Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
1
Dimensions in parentheses are in
millimeters unless otherwise specified.
9/07
Model IS15/S
The Wolf Model IS15/S 15" (381)
integrated electric steamer module is
available in the classic stainless steel
finish.
From a temperature of 140˚F (60˚C) to boil, you can
keep food hot for long periods of time or defrost easily
without drying out or losing its flavor.
The beauty of this module is accented by the sculp-
tured glass domed lid, which is easily inverted for
storage to keep a low profile.
The deep, large vessel with a two gallon (7.6 L)
capacity can hold up to 14 cups of cooked pasta and
includes one solid and one perforated stackable insert
pan.
The Wolf electric steamer module is available in classic
stainless steel.
With Wolf’s integrated modules, you have the ultimate
in customization. You can create your own design by
mixing and matching the various components within
this system.
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Hidden 2600-watt
heating element
Reversible domed
glass lid
Graduated
control lighting
Illuminated electronic
touch controls
Deep drawn pan Digital tempera-
ture readout
Location of
rating plate

Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
2
15" (381)
OVERALL WIDTH
21"
(533)
OVERALL
DEPTH
131/2"(343)
TO DRAIN
OUTLET
71/2"
(191)
OVERALL DIMENSIONS
Dimensions in parentheses are in
millimeters unless otherwise specified.
Unit dimensions may vary by ± 1/8"(3).
FEATURES
Integrated design allows for installation of
multiple cooktops or modules
Stainless steel top construction with classic
stainless steel finish
Hidden 2600-watt heating element
Illuminated electronic touch controls with
graduated control lighting
Large two-gallon (7.6 L) maximum capacity
tub—10-cup capacity for steaming
Two stackable stainless steel steamer insert
pans—one solid and one perforated
Uses include steaming vegetables, eggs and
custard, double boiling, proofing bread
dough, warming food and melting chocolate
Can function as a slow cooker for 8–10
hours
Reversible domed glass lid for easy storage
Independent digital timer
Digital temperature readout and preheat indi-
cator
Electronic drain
CSA certified for US and Canada
Two and five year residential warranty—
exclusions apply; warranty information can
be found on our website, wolfappliance.com

Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
Dimensions in parentheses are in
millimeters unless otherwise specified. 3
VENTILATION OPTIONS
30" (762) Cooktop hood or Pro
wall or wall chimney hood or liner
36" (914) Pro island hood
For additional information, refer to the
Cooktop or Pro Ventilation sections of our
website, wolfappliance.com.
ACCESSORIES
Filler strip
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
Unit dimensions may vary by ± 1/8"(3).
SPECIFICATIONS
Overall Cooktop Width 15" (381)
Overall Cooktop Height 13 1/2"(343)
Overall Cooktop Depth 21" (533)
Heating Element 2600 W
Minimum Cabinet Depth 22 3/4"(578)
Minimum Height Clearance 13 1/2"(343)
Cooktop Cut-Out Width 14" (356)
Cooktop Cut-Out Depth 19 1/4"(489)
Electrical Supply Requirements 240/208 V AC, 60 Hz
15 amp circuit
Conduit 4 ft (1.2 m) flexible 3-wire
Electrical Rating 2.6 kW at 240 V
1.9 kW at 208 V
Shipping Weight 40 lbs (18 kg)
Special Note Module can be installed in combination
with other cooktops or modules
Specifications are subject to change without notice.
Model IS15/S

Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
Dimensions in parentheses are in
millimeters unless otherwise specified. 4
INSTALLATION SPECIFICATIONS
7"*min (178)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
14" (356)
COOKTOP CUT-OUT
WIDTH
14" (356)
COOKTOP CUT-OUT
WIDTH
33" (838) RECOMMENDED
CABINET WIDTH
18"
(457)
NOTE: Application shown allows for installation of two 15" (381) modules side-by-side with 33" (838) recommended cabinet width. 18" (457)
recommended cabinet width for installation of single 15" (381) cooktop or module. *Minimum clearance from both side edges of cooktop cut-out
to combustible materials up to 18" (457) abovecountertop. **Minimum clearance from rear edge of cooktop cut-out to combustible materials up
to 18" (457) abovecountertop.
191/4"(489)
COOKTOP CUT-OUT
DEPTH
21/2"min
(64)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13" max
(330) 30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
FRONT OF COUNTERTOP
21/2"min
(64)
191/4"(489)
COOKTOP
CUT-OUT DEPTH
75/8"
(194)
123/8"
(314)
DRAIN OUTLET
LOCATION
E
131/2"
(343)
15"
(381)
15"
(381)
123/8"
(314)
6"
(152)
DRAIN
OUTLET
LOCATION
2"**
(51)
DIMENSIONS
Minimum Cabinet Depth 22 3/4"(578)
Cooktop Cut-Out Width 14" (356)
Cooktop Cut-Out Depth 191/4"(489)
Location of Electrical Within shaded area
See Installation Instructions shipped with unit for detailed specifications.

Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
Dimensions in parentheses are in
millimeters unless otherwise specified. 5
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions, cut-out dimensions and
installation specifics.
Wolf recommends using 33" (838) wide
cabinets for installation of two integrated
modules side by side. An 18" (457) wide
cabinet is recommended for installation of a
single integrated cooktop module.
IMPORTANT NOTE: Review specific installation
instructions for product to product capabilities
When multiple cooktops or modules are
installed side by side, refer to the countertop
cut-out dimensions on page 6.
AWolf Cooktop or Pro ventilation hood is
recommended. When installing a ventilation
hood, refer to the specific requirements of the
hood for the minimum dimension to countertop.
Also refer to the ventilation recommendation
charts in the cooktop or Proventilation sections
of our website,wolfappliance.com.
IMPORTANT NOTE: Wolf does not recommend
the use of downdraft ventilation with the inte-
grated steamer module.
The Wolf integrated steamer module requires
aseparate, grounded 3-wire 240/208 V AC,
60 Hz, 15 amp service with its own circuit
breaker. It has a 4' (1.2 m) flexible 3-wire
conduit for connection at the electrical supply.
Locate electrical within the shaded area shown
in the illustration on page 4.
You must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
For the drain connection, the 5/8"(16) outlet
from the valve will accept a drain hose that
must flow downward to and tie into an existing
sink drain, or a separate drain with a freefall
may be installed. Following local building codes,
your plumber will dictate how to plumb the
unit. As a third option, the consumer will
supply a heat resistant bucket for drainage in
the location of the drain outlet. Refer to the
illustration on page 4 for location of the drain
outlet.
Refer to the installation instructions
shipped with each Wolf product for detailed
specifications.
This cooktop is intended for indoor use only.
This steamer module must be installed at
least 15" (381) away from a Wolf fryer
module, as contact between water and hot
oil maycause burns from steam and hot oil.

Planning Information
Integrated Electric Steamer Module
MODEL IS15/S
Dimensions in parentheses are in
millimeters unless otherwise specified. 6
MULTIPLE COOKTOP INSTALLATION
With Wolf's integrated modules, you have the
ultimate in customization. You can create your
own design by mixing and matching the various
components within this system. And when you
couple these modules with other cooktops
within the Wolf inventory you and your client will
truly understand freedom of choice.
Some Wolf integrated modules can be installed
together or with a 30" (762) or 36" (914)
cooktop. When multiple units are installed side
by side, the cut-out dimensions that are shown
in the illustration are derived by adding 11/4"(32)
additional space for each additional unit, to give
you your total cut-out width. Refer to the illus-
tration below for countertop cut-out dimensions
for installation of multiple cooktop units.
When two or more cooktops or modules are
installed together, an accessory filler strip is
recommended. Refer to Accessories on page 3.
Countertop cut-out dimensions for installation of multiple cooktop units.
IMPORTANT NOTE: When multiple cooktops
and/or modules are installed side by side, each
unit must have its own separate recommended
electrical circuit. When multiple gas cooktops
and/or modules are installed next to one
another, they can receive their gas supply from a
common line. However, each unit must have its
own regulator installed between the mainline
and the cooktop or module.
IMPORTANT NOTE: Review specifications for
each specific integrated module for installation
requirements and limitations. Refer to the
integrated modules section of our website,
wolfappliance.com.
21/2"min
(64)
FRONT OF COUNTERTOP
191/4"
(489)
CUT-OUT
DEPTH
291/4"(743)
TWO MODULES WIDTH
441/2"(1130) THREE MODULES WIDTH OR
441/4"(1124) 30" COOKTOP AND ONE MODULE
593/4"(1518) FOUR MODULES WIDTH OR
591/2"(1511) 30" COOKTOP AND TWO MODULES OR
501/4"(1276) 36" COOKTOP AND ONE MODULE
14"
(356)
CUT-OUT
WIDTH
