Winmate IV70 User manual

IV70 Motherboard
Mini ITX SBC with Intel ® 3rd Generation Core™ i7/i5 Processors HDMI,
LVDS, VGA, Dual Giga Ethernet, 4 x USB3.0, PCle x16
V120
User Manual
Version 1.3
Document Part Number:
9171111I102J

IV70 Motherboard
II
Preface
Copyright Notice
No part of this document may be reproduced, copied, translated, or transmitted in any
form or by any means, electronic or mechanical, for any purpose, without the prior
written permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
We reserve the right to make changes, without notice, to any product, including circuits
and/or software described or contained in this manual in order to improve design and/or
performance. We assume no responsibility or liability for the use of the described
product(s), conveys no license or title under any patent, copyright, or masks work rights
to these products, and makes no representations or warranties that these products are
free from patent, copyright, or mask work right infringement, unless otherwise specified.
Applications that are described in this manual are for illustration purposes only. We
make no representation or warranty that such application will be suitable for the
specified use without further testing or modification.
Warranty
We warrant that each of its products will be free from material and workmanship defects
for a period of one year from the invoice date. (Standard is one year, extended warranty
will need to discuss with our sales representatives. If the customer discovers a defect, we
will, at its option, repair or replace the defective product at no charge to the customer,
provided it is returned during the warranty period of one year, with transportation
charges prepaid. The returned product must be properly packaged in its original
packaging to obtain warranty service.
If the serial number and the product shipping data differ by over 30 days, the
in-warranty service will be made according to the shipping date. In the serial numbers
the third and fourth two digits give the year of manufacture, and the fifth digit means
the month (e. g., with A for October, B for November and C for December).
For example, the serial number 1W16Axxxxxxxx means October of year 2016.

IV70 Motherboard
III
Packing List
Before using this Motherboard, please make sure that all the items listed below are
present in your package:
IV70 Motherboard
User Manual & Driver CD
If any of these items are missing or damaged, contact your distributor or sales
representative immediately.
Customer Service
We provide a service guide as below for any problem by the following steps: First,
contact your distributor, sales representative, or our customer service center for
technical support if you need additional assistance. You need to prepare the following
information before you call:
Product serial number
Peripheral attachments
Software (OS, version, application software, etc.)
Detailed problem description
The exact wording of any error messages
In addition, free technical support is available from our engineers every business day. We
are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or
e-mail us.

IV70 Motherboard
IV
Advisory Conventions
Four types of advisories are used throughout the user manual to provide helpful
information or to alert you to the potential for hardware damage or personal injury.
These are Notes, Important, Cautions, and Warnings. The following is an example of each
type of advisory.
NOTE:
A note is used to emphasize helpful information
IMPORTANT:
An important note indicates information that is important for you to know.
CAUTION
A Caution alert indicates potential damage to hardware and explains how to
avoid the potential problem.
WARNING!
An Electrical Shock Warning indicates the potential harm from electrical
hazards and how to avoid the potential problem.
Safety Precautions
CAUTION
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution, use a
grounding wrist strap at all times. Place all electronic components
in a static-dissipative surface or static-shielded bag when they are
not in the chassis.

IV70 Motherboard
V
Safety and Warranty
1. Please read these safety instructions carefully.
2. Please keep this user manual for later reference.
3. Please disconnect this equipment from any AC outlet before cleaning. Do not
use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or
letting it fall could cause damage.
7. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
8. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient over-voltage.
11. If any of the following situations arises, get the equipment checked by service
personnel:
A. The power cord or plug is damaged.
B. Liquid has penetrated into the equipment.
C. The equipment has been exposed to moisture.
D. The equipment does not work well, or you cannot get it to work according
to the user’s manual.
E. The equipment has been dropped and damaged.
F. The equipment has obvious signs of breakage.

IV70 Motherboard
VI
About This User Manual
This User Manual provides information about using the IV70 Motherboard. The
documentation set for the IV70 Motherboard provides information for specific user
needs, and includes:
IV70 Motherboard User Manual –contains detailed description on how to
use the motherboard, its components and features.
NOTE:
Some pictures in this guide are samples and can differ from actual
product.
Document Revision History
Version
Date
Note
Author
1.0
12-Dec-2012
Initial release
Henry Hsu
1.1
26-Mar-2015
Add jumper, connector
Austin Chang
1.2
1-Jul-2016
Revise format.
Revise board connector pinouts.
Add Intel ME & USB 3.0 Driver
Installation
Austin Chang
1.3
3-Oct-2016
IV70 V120
Austin Chang

