MODEL NUMBER: HE170703
INSTRUCTION MANUAL
VERSION 1
ISSUED 03/07/18
.
.
.
.
.
.
WARRANTY NOTE
If you experience any issues with this product or its
performance is not what you had expected, please contact
us at Winplus before returning the item to the store.
It is likely that we can resolve any problems for you via
phone or email.
We can be reached on:
Phone: 1300 663 907 (Mon - Fri; 8:30am - 6:00pm AEST)
Email: customercar[email protected]
Web: www.winplus.com.au
IMPORTANT
Getting the most out of your ModelMaker 3D Printer:
Read the manual carefully
It will help you set up with ease
Visit https://cocoonproducts.com.au
We have additional support videos and guides
Call After Sales Support - 1300 663 907
Available Monday - Friday, 8:30am - 6:00pm AEST
We’re always happy to help
.
.
.
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 months from the date of purchase. Defects that occur within this warranty period, under
normal use and care, will be repaired, replaced or refunded at our discretion. The benets
conferred by this warranty are in addition to all rights and remedies in respect of the product
that the consumer has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
MODEL: HE170703 PRODUCT CODE: 59101 10/2018
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION
1300 663 907
AUS customercar[email protected] YEAR WARRANTY
1
ModelMaker 3D Printer
create
.
5
AFTER SALES SUPPORT
SAFETY INSTRUCTIONS
Before you get started, please read these important safety instructions.
CAUTION: The Cocoon Create ModelMaker 3D Printer generates high temperatures and includes
moving parts that can cause injury. Never reach inside of the ModelMaker 3D Printer while it is in
operation, and allow time for the printer to cool down after operation.
Always use the ModelMaker 3D Printer in an open, well ventilated area as vapours/fumes
created at operating temperatures may be irritating.
Do not leave the ModelMaker 3D Printer unattended during operation.
Contact with extruded material may cause burns. Wait for printed objects to cool before
removing them from the build platform.
Always take care when using the Scraper. Never direct the Scraper towards your ngers.
Only use the ModelMaker 3D Printer in a clear working area.
• The printer must not be exposed to water, moisture or rain, or damage will occur.
• The printer is designed to be used with ambient temperature ranging 15°C - 30°C, and humidity
ranging 20% - 50%. Operating outside these limits may result in lower quality models.
• In case of emergency, turn o the 3D printer at the power outlet.
• It is recommended that you use eye protection when cleaning/sanding printed models to avoid small
particles contacting eyes.
• Please read and understand the contents of this installation and user manual carefully. Failure to read
the manual may lead to personal injury, inferior results, or damage to the ModelMaker 3D Printer.
Always make sure that anyone who uses the 3D printer knows and understand the contents of the
manual to make the most out of the ModelMaker 3D Printer.
• The ModelMaker 3D Printer is not intended for use by persons with reduced physical and /or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
• Children should be under constant supervision when using the printer.
• Before Installation, you should make sure that the ModelMaker 3D Printer is unplugged from the
power supply. Only use furniture that can safely support ModelMaker 3D Printer.
• Ensure the mains socket-outlet is near the equipment and is easily accessible.
ModelMaker 3D Printer has been tested according to the AS/NZS 60950-1, Which falls under the low
voltage directive. ModelMaker 3D Printer must be used in conjunction with the original power cord.
In combination, they guarantee safe use in relation to short-circuit, overload, over voltage and over
temperature. Always unplug the printer before doing maintenance or modications.
