Wolf Ig15/s User manual

INSTALLATI N GUIDE

Grill Module

Important Note

To ensure the safe and efficient use of Wolf equipment,

please take note of the following types of highlighted

information throughout this guide:

IMP RTANT N TE highlights information that is especially

important.

CAUTI N signals a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

Contents

WolfGrillModule .............................3

Grill Module Specifications . . . . . . . . . . . . . . . . . . . . . 4

Grill Module Installation . . . . . . . . . . . . . . . . . . . . . . . . 8

ServiceInformation...........................10

Features and specifications are subject to change at any time

without notice. Visit wolfappliance.com/specs for the most

up-to-date information.

IMP RTANT N TE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise specified.

Wolf Grill Module 3

wolfappliance.com/specs

Grill Module Installation

IMP RTANT N TE: Installation of the Wolf electric grill

module must be completed by a qualified installer.

Read this entire installation guide prior to installation and

save for the local inspector’s reference. The homeowner

should keep this installation guide for future reference.

This appliance must be installed in accordance with

National Electrical Codes, as well as all state, municipal

and local codes. The correct voltage, frequency and

amperage must be supplied to the appliance from a dedi-

cated, grounded circuit which is protected by a properly

sized circuit breaker or time delay fuse. The proper

voltage, frequency and amperage ratings are listed on the

product rating plate.

Record the model and serial numbers before installing

the grill module. Both numbers are listed on the product

rating plate, located on the underside of the module.

Refer to the illustration below.

Wolf Grill Module

Model Number IG15/S

Serial Number

Location of rating plate.

RATING P ATE

Grill Module Specifications 4

21" (533)

15"

(381)

61/4"(159)

1/2"(13)

SIDES

1" (25)

FRONT / BACK

Overall Dimensions

GRILL M DULE

Installation Specifications

IMP RTANT N TE: Installation of the Wolf electric grill

module must meet minimum clearance requirements

shown in the installation illustration on page 6.

The Wolf grill module is intended for indoor use. It is

designed to fit a standard 24" (610) deep base cabinet with

25" (635) deep countertop. Before making the countertop

cut-out, verify that the module will clear the side walls of

the base cabinet.

It is recommended that you use a Wolf cooktop ventilation

hood, pro hood or hood liner with the grill module. Refer

to the Wolf design guide.

IMP RTANT N TE: Wolf does not recommend the use of

downdraft ventilation with the grill module.

Failure to locate the grill module without the proper

clearances will result in a fire hazard.

Grill Module Specifications 5

wolfappliance.com/specs

IMP RTANT N TE: This appliance must be installed in

accordance with National Electrical Codes, as well as all

state, municipal and local codes. The correct voltage,

frequency and amperage must be supplied to the

appliance from a dedicated, grounded circuit which is

protected by a properly sized circuit breaker or time delay

fuse. The proper voltage, frequency and amperage ratings

are listed on the product rating plate located on the under-

side of the module. Refer to the illustration on page 3.

The complete appliance must be properly grounded at

all times when electrical power is applied.

Do not ground the appliance with the neutral (white)

house supply wire. A separate ground wire must be

utilized.

If aluminum house supply wiring is utilized, splice the

appliance copper wire to the aluminum house wiring

using special connectors designed and agency certified

for joining copper and aluminum. Follow the connector

manufacturer’s recommended procedure carefully.

Improper connection can result in a fire hazard!

Electrical Requirements

Verify that power is disconnected from the electrical

box before proceeding.

The Wolf electric grill module requires a separate,

grounded 3-wire electrical supply with its own circuit

breaker. ocate the electrical supply within the shaded

area shown in the installation illustration on the following

page.

M DEL IG15/S

•Power supply: 240/208 V AC, 60 Hz, 20 amp service.

•Max connected load: 2.8 kW at 240 V, 2.1 kW at 208 V.

The grill module is provided with a 4' (1.2 m) flexible

3-wire conduit that makes a connection to a junction box.

The conduit consists of two insulated hot lead conductors

and one insulated ground conductor.

IMP RTANT N TE: You must follow all National Electrical

Code regulations. In addition, be aware of local codes and

ordinances when installing your service.

For electrical installation, attach the conductors to the

residence wiring in accordance with National Electrical

Codes and all state, provincial, municipal and local codes.

The wiring diagram covering the control circuit is located

inside the module control box.

Grill Module Specifications 6

Installation Specifications

GRILL M DULE

36" (914)

FLOOR TO

COUNTERTOP

30" (762) min

COUNTERTOP

TO COMBUSTIBLE

MATERIALS

SEE COUNTERTOP

CUT-OUT BELOW

14" (356)

CUT-OUT

WIDTH

COUNTERTOP CUT-OUT

FRONT

191/4"(489)

CUT-OUT

DEPTH

21/2"(64) min

7" (178) TO

COMBUSTIBLE*

7" (178) TO

COMBUSTIBLE*

SIDE

CABINET

13" (330)

max

15" (381)

15"

(381)

61/4"

(159)

18" (457) min

2" (51) min*

FRONT VIEWSIDE VIEW

*Minimum clearance from cooktop cut-out to combustible materials up to 18" (457) above countertop.

