Wood-Mizer® Sawmill
Safety, Setup, Operation
& Maintenance Manual
LT28 rev. A1.00 - A6.01
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
August 2005
Form #1340

Table of Contents Section-Page
ii 2804doc030317 Table of Contents
SECTION 1 INTRODUCTION 1-1
1.1 About This Manual.................................................................................1-1
1.2 Getting Service .......................................................................................1-2
General Contact Information................................................1-2
Branches & Authorized Sales Centers..................................1-3
1.3 Specifications .........................................................................................1-5
1.4 Customer and Sawmill Identification.....................................................1-7
SECTION 2 SAFETY 2-1
2.1 Safety Symbols.......................................................................................2-1
2.2 Safety Instructions..................................................................................2-2
SECTION 3 SAWMILL SETUP 3-1
3.1 Stationary Sawmill Setup .......................................................................3-1
3.2 Portable Sawmill Setup ..........................................................................3-3
3.3 Replacing The Blade ..............................................................................3-7
3.4 Tensioning The Blade.............................................................................3-8
3.5 Tracking The Blade ..............................................................................3-10
3.6 Starting The Engine..............................................................................3-13
SECTION 4 SAWMILL OPERATION 4-14
4.1 Loading, Turning And Clamping Logs ................................................4-14
4.2 Up/Down Operation .............................................................................4-16
4.3 Blade Guide Arm Operation.................................................................4-17
4.4 Clutch Operation ..................................................................................4-18
4.5 Feed Operation .....................................................................................4-19
4.6 Cutting The Log ...................................................................................4-22
4.7 Edging...................................................................................................4-24
4.8 Blade Height Scale ...............................................................................4-25
4.9 Water Lube Operation ..........................................................................4-27
4.10 Preparing The Sawmill For Towing .....................................................4-29
SECTION 5 MAINTENANCE 5-1
5.1 Wear Life................................................................................................5-1
5.2 Blade Guides ..........................................................................................5-2
5.3 Sawdust Removal ...................................................................................5-3
5.4 Carriage Track, Wiper & Scrapers .........................................................5-4
5.5 Vertical Mast Rails.................................................................................5-6
5.6 Miscellaneous .........................................................................................5-7
5.7 Blade Wheel Belts ..................................................................................5-8
5.8 Drive Belt Adjustment............................................................................5-9
TOC

Table of Contents Section-Page
Table of Contents 2804doc030317 iii
5.9 Up/Down System..................................................................................5-11
5.10 Feed Rope.............................................................................................5-14
5.11 Charging The Battery ...........................................................................5-18
MAINTENANCE LOG 5-20
SECTION 6 TROUBLESHOOTING GUIDE 6-1
6.1 Sawing Problems....................................................................................6-1
6.2 Power Feed Problems .............................................................................6-3
LT28 Rev. A1.00 - A6.01 .......................................................6-3
SECTION 7 SAWMILL ALIGNMENT 7-1
7.1 Routine Alignment Procedure ................................................................7-1
Blade Installation..................................................................7-1
Saw Head Tilt........................................................................7-2
Blade Guide Arm Alignment .................................................7-4
Blade Guide Vertical Tilt Alignment.....................................7-6
Blade Guide Horizontal Tilt Adjustment...............................7-8
Blade Guide Flange Spacing ..............................................7-10
Side Support Alignment.......................................................7-11
Blade Height Scale Adjustment...........................................7-13
7.2 Complete Alignment Procedure ...........................................................7-14
Frame Setup .......................................................................7-14
Blade Installation................................................................7-15
Blade Wheel Alignment.......................................................7-16
Bed Rail Adjustment............................................................7-22
Blade Guide Installation .....................................................7-25
Blade Guide Arm Alignment ...............................................7-27
Blade Guide Deflection.......................................................7-29
Blade Guide Vertical Tilt Alignment...................................7-30
Blade Guide Horizontal Tilt Adjustment.............................7-32
Blade Guide Flange Spacing ..............................................7-34
Side Support Alignment.......................................................7-35
Saw Head Tilt......................................................................7-37
Blade Height Scale Adjustment...........................................7-39