HOT SURFACE
DO NOT TOUCH
MOVING PARTS
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 months from the date of purchase. Defects that occur within this warranty period, under
normal use and care, will be repaired, replaced or refunded at our discretion. The benets
conferred by this warranty are in addition to all rights and remedies in respect of the product
that the consumer has under the Competition and Consumer Act 2010 and similar state and
territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
MODEL: HE170703 PRODUCT CODE: 59101 10/2018
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION
1300 663 907
AUS customercare@winplus.com.au YEAR WARRANTY
1
ModelMaker 3D Printer
create
6
CONTENTS
Warranty Details 4
Safety Instructions 5
Parts List 8
Technical Specications 9
Introduction 10
1.1 What is 3D Printing? 10
Product Overview 10
2.1 Printer Front View 10
2.2 Printer Rear View 11
2.3 Control Panel 11
Product Assembly & Initial Setup 12
3.1 Unboxing and Assembly 12
Setup 13
4.1 Home Screen 13
4.2 Navigating the Menus 13
4.3 Menu Tree 14
4.4 Adding Filament 15
4.5 Levelling The Bed 16
4.5.1 The Levelling Wizard 16
4.5.2 Manually Levelling the Bed 16
Printing and Removing Models 18
5.1 Printing a File 18
5.1.1 During Printing 19
5.2 Print Times and Filament Usage 19
5.3 Removing 3D Objects from the Bed 20
5.4 Removing Filament 21
Finishing 21
6.1 Finishing Techniques 21
6.1.1 Useful Tools/Equipment 21
6.1.2 Removing Support Material 22
6.1.3 Sanding 22
6.1.4 Surface Coating 22
Additional Settings 23
7.1 Quick Settings 23
7.2 Advanced Settings 23
7
AFTER SALES SUPPORT
Creating & Printing 3D Designs 24
8.1 Slice to GCODE 24
8.2 3D Modelling Software 24
8.3 Installing Cura 25
8.4 Loading a 3D Design into Cura 26
8.5 Saving les to SD Card 26
8.6 Printing Files from PC via USB 26
Maintenance & Storage 27
9.1 Maintaining your ModelMaker 3D Printer 27
9.2 Replacing the Print Mat 27
9.3 Nozzle Cleaning 27
9.4 Routine Component Check 28
9.5 Changing The PTFE Tube 28
9.6 Printer & Filament Storage 29
Recap 30
9.7 Good 3D Printing Practices 30
Disposal 31
10.1 Disposal of Packaging 31
10.2 Disposal of Product 31
Troubleshooting 32
11.1 Printing Problems 32
11.2 Connectivity Problems 33
11.3 Other Problems 34
11.4 Useful Terms 34
Appendix 36
12.1 Files Loaded on the MicroSD Card 36
Repair and Refurbished Goods or Parts Notice 38
8
PARTS LIST
1 x 3D Printer
1 x Filament Spool Stand
1 x Power Cable
1 x USB Cable
1 x 4GB MicroSD Card
1 x Scraper
1 x PTFE Tube
1 x Hex Key Set
2 x Cable Ties
4 x 10m PLA Filament
3 x Magnetic Print Mats
(One already installed)
1 x Metal Base Mat (Attached)
1 x Glue Stick (Not shown)
1 x Instruction Manual
(Not Shown)
1 x Getting Started Guide
(Not Shown)
1 x Warranty Card
(Not Shown)
1 x Levelling Card
9
AFTER SALES SUPPORT
TECHNICAL SPECIFICATIONS
Printing
Print Technology: Fused Filament Fabrication (FFF)
Build Volume: 120 x 135 x 100mm (Width x Depth x Height)
Layer Resolution: 0.1 – 0.4mm
Positioning Accuracy: X 0.012mm
Y 0.012mm
Z 0.004mm
Extruder Quantity: Single Extruder
Extruder Diameter: 0.4mm
Print Speed: 10mm/s - 70mm/s
Travel Speed: 10mm/s - 70mm/s
Supported Print Materials: Cocoon Create Branded PLA, PLA Wood
Temperature
Ambient Operating Temperature: 15°C – 30°C
Operational Extruder Temperature: 170°C - 250°C
Software
Slicer Software: Cura
Cura Input Formats: .STL, .OBJ, .DAE, .AMF
Cura Output Format: .GCODE
Connectivity: MicroSD Card, USB port
Electrical
Input Rating: 100-240Vac, 50/60Hz, 1.0A
Physical Dimensions
Printer Frame Dimensions: 325 x 240 x 380 (Width x Depth x Height)
Weight: 7KG
10
INTRODUCTION
1.1 What is 3D Printing?
3D Printing is a process whereby a real object is created from a 3D Design. Fused Filament
Fabrication (FFF) is one of the most common technologies used by 3D Printers to achieve this. FFF
works on an‘additive’principle by laying down material, such as PLA lament, in layers to create a
3D object.
PRODUCT OVERVIEW
2.1 Printer Front View
1. Filament Tube
2. X-Axis Frame
3. Cooling Fan
4. Nozzle
5. Print Bed
6. Front Thumbwheels
7. Control Panel
8. Filament Clamp
9. Tower Frame
10. Spool Holder
3
9
8
10
2
5
7
6
4
1
