USE & CARE GUIDE
Cooktop Low-Profile Ventilation Hoods

mportant Note
To ensure the safe and efficient use of Wolf equipment,
please take note of the following types of highlighted
information throughout this guide:
IMPORTANT NOTE highlights information that is
especially important.
CAUTION signals a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
Contents
Wolf Cooktop ow-Profile Ventilation Hoods . . . . . . . . 3
SafetyInstructions ............................4
Cooktop ow-Profile Hood Features . . . . . . . . . . . . . . 6
Cooktop ow-Profile Hood Operation . . . . . . . . . . . . . 8
Cooktop ow-Profile Hood Care . . . . . . . . . . . . . . . . . . 9
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . 13
ServiceInformation...........................14
WolfWarranty ...............................15
Features and specifications are subject to change at any time
without notice. Visit our website, wolfappliance.com for the
most up-to-date information.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.

f serivce should become necessary, you will need the
model and serial numbers of the cooktop low-profile hood.
Both numbers are listed on the product rating plate,
located on the underside of the hood, above the grease
filter. The filter must be removed to access the rating
plate. Refer to the illustration below.
IMPORTANT NOTE: Wolf cooktop low-profile hoods are
recommended for use with Wolf induction, electric and
gas cooktops and integrated modules. For ranges and
rangetops, a Wolf pro ventilation hood is recommended.
Thank You
Your purchase of a Wolf cooktop low-profile hood attests
to the importance you place upon the quality and perform-
ance of your cooking equipment. We understand this
importance and have designed and built your ventilation
hood with quality materials and workmanship to give you
years of dependable service.
Before you begin using your ventilation hood, please take
some time to read this use & care guide. t will be to your
benefit to familiarize yourself with the safety practices,
features, operation and care recommendations for your
ventilation hood.
Your Wolf ventilation hood is protected by a warranty that
is one of the finest in the industry. Take a moment to read
the warranty statement at the end of this guide and refer
to it should service become necessary.
Wolf Cooktop Low-Profile Ventilation Hoods 3
wolfappliance.com
ocation of rating plate.
RAT NG PLATE

Safety nstructions 4
MPORTANT NSTRUCT ONS
IMPORTANT NOTE: Read all safety instructions before
using this appliance.
• Read this use & care guide carefully before using
your new ventilation hood to reduce the risk of fire,
electric shock or injury to persons.
• Ensure proper installation and servicing. This
appliance must be properly installed and grounded
by a qualified technician.
• Warranty service must be performed by a Wolf
authorized service center.
• nstallation work and electrical wiring must be done
by qualified person(s) in accordance with all applica-
ble codes and standards, including fire-rated
construction codes and standards.
• Use the ventilation hood only in the manner intended
by Wolf Appliance, nc. f you have questions,
contact us at 800-332-9513.
• Before servicing or cleaning, switch power off at the
service panel and lock the service disconnecting
means to prevent power from being switched on
accidentally. When the service disconnecting means
can not be locked, securely fasten a prominent
warning device, such as a tag, to the service panel.
• Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of
fuel burning equipment to prevent back drafting.
• Follow the heating equipment manufacturer’s guide-
line and safety standards such as those published
by the National Fire Protection Association (NFPA),
the American Society for Heating, Refrigeration and
Air Conditioning Engineers (ASHRAE) and the local
code authorities.
GENERA SAFETY REQUIREMENTS
• For general ventilating use only. Do not use this
ventilation hood to exhaust hazardous or explosive
materials and vapors.
• For best capture of cooking impurities, the bottom of
the hood should be a minimum of 30" (762) and a
maximum of 36" (914) above the countertop.
• Ducted fans must always be vented to the outdoors.
• To reduce the risk of fire, use only metal ductwork.
• To reduce the risk of fire or electric shock, do not
use this fan with any solid-state speed control
device.
• Use only with ventilation hood cord connection kits
that have been investigated and found acceptable
for use with this model hood.
• When cutting or drilling into wall or ceiling, do not
damage electrical wiring or other hidden utilities.
To reduce the risk of fire and to properly exhaust
air, always duct air outside. Do not vent exhaust air
into spaces within walls or ceilings or into attics,
crawl spaces or garages.
To reduce the risk of injury, disconnect the power
supply before servicing. This hood is equipped with
an integral disconnecting switch located inside the
blower housing. Refer to page 13.

