Woodpecker SPM 2-1000 User manual

TRANSLATION OF THE ORIGINAL VERSION
WOODPECKER
HOKUBEMA Maschinenbau GmbH
Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120
DE 72488 Sigmaringen | Tel. [phone]
E-Mail: [email protected] | Web: https://www.ichbinwoodpecker.de
Operating Manual
Tilting Spindle Moulder
WOODPECKER SPM 2-1000
Machine Type:
SPM 2-1000

BA_WP_SPM2-1000_EN_28-22.docx
2
Table of Contents
1Introduction.................................................................................................................................................... 6
1.1 Legal Notice ............................................................................................................................................................ 6
1.2 Figures .................................................................................................................................................................... 6
2Symbols .......................................................................................................................................................... 6
2.1 General Symbols ..................................................................................................................................................... 6
2.2 Symbols in Safety Instructions................................................................................................................................ 7
3General ........................................................................................................................................................... 8
3.1 Intended Use........................................................................................................................................................... 9
3.2 Target Group and Previous Experience................................................................................................................... 9
3.3 Requirements for the Operators ............................................................................................................................ 9
3.4 Training of Personnel.............................................................................................................................................. 9
3.5 Accident Prevention.............................................................................................................................................. 10
3.6 General Safety Regulations................................................................................................................................... 10
3.7 Included Components........................................................................................................................................... 11
3.8 Optional Accessories............................................................................................................................................. 11
4Safety............................................................................................................................................................ 12
4.1 Basic Safety Instructions ....................................................................................................................................... 12
4.2 Application Area and Intended Use ...................................................................................................................... 12
4.2.1 Permitted Tools................................................................................................................................................................12
4.2.2 Modifications and Conversions to the Machine...............................................................................................................13
4.2.3 Residual Risks...................................................................................................................................................................13
4.2.4 Observe the Environmental Protection Regulations........................................................................................................14
4.2.5 Organisational Measures .................................................................................................................................................14
4.2.6 Personnel Selection and Qualification - Basic Duties .......................................................................................................15
4.3 Safety Instructions for Specific Phases of Operation ............................................................................................ 15
4.3.1 Before Working................................................................................................................................................................15
4.3.2 Normal Operation............................................................................................................................................................16
4.3.3 Special work within the Scope of Maintenance Work as well as Troubleshooting in the Workflow ..............................17
4.3.4 After Work .......................................................................................................................................................................17
4.4 Safe Working Practices ......................................................................................................................................... 17
4.4.1 Operator Training.............................................................................................................................................................17
4.4.2 Stability ............................................................................................................................................................................17
4.4.3 Setting up and Adjusting the Machine.............................................................................................................................17
4.4.4 Tool Handling...................................................................................................................................................................18
4.4.5 Tool Clamping ..................................................................................................................................................................18
4.4.6 Setting the Safety Fence ..................................................................................................................................................18
4.4.7 Direction of Rotation........................................................................................................................................................18
4.4.8 Speed Selection................................................................................................................................................................18
4.4.9 Machine Operation and Selection / Adjustment of Protective Devices ...........................................................................18
4.4.10 Use of work devices with protective function..................................................................................................................20
4.4.11 Noise Reduction...............................................................................................................................................................20
4.5 Construction-related Safety Equipment ............................................................................................................... 20

BA_WP_SPM2-1000_EN_28-22.docx
3
4.6 Electrical Safety Equipment .................................................................................................................................. 20
4.7 Optional Safety Equipment................................................................................................................................... 21
4.7.1 Protective and Pressure Device GAMMA V 1629.............................................................................................................21
4.7.2 Protective and Pressure Device CENTREX 1624 ...............................................................................................................21
4.7.3 Ring Fence TAPOA 1639...................................................................................................................................................21
4.7.4 Ring Fence KOALA 1637 ...................................................................................................................................................21
4.7.5 Power Feeder PV84..........................................................................................................................................................21
4.7.6 Integral Fence Plates Type 211 ........................................................................................................................................21
4.8 Hazardous Areas ................................................................................................................................................... 22
5Machine Data ............................................................................................................................................... 23
5.1 Technical Specifications........................................................................................................................................ 23
5.2 Emission Levels ..................................................................................................................................................... 24
5.2.1 Noise Information ............................................................................................................................................................24
5.2.2 Noise Emission Values......................................................................................................................................................24
5.3 Workplace Requirements ..................................................................................................................................... 24
5.4 Maximum Dimenions............................................................................................................................................ 25
6Installation and Connection.......................................................................................................................... 26
6.1 Check Delivery Conditions .................................................................................................................................... 26
6.2 Transport .............................................................................................................................................................. 26
6.2.1 Unloading with a Forklift Truck ........................................................................................................................................26
6.2.2 Setting Down with a Forklift Truck...................................................................................................................................26
6.2.3 Lifting and Parking with an Overhead Crane....................................................................................................................27
6.3 Machine Installation ............................................................................................................................................. 27
6.4 Temporary Storage ............................................................................................................................................... 28
6.5 Verzurren in einem Transportfahrzeug................................................................................................................. 28
6.6 Connecting the Extraction Unit............................................................................................................................. 29
6.6.1 Automatic switching of the Extraction System (Option) ..................................................................................................29
6.7 Electrical Connections........................................................................................................................................... 30
6.7.1 Supply Cable and External Fuse Protection......................................................................................................................30
7Components & Controls ............................................................................................................................... 31
8Machining Methods...................................................................................................................................... 32
8.1 Permissible Machining Methods........................................................................................................................... 32
8.2 Improper Machining Methods.............................................................................................................................. 32
9Possible Operations...................................................................................................................................... 33
9.1 Milling of Longitudinal Sides................................................................................................................................. 33
9.2 Milling Cross Sides ................................................................................................................................................ 33
9.3 Insert Milling......................................................................................................................................................... 33
9.4 Tenon and Slot Milling .......................................................................................................................................... 33
9.5 Curved Milling....................................................................................................................................................... 33
10 Commissioning ............................................................................................................................................. 34
10.1 Switching ON and OFF .......................................................................................................................................... 34
10.2 Switching the spindle ON and OFF........................................................................................................................ 34