Introduction
About This Manual
1
1-1 2804doc030317 Introduction
SECTION 1 INTRODUCTION
1.1 About This Manual
This manual is to replace or to be used with all previous information received on the
Wood-Mizer®* sawmill. All future mailings will be an addition to or a revision of individual
sections of this manual as we obtain new information.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
For general information regarding Wood-Mizer and our “Forest to Final Form” products,
please refer to the All Products Catalog in your support package.
*Wood-Mizer®is a registered trademark of Wood-Mizer Products, Inc.
280052B
Side Support
Log Loading
Ramp
Optional Trailer Axle
Adjustable Outrigger
Leg (w/Trailer Option)
Pivot Bed Rail
Log Clamp
Engine Drive
Assembly
Manual Feed
(Power Feed Optional)
Trailer Hitch
(w/Optional
Trailer)
Water Lube
Ta n k
Blade Guides

Introduction
Getting Service
Introduction 2804doc030317 1-2
1
1.2 Getting Service
Wood-Mizer is committed to providing you with the latest technology, best quality and
strongest customer service available on the market today. We continually evaluate our
customers’ needs to ensure we’re meeting current wood-processing demands. Your com-
ments and suggestions are welcome.
General Contact Information
Toll free phone numbers are listed below for the continental U.S. and Canada. See the
next page for contact information for specific Wood-Mizer locations.
Office Hours: All times are Eastern Standard Time.
Please have your vehicle identification number and your customer number ready when
you call.
Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Discover
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If your sawmill was purchased outside the United States or Canada, contact the distribu-
tor for service.
United States Canada
Sales 1-800-553-0182 1-877-866-0667
Service 1-800-525-8100 1-877-866-0667
Website www.woodmizer.com www.woodmizer.ca
E-mail [e-mail] [e-mail]
Monday - Friday Saturday
(Indianapolis Office Only)
Sunday
8 a.m. to 5 p.m. 8 a.m. to 12 p.m. Closed

Introduction
Branches & Authorized Sales Centers
1
1-3 2804doc030317 Introduction
Branches & Authorized Sales Centers
UNITED STATES CANADA
1 World Headquarters
8180 W. 10th Street
Indianapolis, IN 46214-2400
Toll Free [phone]
Phone [phone]
Fax [phone]
16 Canadian Headquarters
396 County Road 36, Unit B
Lindsay, ON K9V 4R3
Toll Free [phone]
Phone [phone]
Fax [phone]
Wood-Mizer Branches Authorized Sales Centers* Wood-Mizer Canada
Branches
2 Wood-Mizer Northeast
8604 State Route 104
Hannibal, NY 13074
Phone [phone]
Fax [phone]
E-mail [e-mail]
6 California
6980 Camp Far West Road
Sheridan, CA 95681
Phone [phone]
Fax [phone]
E-mail [e-mail]
17 Wood-Mizer Canada East
Box 173, 2600 #1 Hwy
Aylesford, NS B0P 1C0
Phone/Fax [phone]
3 Wood-Mizer Portland
24435 N.E. Sandy Blvd.
Wood Village, OR 97060
Phone [phone]
Fax [phone]
7 Maine
541 Borough Road
Chesterville, ME 04938
Phone [phone]
Fax [phone]
E-mail [e-mail]
18 Wood-Mizer Canada Quebec
7 ch. Baie Grenville
Grenville-sur-la-Rouge, QC
J0V 1B0
Toll Free [phone]
Phone [phone]
Fax [phone]
4 Wood-Mizer South
74 Pine Road
Newnan, GA 30263-5141
Phone [phone]
Fax [phone]
E-mail [e-mail]
8 Colorado
505 Gregg Drive
Buena Vista, CO 81211
Phone [phone]
19 Wood-Mizer Canada West
4770 46th Avenue S.E.
Salmon Arm, BC V1E 2W1
Toll Free [phone]
Phone [phone]
Fax [phone]
18
2
7
1
9
16
12
17
4
19
6
3
8
10
11
5
13
15
20

