DVD PLAYER WITH
DELUXE SOUND
–If Equipped
The DVD player is a selectable
function of the multi-featured audio
system. The player unit contains DVD/
CD/MP3/AM-FM Stereo radio. It also
accepts portable audio player inputs and
it also functions as an alarm clock.
The player is connected directly to
the TV and can output sound to either
the stereo speakers in the TV or to the
Deluxe Sound speakers in the lounge
area of the coach.
See the audio player manufacturer’s
information in your InfoCase for
complete feature descriptions and
operating instructions.
Provide 12V Power
The TV and
DVD player
operate on 12-volt
DC current.
• Turn on the 12-
Volt Master
Power (TV)
switch, located
on the cabinet
or wall near the
DVD player.
NOTE: When
the TV or DVD
Player are not in use, the Master
Power switch should be turned off to
eliminate drain on the 12-Volt house
battery.
Connect Deluxe Sound
Speakers
• Press the Speaker
switch to TV position
to connect speakers to
TV and DVD. Speaker
switch is located near
the DVD player.
Set TV Video Input
• Turn TV and DVD player On.
• PresstheMODEbuttonontheTVor
theSOURCEbuttonontheremoteto
select “INPUT 1.”
• TheTVscreen
will display
the DVD
player logo
when the
correct input is selected.
Play DVD
• Insert a DVD “face up” into slot on
lower face of the player.
• The DVD will begin to “load”
automatically. The TV screen will
typically display “READING” or
“LOADING.”
• The DVD may load directly
to the main title/menu screen
or it may begin to play
previews.Youmay beableto
skip previews if desired by
pressing the “NEXT” button on the
DVD remote until you see the main
menu screen.
• Whenthemain
menu screen
appears, press
the ENTER
button on the
remote or
“Play/Pause”
button on
DVD player to begin playing the
main feature. Use the arrow buttons
on the DVD remote to select another
feature to play .
• Volume is adjusted with the DVD
remote. Continued—

Audio-Video System
Basic Operation
Guide
Part No. 161501-10-005
Rev. 1001090706
Copyright 2009 Winnebago Industries, Inc.
All rights reserved.
NOTE: See your InfoCase for specific
operating guides for audio and
video components.
TV Sound through Deluxe
Sound Speakers
When watching TV programs alone,
the TV normally plays sound through
its own built-in stereo speakers. If you
wish to connect TV stereo sound output
to the Deluxe Sound speakers for a
richer sound quality, follow these steps:
• Press the Speaker switch to TV
positiontoconnectspeakerstoDVD
player.
• Turn the TV On.
• Press the AUX input
selection button just
below the display on
the face of the DVD
player.Thiswill routethe TVstereo
sound output through the DVD
player and out to the Deluxe Sound
speakers.
• Select TV channels and adjust
volume using the TV remote.