BA_WP_SPM2-1000_EN_28-22.docx
4
10.3 Direction of Rotation Switch................................................................................................................................. 34
10.4 Emergency Stop Button ........................................................................................................................................ 35
11 Adjusting the Milling Spindle........................................................................................................................ 35
11.1 Tilt Adjustment ..................................................................................................................................................... 35
11.2 Height Adjustment................................................................................................................................................ 35
12 Tool Change.................................................................................................................................................. 36
13 Speed Setting................................................................................................................................................ 38
13.1 Selecting the Spindle Speed.................................................................................................................................. 38
13.2 Cutting Speed Chart.............................................................................................................................................. 39
14 Sliding Table.................................................................................................................................................. 40
15 Telescopic Fence........................................................................................................................................... 40
16 Moulder Fences............................................................................................................................................ 41
16.1 Standard Safety Fence .......................................................................................................................................... 41
16.1.1 Adjusting the Fence Plates...............................................................................................................................................41
16.1.2 Folding up the protective bonnet ....................................................................................................................................42
16.2 Optional Safety Fence “PANHANS Type 215” ....................................................................................................... 42
16.2.1 Fence plate adjustment ...................................................................................................................................................42
16.2.2 Fit a grooved board or safety rulers.................................................................................................................................42
16.2.3 Folding up the protective bonnet ....................................................................................................................................43
16.2.4 Tool covers for high milling arbors...................................................................................................................................43
16.3 Attaching and Removing the Safety Fence ........................................................................................................... 43
16.3.1 Attaching the Standard Safety Fence...............................................................................................................................43
16.3.2 Removing the Standard Safety Fence ..............................................................................................................................43
16.3.3 Attaching the PANHANS Safety Fence Type 215 (Option)................................................................................................43
16.3.4 Removing the PANHANS Safety Fence Type 215 (Option) ...............................................................................................43
17 Optional Accessories .................................................................................................................................... 44
17.1 Protective and Pressure Device GAMMA V 1629.................................................................................................. 44
17.2 Protective and Pressure Device CENTREX 1624.................................................................................................... 44
17.3 Ring Fence TAPOA 1639 and KOALA 1637 ............................................................................................................ 45
17.4 Power Feeder PV84 .............................................................................................................................................. 46
17.5 Integral Fence Plates Type 211 ............................................................................................................................. 46
18 Troubleshooting ........................................................................................................................................... 47
19 Maintenance and Inspection........................................................................................................................ 48
19.1 Cleaning ................................................................................................................................................................ 48
19.2 Lubrication............................................................................................................................................................ 48
19.3 Maintaining the Safety Fence ............................................................................................................................... 49
19.4 Checking the Electronic Motor Brake ................................................................................................................... 49
19.5 Checking the Emergency Stop Button................................................................................................................... 49
19.6 Checking the Safety Devices ................................................................................................................................. 49
19.6.1 Checking the Safety Fence ...............................................................................................................................................49
19.6.2 Checking the internal Safety Switches .............................................................................................................................49
19.6.3 Checking the Protective and Pressure Device..................................................................................................................49

BA_WP_SPM2-1000_EN_28-22.docx
5
19.7 Checking the Safety Labels ................................................................................................................................... 49
19.8 Changing and Tensioning the Drive Belt ............................................................................................................... 50
19.8.1 Checking the Drive Belt Tension.......................................................................................................................................50
19.9 Maintaining the Drive Belt.................................................................................................................................... 50
19.10 Taking the Machine out of Operation / Storage ................................................................................................... 51
19.11 Defects and their Remedy .................................................................................................................................... 51
19.12 Average Situations / Emergencies ........................................................................................................................ 51
20 Disassembly and Scrapping .......................................................................................................................... 52
21 Options and Accessories............................................................................................................................... 53
21.1 Optional Safety Equipment................................................................................................................................... 53
21.2 Other Options ....................................................................................................................................................... 53
EU - Declaration of Conformity ............................................................................................................................. 54
List of Figures
Figure 1: Name plate........................................................................................................................................................................... 23
Figure 2: Working area ........................................................................................................................................................................ 24
Figure 3: Maximum dimensions - top view ......................................................................................................................................... 25
Figure 4: Unloading with a forklift truck.............................................................................................................................................. 26
Figure 5: Setting down with a forklift truck......................................................................................................................................... 26
Figure 6: Lifting and parking with a crane ........................................................................................................................................... 27
Figure 7: Adjustable foot..................................................................................................................................................................... 27
Figure 8: Suction nozzle....................................................................................................................................................................... 29
Figure 9: Terminal box......................................................................................................................................................................... 30
Figure 10: Components & controls...................................................................................................................................................... 31
Figure 11: Control panel...................................................................................................................................................................... 34
Figure 12: Hand wheels for height / tilt adjustment ........................................................................................................................... 35
Figure 13: Tool change ........................................................................................................................................................................ 36
Figure 14: Service door........................................................................................................................................................................ 38
Figure 15: Speed setting...................................................................................................................................................................... 38
Figure 16: Cutting speed chart ............................................................................................................................................................ 39
Figure 17: Operating the sliding table ................................................................................................................................................. 40
Figure 18: Operating the telescopic fence........................................................................................................................................... 40
Figure 19: Standard safety fence......................................................................................................................................................... 41
Figure 20: Total adjustment ................................................................................................................................................................ 41
Figure 21: Partial adjustment.............................................................................................................................................................. 41
Figure 22: Clamping lever for fence plate............................................................................................................................................ 41
Figure 23: Fold up protective bonnet.................................................................................................................................................. 42
Figure 24: Components of safety fence type 215................................................................................................................................ 42
Figure 25: Locking mechanism ............................................................................................................................................................ 43
Figure 26: Protective and pressure device GAMMA V 1629................................................................................................................ 44
Figure 27: Protective and pressure device CENTREX 1624.................................................................................................................. 44
Figure 28: Components of the ring fence TAPOA 1639 ....................................................................................................................... 45
Figure 29: TAPOA 1639 ring fence adjustment.................................................................................................................................... 45
Figure 30: Power feeder type PV84..................................................................................................................................................... 46
Figure 31: Integral fence plates........................................................................................................................................................... 46
Figure 32: Components of the integral fence plates ........................................................................................................................... 46
Figure 33: Changing and retensioning the belt.................................................................................................................................... 50
Figure 34: Checking the belt tension................................................................................................................................................... 50
Revisions:
Revision
Editor
Modification
Date
000
AG
Original manual translated
15.07.2022

