WisyCom CPR30 User manual

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
CPR30 – Frequencies programming
Remove CPR30 battery pack: to do it remove “AA” cells and remove two screws near the corners of battery pack. Extract battery pack.
Insert UPK32/100 connector on ST3 (ST3 before used by battery pack).
After a successfully programming, disconnect UPK32/100 and remount CPR30 battery pack.
CPR30-howtoprogramCS029112.doc

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
Reference on the
UPK connecto
r
Reference on the
p
rinted board
WIRELESS-MICROPHONE SYSTEMS
CRT14 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CRT14-howtoprogramCS012206.doc

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
Reference on the
UPK connecto
r
Reference on the
p
rinted board
WIRELESS-MICROPHONE SYSTEMS
CRT16 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CRT16-howtoprogramCS016201.doc
CRT16
CS 016201

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
Reference on the
UPK connecto
r
Reference on the
p
rinted board
WIRELESS-MICROPHONE SYSTEMS
CRT16 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CRT16-howtoprogramCS016202.doc
CRT16
C
S
01620
2

W I S Y C O M S.r . l . • Via Spin, 156 • I-36060 Romano d’Ezzelino (VI) • Italy
Tel. [phone] • Fax [phone] • www.wisycom.com • e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
CSR50 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CSR50-howtoprogramCS035126.doc
Reference on the
UPK connector
CSR50 adapter
Reference on the
printed board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
CST36 & CST50 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
• On CST36 remove RF shield SC1 and operate on PCB top side.
• On CST50 operate on bottom side.
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CST36-CST50-howtoprogramCS037113.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board
PCB top view

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
CST38 – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CST38-howtoprogramCS038100.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
CST910 – Frequencies programming
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
CST910-howtoprogramCS937111.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
MCR40 – Frequencies programming
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
MCR40-howtoprogramCS040202.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
MSR918 UHF – Frequencies programming
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
MSR918U-howtoprogramCS914110.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
MSR918 VHF – Frequencies programming
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
MSR918V-howtoprogramCS914101.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board
MSR916 &

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
MTH200 – Frequencies programming
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies.
Verify unobstructed programming pads before insert UPK connector.
MTH200-howtoprogramCS20030x.doc
Reference on the
UPK connecto
r
Reference on the
p
rinted board

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
WIRELESS-MICROPHONE SYSTEMS
MTP22 – Frequencies programming
Remove MTP22 battery pack: to do it remove “AA” cells and remove two screws near the corners of battery pack. Extract battery pack.
Insert UPK32/100 connector on ST5 (ST5 before used by battery pack).
After a successfully programming, disconnect UPK32/100 and remount MTP22 battery pack.
MTP22-howtoprogramCS020110.doc

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
Reference on the
UPK connecto
r
Reference on the
p
rinted board
WIRELESS-MICROPHONE SYSTEMS
RPU300 VHF – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Do not remove circuit boards from apparatus.
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies, avoiding contact with mechanical body.
Verify unobstructed programming pads before insert UPK connector.
RPU300VU-howtoprogramCS030853-030214.doc
TX side
CS
03085
3
RX side
CS
030214
RTE25-VHF &
RTE25 &
RPU300 Tx

WISYCOM S.r.l. •Via Spin, 156 •I-36060 Romano d’Ezzelino (VI) •Italy
Tel. [phone] •Fax [phone] •www.wisycom.com •e-mail: [email protected]
Reference on the
UPK connecto
r
Reference on the
p
rinted board
WIRELESS-MICROPHONE SYSTEMS
RPU300 UHF – Frequencies programming
(Open device removing screws that retains mechanical body, and operate directly on powered off circuit board).
Do not remove circuit boards from apparatus.
Touch UPK32/UPK100 connector on circuit board’s pads to program apparatus’ frequencies, avoiding contact with mechanical body.
Verify unobstructed programming pads before insert UPK connector.
RPU300UU-howtoprogramCS030851-030214.doc
TX side
CS 030851
RX side
CS 030214
RTE25-UHF &
RTE25 &
RPU300 Tx