NOTE: Application shown allows for installation of two 15" (381) modules side by side.

Grill Module Specifications 7

wolfappliance.com/specs

Installation Specifications

MULTIPLE C KT P INSTALLATI N

If the grill module is to be used in combination with

additional cooktops or modules with a filler strip, refer to

the chart below for the countertop cut-out width. The

dimensions are derived by adding an additional 11/4"(32)

for each additional unit, to give you the total countertop

cut-out width. Dimensions include the filler strip.

When multiple cooktops are installed side by side, each

unit must have its own separate, recommended electrical

circuit.

When two or more cooktops or modules are installed

together, an integrated module filler strip is recommended.

The filler strip and other accessories are available through

your authorized Wolf dealer. For local dealer information,

visit the find a showroom section of our website,

wolfappliance.com.

IMP RTANT N TE: Review specific installation instruc-

tions for product to product capabilities.

Multiple Cooktops

C UNTERT P CUT- UT WIDTH

2 Modules 291/4"(743)

3 Modules 441/2"(1130)

4 Modules 593/4"(1518)

30" (762) Cooktop / Module 441/4"(1124)

30" (762) Cooktop / 2 Modules 591/2"(1511)

36" (914) Cooktop / Module 501/4"(1276)

Grill Module Installation 8

MODULE

FOAM

STRIP

Foam strip. Installation brackets.

31/2"(89)

CLAMPING

SCREW

MODULE

COUNTERTOP

BRACKET

CLIP

Install the Module

Remove the grill module from its shipping carton and

discard packing materials.

ower the grill module into the countertop cut-out

opening. Center the module in the opening and check that

the front edge of unit is parallel to the front edge of the

countertop. Check that all minimum clearances are met.

Using a pencil, outline the rear edge of the module frame

on the countertop. Remove the module from the opening.

IMP RTANT N TE: When repositioning the module in the

countertop opening, lift the entire unit up from the opening

to prevent scratching the countertop.

Apply the foam strip, included in the hardware package,

to the underside of the module frame. Refer to the illustra-

tion below.

Reinsert the grill module into the countertop opening.

Align the rear edge of the module frame with the pencil

line and check that it is parallel to the front edge of the

countertop. ift the entire module to make adjustments.

To attach the brackets to the sides of the module, insert

the clip into the rectangular punchout in the pan and push

down. Install the clamping screw into the bracket and

tighten until the screw contacts the underside of the coun-

tertop. Do not overtighten screws. Refer to the illustration

below.

IMP RTANT N TE: Do not seal the grill module to the

countertop. It must be removed if service is necessary.

Grill Module Installation 9

wolfappliance.com/specs

Before Operating

Read the entire Wolf grill module use & care guide

included with the unit. It contains important safety, opera-

tion, service and warranty information.

Before operating, clean the grill module thoroughly with

hot water and a mild detergent. Rinse and dry with a soft

cloth. This removes any residual oil and grease left on the

surface from the manufacturing process. Refer to care

recommendations in the use & care guide.

Module Removal

IMP RTANT N TE: Removal of the grill module should

only be performed by Wolf factory certified service.

If removing the grill module is necessary for cleaning or

service, first disconnect the electrical supply. Remove the

mounting brackets on each side of module and remove.

To reinstall, follow the steps on the previous page.

The grill module must be disconnected from the

electrical supply before removal.

Service Information 10

Service Information

If service is necessary, maintain the quality built into your

grill module by contacting Wolf factory certified service.

For the name and number of Wolf factory certified service

nearest you, check the contact & support section of our

website, wolfappliance.com or call Wolf customer care at

800-222-7820.

When calling for service, you will need the model and

serial numbers of the grill module. Both numbers are listed

on the product rating plate located on the underside of the

module. Refer to the illustration below for the location of

the rating plate.

IMP RTANT N TE: Installation and service must be

performed by a qualified installer or service agency.

Warranty service must be performed by Wolf factory

certified service.

Troubleshooting

IMP RTANT N TE: If the grill module does not operate

properly, follow these troubleshooting steps:

•Verify that electrical power is being supplied to the

module.

•Check the electrical connections to ensure that the

installation has been completed correctly.

•Follow troubleshooting procedures outlined in the

Wolf grill module use & care guide.

•If the module still does not operate properly, contact

Wolf factory certified service. Do not attempt to repair

the module yourself. Wolf is not responsible for service

required to correct a faulty installation.

Location of rating plate.

RATING P ATE