BA_WP_SPM2-1000_EN_28-22.docx
6
1Introduction
This operating manual applies to the WOODPECKER SPM 2-1000 tilting spindle moulder. The purpose of this
document is to acquaint the user with the machine and enable him to use it to the full extent of its intended
capabilities. Additionally it contains important information to operate the machine safely, properly and econom-
ically. Observance of the manual helps to avoid hazards, reduce repair costs and downtimes and increase the
reliability and service life of the machine.
Furthermore, this operating manual serves to supplement instructions based on national regulations for accident
prevention and environmental protection.
This operating manual must always be available at the place of use of the machine. It must be
read and followed by every person who is assigned to work on the machine, e.g.
•during operation, including set-up, troubleshooting in the work process, removal of pro-
duction waste and maintenance,
•during maintenance (servicing, inspection, repair)
•and/or during transport.)
Apart from the operating manual and the legally binding accident prevention provisions applicable in the country
and place of use, the recognized technical regulations for safe and proper work must also be observed.
1.1 Legal Notice
WOODPECKER is a brand of Hokubema Maschinenbau GmbH. All contents of these operating instructions are
subject to the rights of use and copyright of HOKUBEMA Maschinenbau GmbH. Any reproduction, modification,
further use and publication in other electronic or printed media, as well as their online publication, requires the
prior written consent of HOKUBEMA Maschinenbau GmbH.
1.2 Figures
All photos, figures and graphics contained in this document are for illustration and better understanding only
and may differ from the current state of the product. Title photos and general views may also include optional
components and special accessories.
2Symbols
2.1 General Symbols
Symbol
Meaning

Indicates passages within this operating manual that must be particularly observed in order to
prevent malfunctions or damage to the machine.

Refers to chapters, sections, or figures within this document.

Refers to an external document or a third-party source.

BA_WP_SPM2-1000_EN_28-22.docx
7
2.2 Symbols in Safety Instructions
Symbol
Safety Instruction
General danger symbol, which requires the highest attention!
Failure to observe may result in damage to the equipment, serious injury or even death.
Warning of possible danger from forklift traffic!
Non-observance may result in life-threatening injuries.
Warning indicates a possible hazard under suspended loads!
Non-observance may result in life-threatening injuries.
Warning indicates a possible fall hazard!
Non-observance of these instructions may result in serious injuries.
Warning indicates a possible cutting hazard!
Risk of personal injury and possibly additional damage to equipment.
Reference to the obligation to wear protective gloves!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear hearing protection!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear protective goggles!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear a respiratory protection mask!
Non-observance of these instructions may cause breathing difficulties and lung damage.
Reference to the obligation to wear safety shoes!
Non-observance of these instructions may result in personal injury.
Possible dangerous crushing hazard in the area of stationary objects!
Risk of personal injury and possibly additional equipment damage.
Reference to a possible crushing hazard!
Non-observance increases the risk of injury to hands and fingers!
This symbol warns of the dangers of electric voltage!
Failure to observe may result in damage to the equipment, serious injury or even death.
Fire hazard! Do not smoke and do not ignite open fire.
Access for unauthorized persons prohibited!
Risk of personal injury and possibly additional equipment damage.
This safety notice indicates a possible dangerous pull-in hazard!
Wearing loose clothing, jewellery as well as long untied hair is prohibited!
Risk of personal injury and possibly additional damage to property.

BA_WP_SPM2-1000_EN_28-22.docx
8
3General
The WOODPECKER "SPM 2-1000" model is a universal spindle moulder with height and tilt adjustable milling
arbor, built-in milling spindle lock, two directions of rotation, adjustable speed and separately adjustable total
and partial fence.
Special highlights in the basic equipment are the sturdy and smooth-running format sliding table, the telescopic
fence with 2 flip stops and eccentric clamp, and the three supplementary table extensions.
•The milling spindle is driven by a powerful 4.0 kW / 5.5 HP three-phase motor equipped with a wear-free,
electronic motor brake. An even more powerful motor with 5.5 KW / 7.5 HP is available as an option.
•The machine's four fixed speeds (1400 / 3500 / 6000 / 8000 rpm) can be set by flipping the pulley via the
belt quick tensioning device.
•The milling spindle can be tilted backwards from 90° to 45° via an analogue angle scale.
•The height and tilt adjustment is carried out manually using the two handwheels at the front.
•The milling arbor is designed for conventional and climb milling and has a built-in milling spindle lock, which
allows for quick and convenient tool changes.
•The standard safety fence can be moved manually forwards and backwards by loosening the two clamping
screws. The fine adjustment of the total fence and the partial fence is done manually via adjusting wheels
with a scale for the total fence and a vernier scale for the partial fence.
•The PANHANS Type 215 safety fence incl. cast fence plates and aluminium splitter tongues is available as an
option. The total fence is adjusted via the built-in handwheel (separate measuring device, e.g. setting gauge
or similar required). The partial fence is adjusted via a star knob using the vernier scale.
•The large and solid table top with a 190 mm opening is made of a solid cast iron and measures 1000 x 550
mm. This can be extended with the two included table extensions (500 x 320 mm) on the left and right side.
•The sturdy and smooth-running aluminium sliding table with hardened steel guide rods measures 1150 x
350 mm and is grooved so that the telescopic fence included as standard with two adjustable flip stops and
eccentric clamp can be attached to it. The sliding table can be extended with an attachable table extension
parallel to the telescopic fence.
•The control panel on the front of the machine is equipped with a lockable main switch, an on/off switch for
the spindle, a direction of rotation switch and an emergency stop pushbutton. In addition, the currently set
speed is visualized here via four signal lamps.
•The milling spindle can be secured against turning by a locking bolt for tool change. An internal safety switch
prevents the milling spindle from starting during this process.
•The machine is supplied in a CE-compliant and GS-tested design.