TO REDUCE THE RISK OF INJURY TO PERSONS IN
THE EVENT OF A COOKTOP GREASE FIRE, OBSERVE
THE FO OWING:
• Smother flames with close-fitting lid, cookie sheet,
or metal tray, then turn off the burner. Be careful to
prevent burns. f the flames do not go out immedi-
ately, evacuate and call the fire department.
• Never pick up a flaming pan—you may be burned.
• Do not use water, including wet dishcloths or towels
—a violent steam explosion will result.
USE AN EXTINGUISHER ON Y IF:
• You know you have a class ABC extinguisher and
you already know how to operate it.
• The fire is small and contained in the area where it
started.
• The fire department is being called.
• You can fight the fire with your back to an exit
(NFPA fire safety tips).
Safety nstructions 5
wolfappliance.com
MPORTANT NSTRUCT ONS
GENERA SAFETY REQUIREMENTS
• Do not repair or replace any part of this appliance
unless specifically recommended in this guide. All
other service should be performed by a qualified
technician.
• This ventilation hood is equipped with a thermostat
which may start the blower automatically. To reduce
the risk of injury and to prevent power from being
switched on accidentally, switch power off at service
panel and lock or tag service panel.
• Avoid using food products that produce flames
under the ventilation hood.
• This product may have sharp edges. Be careful to
avoid cuts and abrasions during installation and
cleaning.
TO REDUCE RISK OF COOKTOP GREASE FIRE:
A) Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on
low or medium settings.
B) Always turn hood on when cooking at high heat
or when flambeing foods (i.e. Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambé).
C) Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or filter.
D) Use proper pan size. Always use cookware
appropriate for the size of the surface element.

Cooktop Low-Profile Hood Features 6
Low-Profile Wall Hood Features
•Heavy-duty, stainless steel seamless construction.
•500 CFM internal blower included with ( ) models.
•n-line or remote blower options for models CTEWH36
and CTEWH45.
•Telescopic flue fits 8' to 9' ceilings.
•Front-mounted electronic controls with digital indicator
and four-speed blower control.
•Heat sentry to automatically turn unit on when heat is
sensed and to adjust blower speed.
•Halogen lighting with three settings.
•Delay-off feature to automatically turn unit off.
•Filter clean indicator.
COOKTOP OW-PROFI E WA HOOD
Model CTEWH36 shown.
Front mounted
electronic controls
Telescopic
chimney flue
Halogen lighting Digital indicator
Contemporary
low-profile design
Heavy-duty stainless
steel construction
Aluminum mesh
grease filter(s)
•Stainless steel filter cover(s) with dishwasher-safe
aluminum mesh filter(s).
•Transition with backdraft damper.
•UL listed to US and Canadian safety standards.
•Two and five year residential warranty.

Cooktop Low-Profile Hood Features 7
wolfappliance.com
Low-Profile sland Hood Features
•Heavy-duty, stainless steel seamless construction.
•500 CFM internal blower included.
•Telescopic flue fits 8' to 9' ceilings.
•Front-mounted electronic controls with digital indicator
and four-speed blower control.
•Heat sentry to automatically turn unit on when heat is
sensed and to adjust blower speed.
•Halogen lighting with three settings.
•Delay-off feature to automatically turn unit off.
•Filter clean indicator.
•Stainless steel filter covers with dishwasher-safe
aluminum mesh filters.
•Transition with backdraft damper.
•UL listed to US and Canadian safety standards.
•Two and five year residential warranty.
Front mounted
electronic controls
Telescopic
chimney flue
Contemporary
low-profile design
Heavy-duty stainless
steel construction
Optional Accessories
Optional accessories are available through your Wolf
dealer. To obtain local dealer information, visit the locator
section of our website, wolfappliance.com.
•n-line and remote blowers for wall hood models
CTEWH36 and CTEWH45.
•30" high stainless steel wall shield for wall hoods.
•Recirculating kit and filter for non-ducted applications
(internal blower models).
COOKTOP OW-PROFI E IS AND HOOD
Model CTE H42 shown.
Halogen lighting Digital indicator
Aluminum mesh
grease filters

