Winmate IF70 Mini-ITX SBC User manual

Please read these instructions carefully before using this product, and save this manual for future use.
IF70 Mini-ITX SBC
Mini-ITX SBC with Intel® 9th Gen. Core i3/i5/i7 processor, HDMI, Display Port, LVDS,
Dual Giga Ethernet, USB 3.0 and NGFF Interface
V100
User Manual
Document Version 1.0
Document Part No. 91711110110C

2 IF70 Mini-ITX SBC User Manual
Contents
PREFACE .............................................................................................................................................................................. 4
ABOUT THIS USER MANUAL ................................................................................................................................................ 7
CHAPTER 1: GENERAL INFORMATION .................................................................................................................................. 8
1.1 INTRODUCTION ......................................................................................................................................................................9
1.2 FEATURES..............................................................................................................................................................................9
1.3 MOTHERBOARD SPECIFICATIONS..............................................................................................................................................10
1.4 FUNCTIONAL DESCRIPTION .....................................................................................................................................................12
1.5 PHYSICAL DESCRIPTION..........................................................................................................................................................13
CHAPTER 2: HARDWARE INSTALLATION............................................................................................................................. 14
2.1 MOTHERBOARD COMPONENTS ...............................................................................................................................................15
2.1.1 Component Side.......................................................................................................................................................15
2.1.2 Solder Side ...............................................................................................................................................................16
2.2 MEMORY MODULE (SO-DIMM) INSTALLATION.........................................................................................................................17
2.3 I/O EQUIPMENT INSTALLATION ...............................................................................................................................................18
2.3.1 Power Input 12V DC in .............................................................................................................................................18
2.3.2 Serial COM Port .......................................................................................................................................................18
2.3.3 HDMI .......................................................................................................................................................................18
2.3.4 Display Port..............................................................................................................................................................18
2.3.5 Ethernet Interface....................................................................................................................................................18
2.3.6 USB Port...................................................................................................................................................................18
2.3.7 Audio .......................................................................................................................................................................18
2.4JUMPER SETTINGS ................................................................................................................................................................19
2.4.1 JP1: Panel Power Select ...........................................................................................................................................20
2.4.2 JP2: Backlight Power Select .....................................................................................................................................20
2.4.3 JP3: Backlight Dimming Select.................................................................................................................................20
2.4.4 JP4: Backlight Dimming Control Select ....................................................................................................................20
2.4.5 CLR_CMOS: Clear CMOS Jumper .............................................................................................................................20
2.5 MAINBOARD CONNECTORS ....................................................................................................................................................21
2.5.1 Connector List ..........................................................................................................................................................21
2.5.2 Connector Description .............................................................................................................................................23
CHAPTER 3: INSYDE H20 BIOS SETUP ................................................................................................................................. 35
3.1 HOW AND WHEN TO USE BIOS SETUP.....................................................................................................................................36
3.2 BIOS FUNCTIONS .................................................................................................................................................................37
3.2.1 Main Menu ..............................................................................................................................................................37
3.2.2 Advanced .................................................................................................................................................................38
3.2.3 Security ....................................................................................................................................................................65
3.2.4 Power.......................................................................................................................................................................66
3.2.5 Boot .........................................................................................................................................................................67

3
Preface
3.2.6 Exit ...........................................................................................................................................................................68
3.3 USING RECOVERY WIZARD TO RESTORE COMPUTER ....................................................................................................................69
3.4 HOW TO ENABLE WATCHDOG .................................................................................................................................................70
CHAPTER 4: DRIVER INSTALLATION.................................................................................................................................... 72
4.1 CHIPSET DRIVER...................................................................................................................................................................73
4.2 GRAPHIC DRIVER..................................................................................................................................................................76
4.3 MANAGEMENT ENGINE (ME).................................................................................................................................................81
4.4 AUDIO DRIVER .....................................................................................................................................................................83
4.5 ETHERNET DRIVER ................................................................................................................................................................84
4.6 WATCHDOG DRIVER INSTA LLATION ...........................................................................................................................................87
4.7 DIGITAL IO DRIVER INSTALLATION ............................................................................................................................................91
CHAPTER 5: TECHNICAL SUPPORT ..................................................................................................................................... 94
5.1 DRIVERS .............................................................................................................................................................................95
5.2 SOFTWARE DEVELOPMENT KIT (SDK).......................................................................................................................................95