BA_WP_SPM2-1000_EN_28-22.docx
9
3.1 Intended Use
The WOODPECKER SPM 2-1000 tilting spindle moulder is used exclusively for machining materials for which the
milling cutter used is suitable (e.g. wood, chipboard, veneer). The machines are not suitable for milling metal
resp. plastic and waste wood which could contain nails, screws and other metal parts. The machine may only be
operated on a firm, level surface with a minimum load-bearing capacity of 1,000 kg/m..
Improper use can lead to danger to persons and to a defect or damage to the machine.
3.2 Target Group and Previous Experience
This operating manual is intended for the operating and maintenance personnel of the machine. The operating
personnel is to be determined by the operator and must further meet the following requirements:
•Basic technical knowledge (e.g. apprenticeship as carpenter, machine fitter, etc. and/or practice in operat-
ing tilting spindle moulders resp. woodworking machines)
•Reading and understanding these operating and maintenance instructions
In order to acquire the knowledge required to operate this machine, the operator must ensure the following
measures:
•Product training for every operator (also possible external personnel)
•Regular safety instruction
3.3 Requirements for the Operators
•The tilting spindle moulder may only be operated by trained personnel who have also read this manual.
•Inspection, maintenance, cleaning and repair may only be performed by technical specialists
with product-specific training and mechanical and/or electrical training.
•Specialists with product-specific training are to be commissioned and held responsible for
planning and checking the work.
•The national protective regulations for employees must be observed.
•The operator is responsible for the safe use of the machine.
•The legal minimum age must be observed.
3.4 Training of Personnel
All machine operators must be adequately trained in the operation and maintenance of the machine. In partic-
ular, the training must include the following:
•General rules for the use of the machine, proper operation, correct adjustment of the machine, tool change,
safety fence, slide table with telescopic fence as well as the use of other accessories.
•Proper handling of the workpieces during the machining process. Correct position of the hands on the work-
piece and to the rotating tool during and after machining.
•The personnel must be informed about hazards, risks and appropriate protective measures.
•The personnel must be trained in the area of regular checks of the guards and protective devices.
•The personnel must be trained in the use of the guards and protective devices.

BA_WP_SPM2-1000_EN_28-22.docx
10
3.5 Accident Prevention
To avoid accidents, the following rules must be observed for operation:
•Prevent unauthorized persons from gaining access to the machine.
•Keep unauthorized persons away from the danger areas.
•Repeatedly inform present other persons about existing residual risks (refer to section 4.2.2).
•Conduct and record regular training & instruction for persons who must be in the area of the machine.
•New employees must be trained internally to work on a thickener and this training must be documented.
3.6 General Safety Regulations
In general, the following safety regulations and obligations apply when handling the machine:
•A tilting spindle moulder may only be operated in a technically perfect and clean condition.
•It is prohibited to remove, modify or bypass any protective, safety or monitoring equipment.
•It is forbidden to modify or alter the machine without the written approval of the manufacturer / supplier.
•Faults or damage must be reported to the operator immediately, eliminated without delay and repaired if
necessary.
•For repairs, only original spare parts may be used.
•All protective, safety and monitoring devices must be regularly checked and maintained by the operator.
•Only instructed, trained or qualified persons may work on this machine.
•Maintenance work must be carried out and documented in accordance with the maintenance instruc-
tions.
•After maintenance or repair, the machine may only be started with all protective devices fitted. A respon-
sible person must be defined for this purpose, who checks that the guards have been properly installed.
•For the operation of a tilting spindle moulder, the respective national safety regulations for employees as
well as the national safety and accident prevention regulations apply.

BA_WP_SPM2-1000_EN_28-22.docx
11
3.7 Included Components
•Safety fence with manual total and partial adjustment as well as suction nozzle Ø 120 mm
•Handwheels with analogue scale indicators for height and tilt adjustment
•Format sliding table made of aluminium with hardened steel guide rods
•Second suction nozzle on the right under the table with Ø 120 mm
•Table extension for the support surface of the sliding table
•Telescopic fence with 2 flip stops and 1 eccentric clamp
for mounting in the grooves of the sliding table
•Table extensions for the cast table top on both sides
•4 spindle speeds 1400 / 3500 / 6000 / 8000 rpm
•Milling spindle Ø 30 mm with quick clamping nut
•Built-in milling spindle lock
•Protective and pressure device
•Fine planed cast iron table top
•Adjustable machine feet
3.8 Optional Accessories
•Switch contact for automatic on/off switching of the extraction system
•Customized milling spindles Ø 32, 35, 40, 50 mm (on request)
•Reinforced motor with 5.5 KW / 7.5 HP (400 V)
•PANHANS type 215 safety safety fence
•Power feeder PV84 (4 rollers with tripod)
•Various safety accessories (see 21.1)