Introduction
Branches & Authorized Sales Centers
Introduction 2804doc030317 1-4
1
5 Wood-Mizer Missouri
9664 Lawrence 2130
Mt. Vernon, MO 65712
Phone [phone]
Fax [phone]
E-mail [e-mail]
9 Pennsylvania
22638 Croghan Pike
Shade Gap, PA 17255
Phone [phone]
Fax [phone]
E-mail [e-mail]
Authorized Sales Centers*
20 Ontario North
2340 Dawson Road
Thunder Bay, ON P7G 2G2
Toll Free [phone]
Phone [phone]
Fax [phone]
10 North Carolina
28002 Canton Road
Albemarle, NC 28001
Phone [phone]
Fax [phone]
E-mail [e-mail]
21 East New Brunswick
161 Ave. De L’Eglise
St. Antoine, NB E4V 1M2
Toll Free [phone]
Phone [phone]
Fax [phone]
11 Alaska
10661 Elies Drive
Anchorage, AK 99507
Phone [phone]
E-mail [e-mail]
12 Wisconsin
2201 Highway O
Mosinee, WI 54455
Phone [phone]
E-mail [e-mail]
13 Montana
51 Basin Creek Road
Basin, MT 59631
Phone [phone]
Fax [phone]
E-mail [email protected]
14 Mississippi
123 Cable Bridge Road
Perkinston, MS 39573
Phone [phone]
E-mail [e-mail]
15 Texas
11606 Highway 96 S
P.O. Box 2461
Kirbyville, TX 75956
Phone [phone]
*Authorized Sales Centers offer lim-
ited services such as sawmill
demos and training, routine service
and sales of blades and common
replacement parts

Introduction
Specifications
1
1-5 2804doc030317 Introduction
1.3 Specifications
Model: LT28 Rev. A1.00+
Dimensions: Metric
Length: 26'-4" 8.02m
Width: 6'-6" 1.97m
Height (Ground To Mast): 7'-2" 2.18m
Height (Max Head Position): 8'5" 2.5m
Bed Height (Ground To Bed): 31 1/4" 0.79m
Blade Length: 158" 4.01m
Weights:
Basic Unit with Trailer(with heaviest power option):
Tongue Weight:
Trailer:
Axle Capacity: 3500 lbs 1587kg
Tire Capacity: 1870 lbs 848.2kg
Tire Size: ST215/75R14
Cutting Capacity:
Length: 21' 6.4m
Diameter: 32" 0.81m
Maximum Log Weight: 4400 lbs 1995kg
Max Clamp Width (from stop block): 34" 0.86m
Max Throat Width (guide to guide): 26" 0.66m
Max Cant Width (outer guide to stop block): 22 1/2" 0.57m
Min. Cut Height: 1" 25.4mm
Max. Cut Height: 32 1/2" 0.82m
Maximum Throat Depth: 10 1/2" 0.26m
Power Unit: G18 G25 D17
Manufacturer: Kohler Kohler Kohler
Fuel: gas gas Diesel
Horsepower Rating*: 19 23.5 15.4
Weight (lbs)*: 90 94 145.4
Cooling System*: air air water
Noise Level (dba)*: 95-101.3(@3000 rpm) 96-103(@3000 rpm) 78 (At 7m in an open field at
3600rpm*)
Fuel Consumption(gallon/hour)*: 1.2-1.6 1.5-2
.54 (Full Load, @1800 rpm)
.43 (75% Load, @1800 rpm)
.32 (50% Load, @1800 rpm)
.19 (25% Load, @1800 rpm)
1.10 (Full Load, @3600 rpm)
.87 (75% Load, @3600 rpm)
.66 (50% Load, @3600 rpm)
.39 (25% Load, @3600 rpm)
Rates:
Hourly Production (Average range w/experienced
operators/average size logs):
350 bd ft/hr
*Manufacturer's Specification