IV70 Motherboard
VII
Contents
Table of Contents
PREFACE..............................................................................................................................................I
ABOUT THIS USER MANUAL..............................................................................................................VI
CHAPTER 1 GENERAL INFORMATION..................................................................................................1
1.1 INTRODUCTION...................................................................................................................................1
1.2 FEATURES ..........................................................................................................................................1
1.3 MOTHERBOARD SPECIFICATIONS ............................................................................................................2
1.4 FUNCTIONAL DESCRIPTION....................................................................................................................4
1.5 PHYSICAL DESCRIPTION ........................................................................................................................5
CHAPTER 2 HARDWARE INSTALLATION ..............................................................................................7
2.1 MOTHERBOARD COMPONENTS..............................................................................................................7
2.1.1 Front Side ...............................................................................................................................7
2.1.2 I/O Side...................................................................................................................................8
2.2 MEMORY MODULE (SO-DIMM) INSTALLATION .......................................................................................8
2.3 I/O EQUIPMENT INSTALLATION..............................................................................................................9
2.3.1 12V DC-IN...............................................................................................................................9
2.3.2 PS/2 Keyboard and PS/2 Mouse.............................................................................................9
2.3.3 Serial COM Ports ....................................................................................................................9
2.3.4 Internal VGA...........................................................................................................................9
2.3.5 Ethernet Interface ..................................................................................................................9
2.3.6 USB Ports................................................................................................................................9
2.3.7 Audio Jack ( Pin-header).......................................................................................................10
2.4JUMPER SETTINGS.............................................................................................................................10
2.3.1 Jumper List ...........................................................................................................................11
2.3.2 Connectors and Pin Assignment...........................................................................................14
2.3.3 I/O Side.................................................................................................................................25
CHAPTER 3 DRIVER INSTALLATION ...................................................................................................29
3.1 CHIPSET DRIVER INSTALLATION ............................................................................................................29
3.2 GRAPHIC DRIVER INSTALLATION ...........................................................................................................32
3.3 PANEL RESOLUTION SETTING...............................................................................................................36
3.4 AUDIO DRIVER INSTALLATION ..............................................................................................................38
3.5 ETHERNET DRIVER INSTALLATION..........................................................................................................39
3.6 INTEL®MANAGEMENT ENGINE SOFTWARE ............................................................................................42

IV70 Motherboard
VIII
3.7 FINTEK COM PORT DRIVER INSTALLATION .............................................................................................45
3.8 USB 3.0 DRIVER INSTALLATION (ONLY FOR WINDOWS 7) .........................................................................48
CHAPTER 4 AMI BIOS SETUP ............................................................................................................53
4.1 WHEN AND HOW TO USE BIOS SETUP .................................................................................................53
4.2 BIOS FUNCTIONS .............................................................................................................................55
4.2.1 Main Menu...........................................................................................................................55
4.2.2 Advanced Settings................................................................................................................55
4.2.3 Chipset Setting .....................................................................................................................74
4.2.4 Boot......................................................................................................................................80
4.2.5 Security.................................................................................................................................83
4.2.6 Save & Exit ...........................................................................................................................84
CHAPTER 5 TECHNICAL SUPPORT .....................................................................................................86
5.1 DRIVERS..........................................................................................................................................86
5.2 SOFTWARE DEVELOPMENT KIT (SDK) ...................................................................................................86

IV70 Motherboard
1
General Information
This chapter includes the IV70 Motherboard
background information.

User Manual Chapter 1 General Information
IV70 Motherboard
1
Chapter 1 General Information
This chapter includes the IV70 Motherboard background information.
1.1 Introduction
Thank you for choosing the IV70 Motherboard. The IV70 Motherboard is powered by
Intel® HM76 chipset which designed with Intel’s mobile platform. Intel® HM76 platform
delivers the performance and high scalability cutting-edge embedded computing
application. In peripheral connectivity, IV70 Motherboard features one PCIE x16 and
three Mini-PCIE slot (one for SATA SSD), two SATA connectors (one SATA III), and eight
Hi-Speed USB connectors (four USB3.0 on the I/O side).
Abundant I/O connectors and expandability makes IV70 Motherboard to be the right fit
in the majority of industrial computer applications such as Gaming, POS, KIOSK Systems,
Industrial Automation, and Programmable Control System. Powerful processor in a
compact form-factor meets the demanding performance requirements of today’s
business and industrial applications.
1.2 Features
IV70 Motherboard features:
Socket G2 for Intel® Core™ i7 / i5 / i3 Processor
Mini ITX Form Factor ( 170 x 170 mm )
DDR3 1333/1600MHz Dual-channel
SO-DIMM support up to 16 GB
12V Single Voltage Power Input
Dual display supported by VGA / Dual-channel
24-bit LVDS / HDMI / DVI