BA_WP_SPM2-1000_EN_28-22.docx
12
4Safety
4.1 Basic Safety Instructions
Woodworking machines can be dangerous if used improperly. Therefore, observe the safety instructions listed
in this chapter and the accident prevention regulations of your employer's liability insurance association!
The manufacturer accepts no liability for damage and malfunctions resulting from failure to
observe these operating instructions.
4.2 Application Area and Intended Use
•The tilting spindle moulder SPM 2-1000 is used exclusively for milling of solid wood (soft
and hard woods) as well as plastics and wood-containing board materials.
•This machine is not suitable for processing metal resp. plastic and scrap wood - which
could contain nails, screws and other metal parts.
•The machine may only be operated on a firm, level surface with a minimum load-bearing
capacity of 1,000 kg/m².
Any processing of other materials requires prior consultation with and approval of the manufacturer.
Improper use can lead to danger to persons and to a defect or damage to the machine.
Only workpieces that can be safely placed and guided may be machined.
Metallic materials must not be machined.
The machine is not suitable for operation outdoors or in potentially explosive areas.
•Permissible altitude: max. 1000 m above sea level
•Permissible ambient temperature: +1 …+40° C
•Permissible humidity: max. 90 %
Number of workplaces: 1
Intended use also includes the connection of the machine to an adequately dimensioned extraction system and
compliance with the operating, maintenance and servicing conditions specified in the operating manual.
Any other use is not in accordance with the intended use and is therefore prohibited.
4.2.1 Permitted Tools
Spindle Ø
Clamping length
Milling cutters (profiling)
Tenoning and slotting tools
30 mm
max. 125 mm
Ø max. 180 mm (at 90°)
Ø max. 125 mm (at 45°)
Ø max. 250 mm
The speed limits indicated on the tool must be strictly adhered to!
Only tools according to EN 847-1 are permitted that are marked with the BG-Test test mark
or with the Hand Feed or MAN marks (cutting edge projection: max. 1.1 mm).
Only use tools approved for manual feed! For milling work with a feed unit or the sliding table, tools for par-
tially mechanical feed are approved.

BA_WP_SPM2-1000_EN_28-22.docx
13
4.2.2 Modifications and Conversions to the Machine

Unauthorised conversions and modifications to the machine are strictly prohibited for safety
reasons. This will invalidate the CE declaration of conformity! The manufacturer is not liable
for any resulting damage. The risk for this is borne exclusively by the operator/user.
4.2.3 Residual Risks
The machine is built according to the latest state of the art and the recognised safety rules. Nevertheless, the
use of the machine may cause danger to life and limb of the user or third parties or damage to the machine and
other equipment. Due to the construction of the machine, the following residual risks can occur even when used
as intended and despite compliance with all relevant safety regulations:
Reading and applying the operating manual is mandatory for the operating personnel.
Be alert to possible crushing hazards:
a) when transporting the machine by forklift truck →between forks & pallet / machine
b) when picking up the machine →between machine / pallet and floor
c) when lowering the machine →between machine and fixed equipment
Be alert to possible crushing hazards when lowering the machine (from the cargo pallet to the
floor) with a forklift truck or overhead crane.
Make sure that no objects fall from the forklift truck / crane.
Do not leave any objects / tools on the machine.
It is strictly prohibited to ride on the machine during a lifting operation (with the indoor crane or
forklift). There is a danger of falling!
Unauthorised persons are not allowed to enter the installation area of the machine
(responsibility of the operator).
Be aware of possible tripping and slipping hazards on the floor. Prevent possible hazards by keep-
ing the floor dry and clean and by using anti-slip floor coverings around the machine.
Be aware of the danger from falling objects such as workpieces, tools or similar. Therefore, wear
safety shoes, especially when transporting and setting down the machine.
Pay attention to the existing danger of cuts on the cutter knifes. Never reach into the running cut-
ter! Use a power feeder or pushing device for short and narrow workpieces. Wear protective
gloves when changing the milling cutter.
Be aware of the danger of cutting through chips and splinters and never remove them from the
danger area by hand and/or while the machine is running. Use suitable aids, e.g. hand brushes.
Avoid climb milling. There is an increased risk of drawing in and kickback.
Danger of being drawn in and increased risk of injury when wearing watches and jewellery.
Wearing watches and jewellery is prohibited on the tilting spindle moulder.
Be aware of a possible danger of being drawn in by moving machine parts or tools. This can cause
pieces of clothing or hair to be caught. Always wear tight-fitting clothing or avoid loose clothing
and wear a hair net if necessary.
Danger from electric shock! There are hazards when working on the electrical system.
This work must only be carried out by qualified personnel!
Danger from electric shock! It is strictly forbidden to bypass safety devices (e.g. safety switches).
Electrical equipment must be maintained and cleaned regularly.
Pay attention to the danger of crushing on workpiece guides and moving machine parts.
Make sure that no unauthorised persons are in the area of the machine.