Cooktop Low-Profile Hood Opertation 8
Heat Sentry Feature
The heat sentry feature turns the ventilation hood on when
heat is sensed and adjusts the blower speed automati-
cally. The heat sentry feature is activated when the
exhaust from the hood reaches a threshold temperature
and deactivated when the exhaust temperature decreases.
f the blower is off, it automatically turns the blower on to
H GH speed. f the blower is on at a lower speed setting, it
will automatically adjust to H GH speed. When the temper-
ature level drops, it adjusts the blower back to the setting
on the blower control.
IMPORTANT NOTE: The heat sentry thermostat can start
the blower even if the hood is turned off. When this
occurs, the blower cannot be turned off by the hood
controls. f you must turn off the blower, do it from the
main electrical panel.
Hood Controls
The Wolf cooktop low-profile hood is operated using the
touch control pads on the front face of the hood. Refer to
the illustration below.
) L GHTS. Touch the pad once to turn the lights ON,
touch a second time to turn the lights ON to a brighter
level and touch a third time to turn the lights OFF.
1) A touch activates the blower motor at the first speed
(icon is illuminated). Press the pad for about two
seconds to turn the blower OFF.
2) Activates the blower at the second speed.
3) Activates the blower at the third speed.
4) Activates the blower at the fourth speed.
A) Touch the pad to set a T MER which keeps the blower
operating at the current speed for 10 minutes.
F) F LTER. After 30 hours of operation, the icon is illumi-
nated to indicate that the grease filter(s) must be
cleaned. After 120 hours, the icon flashes to indicate
that the grease filter(s) must be cleaned and the
charcoal filter replaced. To reset the hour counter,
touch (F) while the icon is illuminated or flashing.
Hood controls.

Cooktop Low-Profile Hood Care 9
wolfappliance.com
Halogen Lighting
Wolf cooktop low-profile hoods have halogen lighting with
three settings. Halogen bulbs are included with the hood.
IGHT BU B REP ACEMENT
For replacement, cooktop low-profile hoods require type
T4, 12V, 20 W halogen bulbs available at hardware stores
or through your authorized Wolf dealer. For local dealer
information, visit the find a showroom section of our
website, wolfappliance.com.
IMPORTANT NOTE: Use a paper towel when handling the
replacement halogen bulb to keep oil on fingers from
touching the bulb. Failure to do this will shorten the life of
the bulb.
1) Turn off the blower and lights and allow the halogen
bulb to cool before replacing.
2) Open the light cover by pressing in on the slots as
shown in the illustration below. Remove the old
halogen bulb by pulling it straight out of the socket.
3) Using a paper towel to handle the new halogen bulb,
insert the bulb into the socket. Place the light cover
back onto the light assembly.
HALOGEN
LIGHTING
LIGHT
COVER
ight bulb replacement.
Use caution when handling light bulbs. Halogen bulbs
get hot instantly and adjacent parts may retain heat.

GREASE FI TER REMOVA
To access the grease filter(s), gently pull down on the front
edge of the bottom panel and allow it to rotate downward
as shown in the illustration below. Push the handle for the
filter outward and pull the filter downward to remove.
The aluminum mesh filters and stainless steel covers are
dishwasher safe and are designed to fit most dishwashers.
Place the filter(s) and filter cover(s) into the dishwasher at
approximately 140°F (60°C), or hand wash, and use a
biodegradable detergent. When dry, reinstall using the
reverse procedure.
IMPORTANT NOTE: Do not operate the ventilation hood
without the grease filter(s). This may cause damage to the
blower or other internal components of the hood.
Cooktop Low-Profile Hood Care 10
Grease Filters
The aluminum mesh grease filters should be cleaned
approximately every month, depending on use. The (F)
touch pad of the hood controls will illuminate to indicate
when the filter(s) should be cleaned. This indicator light
comes on after approximately 30 hours of operation. To
reset the hour counter, touch the (F) touch pad while the
icon is illuminated. You may need to clean the filter(s)
more often if your cooking style generates large amounts
of grease, like frying foods or wok cooking.
The grease filters and filter covers are dishwasher safe
and are designed to fit most dishwashers.
GREASE
FILTER
Grease filter removal.

