woodmizer Titan WB2000-EC User manual

Wood-Mizer®
Safety, Setup, Operation
& Maintenance Manual
WB2000-EC rev. A1.01
Safety is our #1 concern! Read and understand
all safety information and instructions before
operating, setting up or maintining this machine.
Form #664
!
This is the original language
for this manual

4 SW-07doc013119Table of Contents
Table of Contents Section-Page
SECTION 1 INTRODUCTION 1-1
1.1 Machine description ...............................................................................1-1
1.2 Machine and site preparation..................................................................1-2
SECTION 2 SAFETY 2-1
2.1 Blade Handling.......................................................................................2-1
2.2 Sawmill Setup.........................................................................................2-2
2.3 Sawmill Operation..................................................................................2-2
SECTION 3 SAWMILL OPERATION 3-1
3.1 Control Box Overview ...........................................................................3-1
3.2 Replacing The Blade ..............................................................................3-3
3.3 Blade tension ..........................................................................................3-4
3.4 Tracking The Blade ................................................................................3-5
SECTION 4 SETUP & OPERATION 4-1
4.1 Sawmill Setup.........................................................................................4-1
4.2 Operating the Setworks controller..........................................................4-5
SECTION 5 MAINTENANCE 5-1
5.1 Wear Life................................................................................................5-1
5.2 Cleaning and Maintenance .....................................................................5-2
5.3 Power Feed .............................................................................................5-5
5.4 Belt Conveyor Alignment.......................................................................5-7
5.5 Safety Devices Inspection ......................................................................5-8
SECTION 6 ALIGNMENT 6-1
6.1. Bed Frame ..............................................................................................6-1
SECTION 7 SAWMILL SPECIFICATIONS 7-1
7.1 Belt Sizes................................................................................................7-1
7.2 Blade Sizes .............................................................................................7-1
7.3 Cutting Capacity.....................................................................................7-1
7.4 Motor Specifications ..............................................................................7-2
7.5 Noise Level.............................................................................................7-3
7.6 Overall Dimensions ................................................................................7-3
7.7 Chains.....................................................................................................7-3
7.8 Sawdust Extractor Specifications...........................................................7-4
7.9 Lube System Specifications ...................................................................7-4

Table of Contents Section-Page
Table of Contents SW-07doc0131195
SECTION 8 LASER INFORMATION 8-1
SECTION 9 MOTOR BRAKE 9-1
9.1 Motor Brake Maintenance......................................................................9-1

General Contact Information
-6 doc013119
Getting Service
Wood-Mizer is committed to providing you with the latest technology, best quality and strongest
customer service available on the market today. We continually evaluate our customers’ needs to
ensure we’re meeting current wood-processing demands. Your comments and suggestions are
welcome.
General Contact Information
From Europe call your local distributor or our European Headquarters and Manufacturing Facility in
Koło, Nagórna 114 St, Poland at [phone]. From the continental U.S., call our U.S.
Headquarter 8180 West 10th St.Indianapolis, IN 46214, toll-free at 1-800-525-8100. Ask to speak
with a Customer Service Representative. Please have your machine identification number and your
customer number ready when you call. The Service Representative can help you with questions
about the operation and maintenance of your machine. He also can schedule you for a service call.
Office Hours:
Please have your vehicle identification number and your customer number ready when you call.
Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Discover
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on size and
quantity of order.
Technical data are subject to change without prior notice.
Actual product may differ from product images. Some illustrations show machines with optional
equipment.
Country Monday - Friday Saturday Sunday
Poland 7 a.m.- 3 p.m. Closed Closed
US 8 a.m.- 5 p.m. 8 a.m.- 12 p.m Closed

Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
doc013119 -7
Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
EUROPE UNITED STATES
European Headquarters
Wood-Mizer Industries Sp. z o.o.
Nagórna 114, 62-600 Koło, Poland
Tel.: [phone]
Fax: [phone]
www.woodmizer.eu
World Headquarters
Wood-Mizer LLC
8180 West 10th Street
Indianapolis,Indiana 46214-2400,
USA
Tel.: [phone]
Fax: [phone]
www.woodmizer.com
BELARUS
MOST-GRUPP
Siemashko 15, k.3
Minsk 2200116
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
SWITZERLAND Stefan Wespi
Maschinen u. Geräte
Spezialarbeiten GmbH
Eichistraße 4
6353 Weggis
Tel.: +41-(0)41 - 3900312
GSM: +41-(0)79 - 9643594
[email protected]
RUSSIA Dariusz Mikołajewski
OOO WOOD-MIZER INDUSTRIES
141031, Moscow
Reg., Mytishenski raj., pos. Veshki,
Zavodskaja str., 3B
Tel.Fax: [phone]
Tel.Fax: [phone]
e-mail: [email protected]
BULGARIA Kalin Simeonov
Ecotechproduct
38 Star Lozenski pat str.
Sofia 1186
Tel.: [phone]
Tel.: [phone]
Tel:/Fax
: [phone]
Kalin Simeonov
GSM: [phone]
e-mail: [email protected]
HUNGARY Wiktor Turoczy
Wood-Mizer Hungary K.F.T.
Szonyi Ut 67., 2921 Komárom
Tel.:/Fax: [phone]
e-mail: [email protected]
RUSSIA Far East Wladimir Głazaczew
“WM Service”
Krasnoretchenskaya Str.111
680006 Khabarovsk
Tel.:/Fax: [phone]
e-mail: [email protected]

Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
-8 doc013119
CROATIA Krešimir Pregernik
Pregimex d.o.o.
S. Batušiæa 31, 10090 Zagreb
Tel.:/Fax: [phone]
Krešimir Pregernik
GSM: [phone]
e-mail: [email protected]
ITALY Pasquale Felice
Wood-Mizer Italia Srl
Cda. Capoiaccio SN
86012 Cercemaggiore
Campobasso
Tel.:/Fax: [phone]
GSM: [phone]
e-mail: [email protected]
SERBIA Dragan Markov
Wood-Mizer Balkan d.o.o.
Svetosavska GA 3/3; P. Fah 25
23 300 Kikinda
Tel.:/Fax: [phone]
Tel.:/Fax: [phone]
GSM: [phone]
e-mail: [email protected]
CZECH REPUBLIC Miroslaw Greill
Wood-Mizer CZ s.r.o.
Osvaldova 91
339 01 Klatovy-Luby
Tel.:/Fax: [phone]
Fax: [phone]
Miroslaw Greill
GSM: [phone]
e-mail: [email protected]
SLOVAKIA Wiktor Turoczy
Wood-Mizer Danubia s.r.o.
Hadovce 5, 94501 Komárno
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
CZECH REPUBLIC Lubomir Kudlik
Wood-Mizer Moravia
Sovadinova 6
69002 Breclav
Tel.:/Fax: [phone]
Lubomir Kudlik
GSM: [phone]
e-mail: [email protected]
LATVIA Vilmars Jansons
OBERTS Ltd
Gaujas str. 32/2
LV-2167 Marupe, Rigas Raj.
Tel.: [phone]
Fax: [phone]
Vilmars Jansons
GSM: [phone]
Andris Orols
GSM: [phone]
e-mail: [email protected]
TURKEY
Er-Ka Ahsap Profil Kerestecilik San.
ve Tic. Ltd. Sti.
Adana Keresteciler Sitesi 191 sk No.41
ADANA
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
FINLAND Howard Blackbourn
Oy Falkberg Jordbruk Ab
Falkintie 220
25610 Ylonkyla
Tel.: [phone]
Fax: [phone]
Howard Blackbourn
GSM: [phone]
e-mail: [email protected]
LITHUANIA Andrius Zuzevicius
UAB Singlis
Savanoriu pr. 187, 2053 Vilnius
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
Dmitrij Gaiduk
GSM: [phone]
e-mail: [email protected]
UKRAINE Ivan Vinnicki
MOST UKRAINA
bul. Myru 3, Bajkivtsi Ternoplskyj r-j
Ternopolska oblast
47711 Ukraine
Tel/Fax: [phone]
GSM: [phone]
GSM: [phone]
E-mail: [email protected]
FRANCE Tizoc Chavez
Wood-Mizer France
556 chemin des Embouffus,
ZAC des Basses Echarrieres
38440 SAINT JEAN DE BOURNAY
Tel: [phone]
GSM: [phone]
Mail: [email protected]
NORWAY Odd Edvoll
Wood-Mizer Nordic AS
Vardelia 17, 2020 Skedsmokorset
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
e-mail: [email protected]
UNITED KINGDOM & IRELAND
Wood-Mizer UK
Hopfield Barn
Kenward Road, Yalding
Kent ME18 6JP, UK
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
SLOVENIA Jan Fale
FAMTEH d.o.o.
Gacnikova pot 2,
2390 Ravne na Koroskem
Tel.: [phone]
Fax: [phone]
Jan Fale
GSM: [phone]
e-mail: [email protected]
Matjaz Kolar
Tel.: [phone]
GSM: [phone]
e-mail: [email protected]

Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
doc013119 -9
GERMANY Klaus Longmuss
Wood-Mizer Sägewerke GmbH
Dorfstraße 5, 29485 Schletau
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Klaus Longmuss
Tel.: [phone]
GSM: [phone]
e-mail: [email protected]
Subagent:
SWEDEN Kjell Larsson
Mekwood AB
Slingan 14, 812 41 Gästrike-Hammarby
Tel.: [phone]
Kjell Larsson
GSM: [phone]
e-mail: [email protected]
IRELAND
Wood-Mizer Ireland
Stephen Brennan
Cum Lahardane Ballina County Mayo
Tel:[phone]
E-mail: [email protected]
Subagents:
DENMARK Brian Jensen
Arnborgvej 9, 7330 Brande- Fasterholt
Tel.: [phone]
Fax: [phone]
Brian Jensen
GSM: [phone]
e-mail: Fasterholt-Savvae[email protected].dk
ROMANIA Adrian Echert
SC WOOD-MIZER RO SRL
TRANSILVANIEI Nr. 5
Sibiu, Cisnadie 555300
Tel.:/Fax: : [phone]
GSM: [phone]
e-mail: [email protected]
Regional Manager - Asia
Wood-Mizer Asia Pte Ltd.
James Wong
Tel: [phone]
Fax: [phone]
WWW: www.woodmizerasia.com
E-mail: [email protected]
Netherlands Chris Dragt
Lange Brink 77d,
7317 BD Apeldoorn
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Subagent:
ROMANIA M. Echert
S.C. Echert Comprod s.r.l
Str. Schitului Nr. 6, Apt.7 etajul-1
725 70 Vatra Dornei, Romania
Tel.:/Fax: [phone]
Tel. : [phone]
Regional Manager - Africa
Wood-Mizer Africa
Jean-Jacques Oelofse
UNIT 3, LEADER PARK, NO: 20 CHARIOT
ROAD
STORMILL, EXT 5, Roodepoort,
Johannesburg
Tel: [phone]
Fax: [phone]
Jean-Jacques Oelofse E-mail:
[email protected]
Jean-Jacques Oelofse
Skype:jean.jacques.pierre.oelofse
USA World Headquarters Canadian Headquarters
Serving North & South America, Oceania, East Asia
Wood-Mizer LLC
8180 West 10th Street
Indianapolis, IN 46214
Phone: [phone] or 800.553.0182
Customer Service: 800.525.8100
Fax: [phone]
Email: [e-mail]
Serving Canada
Wood-Mizer Canada
396 County Road 36, Unit B
Lindsay, ON K9V 4R3
Phone: [phone] or 877.357.3373
Fax: [phone]
Email: [e-mail]
Brazil Headquarters Europe Headquarters
Serving Brazil
Wood-Mizer do Brasil
Rua Dom Pedro 1, No: 205 Bairro: Sao Jose
Ivoti/RS CEP:93.900-000
Tel: [phone]/ +55 51
3563-4784
Email: [e-mail]
Serving Europe, Africa, West Asia
Wood-Mizer Industries Sp z o.o.
Nagorna 114
62-600 Kolo, Poland
Phone: [phone]
Fax: [phone]
Branches & Authorized Sales Centers
For a complete list of dealers, visit www.woodmizer.com

Introduction
Machine description
1
1-1 EGdoc013119
SECTION 1 INTRODUCTION
Thank you for choosing Wood-Mizer wood processing equipment!
Wood-Mizer is committed to providing you with the latest technology, best quality and strongest customer
service available on the market today. We continually evaluate our customers’ needs to ensure we’re
meeting current wood-processing demands. Your comments and suggestions are welcome.
The present documentation contains information that should be used when preparing the machine for
operation, working with it and when servicing or repairing it, as well.
1.1 Machine description
The WB2000EC is intended for sawing wood only. The sawmill must not be used for any other purposes
such as cutting ice, metal or any other materials.
Using the machine correctly, you will obtain a material of the highest quality and high degree of accuracy.
The WB2000EC sawmill should be operated only by adult (over 18 year old) who has read and
understood the entire operator’s manual.
The machine is built to be durable and easy to operate and maintain.