BA_WP_SPM2-1000_EN_28-22.docx
14
Be aware of the risk of injury from flying tool parts in the event of tool breakage.
Therefore wear protective goggles.
Be aware of the risk of injury from flying workpiece parts and chips, splinters and dust coming out
of the machine. Therefore wear protective goggles.
Be aware of the increased noise emission and wear hearing protection.
Be aware of the increased dust generation. Use the extraction device and wear a dust mask if
necessary.
The emergency stop buttons must always be freely accessible. They must not be moved, e.g. with
hopper boxes. Check the function of the emergency stop buttons daily (before starting work).
Fire hazard due to wood dust in connection with flying sparks and/or open fire!
4.2.4 Observe the Environmental Protection Regulations
During all work with the machine, the environmental protection regulations, obligations and laws for waste
avoidance and proper recycling and/or disposal applicable at the place of use must be observed. This applies in
particular to installation, repair and maintenance work involving substances that could pollute the groundwater
(e.g. hydraulic oils and cleaning agents and liquids containing solvents). In any case, prevent them from seeping
into the ground or entering the sewage system.
Store and transport the above-mentioned hazardous substances only in suitable con-
tainers. Avoid leakage of hazardous substances by using suitable collection contain-
ers. Ensure that the above-mentioned substances are disposed of by a qualified dis-
posal company.
4.2.5 Organisational Measures
Always keep this operating manual within easy reach and at the place of use of the machine.
In addition to the operating manual, observe and instruct on generally applicable legal and other binding
regulations for accident prevention and environmental protection.
Supplement the operating manual with further instructions, including supervisory and reporting duties, to
take account of special operational features (e.g. with regard to work organisation, work processes, per-
sonnel employed).
Before starting work on the machine, the person responsible for its operation must have read the operat-
ing instructions, especially the chapter "Safety Instructions". This applies in particular to personnel who
only occasionally work on the machine.
Check that work is carried out in a safety-conscious and hazard-conscious manner and in compliance with
the operating manual.
Operators must not wear open long hair, loose clothing or jewellery (including rings). There is a risk of in-
jury, e.g. by getting caught or drawn in.
Observe the safety instructions and danger warnings on the machine and keep them complete and in legi-
ble condition.
In case of safety-relevant changes to the machine or its operating behaviour, shut down the entire system
immediately and report the fault to the responsible office/person.
Use personal protective equipment as necessary or required by regulations.
Do not make any modifications, additional attachments or conversions to the machine without the manu-
facturer's approval! This will compromise safety and invalidate the manufacturer's warranty and any lia-
bility claim.
Spare parts must meet the technical requirements specified by the manufacturer. The exclusive use of
original spare parts ensures this. Therefore, only use original spare parts from the manufacturer.
Observe the fire alarm and firefighting possibilities. Make the location and operation of fire extinguishers
(fire class ABC) known. Do not use water!

BA_WP_SPM2-1000_EN_28-22.docx
15
4.2.6 Personnel Selection and Qualification - Basic Duties
The machine design and operation is intended for right-handers.
Work on and with the machine may only be carried out by reliable personnel.
Observe the legal minimum age!
Only use trained or instructed personnel. Clearly define the responsibilities of the personnel for operating,
setting up, maintaining and repairing!
Ensure that only authorised personnel work on the machine!
If personnel to be trained or apprenticed have to work on the machine, this may only be done under the
constant supervision of an experienced resp. qualified person.
Work on the electrical equipment of the machine may only be carried out by a qualified electrician or by
untrained persons under the direction and supervision of a qualified electrician in accordance with the
electrotechnical regulations.
4.3 Safety Instructions for Specific Phases of Operation
Defects and damage to the machine are to be reported immediately after detection.
Any mode of operation that compromises safety is prohibited!
Sufficient lighting around the machine must be ensured (at least 500 Lux)!
4.3.1 Before Working
Wear personal protective equipment (safety goggles, safety shoes, hearing protection, dust mask), close-
fitting clothing and, if necessary, a hair net! Take off wrist watches, necklaces and other jewellery.
Always work with all available guards and protective devices! These must be in the correct places and in
perfect working order. Defective protective devices must be replaced immediately.
Do not start work until the motor / tool has reached full speed.
Only use tools in perfect, sharpened condition and with clean clamping surfaces.
Observe the correct direction of rotation of the tool and avoid dangerous climb milling.
Always work with all protective devices! These must be in the correct places and in perfect working order.
Defective protective devices must be replaced immediately.
Do not start work until the motor / tool has reached full speed.
Only use tools in perfect, sharpened condition and with clean clamping surfaces.
Observe the correct direction of rotation of the tool and avoid dangerous climb milling.
Only use tools that are suitable for the operation.
Do not exceed the permissible tool speed.
Adjust the tool only when the tool is at a standstill and with a dial gauge.
Remove any objects lying on the table (tools, spacers, etc.) before milling.
Clean the machine table from dirt and chips and provide a container for waste pieces.
Always check workpieces to be machined for foreign bodies, cracks and loose knots.
Only carry out adjustments to the machine and the fence when the machine is at a standstill.
Required aids such as tool cover, feed device, table extensions, clamping drawer, feed elements (e.g. push
stick, feather boards, etc.) and use them as required.
Use a power feeder whenever possible.
Adjust guards, pressure devices and tool covers as best as possible.
Use continuous fence for safe workpiece guidance. If necessary, compensate for chip removal by means of
a partial fence to ensure a continuous fence.
Keep the floor in the area of movement around the machine free of tripping hazards.
Ensure that the machine is connected to an extraction system.
If gloves are required for workpiece handling, they must be fingerless.

BA_WP_SPM2-1000_EN_28-22.docx
16
4.3.2 Normal Operation
Guards: Take measures to ensure that the machine can only be operated in a safe and functional
condition. Only operate the machine when all guards and safety-related devices such as
- detachable guards (e.g. tool covers and fence covers),
- emergency stop system, sound insulation, suction device etc.
are present and in working order.
Workpiece: Before machining, inspect the workpiece for foreign inclusions, knots, twists, objects
and other irregularities.
Working area: An obstacle-free work area around the machine is essential for safe operation.
The floor should be level, well maintained and free from debris such as chips and cut-off workpieces.
Rotation speed: The speed must correspond to the milling cutter and the respective operation.
The maximum speed indicated on the tool must not be exceeded. If a speed range is indicated on the
milling cutter, this must be adhered to by not going above or below the speed range stated.
Cutting area during operation: Never attempt to remove splinters, chips or other parts from the cutting
area while the machine is running! Never remove splinters and chips by hand!
- Cover the milling cutters before the fence by means of a protective device
- Clamp milling cutters as deeply as possible
- Adapt the table opening to the tool diameter with insert rings or optional Table Slide
- Place the fence halves as close as possible to the milling tool and clamp them securely
- Close the protective cover of the fence
Power feeder: Generally adjust so that the workpiece is guided safely along the fence. Set the feeder
at an angle of approx. 5° to the feed direction and keep the opening to the fence as small as possible.
Manual feeding: When feeding the workpiece manually, place the hands flat on the workpiece with
closed fingers and push forward evenly.
Special tools: For certain operating phases and operations it is necessary to use special tools
(e.g. feed device, table extensions, clamping drawer, push bar or comparable feed elements).
Single pieces / samples: Always use all protective devices and appropriate tools!
Insert milling: During insert milling, use optional table extensions with cross fences as well as a
Kickback guard adapted to the workpiece dimensions.
Workpieces with small cross-section: Always use one with a push block for machining.
Short workpieces: For short workpieces, use a workpiece holder and bridge the fence halves.
Long workpieces: When milling, generally use feather boards and table extensions and secure the work-
piece against tipping.
Narrow grooves: Always use a suitable grooving cutter (no circular saw blades).
Milling narrow cross sides: Generally feed workpiece with push block.
Curved or round workpieces: Use special suction bonnet when milling with a thrust ring or ring fence
guard.
Extraction: The machine must be connected to an effective extraction system. This requires a flow velocity
of at least 20 m/s for dry chips and 28 m/s for moist chips (moist 18 % or more).
Machine condition: Check the machine for externally visible damage and defects at least once per shift!
Any changes that have occurred (including those in the operating behaviour) must be reported immedi-
ately to the responsible office or person! If necessary, stop and secure the machine immediately!
Work interruptions: Switch off the machine even during short interruptions! Never leave the machine
running unattended!