4 IF70 Mini-ITX SBC User Manual
Preface
Copyright Notice
No part of this document may be reproduced, copied, translated, or transmitted in any form or
by any means, electronic or mechanical, for any purpose, without the prior written permission of
the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective owners.
Disclaimer
We reserve the right to make changes, without notice, to any product, including circuits and/or
software described or contained in this manual in order to improve design and/or performance.
We assume no responsibility or liability for the use of the described product(s), conveys no
license or title under any patent, copyright, or masks work rights to these products, and makes
no representations or warranties that these products are free from patent, copyright, or mask
work right infringement, unless otherwise specified. Applications that are described in this
manual are for illustration purposes only. We make no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Warranty
We warrant that each of its products will be free from material and workmanship defects for a
period of one year from the invoice date. (Standard is one year, extended warranty will need to
discuss with our sales representatives. If the customer discovers a defect, we will, at its option,
repair or replace the defective product at no charge to the customer, provided it is returned
during the warranty period of one year, with transportation charges prepaid. The returned
product must be properly packaged in its original packaging to obtain warranty service.
If the serial number and the product shipping data differ by over 30 days, the in-warranty
service will be made according to the shipping date. In the serial numbers the third and fourth
two digits give the year of manufacture, and the fifth digit means the month (e. g., with A for
October, B for November and C for December).
For example, the serial number 1W19Axxxxxxxx means October of year 2019.
Packing List
Before using this Motherboard, please make sure that all the items listed below are present in
your package:
•IF70 Mini-ITX SBC
•User Manual & Driver CD
If any of these items are missing or damaged, contact your distributor or sales representative
immediately.

5
Preface
Customer Service
We provide a service guide as below for any problem by the following steps: First, contact your
distributor, sales representative, or our customer service center for technical support if you need
additional assistance.
You need to prepare the following information before you call:
•Product serial number
•Peripheral attachments
•Software (OS, version, application software, etc.)
•Detailed problem description
•The exact wording of any error messages
In addition, free technical support is available from our engineers every business day. We are
always ready to give advice on application requirements or specific information on the installation
and operation of any of our products. Please do not hesitate to call or e-mail us.
Advisory Conventions
Four types of advisories are used throughout the user manual to provide helpful information or to
alert you to the potential for hardware damage or personal injury. These are Notes, Important,
Cautions, and Warnings. The following is an example of each type of advisory.
NOTE:
A note is used to emphasize helpful information
IMPORTANT:
An important note indicates information that is important for you to know.
CAUTION
A Caution alert indicates potential
damage to hardware and explains how to
avoid the potential problem.
WARNING!
An Electrical Shock Warning indicates the potential harm from electrical
hazards and how to avoid the potential problem.

6 IF70 Mini-ITX SBC User Manual
Safety Precautions
CAUTION
Always ground
yourself to remove any static charge before touching the CPU
card. Modern electronic devices are very sensitive to static electric charges. As
a safety precaution, use a grounding wrist strap at all times. Place all
electronic components in a static
-dissipative surface or static-
shielded bag
when they are not in the chassis.
Safety and Warranty
1. Please read these safety instructions carefully.
2. Please keep this user manual for later reference.
3. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or
spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
8. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient over-voltage.
11. If any of the following situations arises, get the equipment checked by service personnel:
A. The power cord or plug is damaged.
B. Liquid has penetrated into the equipment.
C. The equipment has been exposed to moisture.
D. The equipment does not work well, or you cannot get it to work according to the user’s
manual.
E. The equipment has been dropped and damaged.
F. The equipment has obvious signs of breakage.

7
About This User Manual
About This User Manual
This User Manual provides information about using the IF70 Mini-ITX SBC. The documentation
set for the IF70 Mini-ITX SBC provides information for specific user needs, and includes:
•IF70 Mini-ITX SBC User Manual – contains detailed description on how to use the
motherboard, its components and features.
NOTE:
Some pictures in this guide are samples and can differ from actual product.
Document Revision History
Version Date Note
1.0 10-May -2020 Initial document release

8 IF70 Mini-ITX SBC User Manual
Chapter 1: General Information
This chapter includes the IF70 Mini-ITX SBC background information.
1.1 Introduction
1.2 Features
1.3 Motherboard Specifications
1.4 Functional Description
1.5 Physical Description

