Wolf CT15E User manual

INSTALLATION INSTRUCTIONS
ELECTRIC COOKTOPS

As you follow these instructions, you will
notice WARNING and CAUTION symbols.
This blocked information is important for the
safe and efficient installation of Wolf equip-
ment. There are two types of potential
hazards that may occur during installation.
Another footnote we would like to identify is
IMPORTANT NOTE: This highlights informa-
tion that is especially relevant to a problem-
free installation.
signals a situation where minor injury or
product damage may occur if you do not
follow instructions.
states a hazard that may cause serious
injury or death if precautions are not
followed.
WOLF®is a registered trademark of Wolf Appliance, Inc.
CONTACT
INFORMATION
Wolf Customer
Service:
800-332-9513
Website:
wolfappliance.com

3
WOLF ELECTRIC COOKTOPS
BEFORE YOU START
Proper installation is your responsibility.
Have a qualified technician install this
cooktop. You must also assure that electri-
cal installation is adequate and in compli-
ance with all local codes and ordinances.
Installations and repairs must be performed
byaqualified or licensed contractor or
electrician qualified or licensed by the state,
province, or region where this appliance is
being installed.
Make sure you have everything necessary
for correct installation. It is the responsibil-
ity of the installer to comply with the
installation clearances specified in this book
and on the product rating plate. The rating
plate is located on the underside of the
cooktop. Refer to the illustration below.
Electrical ground is required; see Electrical
Requirements on page 14.
Warranty service must be preformed by a
Wolf authorized service center.
This cooktop is intended for indoor use.
INSTALLATION REQUIREMENTS
IMPORTANT NOTE: Save these Installation
Instructions for the local inspector’s use.
Please read the entire Installation Instruc-
tions prior to installation.
This installation must be completed by a
qualified technician.
Installer: please retain these instructions
for local inspector’s reference, then leave
them with the homeowner.
Homeowner: please read and keep these
instructions for future reference and be sure
to read the entire Use & Care Information
prior to use.
IMPORTANT NOTE: This appliance must be
installed in accordance with National Electrical
Codes, as well as all state, municipal and local
codes. The correct voltage, frequency and
amperage must be supplied to the appliance
from a dedicated, grounded circuit which is
protected by a properly sized circuit breaker or
time delay fuse. The proper voltage, frequency,
and power ratings arelisted on the product
rating plate.
Recordthe model and serial numbers before
installing the cooktop. Both numbers are on
the rating plate, located on the underside of
the cooktop. Refer to the illustration below.
RATING PLATE
INFORMATION
Model Number
Serial Number
Rating plate location
CLEAR
O
SIM HIGH
OFFON
OFF ON
SIMHIGH
OFF ON
SIMHIGH
BRIDGE
ZONE2
ZONE3
HIGH
MELTOFF ON
Location of rating
plate under cooktop

4
WOLF ELECTRIC COOKTOPS
LOCATION IN COUNTERTOP
A) Minimum flat countertop surface. Must be
equal to or greater than cooktop width.
B) Minimum 1" (25) wide clearance from the
cooktop side edge to any combustible
surface up to 18" (457) above the cooktop
(noted by shaded area).
OVERHEAD CABINET DIMENSIONS
C) Minimum spacing between overhead side
cabinets must be greater than or equal to
the nominal width of the cooktop unit(s).
D) Minimum 18" (457) vertical distance from
the countertop to the bottom of side
cabinets within minimum side clearance.
E) Minimum vertical distance between the
countertop and combustible materials
above the cooktop must be 30" (762).
F) Minimum 1" (25) from rear wall.
G) Maximum 13" (330) depth of overhead and
side cabinets directly above and within side
clearance.
Failure to locate the cooktop unit
without the proper clearances will result
in a fire hazard.
C
G
D
A
B
B
E
F
Minimum clearances for installation
SITE PREPARATION
IMPORTANT NOTE: Installation of the Wolf
electric cooktop must meet the following
location requirements. All dimensions listed
are minimum requirements for safe operation.
Refer to the illustration below.
To eliminate the risk of burns or fire by
reaching over heated surface units,
cabinet storage space located above the
surface units should be avoided. If
cabinet storage is to be provided, the risk
can be reduced by installing a ventilation
hood that projects horizontally a
minimum of 5" (127) beyond the bottom
cabinets.

