Winegard ConnecT WF1 User manual

Secure personal
connection
Simple to scan
and find network
Connect to WiFi
where others can’t
+Increased
WiFi range
Introducing the Winegard ConnecT WF1, a fully
integrated system that works together for faster
speeds and increased range from any WiFi source.
The Winegard ConnecT helps you keep mobile
devices, media players and computers connected
to WiFi. Get ready for a consistent, reliable
connection and expanded coverage wherever the
road may take you.
Key Benefits for Your Customers
Connect - to WiFi where others can’t!
Simple - Step-by-step on screen instruction makes
setting up a breeze. Anyone can do it!
Secure - Always secure. Set-up your secure network
once and you are done.
Mobile - Increase the range for mobile devices inside
and around your RV.
Streaming - Maximizes signal for increased speeds
delivering access to multiple devices.
Features and Benefits
Simple Set-Up
nStep-by-step on screen instruction
nScan for and select WiFi network
nConnect your WiFi devices to your new extended
network instantly
nEasily connects your mobile devices, smart TVs and
gaming controls, one-time set-up takes just minutes
Secure Internet
nConnecT Advanced WiFi protected access
(WPA and WPA2 – PSK)
nGuest Network Access – separate and secure
nDouble Firewall protection (SPI and NAT)
nDenial-of-service (DoS) attack prevention
Integrated System
nEasily connects your mobile devices, smart TVs and
gaming controls
nMulti-user MIMO-ready for faster performance to
each device
nAdvanced WiFi connectivity with powerful amplifiers
and three high performance external antenna
Winegard®ConnecT™WF1 LONG RANGE, HIGH PERFORMANCE WIFI EXTENDER
Winegard®ConnecT WF1 pg 1 of 3 WC-1204
Black and white models available

3 lbs
10.3”
12.4”
Quality Design
nProven dome desing tested to meet the demands of the
mobile enviornment.
nDurable housing materials for maximum UV and
weather resistance for long lasting durability.
nDesigned and manufactured in the U.S.A.
nBacked by 2 years parts, 1 year labor limited warranty.
Specifications:
nWireless Standard
802.11a/b/g/n/ac
nFrequency Band
2.4GHz, 5GHz Simultaneous (5GHz indoor unit only)
nWireless Speed
2.4GHz: 450Mbps (Rx), 450Mbps (Tx)
5GHz: 1300Mbps (Rx), 1300Mbps (Tx)
nAmplifiers
Outdoor: (3) 2.4GHz amplifiers
Indoor: (3) 2.4GHz amplifiers,
(3) 5GHz amplifiers
nAntennas
Outdoor: (3) Detachable high gain 5dBi antennas
Indoor: (3) Internal 2.4GHz 4dBi antennas
(3) Internal 5GHz 6dBi antennas
nWireless Security
WEP, WPA, WPA2, WPA mixed
nPorts
(1) RJ45 10/100/1000m Lan Port (IDU only)
(1) RJ45 PoE (ODU & IDU)
(2) USB 2.0 Ports
nPower Rating
Switching, AC Input 100-240v, 1.5A
nSetup Requirements
Wireless 802.11a/b/g/n 2.4GHz network
Computer, tablet or smartphone with a web browser
WF-3000
Winegard ConnecT WF1
ODU (white) IDU (black)
WF-3035
Winegard ConnecT WF1
ODU (black) IDU (black)
Winegard®ConnecT WF1 pg 2 of 3 WC-1204
nDimensions: 10.3” dia x 12.4”h
nWeight: 3 lbs.
WiFi signal captured by
Winegard ConnecT™is
rebroadcasted through the RV
for a secure connection at the
fastest speed available.
WiFi signal from public/private
accessible WiFi hotspots
(RV parks, rest stops, retail stores, etc).
Winegard®ConnecT™WF1 LONG RANGE, HIGH PERFORMANCE WIFI EXTENDER
How it works

Winegard®ConnecT WF1 pg 3 of 3 WC-1204
FAQs
Q. Am I able to paint the Winegard ConnecT WF1?
A. Do not paint any portion of the WF1. Painting the system could damage the system and will void the warranty.
Q. Why doesn’t my system have a “Scan for WiFi” button?
A:One of two things is happening. Either you have logged into the system before the outdoor antenna has fully
powered up. Please wait four to five minutes for the system to fully boot before logging in. - OR - The Ethernet
cable for the outdoor antenna is plugged into the Ethernet port on the indoor unit. Plug it into the port labeled
“POE”.
Q. The system says that it is connected, why won’t web pages load?
A:Some WiFi sources do not require a password to connect but do require something before they will let you use
their network. In these cases, they will often have a “SPLASH” page that requires you to either agree to their
rules or enter a password before they will allow you to use their network.
These pages will not always load on the web browser that you select but instead open on your devices default
browser. Sometimes browsing to a webpage will also bring up this splash page.
Q. The system keeps making me log in everytime I try to change screens…?
A:Check to see if you have a second window open that is connected to your Winegard ConnecT settings screen.
Close this window and the problem should go away.
Q. What if I forget my password?
A:If you have not changed your default password, it will be listed on the back of the indoor unit. If you have
changed this password, you can reset the unit using the RESET button on the bottom of your indoor unit. Press
this button and your system will return to the factory settings. Once reset, the default password will unlock your
system.
Q. I changed my password and nothing happened.
A: The Winegard ConnecT will reject any password that is not long enough. Try entering a password of at least
eight characters. This will improve the security of your devices.
Q. What do I do if 10.11.12.1 does not bring up the login screen?
A:One of several things has happened. The first thing to check is the WiFi signal that your model is connected to. If
this is not the Winegard ConnecT SSID, this address isn’t valid. If you are indeed connected to the correct network,
the address may have been changed. To resolve this, press the reset button on the bottom of your indoor unit.
This will return the unit to its factory settings.
Q. My default SSID does not appear on my device when I search for it.
A:When the Winegard ConnecT first powers on or has reset for any reason, it stops broadcasting the SSID. It may
take between four and five minutes from the time it regained power to start broadcasting again.
Q. I changed my Winegard ConnecT’s SSID and was disconnected.
A:This is normal. The old SSID that you were connected to is no longer valid, simply open your device’s WiFi
screen and search for the name you chose for your network. Select this and enter the password.
Q. I am connected to a network but the speed isn’t very good.
A. The Winegard ConnecT can only only extend the signal range for what is available. Try moving closer to the
source of the signal and logging on with your device directly. If the speed is still slow, try searching for another
available network.
For more information, videos and promotional materials visit dealers.winegard.com
Winegard Company | 2736 Mt. Pleasant St. | Burlington, IA 52601 | 1-800-288-8094 www.winegard.com