Introduction
Machine and site preparation
EGdoc013119 1-2
1
1.2 Machine and site preparation
The sawmill is delivered and installed at customer’s premises by the Wood-Mizer Customer Service.
The major components of the WB2000EC sawmill are shown in the figure below.
FIG. 1-1
Saw Head
Blade Motor
Operator’s Stand
Debarker
Sawmill Bed

Safety
Blade Handling
2
2-1 EGdoc013119
SECTION 2 SAFETY
This symbol calls your attention to instructions concerning your personal safety. Be sure to observe and
follow these instructions. This symbol accompanies a signal word. The word DANGER indicates an
imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING!
suggests a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION refers to potentially hazardous situations which, if not avoided, may result in minor or
moderate injury to persons or equipment. Read all safety instructions before operating this machine and
observe all safety warnings!
Warning stripes are placed on areas where a single decal would be insufficient. To avoid serious injury,
keep out of the path of any equipment marked with warning stripes.
Read all safety instructions before operating this sawmill and observe them during operation of the
machine! Also read any additional manufacturer’s manuals and observe any applicable safety
instructions including dangers, warnings, and cautions.
Always be sure that all safety decals placed on the machine are clean and readable. Replace
immediately all damaged safety decals to prevent personal injury or damage to the equipment. Contact
your local Wood-Mizer dealer, or call Wood-Mizer Customer Service Department to order more decals.
IMPORTANT! It is always the owner's responsibility to comply with all applicable federal, state and local
laws, rules and regulations regarding the ownership, operation and towing of your Wood-Mizer sawmill.
All Wood-Mizer mill owners are encouraged to become thoroughly familiar with these applicable laws
and comply with them fully while using or towing the mill.
Always properly dispose of all sawing by-products, including sawdust and other debris, coolant, oil, fuel,
oil filters and fuel filters.
Safety instructions are listed in this section by the following operations:
Blade Handling,
Sawmill Setup,
Sawmill Operation,
Sawmill Maintenance.
2.1 Blade Handling
DANGER! Always disengage the blade and shut off the sawmill motor
before changing the blade. Failure to do so may result in serious injury.
WARNING! Always wear gloves and eye protection when handling
bandsaw blades. Changing blades is safest when done by one person!
Keep all other persons away from area when coiling, carrying or changing
a blade. Failure to do so may result in serious injury.

Safety
Sawmill Setup
EGdoc013119 2-2
2
2.2 Sawmill Setup
WARNING! Securely fasten rails of a sawmill to the floor before operating
the sawmill. Failure to do so may result in serious injury or death.
WARNING! The sawmill should be set up on firm, level ground and must
be fastened to the ground.
CAUTION! Changes in temperature could cause blade tension changes.
Release the blade tension when the sawmill is not in use.
2.3 Sawmill Operation
IMPORTANT! The sawmill is intended for sawing wood only. See
Section 6.3 Cutting Capacity for log size capacities of the machine.
IMPORTANT! The sawmill’s operator should get training in operation and
adjustment of the machine.
DANGER! Make sure all guards and covers are in place and secured
before operating. Failure to do so may result in serious injury.
Be sure the blade housing and pulley covers are in place and secured,
and the safety switches located on them are engaged. Use the rubber
latches to fasten the blade housing covers shut.
DANGER! Always keep hands away from moving bandsaw blade. Failure
to do so may result in serious injury.
DANGER! Keep all persons out of the path of moving equipment and logs
when operating the sawmill or loading and turning logs. Failure to do so
may result in serious injury.
DANGER! Maintain a clean and clear path for all necessary movement
around the mill and lumber stacking areas. Failure to do so may result in
serious injury.
DANGER! Always be sure all persons are out of the path of the blade
before starting the motor. Failure to do so may result in serious injury.
WARNING! When operating or servicing the machine, always wear eye,
ear and foot protection as well as safety clothing. Failure to do so may
result in serious injury.
!

