Wolfgang Puck Bistro BFPR0007 Installation instructions

Wolfgang Puck
IMPORTANT NOTICE
PLEASE DO NOT RETURN TO STORE.
If you have any problems with this unit,
contact Consumer Relations for service
PHONE: [phone] or
visit our website at www.wphousewares.com
Please read operating instructions
before using this product.
Please keep original box and packing materials
in the event that service is required.
W.P. APPLIANCES, INC. Toll Free [phone]
Model BFPR0007 Printed in China REV 3.0
All trademarks, service marks and trade names (collectively the “Marks”) are proprietary
to Wolfgang Puck World Wide.
7 Cup Food Processor
Use and Care
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 1

1 2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1Read all instructions.
2To protect against risk of electrical shock, do not put base in water
or other liquid. For detailed cleaning instructions see the section
marked ‘Care and Cleaning’ in this instruction manual.
3Close supervision is necessary when any appliance is used by or
near children.
4Unplug from outlet when not in use, before putting on or taking off
parts, before removing food and before cleaning. To unplug, grasp
plug and pull from electrical outlet. Never pull cord.
5Blades are sharp. Handle them carefully.
6Do not use outdoors.
7Do not let cord hang over edge of table or counter, or touch
hot surfaces.
8Do not operate any appliance with a damaged cord or plug, or
after appliance has been dropped or damaged in any way. Return
appliance to the nearest authorized service facility for examination,
repair or electrical or mechanical adjustment.
9Keep hands as well as spatulas and other utensils away from moving
blades or discs while processing food, to prevent the possibility of
severe personal injury or damage to food processor. A spatula may
be used, but must be used only when food processor is not running.
10 Never feed food by hand. Always use food pusher.
11 Avoid contact with moving parts.
12 Make sure motor has completely stopped before removing cover.
Never use the cover interlock as a means of turning on or shutting
off the motor. Only use the On button or Pulse button to operate
this appliance.
13 To reduce the risk of injury, never place cutting blade or discs on
base without putting bowl properly in place. Store blades and discs
as outlined in this instruction manual and keep the appliance out of
reach of children.
14 Be sure cover and feed tube are securely locked in place before
operating food processor.
15 Never try to override or tamper with cover interlock mechanism.
16 Do not operate this, or any other motor-driven appliance, while
under the influence of alcohol or other substances that affect your
reaction time or perception.
17 The use of attachments not recommended or sold by WP
Appliances, Inc. specifically for this model may cause fire, electrical
shock, personal injury, or damage to your food processor.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SHORT POWER CORD
A short power-supply cord is provided to reduce the hazards resulting
from entanglement or tripping over a longer cord. An extension cord
may be used with care; however, be sure the marked electrical rating is
at least as great as the electrical rating of this appliance. The extension
cord should be positioned such that it does not drape over the counter
or table top where it can be pulled on by children or tripped over.
The electrical rating of this appliance is listed on the bottom panel of
the unit.
POLARIZED PLUG
This appliance has a polarized plug (one prong is wider than the other).
To reduce the risk of electric shock, this plug will fit into a polarized
outlet only one way. If the plug does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not
modify the plug in any way.
Do not attempt to defeat this safety feature by
modifying the plug in any way.
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 1

3
Additional Safety Precautions
If you have any concerns regarding the performance and use of
your appliance, please visit www.wphousewares.com or contact the
Wolfgang Puck Consumer Service Line at 800-275-8273.
• Always use extreme care when handling Processing Blades and
cutting discs. These are extremely sharp and may cause injury if
handled incorrectly. Always store Processing Blades and cutting
discs as referenced in the section “Storing Your Food Processor”.
• Unplug from power outlet when not in use, before putting on or
taking off attachments, and before cleaning.
• Do not put hot liquids into the food processor, warm liquids are
acceptable.
• Avoid contacting moving parts at all times.
• Place the processor bowl onto the base of the processor before
fitting any attachments.
• All blades and attachments should be removed with care
before cleaning.
• Do not overfill the processor. The maximum level for the 7 cup work
bowl is 3 cups of liquid, or 6 cups of solids. The maximum level for
the mini-bowl is 1/2 cup of liquid, or 1 cup of solids.
• Always remove the blade before emptying the processor bowl of
its contents.
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 3

