SERVICE MANUAL
and
INSTRUCTIONS FOR
CONTINUED AIRWORTHINESS
for the
WIPLINE MODEL 2100/2350
AMPHIBIOUS AND SEAPLANE FLOATS
Wipaire Part Number: 1002549 Rev. J

WIPLINE MODEL 2100/2350 SERVICE MANUAL
Page 2 1002549 • Rev F
THIS PAGE INTENTIONALLY LEFT BLANK

WIPLINE MODEL 2100/2350 SERVICE MANUAL
1002549 • Rev FPage 3
TABLE OF CONTENTS
SECTION PAGE
LOG OF REVISIONS................................................................................................................. 5
INTRODUCTION ....................................................................................................................... 8
1.0 GENERAL............................................................................................................................ 9
2.0 FLOAT HULL MAINTENANCE............................................................................................10
2.1 GENERAL .......................................................................................................................10
2.2 CLEANING......................................................................................................................10
3.0 CORROSION......................................................................................................................11
4.0 FLOAT HANDLING, JACKING, AND AIRCRAFT TOWING ................................................12
5.0 RETRACT SYSTEM OPERATION AND MAINTENANCE...................................................13
5.1 DESCRIPTION AND OPERATION..................................................................................13
5.2 ADJUSTMENT/TEST ......................................................................................................14
FIGURE 5-1 SCHEMATIC HYDRAULIC SYSTEM................................................................16
FIGURE 5-2 SCHEMATIC ELECTRICAL SYSTEM...............................................................17
FIGURE 5-3 MAIN GEAR ACTUATION ................................................................................18
FIGURE 5-4 NOSE GEAR RETRACTION SYSTEM.............................................................19
FIGURE 5-5 MAIN GEAR WHEEL ASSEMBLY ....................................................................20
6.0 RETRACT SYSTEM OPERATION AND MAINTENANCE...................................................21
6.1 DESCRIPTION AND OPERATION..................................................................................21
6.2 SERVICE SCHEDULE ....................................................................................................23
7.0 MAIN GEAR REMOVAL AND OPERATION .......................................................................26
7.1 REMOVAL AND DISSASSEMBLY OF MAIN GEAR........................................................26
7.3 DISSASSEMBLY OF SHOCK STRUT.............................................................................30
7.4 SERVICING HYDRAULIC ACTUATOR CYLINDERS (NOSE OR MAIN ACTUATORS)..31
7.5 HAND PUMP OPERATION.............................................................................................34
7.6 GEAR SELECTOR..........................................................................................................35
7.7 MAIN WHEELS AND BRAKES........................................................................................36
7.8 VISUAL POSITION INDICATORS MAIN AND NOSE GEAR...........................................36
8.0 NOSE GEAR.......................................................................................................................37
8.1 DESCRIPTION................................................................................................................37
8.2 SERVICE SCHEDULE ....................................................................................................37
8.3 NOSE TROLLEY REMOVAL FROM BOX ASSEMBLY...................................................37

WIPLINE MODEL 2100/2350 SERVICE MANUAL
Page 4 1002549 • Rev J
8.4 REASSEMBLE NOSE TROLLEY TO NOSE BOX...........................................................37
8.5 REMOVAL OF NOSE BOX FORK FROM PIVOT ASSEMBLY........................................38
8.6 NOSE BOX REMOVAL FROM FLOAT............................................................................38
8.7 NOSE BOX TRACK WEAR.............................................................................................38
FIGURE 7-3 FRONT VIEW NOSE BOX................................................................................40
FIGURE 7-4 POSITION OF TROLLEY TO NOSE BOX.........................................................41
9.0 WATER RUDDER RETRACTION AND STEERING SYSTEM............................................42
9.0 DESCRIPTION................................................................................................................42
9.1 ADJUSTMENT ................................................................................................................42
9.2 SERVICE SCHEDULE ....................................................................................................42
10.0 REPAIRING FLOAT HULL SKINS ....................................................................................48
FIGURE 9-1 TYPICAL SKIN REPAIR....................................................................................49
FIGURE 9-2 TYPICAL SKIN REPAIR....................................................................................50
FIGURE 9-3 TYPICAL SKIN REPAIR....................................................................................51
KEEL SPLICE REPAIR .........................................................................................................52
FIGURE 9.4 SPLICE SECTION CUTS..................................................................................52
FIGURE 9.5 DOUBLER SECTIONS......................................................................................53
FIGURE 9.6 FRONT VIEW WITH STIFFENERS...................................................................53
FIGURE 9.7 FINISHED KEEL WITH STIFFENERS ..............................................................54
11.0 WEIGHT AND BALANCE..................................................................................................55
WEIGHING PROCEDURES FOR PIPER PA-18 FLOATPLANE...........................................55
WEIGHING PROCEDURES FOR PIPER PA-12 FLOATPLANE...........................................56
WEIGHING PROCEDURES FOR CUB CRAFTERS CC-18 AND CC-19 FLOATPLANE ......57
WEIGHING PROCEDURES FOR THE HUSKY A-1, A-1A, A-1B OR A-1C FLOATPLANE...58
WEIGHING PROCEDURE FOR CESSNA 172 FLOATPLANE..............................................59
WEIGHING PROCEDURE FOR CESSNA 170 FLOATPLANE..............................................60
WEIGHING PROCEDURE FOR CESSNA 175 FLOATPLANE..............................................61

