
Only chemicals recommended by the manufacturer shall be used.
This appliance has been designed for use with the brushes specified by the manufacturer. The fitting
of other brushes may affect its safety.
Do not use on surfaces having a gradient exceeding 2%.
SAVE THESE INSTRUCTIONS
!
WARNING:

HAZARD INTENSITY LEVEL
SABER (SC) 86038350 01/29/07
2-2
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR
SAFETY . The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property
damage.
FOR SAFETY: To identify actions which must be followed for safe operation or equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate
all safety devices on the machine. Please take the necessary steps to train the machine operating
personnel.
FOR SAFETY
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use Windsor approved replacement parts.
Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep
solution tank in raised position when charging. Keep sparks and flames away from the batteries.
Do not smoke around batteries.
Disconnect batteries before working on machine. Only qualified personnel should work inside
machine. Always wear eye protection and protective clothing when working on or near batteries.
Avoid skin contact with the acid contained in the batteries.
Never allow metal to lie across battery tops.
!WARNING
!WARNING
!WARNING
!WARNING
!CAUTION

SAFETY LABEL LOCATION
SABER (SC) 86038350 01/29/07 2-3
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become
illegible, promptly replace them.
SAFETY DECAL
86252530
PRV NO. 81494
BATTERY CAUTION
86252520
PRV NO. 80885
CAUTION
Explosive Gas is Given Off
By Batteries During Charge.
Cover Open.
1. Keep Battery Compartment
Sparks In Area.
2. No Smoking, Flame Or
Ventilated Area.
3. Charge Only In Well

TECHNICAL SPECIFICATIONS
SABER (SC) 86038350 01/29/07
3-1
ITEM DIMENSION/CAPACITY
Nominal power – non-traction model 1100 W
Nominal power – traction model 1200 W
Rated Voltage 24VDC
Rated Amperage – non-traction model 45 Amps
Rated Amperage – traction model 50 Amps
Batteries 2 x 12 Volt 105-130-195 AH @
20hr rate
Scrub Brush Motor .75 hp (0.56 kW)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor – traction model .38 hp (0.28 Kw)
Mass (GVW) – non-traction model 543 lbs. (246.5 kg)
Mass (GVW) – traction model 556 lbs. (252.4 kg)
Weight empty without batteries – non-traction model 213 lbs. (96.1 kg)
Weight empty without batteries – traction model 232 lbs. (105.3 kg)
Solution Control – non-traction model Gravity feed, fully variable
Solution Control – traction model Gravity feed, fully variable with
automatic shut-off in neutral
Solution tank capacity 13 gal. (50 l)
Recovery tank capacity 16 gal. (60 l)
Scrub brush diameter 20 in (51 cm)
Scrub brush pressure – non-traction model 50 lbs. (23 kg)
Scrub brush pressure – traction model 100 lbs. (45 kg)
Scrub brush speed 200 rpm
Tires – non-traction model 2 x 8 in (20 cm) thermoplastic
elastomer non-marking
Tires – traction model 2 x 8 in (20 cm) foam filled non-
marking
Casters 3.5 x 1.25 in (9 cm) polyurethane
solid non-marking
Foundation Pressure – non-traction model 105 lbs./in 2( 725 kPa)
Foundation Pressure – traction model 46 lbs./in 2( 315 kPa)
Maximum Speed – traction model 2.75 miles/hour (4.5 km/hour)
Coverage 9500 ft2/hour at 2 mph with
2 in. overlap
Frame Construction Steel with epoxy powdercoat
finish.
Minimum aisle u-turn width 45 in. ( 114.3 cm)
Maximum rated climb and descent angle with empty tanks 2%
Maximum rated climb and descent angle with full tanks 2%

TECHNICAL SPECIFICATIONS
SABER (SC) 86038350 01/29/07 3-2
ITEM MEASURE
Height 43 in. ( 109.2 cm)
Length 54 in. (137.1 cm)
Width without squeegee 22 in. (55.9 cm)
Width of squeegee 31 in. ( 78.7 cm)
Width of scrub path 20 in. (51 cm)
SPECIAL NOTES:
The A-weighted sound pressure level emitted
by the appliance was measured to be 72.5 dBA.
This is a space-averaged, broad-band
measurement determined according to IEC
704-I. This appliance contains no possible
source of impact noise.
The overall root-mean-square acceleration at
the operator’s arms was measured to be less
than 1.0m/s2. This is a tri-axial, broad-band
measurement made during normal operation on
a composite tile floor.
Length
Height
Width

HOW THE MACHINE WORKS
SABER (SC) 86038350 01/29/07
3-3
The Saber Compact is a battery powered, hard
floor scrubber intended for commercial use. The
appliance applies a cleaning solution onto a hard
floor, scrubs the floor with a brush, and then
vacuums the soiled water back into the recovery
tank.
The machine's primary systems are the solution
system, scrub system, recovery system. The
traction model has a directional control system as
well.
The function of the solution system is to store
cleaning solution and deliver it to the scrub
system. The solution system consists of the
solution tank, strainer, valve and controls. The
solution tank stores cleaning solution (water and
detergent) until it is delivered to the scrub system.
The strainer protects the valve from debris. The
non-traction model has a ball-type valve which
controls the delivery of cleaning solution to the
scrub system. The traction model has a solenoid
type valve, which controls the delivery of cleaning
solution to the scrub system. The valve
automatically prevents solution flow unless the
scrub brushes are turned on and the machine is
being propelled. The solution control knob
controls the amount of cleaning solution delivered
to the scrub system.
The function of the scrub system is to scrub the
floor. The scrub system consists of a rotary type
disk scrub brush, motor, self-adjusting scrub deck
skirt, lift linkage and controls. The brush scrubs
the floor and the motor drives the brush. The
brush drive hub allows the scrub brush to follow
irregularities and changes in the floor without
loosing contact with floor. The self-adjusting
scrub deck skirt controls the cleaning solution on
the floor so that the squeegee can pick it up. The
brush lift lever raises and lowers the scrub deck.
On the traction model the brush lift lever can be
locked into an increased brush pressured
position.
The function of the recovery system is to vacuum
the soiled water back into the recovery tank. The
recovery system consists of the squeegee,
vacuum motor, screen, recovery tank and
controls. The squeegee wipes the dirty solution
off the floor as the machine moves forward. The
vacuum motor provides suction to draw the dirty
solution off the floor and into the recovery tank.
The screen protects the vacuum fan from debris.
The recovery tank stores the dirty solution. The
float ball in the tank activates when the recovery
tank is full.
On the traction model, the function of the
directional control system is to control the
direction and speed of the machine. The
directional control system consists of buttons,
speed control knob/potentiometer, controller and
transaxle. The speed control knob actuates a
potentiometer, which signals speed. The
controller interprets the forward/reverse signals
from the buttons and the speed signal from the
potentiometer to command the transaxle to propel
the machine in the direction, and at the speed,
desired.
The buttons on the control handles signal forward.
When the reverse button on the control panel is
pushed, in addition to either button on the control
handles, reverse is signaled.