Safety
Sawmill Operation
2
2-3 EGdoc013119
WARNING! Secure all loose clothing and jewelry before operating the
sawmill. Failure to do so may result in serious injury or death.WARNING!
Always make sure a log is clamped securely before sawing. Failure to do
so may result in serious injury or death.
WARNING! Use ONLY oil specified in Section 6.9 Lube System
Specifications with the blade lube system. Never use flammable fuels or
liquids! If these types of liquids are necessary to clean the blade, remove it
and clean with a rag. Failure to do so may result in serious injury or death.
When cutting in freezing temperatures, use an anti-freeze, non-flammable
additive.
CAUTION! Make sure the log handling accessories are below bed level
before loading a log onto the bed. Failure to do so may result in machine
damage or cause misalignment.
CAUTION! Before loading a log, make sure the saw head is moved far
enough so the log does not hit it. Failure to do so may result in sawmill
damage.
CAUTION! Do not try to force the saw head beyond its upper and lower
travel limits. Damage to the up/down system may result.
CAUTION! Never clean the blade or the blade wheels with a brush or a
scraper during sawmill operation.
CAUTION! Before installation of the blade, inspect it for damage and
cracks. Use only properly sharpened blades. Always handle the blade with
extreme caution. Use suitable carrier equipment for transporting blades.
CAUTION! When not in use, coil the blade as described in Blade
Handbook (WM Form #600). Wipe blade dry and store in a worm, dry
place.
CAUTION! If the blade breaks during sawmill operation, the blade motor
will be stopped automatically. Wait until both wheels have come to a
complete stop before you open the blade housing covers.
CAUTION! Be sure to stop the blade when returning the saw head. This
will not only prevent the blade from being pulled off and ruined by a wood
sliver, but also will increase the life of the blade.
CAUTION! The sawmill’s work-stand should be equipped with a 4 kg or
bigger dry powder extinguisher.
CAUTION! If at any time you need to immediately stop the blade motor,
press the emergency stop button located on the control box.

Safety
Sawmill Operation
EGdoc013119 2-4
2
CAUTION! Always wear gloves when handling the blade. Never grab the
blade with bare hands!
CAUTION! The sawmill should be operated with a sawdust extraction
system only.
WARNING! Always wear eye, ear, respiration, and foot protection when
operating or servicing the resaw.
WARNING! Always secure the saw head with a chain or a brace before
adjusting the up/down chain. The saw head may fall, causing severe injury
or death.
WARNING! Always secure the saw head with a chain or a brace before
adjusting the saw head guide rollers. The cutting head may fall, causing
severe injury or death.
CAUTION! Do not use chain lube. It causes sawdust buildup in chain
links.
CAUTION! Due to variations in the vertical mast, the guide roller spacing
may vary throughout the travel of the saw head. Check the guide roller
spacing at the top and bottom ends of the mast only. Rollers adjusted too
tight will cause premature up/down motor failure.
DANGER! Always disconnect and lock out power supply before
performing any maintenance work, cleaning or servicing the sawmill!
IMPORTANT! No exchange with a different type of laser is permitted. No
additional optical equipment shall be used.
DANGER! Visible and/or invisible laser radiation. Avoid eye or skin
exposure to direct or scattered radiation.
IMPORTANT! Adjust the adjustable blade guard arm as close to the
workpiece as practicable to clear the widest section of the log.
!
!

Safety
Sawmill Operation
2
2-5 EGdoc013119
See Table 2-1 Pictographic safety decals placed on the WB2000 sawmill are shown in the table below.
TABLE 2-1
Decal View Decal No. Description
096317 CAUTION! Read thoroughly the manual
before operating the machine. Observe all
safety instructions and rules when
operating the sawmill.
099220 CAUTION! Close all guards and covers
before starting the sawmill.
099219 Blade tension. Turning the bolt clockwise
will increase the blade tension, and turning
the bolt counterclockwise will decrease the
tension.
099220
099219
+

Safety
Sawmill Operation
EGdoc013119 2-6
2
099221 CAUTION! Keep all other persons at a safe
distance from work area when operating
the machine.
098176 CAUTION! Keep a safe distance from the
debarker blade!
096316 CAUTION! Do not open or close the
electric box when the switch is not in the
”0” position.
TABLE 2-1
099221
098176

Safety
Sawmill Operation
2
2-7 EGdoc013119
096319 CAUTION! Disconnect power supply
before opening the box.
099222 CAUTION! Sawdust chute. Protect eyes!
096321 Blade movement direction
511621 Blade tension
099504 Visible and/or invisible laser radiation.
Avoid eye or skin exposure to direct or
scattered radiation.
TABLE 2-1
099504

Safety
Sawmill Operation
EGdoc013119 2-8
2
S12004G CAUTION! Always wear safety goggles
when operating the sawmill!
S12005G CAUTION! Always wear protective ear
muffs when operating the sawmill!
501465 CAUTION! Always wear safety boots when
operating the sawmill!
501467 Lubrication point
P11789 Aligning the blade on the wheels
TABLE 2-1

Safety
Sawmill Operation
2
2-9 EGdoc013119
P85070 CE sign
099401 Russian safety certification
S20097F Motor rotation direction
TABLE 2-1
099401
S20097F
2925 RPM
