Wolf C48SS-2FT36 User manual

CHALLENGER XL™SERIES
48” DOUBLE OVEN GAS RANGE
OPEN BURNERS / FRY TOPS
Item # __________________ C.S.I. Section 11420
Model C48SS-8 shown with optional casters
SPECIFICATIONS
48” wide gas restaurant range, Wolf Model No. C48SS-8.
Fully MIG welded aluminized steel frame for added durability.
Stainless steel front, sides, backriser, highshelf and 6” adjustable
legs. Extra deep crumb tray with welded corners. Eight 30,000
BTU/hr cast burners with lift-off burner heads. Energy saving
flashtube open burner ignition system (one pilot for every two
burners) shrouded for reliability. Heavy duty cast grates, easy
lift-off 12” x 12 1/2” in the front and 12” x 14 1/2” in the back to
better accommodate stock pots or large pans. Grates have a
built in aeration bowl for greater efficiency. Burner knobs are
cool to the touch, high temperature material. Two ovens: 20,000
BTU/hr space-saver standard ovens with porcelain oven bottom
and door panel, measures 26 1/4”d x 20”w x 14”h. Sheet pans
(18” x 26”) fit front to back. Oven thermostat adjusts from 250°F
to 500°F with a low setting. Ovens are supplied with two racks,
two rack guide sets, and four rack positions. Oven doors are
heavy duty with an integrated door hinge spring mechanism
requiring no adjustment. 1” rear gas connection and pressure
regulator. Total input 280,000 BTU/hr.
Exterior Dimensions:
34 3/4”d x 48”w x 58”h on 6” adjustable legs
F-37371 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 QLouisville, KY 40201 QToll-free: 1-800-814-2028 QLocal: 502-778-2791 QQuote & Order Fax: [phone]
C48SS-8T2 Standard Ovens
C48SS-6FT12T2 Standard Ovens
C48SS-4FT24T2 Standard Ovens
C48SS-2FT36T2 Standard Ovens
STANDARD FEATURES
Fully MIG welded frame■
Stainless steel front, sides, backriser, lift-off high shelf■
6” Stainless steel adjustable legs■
30,000 BTU/hr open top burners with lift-off heads■
Shrouded flash tube pilot system (one pilot per■
two burners)
Heavy duty cast grates, easy lift-off 12” x 12 1/2” in■
front and 12” x 14 1/2” in the rear
Extra deep pull out crumb tray with welded corners■
20,000 BTU/hr space saver standard oven cavity■
measures 26 1/4”d x 20”w x 14”h
Sheet pans (18” x 26”) fit front to back■
Oven thermostat adjusts from 250°F to 500°F■
Two oven racks and four rack positions for each oven■
One year limited parts and labor warranty■
OPTIONAL FEATURES (Factory Installed)
6” stainless steel stub backT
Reinforced high shelf for mounting salamander broilerT
Hot top section in lieu of one open burnerT
ACCESSORIES (Packaged & Sold Separately)
Extra oven rackT
Extra rack guides (set of two)T
Casters (set of six)T
Flanged feet (set of six)T
Reinforced high shelf for mounting salamander broilerT
This appliance is manufactured for commercial
use only and is not intended for home use.

CHALLENGER XL™SERIES
48” DOUBLE OVEN GAS RANGE
OPEN BURNERS / FRY TOPS
F-37371 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 QLouisville, KY 40201 QToll-free: 1-800-814-2028 QLocal: 502-778-2791 QQuote & Order Fax: [phone]
A pressure regulator sized for this unit is included.1.
Natural gas 5.0” W.C., propane gas 10.0” W.C.
Gas line connecting to range must be 1” or larger. If2.
flexible connectors are used, the inside diameter must be
1” or larger.
An adequate ventilation system is required for commercial3.
cooking equipment. Information may be obtained by
writing to the National Fire Protection Association,
1 Batterymarch Park, Quincy, MA 02269, www.NFPA.org.
When writing, refer to NFPA No. 96.
These units are manufactured for installation in4.
accordance with ANSZ223.1A (latest edition), National
Fuel Gas Code. Copies may be obtained from The
American Gas Association, 400 N Capitol St. NW,
Washington, DC 20001, www.AGA.org.
Clearances5. Rear Sides
Combustible 6” 10”
Standard Oven Non-combustible 0” 0”
Convection Oven Non-combustible Min. 4” 0”
For proper combustion, install equipment on adjustable6.
legs or casters provided with unit.
For proper combustion, install equipment on adjustable7.
legs or casters provided with unit.
NOTE: In line with its policy to continually improve its product,
Wolf Range Company reserves the right to change materials
and specifications without notice.
Specify type of gas when ordering. Specify altitude when
above 2,000 feet.
INSTALLATION INSTRUCTIONS
TOP
CONFIGURATION MODEL NUMBER DESCRIPTION TOTAL INPUT BTU / HR SHIPPING WEIGHT LBS / KG
C48SS-8 8 Burners / 2 Standard Ovens 280,000 680 / 309
C48SS-6FT12 6 Burners / 12” Fry Top / 2 Standard Ovens 240,000 720 / 327
C48SS-4FT24 4 Burners / 24” Fry Top / 2 Standard Ovens 200,000 740 / 336
C48SS-2FT36 2 Burners / 36” Fry Top / 2 Standard Ovens 160,000 770 /350