9
0BChapter 1: General Information
1.1 Introduction
Thank you for choosing the IF70 Mini-ITX SBC. The IF70 Mini-ITX SBC is powered by Intel®
H310/ Q370 chipset, 17 x 17 mm, and Socket LGA 1151 Intel® 9th Gen. Core™ i7/i5/i3
Processor. The Intel® 9th Generation Core™ processor based on 64-bit, multi-core processors
built on 22-nanometer process technology. The processors are designed for a two-chip platform
consisting of a processor and Platform Controller Hub (PCH) to be used with the mobile chipset.
High performance platform delivers the performance and high scalability cutting-edge
embedded computing application.
In peripheral connectivity, IF70 Mini-ITX SBC features two NGFF Sockets two Serial ATA III
(6Gb/s)connectors, four serial ports (four pin headers), 4 super-speed USB 3.1 connectors and
four hi-speed USB 2.0 connectors(four pin headers). Additionally, IF70 Mini-ITX SBC features
build-in a 12V DC in power adapter.
Abundant I/O connectors and expandability makes IF70 Mini-ITX SBC to be the right fit in the
majority of industrial computer applications such as machine vision and control, gaming, POS,
KIOSK systems, industrial automation, and others. Powerful processor in Mini ITX form-factor
meets the demanding performance requirements of modern industrial applications.
1.2 Features
IF70 Mini-ITX SBC features:
•Mini ITX Form Factor (170 x 170 mm)
•Intel® 9th Generation Core™ i7/i5/i3 Processor (Coffee Lake Refresh S)
•Intel® H310 (Optional Q370) Chipset
•Intel® UHD Graphics 630, supports DirectX 12 and OpenGL4.5
•Default 1 × DDR4 2666 MHz SO-DIMM (Max. 16 GB)
•Optional 2× DDR4 2666 MHz SO-DIMM (Max. 32 GB)
•Integrated Dual Gigabit Ethernet
•Optional 1 x PCI-E (x16)
•2 x SATAIII, 4 x USB 3.0, 4 x USB 2.0

10 IF70 Mini-ITX SBC User Manual
1.3 Motherboard Specifications
Model Name
IF70 Mini-ITX SBC
System
Specifications
CPU
Socket LGA 1151
Intel® i7-9700TE Processor, 1.8 GHz to 3.8 GHz
Intel® i5-9500TE Processor, 2.2 GHZ to 3.6 GHz
Intel® i3-9100TE Processor ,2.2 GHz to 3.2 GHz
Chipset
Intel® H310 (Optional Q370)
System
Memory
Default : 1 x DDR4 2666 MHz SO-DIMM (max. 32 GB)
Optional: 2 x DDR4 2666 MHz SO-DIMM (max. 64 GB)
Storage
SATA3 x 2
M.2 SATA x 1 (KEY B)
BIOS Insyde BIOS
OS Windows® 10 IoT Enterprise
Display
Specifications
Display
Interface
Intel® UHD Graphics 630,
supports DirectX 12 and OpenGL4.5
HDMI resolution up to 4096 x 2304 @24Hz
DP interface,
supports max. resolution 4096 x 2304 @60Hz
LVDS 48 bit 1920 x 1200@60Hz
Audio Audio Codec Realtek HD codec
Ethernet Ethernet
Controller
Intel I211IT Gigabit-LAN Controller + I219LM
Gigabit-LAN PHY
I/O Ports
Specification
External I/O
4 x USB 3.0
2 x RJ-45 for Giga LAN
1 x DP 1.2
1 x HDMI 1.4
1 x Audio Jack (Mic-in, Line-out)
1 x (+12V) DC-in Power Jack
1 x Clear CMOS Button
1 x Reset Button
Internal I/O
1 x RS-232 2x5 pin-header
1 x RS-232/422/485 2x5 pin-header
4 x USB 2.0
1 x LVDS by DF-13 40 pin connector
2 x SATA III
1 x SATA power by 2x4 pin wafer
1 x 10-pin pin-header for DIO

11
0BChapter 1: General Information
1 x 3-pin digital panel backlight brightness controller
1 x 7-pin inverter
2 x 2-pin wafer for +5V external power (Red)
1 x 2-pin wafer for 12V external power (Yellow)
1 x 3-pin pin-header for CPU Fan (smart fan)
1 x VR controller
1 x OSD membrane control
1 x eDP panel byDF-13 20pin connector (Optional)
Expansions
Slot
1 x M.2 Slot (for SSD)
1 x M.2 Slot (Wi-Fi module)
1 x PCIE3.0 (x16) slot (Optional)
Mechanical
Specifications
Dimensions 170 (W) x 170(L) mm
Environment
Considerations
Operating
Temp. -20°C ~ 60°C
Storage
Temp. -40°C ~ 70°C
Operating
Humidity 10% ~ 95%, non-condensing
Power
Management
Power Supply +12V Power Input
Packing List Standard IF70 Mini-ITX SBC
IF70 Mini-ITX SBC Manual & Driver CD

12 IF70 Mini-ITX SBC User Manual
1.4 Functional Description
Function block (V100)

13
0BChapter 1: General Information
1.5 Physical Description
Board Dimensions (V100)

14 IF70 Mini-ITX SBC User Manual
Chapter 2: Hardware Installation
This chapter provides information on how to use jumpers and connectors on
the IF70 Mini-ITX SBC. Be cautious while working with these modules.
Carefully read the content of this chapter in order to avoid any damages.
2.1 Motherboard Components
2.2 Memory Module Installation
2.3 I/O Equipment Installation
2.4 Jumper Settings
2.5 Motherboard Connectors

15
1BChapter 2: Hardware Installation
2.1 Motherboard Components
2.1.1 Component Side
IF70 Mini-ITX SBC Top Layer (CPU Side, Top View)
IF70 Mini-ITX SBC Side Layer (IO Side, Front View)