BA_WP_SPM2-1000_EN_28-22.docx
17
4.3.3 Special work within the Scope of Maintenance Work as well as Troubleshooting
in the Workflow
Observe maintenance and inspection activities prescribed in the operating manual!
These activities, as well as all other repair work, may only be carried out by qualified personnel!
For all work concerning operation, production adjustment, conversion or setting of the machine and its
safety-related equipment as well as maintenance and repair, observe switch-on and switch-off procedures
according to the operating manual and instructions for maintenance work!
Secure the machine against unexpected restarting during maintenance and repair work.
➔Lock the main switch with a padlock!
Always tighten screw connections that have been loosened during maintenance and repair work!
If it is necessary to dismantle safety equipment during set-up, maintenance and repair, the safety equip-
ment must be reassembled and checked immediately after completion of the maintenance and repair
work!
Ensure safe and environmentally friendly disposal of operating and auxiliary materials (e.g. oils) and re-
placement parts (e.g. electronic components). See chapter 20 “Disassembly and Scraping”.
4.3.4 After Work
Before leaving the machine, switch off the main switch and the extraction system.
Secure the machine against unauthorised use and never leave it unattended in an unsecured condition.
Clean the machine with an industrial hoover (avoid compressed air!).
4.4 Safe Working Practices
Depending on the work to be carried out, the guards must be used for fence milling, insert milling, curved milling
and also for tenoning. Nevertheless, in order to prevent accidents, it is necessary that the user observes safe
working practices.
4.4.1 Operator Training
It is important that all users of the tilting spindle moulder are adequately instructed in the use, setting and oper-
ation. This concerns in detail:
Possible hazards that may occur when working with the machine.
The basics of machine operation, correct setting and use of the fences, templates, aids and guards.
The correct selection of the tool for the respective processing.
The safe workpiece guidance and feeding.
The correct hand position and safe stacking and unstacking of the workpieces before and after machining.
4.4.2 Stability
For safe operation of the machine, it is necessary that it is stable and securely fastened to the floor or
another safe part of the building.
4.4.3 Setting up and Adjusting the Machine
Before starting the adjustment, the machine must be disconnected from the mains supply.
For tool clamping, refer to the recommendations of the tool manufacturer.
To ensure safe and effective machining, the tool must be suitable for the material to be machined.
Tools must be sharp and mounted on carefully balanced tool holders.

BA_WP_SPM2-1000_EN_28-22.docx
18
4.4.4 Tool Handling
Tools must be handled with care and tool transport equipment must be used whenever possible.
4.4.5 Tool Clamping
Use suitable devices, e.g. setting gauges, to clamp the tool when the machine is at a standstill.
To keep the gap between the spindle and the table as small as possible, the matching table insert rings
must be used.
4.4.6 Setting the Safety Fence
For milling straight workpieces, the safety fence must always be used to ensure adequate guidance of the
workpiece.
Whenever the operation allows it (also for test cuts), an auxiliary fence must be used to keep the gap be-
tween the tool and the fence rulers as small as possible.
Whenever the working process allows it (also for test cuts), a power feeder must be used. This must be
equipped with a separate ON and OFF switch.
For manual feed at the fence, a push stick must be used together with the safety guard to support the feed.
Roller stands or table extensions must be used as supports for long workpieces.
4.4.7 Direction of Rotation
It is important that the tool is clamped in the correct direction of rotation.
The safer machining method is conventional milling. The machine user must ensure that the workpiece is
fed against the tool in the opposite direction to the spindle rotation.
Climb milling with manual feed involves considerable dangers. This operation is only permitted with ap-
propriate devices and suitable tools. If the machine is switched to climb milling, this dangerous operation
is signalled by a signal lamp on the control panel.
4.4.8 Speed Selection
The user must ensure that the correct speed is selected for the clamped tool.
For the optimum cutting speed, please refer to the diagram attached to the machine.
4.4.9 Machine Operation and Selection / Adjustment of Protective Devices
By using different milling spindles, tools and cutters, a large number of different machining oper-
ations can be carried out on the spindle moulder. Therefore, it is not possible to use only one pro-
tective device for all operations.
•Each operation should be considered separately. The most appropriate protective measures must be se-
lected for each specific operation.
•The type of tool, its blade projection and its height on the spindle determine the smallest possible table
opening.
•This can be achieved by selecting the appropriate table insert rings, which reduces the risk of the workpiece
catching on the edge of the opening.
•The tool must be covered as far as the respective operation permits.
•A detachable power feeder attached to machine table combined with the safety fence can provide the most
effective tool guarding. This combination is usually the best protective measure on table milling machines.
The feeding device must be easily adaptable to the different workpiece dimensions and not cause any draw-
ing-in hazards.

