UMC-A18QA-V LGA-type LTE Mod le
User Man al

UMC-A18QA-V Product
Specification
Page 2
C O NTEN T S
A. Prod ct Description ......................................................................................... 3
B. Main Feat res ................................................................................................. 6
B.1 Application inter ace eatures ......................................................................................... 7
B.2 Packet mode eatures ..................................................................................................... 7
B.3 LTE eatures ..................................................................................................................... 7
B.4 Short Message Service (SMS) eatures ............................................................................ 7
B.5 RF Speci ication ............................................................................................................... 7
E. Mo nting considerations ................................................................................. 9
F. Mechanic Specifications................................................................................. 10
G. Package Specifications ................................................................................... 12
H. Label Form.................................................................................................... 12
I. Electrostatic discharge (ESD)........................................................................... 12

UMC-A18QA-V Product
Specification
Page 3
A. PRODUCT DESCRIPTION
© Wistron NeWeb Corporation
THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PROPRIETARY AND
IS THE EXCLUSIVE PROPERTY OF WNC AND SHALL NOT BE DISTRIBUTED,
REPRODUCED, OR DISCLOSED IN WHOLE OR IN PART WITHOUT PRIOR WRITTEN
PERMISSION FROM WNC.
LIMITATION OF LIABILITY
THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PURELY FOR
DESIGN REFERENCE AND SUB ECT TO REVISION BY WNC AT ANY TIME. NOTHING IN
THIS DOCUMENT SHALL BE CONSTRUED AS GRANTING ANY WARRANTY OR RIGHT TO
USE THE MATERIAL CONTAINED HEREIN WITHOUT WNC’S PRIOR EXPRESS WRITTEN
CONSENT. WNC SHALL NOT BE LIABLE FOR ANY USE, APPLICATION OR
DEVELOPMENT DERIVED FROM THE MATERIAL WITHOUT SUCH PRIOR EXPRESS
WRITTEN CONSENT.
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiated radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.

UMC-A18QA-V Product
Specification
Page 4
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
End roduct Labeling
The final end product must be labeled in a visible area with the following: “Contains FCC ID:
NKRA18QA-V”. The grantee's FCC ID can be used only when all FCC compliance requirements are
met.
RF Exposure Information
This device is intended only for ODM/OEM integrators under the following conditions:
(1) The antenna must be installed such that 20cm is maintained between the antenna and users,
(2) The transmitter module may not be co-located with any other transmitter or antenna.
(3) To comply with FCC regulations limiting both maximum RF output power and human
exposure to RF radiation, the maximum antenna gain including cable loss in a mobile exposure
condition must not exceed:
Standalone Condition:
3.0 dBi in 700 MHz Band
5.3 dBi in 1700 MHz Band
IM ORTANT NOTE:
This module is intended for ODM/OEM integrator. The integrator is still responsible for the
FCC compliance requirement of the end product, which integrates this module. 20cm
minimum distance has to be able to be maintained between the antenna and the users for
the host this module is integrated into. Under such configuration, the FCC radiation exposure
limits set forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the
user's authority to operate this equipment.
USERS MANUAL OF THE END RODUCT:

UMC-A18QA-V Product
Specification
Page 5
In the users manual of the end product, the end user has to be informed to keep at least
20cm separation with the antenna while this end product is installed and operated. The end
user has to be informed that the FCC radio-frequency exposure guidelines for an
uncontrolled environment can be satisfied. The end user has to also be informed that any
changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment. If the size of the end product is smaller than 8x10cm,
then additional FCC part 15.19 statement is required to be available in the users manual:
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Figure1: UMC-A18QA-V LGA-type LTE Module
A.1 General Descriptions
This document describes the speci ications o UMC-A18QA-V LGA LTE Module. This
module is based on Qualcomm MDM9207-0 plat orm and capable to allow users
enjoying high speed internet access anywhere and anytime over 4G LTE broadband
network.
With integrating UMC-A18QA-V module, the end products are enhanced in both
unctionality and usability based on leading edge mobile wireless technology.
This document will introduce hardware, so tware, mechanical and environmental
speci ications in ollowing sections.