16 IF70 Mini-ITX SBC User Manual
2.1.2 Solder Side
IF70 Mini-ITX SBC Bottom Layer (IO Side, Top View)

17
1BChapter 2: Hardware Installation
2.2 Memory Module (SO-DIMM) Installation
The IF70 Mini-ITX SBC has two 260-pin SODIMM slot. The socket supports DDR4.
When installing the memory unit, please follow the steps below:
1. Firmly insert the SO-DIMM at an angle of about 30-degree into the slot. Align the
SO-DIMM with the slot until it is fully inserted. The notch on the SO-DIMM should match
the break on the slot.
2. Press downwards on SO-DIMM until the retaining clips at both ends fully snap closed
and the SO-DIMM is properly seated.
CAUTION
The SO-DIMM only fits in one correct orientation. It will cause permanent
damage to the development board and the SO-DIMM if the SO-DIMM is
forced into the slot at the incorrect orientation.

18 IF70 Mini-ITX SBC User Manual
2.3 I/O Equipment Installation
2.3.1 Power Input 12V DC in
The IF70 Mini-ITX SBC allows plugging 12V DC-IN jack on the board without another power
module converter under power consumption by Intel® 9th Generation Core i7/i5/i3 Processor
and H310 chipset.
2.3.2 Serial COM Port
Four COM Port Pin Headers build in the IF70 Mini-ITX SBC. Optional COM ports support
RS-422/485.
*When an optional touch-screen is ordered with PPC, serial com port can connect to a serial or
an optional touch-screen.
2.3.3 HDMI
The IF70 Mini-ITX SBC has one HDMI port that can be connected to an external LCD monitor.
Use HDMI cable to connect to an external LCD monitor, and connect the power cable to the
outlet. The HDMI connector is a standard 19-pin HDMI connector.
2.3.4 Display Port
The Motherboard has one Display Port that can be connected to an external LCD monitor. Use
Display Port cable to connect to an external LCD monitor, and connect the power cable to the
power outlet. The Display Port connector is a standard 20-pin DP connector.
2.3.5 Ethernet Interface
The IF70 Mini-ITX SBC is equipped with Intel® I211-AT Gigabit-LAN Controller + I219-LM
Gigabit-LAN PHY which is fully compliant with the PCI 10/100/1000 Mbps Ethernet protocol
compatible. It is supported by major network operating systems. The Ethernet ports provide two
standard RJ-45 jacks.
2.3.6 USB Port
Eight USB devices (four with pin headers) may be connected to the system though an adapter
cable. Various adapters may come with USB ports. USB usually connect the external system to
the system. The USB ports support hot plug-in connection. Whatever, you should install the
device driver before you use the device.
2.3.7 Audio
The Audio 7.1 channel capabilities are provided by a Realtek chipset supporting digital audio
outputs. The audio interface includes two jacks: line-out and mic-in.

19
1BChapter 2: Hardware Installation
2.4 Jumper Settings
This section explains how to set jumpers for correct configuration of the motherboard.
NOTE:
A pair of needle nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes. Generally,
you simply need a standard cable to make most connections.
The jumper setting diagram is shown below. When the jumper cap is placed on both pins, the
jumper is SHORT. The illustration below shows a 3-pin jumper; pins 1 and 2 are short. If you
remove the jumper cap, the jumper is OPEN.
PIN 1-2 SHORT
PIN 3 OPEN
CAUTION
To avoid damaging the module, always turn off the power supply
before setting jumpers or clearing CMOS.
Jumpers
Label
Function
Note
JP1
Panel Power Select
2x3 header, pitch 2.0mm
JP2
BackLight Power Select
1x3 header, pitch 2.0mm
JP3
Backlight Dimming Select
1x3 header, pitch 2.0mm
JP4
Backlight Dimming Control
Select
1x3 header, pitch 2.0mm
JP5
MCU ISP Burnin to Select
1x3 header, pitch 2.0mm

20 IF70 Mini-ITX SBC User Manual
2.4.1 JP1: Panel Power Select
2.4.2 JP2: Backlight Power Select
2.4.3 JP3: Backlight Dimming Select
2.4.4 JP4: Backlight Dimming Control Select
2.4.5 CLR_CMOS: Clear CMOS Jumper
Remember to set jumper back to Normal before turning on the power supply.
Pin №
Name
1-2 (Default)
+3.3V
3-4
+5V
5-6
+12V
Pin №
Name
1-2 (Default)
+5V
2-3
+12V
Pin №
Name
1-2 (Default)
PWM Mode
2-3
DC Mode
Pin №
Name
1-2
Chipset
2-3(Default)
VR Control
Pin №
Function
1
+V3.3A
2
P0
3
GND