CHARCOA FI TER REMOVA
First remove the grease filter(s) as discribed on the
previous page. Then remove the charcoal filter as shown
in illustration below. Push the catch towards the inside
and turn the charcoal filter so that the two filter clips slip
out of their seats. nstall the new charcoal filter using the
reverse procedure.
Cooktop Low-Profile Hood Care 11
wolfappliance.com
Charcoal Filter
RECIRCU ATING APP ICATION
f the ventilation hood is used in a recirculating or non-
ducted application, the charcoal filter must be replaced at
regular intervals. The (F) touch pad of the hood controls
will flash to indicate when the charcoal filter needs to be
replaced. This indicator light flashes after approximately
120 hours of operation. To reset the hour counter, press
the (F) touch pad while the icon is flashing.
IMPORTANT NOTE: Resetting the 120 hour counter for the
charcoal filter will not affect the 30 hour counter for the
grease filter.
Replacement charcoal filters are available through your
authorized Wolf dealer. For local dealer information,
visit the find a showroom section of our website,
wolfappliance.com.
GREASE
FILTER
CHARCOAL
FILTER
Charcoal filter removal.

Cooktop Low-Profile Hood Care 12
CONTRO S
Use a spray degreaser to remove fingerprints and greasy
spatters. Spray on a cloth and wipe the surface. Use a
clean cloth or sponge and wipe the surface with warm
water and a mild detergent. Rinse and dry immediately.
GREASE FI TERS
The aluminum mesh filters and stainless steel filter covers
should be cleaned approximately every month, depending
on use. You may need to clean the filters more often if
your cooking style generates large amounts of grease, like
frying foods or wok cooking.
The filters and filter covers are dishwasher safe and are
designed to fit most dishwashers. Wolf recommends
wiping filters and filter covers to remove any excess
grease before placing in the dishwasher. Refer to filter
removal on page 10.
Care Recommendations
STAIN ESS STEE EXTERIOR
IMPORTANT NOTE: Do not use abrasive cleaners; they will
permanently scratch stainless steel surfaces. Salt and
some cooking liquids may pit and stain the surface.
Remove these spatters immediately.
Use a spray degreaser to remove fingerprints and greasy
spatters. Spray on a cloth and wipe the surface. Buff dry
immediately to avoid streaking. For hard water stains, use
white vinegar and water.
For general cleaning, use a soft, nonabrasive stainless
steel cleaner like Signature polish and apply with a soft
lint-free cloth. To bring out the natural luster, lightly wipe
the surface with a water-dampened microfiber cloth
followed by a dry polishing chamois. All work should
follow the grain direction of the finish. Better results are
obtained by keeping the cloth in continuous contact with
the stainless steel.
Signature polish is available from Signature Limited
Laboratory, P. O. Box 13436, Dayton, Ohio 45413, or call
877-376-5474.

Troubleshooting Guide 13
wolfappliance.com
Troubleshooting
f your Wolf ventilation hood is not operating properly, use
the following troubleshooting guide before calling your
Wolf authorized service center. This guide will save you
time and trouble and may help you avoid the expense of a
service call.
Ventilation hood does not operate.
•Check the household fuse or circuit breaker to see if it
has been blown or tripped. A power outage may also
have caused a disruption in service.
•No electricity is being supplied to the ventilation hood.
Have an electrician verify that the hood is connected to
a proper electrical circuit.
Blower runs but lights do not operate.
•Check the light bulbs to see if they have burned out.
DISCONNECTING
SWITCH
ocation of disconnecting
switch.
DISCONNECTING SWITCH
IMPORTANT NOTE: To reduce the risk of injury, disconnect
the power supply before servicing. This hood is equipped
with an integral disconnecting switch located inside the
blower housing. Refer to the illustration below.