5 6
Table of Contents
Important Safeguards 1
Additional Safety Precautions 3
About Wolfgang Puck 5
Know Your Food Processor 7
Attachments for Your Food Processor 9
Before Your First Use 1 1
Assembling Your Food Processor 1 1
Assembling Your Attachments 12
Using Your Mini Bowl 14
Using Your Food Processor 14
Storing Your Food Processor 15
Helpful Hints 17
Disassembly 19
Care and Cleaning 20
Troubleshooting 21
Appetizers, Salads & Entreés 23
Pizzas 44
Sauces and Dressings 51
Dough and Crust 66
Desserts 78
Limited Warranty 90
Wolfgang Puck,
owner of the famous
Spago restaurants and
one of the most influential
chef-restauranteurs in
America, is credited with
reviving California’s rich
culinary heritage. His
cooking innovations, a
result of blending fresh
California ingredients with his classical French techniques, are
enjoyed by world leaders, stars and fellow chefs alike. He established
other trend-setting restaurants like Postrio in San Francisco, Chinois
on Main in Santa Monica, Trattoria del Lupo, Cut, and his latest
creation, Jai, an Asian fusion restaurant in San Diego. Home chefs can
also share Mr. Puck’s talents through his cookbooks, cutlery,
cookware and, of course, through his appliances!
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 5

7 8
Processing cover
The processing cover activates the
automatic safety system. The Food
Processor will not operate unless the cover
is correctly positioned on the processing
bowl and locked into place.
Food pusher
Guides food evenly down the feed tube
and can also be used to close the chute
while processing to prevent food from
escaping through the feed tube.
Feed tube
The feed tube is used to guide ingredients
down into the selected blades and allows
you to add ingredients during other
processing tasks.
Spindle
Drives all the food processing
attachments. The Spindle must be in
place to operate the food processor.
Processing bowl
The liquid-sealed processing bowl
achieves a large working capacity due to
the liquid seal around the base of the
drive shaft and the lip of the lid.
Cord storage facility
For added convenience the unused cord
length can easily be pushed into the base
of the processor for storage.
Non-slip feet
Keeps the food processor secure on the
countertop during use.
640 watt induction motor
The base houses a powerful 640 watt motor,
which provides great processing results
every time. Ideal for high load applications
during processing. It provides greater
starting strength and maintains a constant
speed throughout. Its reliable, long life and
quiet performance is backed by
a 5 year guarantee.
On / Off button
For easy use, the large ON / OFF button
starts and stops the operation of the
food processor.
Pulse
The control panel includes a Pulse
feature for optimum cutting precision
during processing.
Storage drawer
Unique drawer design
enables attachments to be
stored conveniently within
the appliance when not
in use.
Know Your Food Processor
Photos throughout manual may differ
slightly from actual product.
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 7

910
Attachments for Your
Food Processor
Processing Blade
Stainless steel smooth edged processing blade
is designed for cutting, chopping, kneading,
and whisking.
Spindle
The Spindle holds the Processing Blade, the
adjustable slicing disc as well as reversible
discs. Ensure that the Processing Blade clicks
into place over the Processing Blade Lock. To
remove, simply depress the Processing Blade
Locks on either side of the Spindle while
grasping the Processing Blade by the plastic
center and lifting up.
Reversible Shredding Disc – Fine and Coarse
Ideal control, the reversible stainless steel
shredding blades allow for the choice of fine
or coarse results.
Reversible Grating and Shaving Disc
Unique to processing is the shaving blade.
It creates thin flakes, great for parmesan and
sweet potato crisps. The other side will achieve
finely grated results, ideal for hard cheeses
and chocolate.
Attachments for Your
Food Processor
Spatula
The spatula is ideal for assisting with all food
processing tasks.
Mini Bowl and Processing Blade
(Optional accessory set must be
purchased separately)
Fits directly into the 7 cup work bowl and
is perfect for smaller batches such as spices,
garlic cloves, etc.
Variable Slicing Blade
The variable stainless steel slicing blade
allows foods to be sliced to a variety of
thicknesses, from 0mm – 7mm. You can adjust
the thickness by turning the outer center
Spindle of the blade shaft.
Optional Accessory
blade adjustment
Processing Blade Lock
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 9