5
Dimensions in parentheses are in
millimeters unless otherwise specified.
INSTALLATION INSTRUCTIONS
INSTALLATION SPECIFICATIONS
The illustrations on pages 6–11 provide the
overall dimensions, installation specifications
and countertop cut-out for each of the Wolf
electric cooktop models.
These cooktops are designed to fit a standard
24" (610) deep base cabinet with a 25" (635)
deep countertop. Before making the counter-
top cut-out, verify that the cooktop will clear
the side walls of the base cabinet below.
Clearance is required for the conduit located at
the right rear of the cooktop. Refer to the illus-
tration below for dimensions.
FRAMED ELECTRIC COOKTOPS
For framed models, a minimum 53/4" (146)
clearance is required between the countertop
and any combustible surface directly below
the cooktop.
Wolf framed electric cooktops are designed to
be installed in combination with other cooktop
units.
IMPORTANT NOTE: When multiple cooktop
units areinstalled side by side, refer to the
countertop cut-out dimensions on page 9.
Wolf framed electric cooktops can accommo-
date a Wolf downdraft ventilation system.
Refer to installation instructions provided with
the downdraft for additional specifications.
11/4"(32)
2"
(51)
2"
(51)
Conduit dimensions
UNFRAMED ELECTRIC COOKTOPS
For unframed models, a minimum 61/4"(159)
clearance is required between the countertop
and any combustible surface directly below
the cooktop.
IMPORTANT NOTE: Unframed electric
cooktops are not designed to be installed in
combination with other cooktops.
IMPORTANT NOTE: Unframed electric
cooktops cannot be installed with a downdraft
ventilation system.
For installation options of the unframed
electric cooktops, refer to Unframed Installa-
tions on pages 12–13.

6
E
4" (102)
15"
(381)
15"
(381)
2"*min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
133/8"(340)
COOKTOP CUT-OUT
WIDTH
133/8"(340)
COOKTOP CUT-OUT
WIDTH
33" (838) RECOMMENDED
CABINET WIDTH
18"
(457)
NOTE: Application shown allows for installation of two 15" (381) modules side-by-side with 33" (838) recommended cabinet width. 18" (457)
recommended cabinet width for installation of single 15" (381) cooktop or module. *Minimum clearance from both side edges of cooktop cut-out
to combustible materials up to 18" (457) abovecountertop. **Minimum clearance from rear edge of cooktop cut-out to combustible materials up
to 18" (457) abovecountertop.
191/4"(489)
COOKTOP CUT-OUT
DEPTH
21/2"min
(64)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13" max
(330) 30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
FRONT OF COUNTERTOP
21/2"min
(64)
191/4"(489)
COOKTOP
CUT-OUT DEPTH
2"**
(51)
Overall Dimensions
Countertop Cut-Out
21"
(533)
OVERALL
DEPTH
15" (381)
OVERALL WIDTH
5" (127)33/4"(96)
CONDUIT
MODEL CT15E
Overall Width 15" (381)
Overall Height 33/4"(96)
Overall Depth 21" (533)
Minimum Cabinet Depth 223/4"(578)
Minimum Height Clearance* 4" (102)
Cut-Out Width 133/8"(340)
Cut-Out Depth 191/4"(489)
INSTALLATION SPECIFICATIONS – MODEL CT15E
FRAMED MODEL CT15E
The illustrations below provide installation
specifications for Model CT15E.
If Model CT15E is installed above cabinets, the
electrical placement is not critical. A grounded
electrical box should be located within 4'
(1.2 m) of the right rear of the cooktop.
For installation above an oven, unless you are
using cabinets deeper than 24" (610), it is
recommended that the electrical supply be
placed in the base cabinet to the right of the
oven.
WOLF ELECTRIC COOKTOPS
IMPORTANT NOTE: Do not block the cooling
fan located at the bottom of the cooktop.
*Minimum 53/4" (146) clearance is required
between countertop and any combustible
surface directly below the cooktop.
For detailed conduit dimensions, refer to
the illustration on page 5.
Dimensions may vary to ±1/8"(3).