Service nformation 14
Service nformation
When requesting information, literature, replacement parts
or service, always refer to the model and serial number of
your ventilation hood. This information is found on the
product rating plate located on the underside of the hood,
above the grease filter. The filter must be removed to
access the rating plate. Refer to the illustration on page 3.
Record the rating plate information below for future
reference.
BEFORE CA ING FOR SERVICE
Before calling a Wolf authorized service center, refer to the
troubleshooting guide on page 13.
PRODUCT REGISTRATION
Register your new Wolf product today so that we may
ensure your satisfaction. You may register by one of the
following options:
1) Mail in the completed Wolf product registration card.
2) Register online at wolfappliance.com.
3) Register by phone by calling Wolf customer service at
800-222-7820.
The model and serial numbers of your unit are printed on
the enclosed Wolf product registration card. f you provide
us with your e-mail address, we will send you exciting new
product updates and recipes as they become available,
along with information on special events.
Model Number:
Serial Number:
nstallation Date:
Wolf Authorized Service Center:
Phone:
Authorized Wolf Dealer:
Phone:
The information and images in this guide are the copyright property of Wolf Appliance, nc. Neither this guide nor any information or images contained herein
may be copied or used in whole or in part without the express written permission of Wolf Appliance, nc. ©Wolf Appliance, nc. all rights reserved.
Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, nc.
Sub-Zero, Sub-Zero & Design, Dual Refrigeration, Constant Care and The Living Kitchen are registered trademarks and service marks of Sub-Zero, nc.
(collectively, the “Company Marks.”) All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.

Wolf Appliance Products Limited Warranty
RES DENT AL USE ONLY
FU TWO YEAR WARRANTY*
For two years from the date of original installation, your Wolf Appliance product warranty covers all parts and
labor to repair or replace any part of the product that proves to be defective in materials or workmanship. All
service provided by Wolf Appliance under the above warranty must be performed by a Wolf authorized service
center, unless otherwise specified by Wolf Appliance. Service will be provided in the home during normal
business hours.
IMITED THIRD THROUGH FIFTH YEAR WARRANTY
From the third through fifth year from the date of original installation, Wolf Appliance will repair or replace the
following parts that prove to be defective in materials or workmanship: gas burners (excluding appearance),
electric heating elements, blower motors (ventilation hoods), electronic control boards, magnetron tubes and
induction generators. Labor to remove and replace defective parts is not covered. Wolf Appliance recommends
that you use a Wolf authorized service center to perform such service.
IMITED IFETIME WARRANTY
For the life of the product, Wolf Appliance will repair or replace any outdoor gas grill body or hood that rusts
through due to defective material or workmanship. Labor to remove and replace defective parts is not covered.
Wolf Appliance recommends that you use a Wolf authorized service center to perform such service.
TERMS APP ICAB E TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only to products
installed in any one of the fifty states of the United States, the District of Columbia or the ten provinces of
Canada. This warranty does not cover any parts or labor to correct any defect caused by negligence, accident
or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ON Y ONES THAT WO F APP IANCE,
INC. WI PROVIDE, EITHER UNDER THIS WARRANTY OR UNDER ANY WARRANTY ARISING BY OPERATION
OF AW. WO F APP IANCE, INC. WI NOT BE RESPONSIB E FOR ANY CONSEQUENTIA OR INCIDENTA
DAMAGES ARISING FROM THE BREACH OF THIS WARRANTY OR ANY OTHER WARRANTY, WHETHER
EXPRESS, IMP IED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have
other legal rights that vary from state to state.
To receive parts and/or service and the name of the Wolf authorized service center nearest you, contact
Wolf Appliance, nc., P.O. Box 44848, Madison, W 53744; check the contact & support section of our website,
wolfappliance.com or call 800-332-9513.
*Stainless steel doors, panels, handles, product frames and interior surfaces are covered by a limited 60-day
parts and labor warranty for cosmetic defects.

WO F APP IANCE, INC. P. O. BOX 44848 MADISON, WI 53744 WO FAPP IANCE.COM 800.332.9513
817000 REV-A 5/2010