11 12
Assembling Your Attachments
Warning: Use caution, as blades are
extremely sharp. Always handle all blades by
their central plastic section. Never grasp the
cutting blade itself.
Note: All attachments must be firmly attached
to the Spindle. Always adjust the attachments
until you are sure that they are correctly fitted.
Placing the Spindle
1Fit the Spindle onto the drive shaft,
see figure 4.
Processing Blade
1Fit the processor bowl and Spindle as
detailed previously in figures 1, 2 & 4.
2Remove the processing blade from the
storage drawer.
3Fit the processing blade over the Spindle
and press down on the plastic center until
the blade clicks into place. It may be
necessary to turn the blade slightly left or
right in order to fit the blade properly
onto the shaft. See figure 5.
4Place ingredients into the processing bowl.
5Fit the processing cover to the processing
bowl (see figure 3), and place the food
pusher in the feed tube.
6Plug the power cord into a 120V AC
power outlet.
7Start processing using the On/Off or
Pulse buttons.
8When processing is complete, remove the
Spindle and blade from the processing
bowl before removing the processed food.
figure 4
figure 5
Before Your First Use
Before you assemble the food processor,
ensure that the power cord is unplugged.
1Place the motor base facing you on a dry,
level surface.
2Place the processing bowl onto the motor
base, the bowl will only sit correctly on the
base when the handle is at the 3 o’clock
position, see figure 1.
3Rotate the handle clockwise to lock, as
indicated by the graphics on the left side
of the motor base. The bowl handle should
be at the 6 o’clock position, see figure 2.
4Position the lid onto the processing bowl.
You will notice an arrow on the lid in front
of the feed tube. When placing the lid onto
the bowl this arrow needs to align with the
arrow on the handle of the bowl. To lock,
turn the lid clockwise, as indicated by the
graphics on the top of the handle, until it
snaps into place. See figure 3.
figure 1
figure 2
figure 3
Prior to using your Food Processor, wash all parts as outlined in the
section “Care and Cleaning.”
Assembling Your
Food Processor
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 11

13 14
Using Your Food Processor
Important: If the processing bowl and cover are not correctly
assembled, the Food Processor will not function.
1Plug the power cord into a 120V AC power.
2Using the On/Off button on the control panel, press once to start
processing. The Pulse function remains on as long as the Pulse
button is pressed down. Further ingredients can also be added while
processing by pouring through the feed tube once the food pusher
has been removed.
3After you have completed processing, press the On/Off button to
stop processing.
Note: For maximum control load the feed tube first before turning on
your food processor. Always use the food pusher for more evenly
processed foods and never use your fingers.
Important: The Food Processor is fitted with a safety thermal cut-out
device and will shut off in the event of overload. If this occurs, press the
Off button to turn the power off and unplug the food processor from
the wall outlet. Wait 15 minutes and then restart.
Assembling Your Attachments
Reversible Grating, Shaving
and Shredding Blades
1Fit the processor bowl and Spindle as
detailed previously, in figures 1, 2 and 4.
2Select the ‘Reversible’ disc of your choice
- Shredding (fine or coarse), Grating or
Shaving, and fit over the Spindle. See
figure 6.
Warning: Use caution as the blades are sharp.
4Fit the processing cover to the processing
bowl as previously shown in figure 3 and
place the food pusher in the feed tube.
5Plug the power cord into a 120V AC
power outlet.
6Start processing using the On/Off or
Pulse buttons.
7When processing is complete, remove the
disc and Spindle from the processing bowl
before removing the processed food.
figure 6
figure 7
continued
Using Your Mini Bowl
(Optional Accessory - Sold Separately)
1Fit the processor bowl and Spindle as detailed previously,
in figures 1, 2 and 4.
2Place the Mini Bowl over the Spindle of the Food Processor
3Place the Mini Processing blade over the center shaft of the Mini
Processing bowl.
4Fit the processing cover to the processing bowl as previously shown
in figure 3 and place the food pusher in the feed tube.
5Plug the power cord into a 120V AC power outlet.
6Start processing using the On/Off or Pulse buttons.
7When processing is complete, remove the Mini Processing blade
from the mini bowl before removing the processed food.
Note: You can store your ingredients in the Mini Bowl by placing the Mini
Bowl lid over the bowl and pressing the center of the lid until it snaps
into place. The lid of the mini bowl will not snap into place unless the
mini blade has been removed.
Variable Slicing Blade
1Fit the processor bowl and Spindle as detailed previously in figures
1, 2 and 4.
2Fit the slicing disc over the Spindle, see figure 7.
Warning: Use caution as the blades are sharp.
3The Slicing blade will adjust from 0 - 7mm in thickness. To adjust
the Slicing Blade, hold the blade by grasping the finger hole and
turn the center Spindle to the desired thickness. See figure 2.
4Fit the processing cover to the processing bowl as previously shown
in figure 3 and place the food pusher in the feed tube.
5Plug the power cord into 120V AC power outlet.
6Start processing using the On/Off or Pulse buttons.
When processing is complete, remove the disc and Spindle from the
processing bowl before removing the processed food.
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 13