7
2"*min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
191/4"(489)
COOKTOP CUT-OUT
DEPTH
21/2"min
(64)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13" max
(330) 30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
24"min
(610)
*Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18" (457) above countertop. **Minimum clearance
from rear edge of cooktop cut-out to combustible materials up to 18" (457) abovecountertop.
4" (102)
10"
(254)
31/2"(89)
33/4"min
(95)
30-INCH OVEN OPENING
E
283/8"(721) COOKTOP
CUT-OUT WIDTH
283/8"(721)
COOKTOP CUT-OUT WIDTH
FRONT OF COUNTERTOP
21/2"min
(64)
191/4"(489)
COOKTOP
CUT-OUT DEPTH
33" (838) RECOMMENDED
CABINET WIDTH
30"min (762)
2"**
(51)
Overall Dimensions
Countertop Cut-Out
21"
(533)
OVERALL
DEPTH
30" (762)
OVERALL WIDTH
5" (127)33/4"(96)
CONDUIT
FRAMED MODEL CT30E
The illustrations below provide installation
specifications for Model CT30E.
For ease of installation, 33" (838) cabinets are
recommended for installation of Model CT30E.
AWolf 30" (762) or 36" (914) built-in single
oven may be installed below Model CT30E. For
this installation, unless you are using cabinets
deeper than 24" (610), it is recommended that
the electrical supply be placed in the base
cabinet to the right of the oven.
Refer to installation instructions provided with
the built-in oven for additional specifications.
If Model CT30E is installed above cabinets, the
electrical placement is not critical. A grounded
electrical box should be located within 4'
(1.2 m) of the right rear of the cooktop.
IMPORTANT NOTE: Do not block the cooling
fan located at the bottom of the cooktop.
IMPORTANT NOTE: Installation specifications
for Model CT30E-208/S are identical to Model
CT30E. Only the electrical specifications differ.
MODEL CT30E
Overall Width 30" (762)
Overall Height 33/4"(96)
Overall Depth 21" (533)
Minimum Cabinet Depth 223/4"(578)
Minimum Height Clearance* 4" (102)
Cut-Out Width 283/8"(721)
Cut-Out Depth 191/4"(489)
INSTALLATION SPECIFICATIONS – MODEL CT30E
Dimensions in parentheses are in
millimeters unless otherwise specified.
INSTALLATION INSTRUCTIONS
*Minimum 53/4" (146) clearance is required
between countertop and any combustible
surface directly below the cooktop.
For detailed conduit dimensions, refer to
the illustration on page 5.
Dimensions may vary to ±1/8"(3).

8
WOLF ELECTRIC COOKTOPS
FRAMED MODEL CT36E
The illustrations below provide installation
specifications for Model CT36E.
For ease of installation, 39" (991) cabinets are
recommended for installation of Model CT36E.
AWolf 30" (762) or 36" (914) built-in single
oven may be installed below Model CT36E. For
this installation, unless you are using cabinets
deeper than 24" (610), it is recommended that
the electrical supply be placed in the base
cabinet to the right of the oven.
Refer to installation instructions provided with
the built-in oven for additional specifications.
If Model CT36E is installed above cabinets, the
electrical placement is not critical. A grounded
electrical box should be located within 4'
(1.2 m) of the right rear of the cooktop.
IMPORTANT NOTE: Do not block the cooling
fan located at the bottom of the cooktop.
2"*min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
191/4"(489)
COOKTOP CUT-OUT
DEPTH
21/2"min
(64)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13" max
(330) 30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
24"min
(610)
*Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18" (457) above countertop. **Minimum clearance from
rear edge of cooktop cut-out to combustible materials up to 18" (457) abovecountertop.
343/8"(873)
COOKTOP CUT-OUT WIDTH
343/8"(873)
COOKTOP CUT-OUT WIDTH
39" (991)
RECOMMENDED CABINET WIDTH
36"min (914)
4" (102)
10"
(254)
31/2"(89)
36-INCH OVEN OPENING
33/4"min (95)
E
21/2"min
(64)
FRONT OF COUNTERTOP
191/4"(489)
COOKTOP
CUT-OUT DEPTH
2"**
(51)
Overall Dimensions
Countertop Cut-Out
21"
(533)
OVERALL
DEPTH
36" (914)
OVERALL WIDTH
5" (127)33/4"(96)
CONDUIT
MODEL CT36E
Overall Width 36" (914)
Overall Height 33/4"(96)
Overall Depth 21" (533)
Minimum Cabinet Depth 223/4"(578)
Minimum Height Clearance* 4" (102)
Cut-Out Width 343/8"(873)
Cut-Out Depth 191/4"(489)
INSTALLATION SPECIFICATIONS – MODEL CT36E
*Minimum 53/4" (146) clearance is required
between countertop and any combustible
surface directly below the cooktop.
For detailed conduit dimensions, refer to
the illustration on page 5.
Dimensions may vary to ±1/8"(3).