Introduction
Specifications
Introduction 2804doc030317 1-6
1
Battery Specifications
Group
No.
Type No. Performance Level Approximate
Weight
Maximum Overall Dimensions
Cranking
Performance
Reserve
Capacity
Wet Length Width Height
26 526MF 535CC 80 31.0 lb.
(14.06 kg)
8.5 in.
(216 mm)
6.75 in.
(171 mm)
8.0 in.
(203 mm)

Introduction
Customer and Sawmill Identification
1
1-7 2804doc030317 Introduction
1.4 Customer and Sawmill Identification
Each Wood-Mizer sawmill has a model number and a 17-digit Vehicle Identification Num-
ber (VIN). In addition, when you pick up your mill, you will receive a customer number.
These three numbers will help expedite our service to you. Please locate them now and
write them below so you have quick, easy access to them. See the following figures for
model number and V.I.N. descriptions and locations.
(To be filled in by purchaser)
Mill Model ___________________
Mill VIN ___________________
Customer No. ___________________
See below for a description of the V.I.N.
LT28 G18
Basic Sawmill I.D. Engine/Motor
Configuration
MODEL NUMBER DESCRIPTION
Company Identification Number
456=Wood-Mizer Indiana
Weight Class; A=Under 3,000 lbs B=3,001-4,000 lbs
C=4,001-5,000 lbs D=5,001-6,000 lbs
Product No.; 2=LT28, 3=LT30/40, 4=LT30HD/40HD,
5=LT/40 Super, 6=LT40HD Super,
7=LT60HD/70HD, 8=LT50HD
Length of the Trailer;
20=20 Ft., 24=24’, 35=35’
Number of axles on the trailer
Check Digit
Add all the numbers and divide by 11
Year of Manufacture;
X=1999, Y=2000, 1=2001, 2=2002, 3=2003, etc...
State of Manufacture
N=Indiana, P=Poland
Month of Manufacture
A=January, B=February, C=March, etc...
Revision Level
Sequence Number
Ranging from 000-999
End of 17-Digit VIN
Revision Level (Repeated)
Two-Digit Minor Revision Level
456 A 5 24 1 X S N A F9 017 F9 .01
V.I.N. DESCRIPTION.

Introduction
Customer and Sawmill Identification
Introduction 2804doc030317 1-8
1
The model number and V.I.N. can be found in the following locations.
MODEL NUMBER AND V.I.N. LOCATIONS.
2
1
3
250042

Safety
Safety Symbols
2
2-1 2804doc030317 Safety
SECTION 2 SAFETY
2.1 Safety Symbols
The following symbols and signal words call your attention to instructions concerning your
personal safety. Be sure to observe and follow these instructions.
DANGER! indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING! suggests a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION! refers to potentially hazardous situations which, if not
avoided, may result in minor or moderate injury or damage to
equipment.
IMPORTANT! indicates vital information.
NOTE: gives helpful information.
Warning stripes are placed on areas where a single decal would be
insufficient. To avoid serious injury, keep out of the path of any
equipment marked with warning stripes.

Safety
Safety Instructions
Safety 2804doc030317 2-2
2
2.2 Safety Instructions
NOTE: ONLY safety instructions regarding personal injury are listed in this section. Cau-
tion statements regarding only equipment damage appear where applicable throughout
the manual.
OBSERVE SAFETY INSTRUCTIONS
IMPORTANT! Read the entire Operator's Manual before operating
the sawmill. Take notice of all safety warnings throughout this man-
ual and those posted on the machine. Keep this manual with this
machine at all times, regardless of ownership.
Also read any additional manufacturer’s manuals and observe any
applicable safety instructions including dangers, warnings, and
cautions.
Only persons who have read and understood the entire operator's
manual should operate the sawmill. The sawmill is not intended for
use by or around children.
IMPORTANT! It is always the owner's responsibility to comply with
all applicable federal, state and local laws, rules and regulations
regarding the ownership, operation and towing of your Wood-Mizer
sawmill. All Wood-Mizer mill owners are encouraged to become
thoroughly familiar with these applicable laws and comply with
them fully while using or towing the mill.