WIPLINE MODEL 2100/2350 SERVICE MANUAL
1002549 • Rev JPage 5
LOG OF REVISIONS
REV PAGES DESCRIPTION DATE
A 12, 23 Added an inspection time limit and tolerances for
the Nose Block Track wear. 4/18/06
B 38-40 ADDED KEEL SPLICE REPAIR & FIGURES 6/30/06
5-7 ADDED TABLE OF CONTENTS AND
RENUMBERED ALL PAGES 6/30/06
C 17-19
NEW INSTRUCTIONS TO CHECKLIST &
CHANGED FORMAT TO INCLUDE MECH.
SIGNATURE & RT. LT. FLOAT
10/5/06
D 28-30, 23,
46-53
Altered Checklist format with INSP. Sign-off.
Added hydraulic actuator rebuild instructions to
pg 23. Added weighing info.
5/1/08
E 12, 13, 20,
27, 28 Sections 5.2 instructions, 6.1 instructions, 7.4 instructions 6/25/08
F ALL Reformat of entire document, Add green grease
as approved grease
4/12/2013
G 24, 25, Added Shear Torque chart, PR 1440 C Sealant
and Tef-Gel Removed Warranty Claim Form. 5/26/2015
H 11, 24, 25
Added Dow Corning DC4, Corrosion X, and
Mobil Aviation Grease SHC 100 to approved
product list. Modified torque limits section
12/4/2015
J Cover, 4,
5, 57 Added Wipaire document number to cover, CC- 19 aircraft added to weighing procedures 1/12/2017

WIPLINE MODEL 2100/2350 SERVICE MANUAL
Page 6 1002549 • Rev F
NEW CUSTOMER INFORMATION
Customer Name
Billing Address
Shipping Address
Phone Number
Fax Number
Purchasing Contact
Phone Number
E-Mail
Fax Number
Accounts Payable Contact
Phone Number
E-Mail
Fax Number
Type(s) of Aircraft Owned or Maintained
Model(s) of Floats and Skis Owned or Maintained
FedEx and/or UPS account number (if applicable)
Please return to Wipaire Customer Service:
Fax [phone] Phone [phone] [e-mail]

WIPLINE MODEL 2100/2350 SERVICE MANUAL
1002549 • Rev F Page 7
THIS PAGE INTENTIONALLY LEFT BLANK

WIPLINE MODEL 2100/2350 SERVICE MANUAL
Page 8 1002549 • Rev F
INTRODUCTION
This manual describes the general service and maintenance for the float, hull, gear
systems, installation, and control parts. For service and repair not covered by this manual,
contact Wipaire Customer Service.
The service products referred to throughout this manual are described by their trade
name and may be purchased from the Wipaire Parts Department.
To contact Wipaire for technical support or parts sales, call, write or email:
Wipaire, Inc.
1700 Henry Avenue – Fleming Field
South St. Paul, MN 55075
Telephone: [phone]
Toll Free: 1-888-947-2473
Fax: [phone]
[email protected]

WIPLINE MODEL 2100/2350 SERVICE MANUAL
1002549 • Rev F Page 9
1.0 GENERAL
The model 2100/2350 seaplane or amphibious float is an all aluminum-constructed float
with watertight compartments. The actual displacement in fresh water for each float is 2323
pounds (model 2100) and 2570 pounds (model 2350) buoyancy for the seaplane and 2185
pounds (model 2100) and 2432 pounds (model 2350) buoyancy for the amphibian. The
amphibian float is geometrically the same as the seaplane except for the addition of landing
gear and internal structure for the gear.
The water rudder system is cable operated with ball bearing pulleys. Water rudder
cables tie into the existing aircraft rudder system.
The main landing gear has a 5.00 x 5 6-ply tire and the nose landing gear has a 2.50 x 4
4-ply tire. The gear system is hydraulically actuated and driven by one reversible electric
pump. Brakes are hydraulic and have a caliper on each main wheel.
Steering on land is accomplished by differential braking. The nose wheels are full
castering.
Access to the float interior is accomplished by removing covers on the top deck, side skins
and two covers inside the wheel well. When necessary, water inside the float hulls may be
removed through pumpout cups located on the outboard edge of each float top skin.

WIPLINE MODEL 2100/2350 SERVICE MANUAL
Page 10 1002549 • Rev F
2.0 FLOAT HULL MAINTENANCE
2.1 GENERAL
The float structure side and top skins are 6061-T6 and forward and aft bottom skins
are 2024-T3 aluminum sheet and 6061-T6 extrusions. Skins are alodined and primed after
being cleaned and acid-etched. Exterior is finished with an enamel color paint, or
equivalent.
2.2 CLEANING
The outside of the float should be kept clean by washing with soap and water, with
special care taken to remove engine exhaust trails, water line marks, and barnacle deposits
as these are all linked to corrosion. After saltwater operation, washing with fresh water
should be done daily with special attention to hard-to-reach places, such as seams, wheel
well, etc. The float interior should be flushed if salt water enters the compartments; it’s
easy to tell by the smell inside the float lockers. At night or when the floatplane is in
storage, the inspection and/or baggage covers should be opened so the interior has a
chance to dry out. THE ABOVE CLEANING TECHNIQUES ARE VITAL
FOR KEEPING CORROSION TO A MINIMUM. SALTWATER
OPERATIONS ARE STRONGLY LINKED TO
CORROSION AND MUST BE ADDRESSED PROACTIVELY.
2.1 Hard Landing and Damage Investigation
After a thorough cleaning of the damaged area, all structural parts should be carefully
examined to determine the extent of damage. Frequently, the force causing the initial damage
is transmitted from one member to the next, causing strains and distortions. Abnormal stresses
incurred by shock or impact forces on a rib, bulkhead, or similar structure, may be transmitted to
the extremity of the structural member, resulting in secondary damage, such as sheared or
stretched rivets, elongated bolt holes, or canned skins or bulkheads. Points of attachment
should be examined carefully for distortion and security of fastenings in the primary and
secondary damaged areas at locations beyond the local damage.