9
Dimensions in parentheses are in
millimeters unless otherwise specified.
INSTALLATION INSTRUCTIONS
MULTIPLE COOKTOP INSTALLATION
If the framed electric cooktop is to be used
with any combination of additional cooktop
units or modules with a filler strip, the cut-out
width is calculated by adding the correspon-
ding units' cut-out dimensions plus 11/4"(32)
for each additional unit. Refer to the illustra-
tion below.
IMPORTANT NOTE: For Model CT15E, the
cut-out width should be increased from 133/8"
(340) to 14" (356) when installed with multiple
units.
IMPORTANT NOTE: Unframed electric
cooktops Models CT30EU and CT36EU are not
designed to be installed in combination with
other cooktop units.
IMPORTANT NOTE: When multiple units are
installed side by side, each unit must have its
own separate recommended electrical circuit.
21/2"min
(64)
FRONT OF COUNTERTOP
191/4"
(489)
CUT-OUT
DEPTH
291/4"(743)
TWO MODULES WIDTH
441/2"(1130) THREE MODULES WIDTH OR
441/4"(1124) 30" COOKTOP AND ONE MODULE
593/4"(1518) FOUR MODULES WIDTH OR
591/2"(1511) 30" COOKTOP AND TWO MODULES OR
501/4"(1276) 36" COOKTOP AND ONE MODULE
14"
(356)
CUT-OUT
WIDTH
Countertop cut-out dimensions for installation of multiple cooktops
ACCESSORIES
Optional acces-
sories are available
through your
Wolf dealer. To
obtain local dealer
information, visit
the Showroom
Locator section of
our website,
wolfappliance.com.
When two or more modules are installed
together, an integrated module filler strip
(#802726) is recommended. If a 30" (762)
downdraft ventilation system is also installed,
an integrated module support for downdraft
ventilation (#803386) is also required. Contact
your Wolf dealer for information on these
accessory components.

10
2"*min (51)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
30-INCH OVEN OPENING
33" (838) RECOMMENDED
CABINET WIDTH
30"min (762)
283/8"(721) COOKTOP
CUT-OUT WIDTH
15/16"(33)
RADIUS
27/16"(62)
193/8"(492)
COOKTOP
CUT-OUT DEPTH
7/16"(11) RADIUS
301/8"** (765)
RECESSED AREA FOR
FLUSH MOUNT INSTALLATION ONLY
FRONT OF COUNTERTOP
19/16"(40)
211/8"** (537)
RECESSED AREA
FOR FLUSH MOUNT
INSTALLATION ONLY
**Minimum dimension, but may be exceeded by up to 1/8" (3).
RECESSED AREA FOR
FLUSH MOUNT INSTALLATION ONLY
5/16"(8)
7/8"
(22) max
COUNTERTOP
PROFILE
13" max
(330)
24"min
(610)
4"min (102)
SEE COUNTERTOP
CUT-OUT BELOW
SEE COUNTERTOP
CUT-OUT BELOW
*Minimum clearance from both side edges and back edge of cooktop cut-out to combustible materials up to 18" (457) above countertop.
2"* (51)
E
10"
(254)
4"min (102)
TO OVEN
OPENING
31/2"(89)
41/2"(114)
Overall Dimensions
Countertop Cut-Out
21"
(533)
OVERALL
DEPTH
30" (762)
OVERALL WIDTH
51/2"(140)41/4"(108)
CONDUIT
UNFRAMED MODEL CT30EU
The illustrations below provide installation
specifications for Model CT30EU.
For ease of installation, 33" (838) cabinets are
recommended for installation of Model CT30EU.
AWolf 30" (762) built-in single oven may be
installed below Model CT30EU. For this installa-
tion, unless you are using cabinets deeper
than 24" (610), it is recommended that the
electrical supply be placed in the base cabinet
to the right of the oven. Refer to installation
instructions provided with the built-in oven for
additional specifications.
If Model CT30EU is installed above cabinets,
electrical placement is not critical. A grounded
electrical box should be located within 4'
(1.2 m) of the right rear of the cooktop.
For Model CT30EU installation options, refer
to Unframed Installations on pages 12–13.
IMPORTANT NOTE: For flush mount applica-
tions, it is recommended to measure the
cooktop glass before cutting the countertop to
ensure a proper fit. Small variances may exist
between the template and the cooktop.
MODEL CT30EU
Overall Width 30" (762)
Overall Height 41/4"(108)
Overall Depth 21" (533)
Minimum Cabinet Depth 223/4"(578)
Minimum Height Clearance* 41/2"(114)
Cut-Out Width 283/8"(721)
Cut-Out Depth 193/8"(492)
INSTALLATION SPECIFICATIONS – MODEL CT30EU
WOLF ELECTRIC COOKTOPS
*Minimum 61/4" (159) clearance is required
between countertop and any combustible
surface directly below the cooktop.
For detailed conduit dimensions, refer to
the illustration on page 5.
Dimensions may vary to ±1/8"(3).