Safety
Safety Instructions
2
2-3 2804doc030317 Safety
WEAR SAFETY CLOTHING
WARNING! Secure all loose clothing and jewelry before operating
the sawmill. Failure to do so may result in serious injury or death.
WARNING! Always wear gloves and eye protection when handling
bandsaw blades. Changing blades is safest when done by one per-
son! Keep all other persons away from area when coiling, carrying
or changing a blade. Failure to do so may result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot protection
when operating or servicing the sawmill.
KEEP SAWMILL AND AREA AROUND SAWMILL CLEAN
DANGER! Maintain a clean and clear path for all necessary move-
ment around the mill and lumber stacking areas. Failure to do so
will result in serious injury.

Safety
Safety Instructions
Safety 2804doc030317 2-4
2
HANDLE FUEL/LUBRICANTS SAFELY
DANGER! Due to the flammable nature of fuel and oil, never
smoke, weld, grind or allow sparks near your engine or storage
tanks, especially during times of fueling.
DANGER! Never allow fuel to spill on a hot engine during fueling
operations or otherwise. The hot temperature of your engine could
induce a fire or explosion.
WARNING! Store gasoline away from sawdust and other flamma-
ble materials. Failure to do so may result in serious injury.
WARNING! Use ONLY water and Wood-Mizer Lube Additive with
the water lube accessory. Never use flammable fuels or liquids
such as diesel fuel. If these types of liquids are necessary to clean
the blade, remove it and clean with a rag. Failure to do so can
damage the equipment and may result in serious injury or death.
WARNING! Drum switch grease contains Petroleum Hydrocarbon
Lubricant. Eye and skin irritant. If introduced into eyes, flush with
water for at least 15 minutes. If film or irritation persists, seek med-
ical attention. Wash skin with soap and water. If ingested, do not
induce vomiting - contact a physician. KEEP OUT OF THE REACH
OF CHILDREN.
DISPOSE OF SAWING BY-PRODUCTS PROPERLY
IMPORTANT! Always properly dispose of all sawing by-products,
including sawdust and other debris, coolant, oil, fuel, oil filters and
fuel filters.

Safety
Safety Instructions
2
2-5 2804doc030317 Safety
USE CAUTION WHEN WORKING WITH BATTERIES
DANGER! Batteries expel explosive gases. Keep sparks, flames,
burning cigarettes, or other ignition sources away at all times.
Always wear safety goggles and a face shield when working near
batteries. Failure to do so will cause serious injury. 1
WARNING! Battery posts, terminals and related accessories con-
tain lead and lead compounds, chemicals known to the State of
California to cause cancer and reproductive harm. Wash hands
after handling.
WARNING! Charge the battery in a well ventilated area. Do not
attempt to charge a frozen battery.
Use extreme care to avoid spilling or splashing electrolyte (which is
dilute sulfuric acid) as it can destroy clothing and burn the skin. If
electrolyte is spilled or splashed on clothing or the body, it should
be neutralized immediately and then rinsed with clean water. A
solution of baking soda, or household ammonia, and water may be
used as a neutralizer.
Electrolyte splashed into the eyes is extremely dangerous. If this
should happen, force the eye open and flood it with cool, clean
water for approximately fifteen minutes. A doctor should be called
immediately when the accident occurs and “on-the-spot” medical
attention given if possible. If a doctor cannot come to the scene of
the accident immediately, follow his instructions concerning actions
to take. Do not add eye drops or other medication unless advised
to do so by the doctor. Do not place a battery or acid within the
reach of children. If acid (electrolyte) is taken internally drink large
quantities of water or milk. Follow with milk of magnesia, beaten
egg or vegetable oil. Call a physician immediately.
If electrolyte is spilled or splashed on any surface of the machine, it
should be neutralized and rinsed with clean water.
CAUTION! Do not overcharge the battery. Overcharging may
reduce the overall service life of the battery.
CAUTION! Be sure the battery is fully charged before transporting
the sawmill. If the battery is not fully charged, excessive vibration
could reduce the overall service life of the battery.
1 Battery Council International, copyright 1987