BA_WP_SPM2-1000_EN_28-22.docx
19
4.4.9.1 Milling at the fence, where the machining extends over the full workpiece length
With workpieces that usually have a right-angled cross-section over their entire length, this machining operation
is carried out by using a safety fence. Since the fence rulers are at a 90° angle to the table top, the workpiece can
be guided at right angles along the fence rulers.
Since the opening between the fence rulers on a table milling machine must be wide enough for the tool to pass
through, unnecessary danger areas are created on the knives, on the tool body and on the spindle. The gap
between the two fence rulers must be closed as much as possible. Otherwise there is a risk that the workpiece
leading edge will catch on the edge of the take-off ruler. These hazards are avoided by the use of an auxiliary
fence or suitable fence bridges, protective inserts, etc.
The manufacture of an auxiliary fence must be carried out with care. It is recommended that the knives are
passed through by fine adjustment of the fence and not by pushing the fence into the tool by hand.
4.4.9.2 Insert Milling
Insert milling is milling at the fence, whereby the workpiece is not machined over its entire length. Instead of
starting the cut at the beginning of the workpiece, the knives must plunge into the solid material and (depending
on the requirement) plunge out again before reaching the end of the workpiece. The splinter tabs must be placed
as close as possible to the cutter.
If the workpiece cannot be held safely by hand due to its small dimensions, a tenoning clamp or another work-
piece holding device, together with a suitable guard (which secures the tool as far as possible) must be used. The
tenoning clamp must allow fast and accurate insertion of the workpiece and ensure firm clamping.
A securely fastened telescopic fence as well as a kickback guard must also be used. For very long workpieces, use
an auxiliary fence if necessary.
Quick clamps, acting either via toggle levers or eccentrics, ensure fast and convenient workpiece clamping. Quick
clamps, acting either via toggle levers or eccentrics, ensure fast and convenient workpiece clamping. Rear and/or
front cross fences attached to the fence or on the table ensure more accurate work with the tenoning clamp. In
addition, extension and retraction bars should be provided on the tenoning clamp.
4.4.9.3 Curved Milling
For shaping the workpiece to be machined, a clamping template must always be used for curve milling. The shape
of the workpiece is achieved by pressing the template against the ring fence guard (see section 17.3), while
the knives are simultaneously passing by.
A clamping template cannot be used if the operation makes this impossible, e.g. if
•the workpiece is so large that the use of the template makes the work impracticable or
•the workpiece is so small or so shaped that a secure fixture in the template is not possible.
4.4.9.4 Inclined Milling
A special clamping device or inclinable stop rulers must be used to ensure a secure support during inclined mill-
ing. Push sticks must be used at the end of the milling process.
4.4.9.5 Climb Milling
Climb milling is a very dangerous operation as the operator is not able to stop the sudden forward movement of
the workpiece when it is caught by the knives. In addition, the workpiece can be dangerously ejected. Climb
milling should generally be avoided, even if a clamping device or a workpiece holding device is used. If the direc-
tion of rotation switch on the control panel is set turned to the “climb milling” position, this is signalled by an
illuminated signal lamp next to the switch.
4.4.9.6 Other Work
If other work is carried out on the machine, suitable clamping devices or workpiece holding devices must be used
to reduce the risk of accident.

BA_WP_SPM2-1000_EN_28-22.docx
20
4.4.10 Use of work devices with protective function
The following devices can be used to support the machine operator during work:
•Table extensions (2 x lateral and 1 x front) for large and long workpieces
•Sliding table, clamping drawers, sliding blocks and comparable aids
•Telescopic fence with two flip stops and workpiece clamping device
•Approach rails on workpiece guides
•Detachable power feeder
4.4.11 Noise Reduction
•The condition of the tools is important to reduce the noise level.
•The material and the requirement of the guards must be chosen in such a way that the noise level is reduced.
•The correct tool speed selection must be used to reduce the noise level.
If the workplace-related noise emission values of the machine exceed 85 dB(A),
suitable hearing protection must be made available to the personnel!
The use of personal hearing protection is not a substitute for the above options.
4.5 Construction-related Safety Equipment
•The main switch can be locked to protect the machine against unauthorized/unintentional switch-on during
standstill as well as during repair and maintenance work.
•The tool cover is ensured by means of a protective and pressure device (standard version).
•The safety fence has a protective bonnet to cover the tool from the top side. It is also equipped with a suction
nozzle to extract chips and dust directly at the point of origin.
•With the insert rings included as standard, the table opening can be adapted to the tool diameter as far as
possible in order to keep it as small as possible.
•The smooth-running and lockable sliding table with extendable fence and eccentric clamp can be rotated by
± 45°. This allows even large workpieces to be processed safely.
4.6 Electrical Safety Equipment
•The machine is equipped with an emergency stop button on the front control panel. This is directly accessible
at the workstation and immediately puts the machine out of operation in the event of danger.
•The main switch can be locked to protect the machine against unauthorised/unintentional switch-on during
standstill as well as during repair and maintenance work.
•Electronic brake for electrodynamic braking of the motors. This ensures the standstill of the tool in less than
10 seconds after the motor is switched off.
•Undervoltage protection: In the event of a voltage interruption, the machine is brought to a standstill, where
it remains even when the voltage is restored. To restart the machine, it must be switched on again.
•Protection against electric shock: The housing of the machine and the drives are protected against electric
shock by a neutral line.
•Dust protection: The control cabinet and drive unit are protected against contact, dust and splash water on
all sides with IP54 protection.
•Safety switch for tool change. A locking bolt can be used to activate an anti-rotation device for the milling
spindle. The internal switch then prevents the spindle from starting dangerously.
•Short-circuit protection: The machine has an overload protection for the motor (thermal cut-out switch).
•The service door on the left side of the machine is equipped with a safety switch. This switches off the spindle
drive as soon as the door is opened and prevents the drive from being switched on when the door is open.
•A signal light indicates the set direction of rotation during the dangerous “climb milling”operation.