15 16
Storing Your Food Processor
Processing Bowl storage
1Fit the Processor Bowl and Spindle as detailed previously,
in figures 1, 2 and 4.
2Place the Variable Slicing blade over the Spindle, see figure 7,
and then fit the processing cover to the processing bowl as
previously shown in figure 3.
3Place the food pusher in the feed tube.
Cord storage
The power cord can be stored by pushing it into the back of the
motor base.
continued
Storing Your Food Processor
The Wolfgang Puck Food Processor was
designed so that all attachments can be stored
within the unit itself.
Storage Drawer
The Processing Blade, Reversible Shredding
Disc, Reversible Grating and Shaving Disc and
Spatula are all stored in the storage drawer.
(The Spindle and Variable Slicing Disc are
stored in the Processing Bowl. See next page.)
1Remove the storage drawer from the base
of the food processor.
2Place the elevated end of the Processing
Blade toward the front of the storage
drawer as indicated in figure 8, and
press down.
3Place one of the Reversible Discs in
storage drawer as indicated in figure 9.
4Lie spatula on top of Reversible Disc in the
storage drawer as indicated in figure 10.
5Place the remaining Reversible Disc in
storage drawer as indicated in figure 11.
6Your food processor drawer is now
properly assembled, as shown in figure 12.
figure 8
figure 9
figure 10
figure 11 figure 12
HSN_7CupFoodProcManual 4/20/09 10:50 AM Page 15

17 18
Helpful Hints
figure 13 figure 14
• The most important factor for successful slicing and shredding is the
way in which the food is packed into the feed tube. To prepare shorter
slices, pack the food items vertically in the feed tube, see figure 13. To
prepare longer slices, pack food items horizontally in the feed tube,
see figure 14.
continued
Helpful Hints
• For consistent results, you should try to process pieces of food that are
approximately equal in size. When you break, cut or tear food into
uniform pieces before you begin processing, the finished results will be
more uniform. More consistent processing results are achieved if the
container is not overloaded.
• Pre-cut meat into cubes approximately 1” square. It is best to
process very cold meat (not frozen). Always use the Pulse button in
2 second increments.
• When processing vegetables such as onions, peel and quarter or cut
large vegetables into eighths.
• When processing herbs or garlic cloves, best results are achieved when
using the Mini Bowl. Herbs must be dry prior to processing.
• The quantities that can be processed within the Processing Bowl will
vary with the density of the mixture.
• When various recipes require dry ingredients such as flour, add them
directly into the Processing Bowl before processing. There is no need
to sift ingredients when using your food processor. Liquid ingredients
may be added while the processor is operating by pouring through the
Feed Tube in the processor cover.
• When processing sauces or semi-liquid ingredients, stop the food
processor and scrape down the container sides with the spatula
provided.
• When slicing, shredding and grating, cut all ingredients to a size that
fits comfortably into the Feed Tube. Pack the feed tube and, while
holding food steady and upright with the food pusher, press down
evenly until all ingredients are sliced or shredded. Do not use excessive
force or you may damage the food processor.
• For best results, please follow the dough recipes and pasta recipes
exactly to create the best consistency and results.
Warning: Never use fingers to push food down the feed tube. Always
use the food pusher.
• For best results when slicing, the Feed Tube should always be packed
firmly to allow each piece of food to support the others. There will
always be a small portion of food left unprocessed between the food
pusher and the blade. When using the Variable Slicing Disc, excessive
force will cause food to be sliced unevenly. Only slight pressure is
needed from the food pusher when using this attachment.
• For best results when shredding and grating remember that softer
foods such as cheese (cheddar, mozzarella or swiss) should be well
chilled (not frozen) before processing. Harder foods such as Parmesan
or Romano cheese should be at room temperature before processing.
Never attempt to shred or grate cheese that cannot be pierced with a
fork or a knife tip.
HSN_7CupFoodProcManual 4/20/09 10:51 AM Page 17
