Wolf SRT364C User manual

36" Sealed Burner Rangetops
The patented, dual-stacked sealed
gas burners of our new sealed burner
rangetop take control to a new level.
Two levels, really. The upper-tier burner
delivers maximum heat transfer at
higher settings; the lower-tier
continuous flame ably handles the
subtleties of simmering and melting.
The Wolf exclusive infrared charbroiler
and infrared griddle ensure this
rangetop stands out from the rest in
performance and also beauty.
Features
Natural or LP gas models
Classic stainless steel exterior finish with
island trim included
Optional infrared charbroiler and infrared
griddle configurations
Distinctive red control knobs—black knobs
optional
Platinum bezels surround all knobs—
chrome or brass bezels optional
Dual-stacked, sealed burners, all with
simmer capabilities and automatic
reignition at all settings
Melt feature on 9,200 Btu/hr burner
Porcelain-coated cast iron continuous
top grates
Dual-Stacked
Sealed Burner
Model SRT366
Model SRT364C
Model SRT364G
Surface Features
Model SRT366 SRT364C SRT364G
Surface Burners – 15,000 Btu/hr
with 950 Btu/hr delivered at simmer 5 3 3
Surface Burner – 9,200 Btu/hr
with 325 Btu/hr delivered at simmer 1 1 1
Infrared Charbroiler – 16,000 Btu/hr
Infrared Griddle – 15,000 Btu/hr
Model numbers are for natural gas sealed burner rangetops, add (-LP) to the model number for LP gas.
Accessories
Classic stainless steel risers in 5" and
10" heights, or 20" riser with shelf
Black control knobs
Chrome or brass bezels
Porcelain-cast wok grate and single
burner grate
Porcelain-cast two-burner S-grate
Hardwood cutting board
(griddle model only)
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer information,
visit the Showroom Locator section of our
website, wolfappliance.com.
Model SRT366 shown
This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

357/8" (911)
OVERALL WIDTH
241/4"
(616)
121/2"
(318)
WITH 5"
RISER
171/2"
(445)
WITH 10"
RISER
271/2"
(699)
WITH 20"
RISER
281/2" (724)
OVERALL DEPTH
81/2" (216)
OVERALL
HEIGHT
COOKING
SURFACE
71/2"
(191)
91/4"
(235)
Installation Notes
A riser is required for installations
against a combustible surface.
A Wolf Pro wall, chimney, island ventila-
tion hood or hood liner is recommended.
Natural gas and LP gas installations
above 8,000' require the high altitude kit.
Unit dimensions may vary by ±
1
/ 8 ".
VENTILATION HOOD
36" (914)
FINISHED ROUGH OPENING WIDTH
30"min (762) TO
36"max (914)
TO BOTTOM OF
VENTILATION HOOD
36"min (914)
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
44"min (1118)
FOR CHARBROILER
3/4" (19)
PLATFORM
TOP VIEW
OF PLATFORM
EG
16"
(406)
16" (406)
4" (102) BACK
WALL
ISLAND INSTALLATIONS: 12" (305) MINIMUM
CLEARANCE FROM BACK OF RANGETOP TO
COMBUSTIBLE REAR WALL ABOVE COUNTERTOP–
0" (0) TO NON-COMBUSTIBLE MATERIALS
LOCATION OF GAS AND
ELECTRICAL SUPPLY CUT-OUT
WITHIN SHADED AREA
THROUGH BOTTOM OF
PLATFORM
36"
(914)
18"min (457)
TO COUNTERTOP
3/4" (19)
PLATFORM
81/2"
(216)
COOKING
SURFACE
71/2"
(191)
24" (610)
13" max
(330)
6"min (152)
TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
Specifications
Exterior Finish Classic Stainless Steel
Overall Width 357/8"
Overall Height
(to cooking surface) 81/2"
Overall Depth 281/2"
Opening Width 36"
Opening Height
(to countertop) 71/2"
Opening Depth 24"
Electrical Requirements 110/120 V AC
50/60 Hz, 15 amp circuit
Power Cord 6' cord with grounded plug
Shipping Weight 190–220 lbs
Installation Specifications
Overall Dimensions
36" Sealed Burner Rangetops
Dimensions in parentheses are in
millimeters unless otherwise specified.