Safety
Safety Instructions
Safety 2804doc030317 2-6
2
CAUTIONS FOR SAWMILL SETUP
WARNING! Do not set up the mill on ground with more than a 10
degree incline. If setup on an incline is necessary, put blocks under
one side of the mill or dig out areas for the outrigger legs to keep
mill level. Setting up the mill on an incline could cause it to tip over,
resulting in serious personal injury.
WARNING! Chock the trailer wheels to prevent movement before
unhitching it from the towing vehicle. Failure to do so may result in
serious injury or death.
WARNING! Put front outrigger down before moving saw head from
the rest position. Failure to do so may result in serious injury.
WARNING! Always make sure the trailer is supporting the sawmill
frame when operating a sawmill with adjustable outriggers. Failure
to do so may result in serious injury or death. The adjustable out-
riggers are intended to support the saw frame with assistance from
the trailer.
WARNING! The adjustable outriggers supplied with portable saw-
mills are not intended for setup on concrete or other hard surfaces.
Long-term use of the adjustable outriggers on hard surfaces may
cause the outriggers to fail, causing the sawmill to drop. This could
result in possible serious injury or death.
If setting the sawmill up on concrete or other hard surface, replace
the adjustable outrgger legs with stationary legs.
WARNING! Securely fasten the feet of a stationary sawmill to the
floor before operating the sawmill. Failure to do so may result in
serious injury or death.

Safety
Safety Instructions
2
2-7 2804doc030317 Safety
CHECK SAWMILL BEFORE OPERATION
DANGER! Make sure all guards and covers are in place and
secured before operating or towing the sawmill. Failure to do so
may result in serious injury.
Be sure the blade housing and pulley covers are in place and
secure. Use the safety retainer pin and cable to fasten blade hous-
ing covers.
WARNING! Use both hands to operate the blade tensioner handle.
Be sure the handle lock engages (flips down) after tensioning the
blade. Failure to do so may result in injury.

Safety
Safety Instructions
Safety 2804doc030317 2-8
2
KEEP PERSONS AWAY
DANGER! Stay clear of the area between the trailer axle and saw
carriage. Failure to do so will result in serious injury.
DANGER! Keep all persons out of the path of moving equipment
and logs when operating sawmill or loading and turning logs. Fail-
ure to do so will result in serious injury.
DANGER! Always be sure the blade is disengaged and all persons
are out of the path of the blade before starting the engine or motor.
Failure to do so will result in serious injury.

Safety
Safety Instructions
2
2-9 2804doc030317 Safety
KEEP HANDS AWAY
DANGER! Always disengage the blade and shut off the sawmill
engine before changing the blade. Failure to do so will result in
serious injury.
DANGER! Engine components can become very hot during opera-
tion. Avoid contact with any part of a hot engine. The exhaust com-
ponents of your engine are especially hot during and following
operation. Contact with hot engine components can cause serious
burns. Therefore, never touch or perform service functions on a hot
engine. Allow the engine to cool sufficiently before beginning any
service function.
DANGER! Always keep hands away from moving bandsaw blade.
Failure to do so will result in serious injury.
DANGER! Always be aware of and take proper protective mea-
sures against rotating shafts, pulleys, fans, etc. Always stay a safe
distance from rotating members and make sure that loose clothing
or long hair does not engage rotating members resulting in possi-
ble injury.
WARNING! Do not spin the blade wheels by hand. Spinning the
blade wheels by hand may result in serious injury.
WARNING! Always disengage the clutch/brake mechanism when-
ever the sawmill is not cutting. Failure to do so may result in seri-
ous injury.
WARNING! Do not for any reason adjust the engine drive belt with
the engine running. Doing so may result in serious injury.
WARNING! Always keep clear of exiting sawdust. Keep hands,
feet and any other objects away from the sawdust chute when
operating sawmill. Failure to do so may result in serious injury.