UMC-A18QA-V Product
Specification
Page 6
Product in ormation:
Part N mber Category LTE GNSS Footprint Dimension
UMC-A18QA-V CAT4 B4, B13 GPS LGA 263 pads 28.5x23.5x2.3mm
A.2 Applicable Device
WNC UMC-A18QA-V module is a high speed LTE modem with LGA orm actor
and is ocusing on the gateway, notebook, tablet and other portable device or
M2M marketing.
Notebook
Tablet
Mobile Internet Device
Wireless Router
Wireless Multimedia Device
Wireless M2M solution
B. MAIN FEATURES
Support 1.8/3.0V USIM
Operation System (OS) Support - Linux (device driver)
Certi ication
GCF/Verizon (in plan)
FCC (in plan)
Operating Ambient Temperature
Operating : -30°C ~ +70°C
-20°C~+60°C: ull unctions compliant with 3GPP
-30°C~+70°C: unctional workable

UMC-A18QA-V Product
Specification
Page 7
Storage : -40°C ~ +85°C
B.1 APPLICATION INTERFACE FEATURES
WNC MAL (Modem Abstraction Layer) Manager SDK or Linux
B.2 PACKET MODE FEATURES
LTE data rates with category 4 (UMC-A18QA-V)
150 Mbps DL with 20 MHz bandwidth
50 Mbps UL with 20 MHz bandwidth
B.3 LTE FEATURES
3GPP LTE Release 10
Bandwidth support 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15 MHz and 20 MHz per
3GPP standard
VoLTE
IPv4 and IPv6 supported
LTE Rel-10 MDT with location in ormation
B.4 SHORT MESSAGE SERVICE (SMS) FEATURES
SMS over SGs
SMS over IMS
B.5 RF SPECIFICATION

UMC-A18QA-V Product
Specification
Page 8
Cellular Frequency Band
E
-
UTRA
Operating Band
Uplink Freq ency
UE Transmit
Downlink Freq ency
UE Receive
Band 4
1710
MHz
-
1755
MHz
2110
MHz
-
2155
MHz
Band 13
777
MHz
-
787
MHz
746
MHz
-
756
MHz
LTE Channel Bandwidth
E-UTRA
Operating Band
Channel Bandwidth
(CHBW)
1.4
MHz
3
MHz
5
MHz
10
MHz
15 MHz
20 MHz
Band 4 Yes Yes
Yes
Yes
Yes
Yes
Band 13
Yes
1
Yes
1
Note 1: re ers to the CHBW or which a relaxation o the speci ied UE receiver
sensitivity requirement is allowed as de ined in section 7.3 o 3GPP TS 36.101.
LTE Max. TX Output Power
LTE Band Items
Parameter
Partial RB
Unit Min Typ Max
B4,
B13
Max TX Power
QPSK
-
1RB#0
, 10MHz
dBm
20.3
25.7
Note: The RF Transmit Speci ication is de ined at the LGA pad.
LTE Re erence Sensitivity
LTE Band
Items
Parameter
Min
Typ
Max
Unit
Band 4 Receive Sensitivity 10MHz -97.0 dBm
Band 13 Receive Sensitivity 10MHz -94.0 dBm

UMC-A18QA-V Product
Specification
Page 9
Note: The RF Receive Speci ication is de ined at the LGA pad.
GPS Receive Speci ications
The GPS is an optional eature in UMC-A18QA-V, depending on additional request.
E. MOUNTING CONSIDERATIONS
Re low soldering pro ile:
Profile Min. Max. Unit
Preheat time rom140°C to 190°C 70 105 S

UMC-A18QA-V Product
Specification
Page 10
Time maintained above 230°C 40 60 S
Peak package body temperature 230 250 °C
Time maintained above 217°C 60 90 S
F. MECHANIC SPECIFICATIONS
Dimension: 28.5mm [L] x 23.5mm [W] x 2.3mm [H]
PCB FOOTPRINT (Top View)

UMC-A18QA-V Product
Specification
Page 11
Module Dimension (Top and Side View)

UMC-A18QA-V Product
Specification
Page 12
G. PACKAGE SPECIFICATIONS
Tape & Reel
H. LABEL FORM
Dimension : 19mm * 19mm (example as shown below)
I. ELECTROSTATIC DISCHARGE (ESD)
+/- 2KV

UMC-A18QA-V Product
Specification
Page 13
S
20 Park Aven e II,
Hsinch Science Park,
Hsinch 308, Taiwan, R.O.C.
TEL: [phone]
FAX: [phone]
Website: http://www.wnc.com.tw
