Woodbridge Bid 01 User manual

WOODBRIDGE

20220630 REV. 1

Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Paciﬁc Time)

Or Email: [email protected]

www.woodbridgebath.com

Installation Manual

WOODBRIDGE

ELECTRONIC TOILET SEAT

●Thank you for choosing our products.Please read the instructions carefully before

installation and keep it available for future maintenance or reference.

●Our company reserves the right of final interpretation for this manual.

The manual is subject to change without notice.

INSTALLATION MANUAL BID 01

WOODBRIDGE

www.woodbridgebath.com

WOODBRIDGE IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USING

When using electrical products, especially when children are present, basic safety

precautions shouldalways be followed, including the following:

1.The appliance is not to be used by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction.

2.Children being supervised not to play with the appliance.

3.This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved.

4.Children shall not play with the appliance.

5.Cleaning and user maintenance shall not be made by children without supervision.

DANGER–To reduce the risk of electrocution:

1. Do not use while bathing.

3. Do not place in or drop into water or other liquid.

4. Do not reach for a product that has fallen into water. Unplug immediately.

5. Do not wash the main unit or electrical plug with water or detergent.

6. Do not handle the electrical plug with wet hands.

7. Do not put a hand or other staff over the outlet of air dryer or block the outlet of air dryer.

8. Never disassemble,repair or modify this product.

9. During installation, disassembly, repaire and maintenance of the product,the power plug

must be switched off and water supply be shut off.

WARNING–To reduce the risk of burns, electrocution, fire, or injury to persons.

1. Close supervision is necessary when this product is used by, on, or near children or

invalids.

2. Use this product only for its intended use as described in this manual. Do not use

attachments not recommended by the manufacturer.

3. Never operate this product if it has a damaged cord or plug, if it is not working properly,

if it has been dropped or damaged, or dropped into water. Return the product to a

service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never use while sleeping or drowsy.

6. Never drop or insert any object into any opening or hose.

7. Do not use outdoors or operate where aerosol (spray) products are being used or

where oxygen is being administered.

8. Connect this product to a properly grounded outlet only. See Grounding Instructions.

9. Do not throw cigarettes and other burning stuff into toilet, otherwise it might cause fire.

10.This product is electric appliance, so it must be placed far away from water. Please

don’t drench urine and other liquid to it.

11.Do not lay on side or upside the product during the electrical circuit.

12.It is prohibited to use other electric appliances in the same socket.

13.It is forbidden to use the power extension or unstable loose outlet.

14.The old aging water supply hose can not be used, otherwise it might cause leakage,

fire or electrical shock.Installation of the bidet seat should include specified components

and new water supply hose.

2. Do not place or store product where it can fall or be pulled into a tub or sink.

WOODBRIDGE

www.woodbridgebath.com 2

WOODBRIDGE

CAUTION–

DANGER –

IMPORTANT SAFETY INSTRUCTIONS

Indicates that failure to follow the instruction may cause body injury or

property damage.

GROUNDING INSTRUCTIONS

Improper use of the grounding plug can result in a risk of electric shock.

SAVE THESE INSTRUCTIONS

1. Do not install or use the product in wet places as steam room etc.This product must be

connected to properly grounded power outlet socket.

2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place

where is not easily got wet.

3. This product should be used with AC 110V-120V,50/60Hz electrical current only,load current

is at least 15A. P ower plug must be equipped with ground fault circuit interrupter or ground

fault electrical leakage protector or similar high sensitive, rapid type leakage switch

(Rated sensitive current under 6mA).

4. When it thunders,it is strongly recommended to pull out the power plug.

5. Do not stand on ceramic toilet.

6. Ceramic toilet must install floor fixing bolt.

7. Do not stand on product unit,seat and cover.

8. Do not lean against the seat cover when using the product,to avoid damage.

9. This product is equipped with soft-closing seal cover.Heavy pressing or pushing may damage

the soft-closing damper.

10. Do not use lacquer thinner,petrol,liquid medicine,detergent,insecticide,toilet cleanser and

scrubbing brush to clean the product.

11.Exposure to direct sunlight is prohibited.

12.Only use tap water or potable water;otherwise it may cause chafing.

13.Do not connect water supply to heater outlet.Make sure inlet water temperature at 3~35˚C

14.When the room temperature is under zero degree,please dry up the water tank,to avoid

freezing.

15.Raise rest room temperature to prevent the toilet from damage due to freezing.

16.When move the product from cold or wet environment into normal room temperature,wait for

2 hours until the condensation water is fully volatilized.Doing so can prevent the product from

electrical short-circuit.

17.When not using the product over three(3) days,drain the water out of the container and pull

the elelctrical plug from the wall outlet.

18.Stop using the product and shut off the power when product malfunctions,please contact the

service people for professional service.

This product should be grounded. In the event of an electrical short circuit, grounding reduces

the risk of electric shock by providing an escape wire for the electric current. This product is

equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged

into an outlet that is properly installed and grounded.

If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to

either flat blade terminal. The wire with insulation having an outer surface that is green with or

without yellow stripes is the grounding wire.

This product is factory equipped with a specific electric cord and plug to permit connection to a

proper electric circuit. Make sure that the product is connected to an outlet having the same

configuration as the plug. No adapter should be used with this product. Do not modify the plug

provided — if it will not fit the outlet, have the proper outlet installed by a qualified electrician. If

the product must be reconnected for use on a different type of electric circuit, the reconnection

should be made by qualified service personnel.

WOODBRIDGE

3www.woodbridgebath.com

WOODBRIDGE TECHNICAL SPECIFICATION

600ml

Container capacity

1000W

250W

50W

Rating power

Main Unit

Rating pressure

Water pressure

range

Electrical wire length is about 1.8m

Minimum water pressure 0.07MPa (20L/min. flowing pressure).

Maximum water pressure 0.8MPa (Hydrostatic pressure)

1050-1250W

110-120V,50/60Hz

Heating power

Water

temperature

ater volume

Cleansing mode

Spray cleansing

location

Water pressure

protector

Cleaning

device

Anti-fouling device

Safety device

6 different level adjustment

5 different level adjustment

Rear cleaning/Rear massage,Front cleaning for ladies

Pressure stabilize,Automatic pressure discharging

Warm wind speed

Warm wind

temperature

Heating power

Safety device

Drying

device

6 different level adjustment

Over 4 M/S

Temperature sensor, Temperature controller, Thermal fuse

Temperature controller, Thermal fuse, Ground protection,

Leakage protection device, Air burning preventer

Heated seat

Surface

temperature

Heating power

Open and close

device

Heated burning

protection

Safety device

Quiet soft-closing device

The seat temperature will automatically lower to level

1 in 10 minutes after using

Intelligent

Night light

assembly

Mute setting

Intellignt,often in the off state

Buzzeroff during night

User ID setting To avoid disturbance from remote controls by multi-user

5 different level adjustment

Speedy water discharge device, Automatic nozzle cleaning,

Anti-syphon device, Anti-backflow device, Filter device

Seat sensor,

Temperature sensor

, Temperature controller,

Thermal fuse

WOODBRIDGE

www.woodbridgebath.com 4

WOODBRIDGE PACKAGING LIST

STOP

NOZZLE

CLEANING

REAR FRONT DRY

MASSAGE

USER 1 USER 2

WATER

DRY SEAT

PRESSURE

POSITION

ENERGY

SAVER

Remote

Control

Panel Parts

Base Plate

Parts

Water Supply

Assembly

Installation

paperboard

Installtion

Manual

Warranty

Card Warranty Card

Installtion Manual

Installation

paperboard

Installtion

Manual

Warranty

Card

Installation

paperboard

Main Unit

pcs

Base plate
