Worcester GREENSTAR SYSTEM FILTER Release note

UK/IE
INSTALLATION & SERVICING INSTRUCTIONS
GREENSTAR SYSTEM FILTER
6720803839
-00.1Wo
FOR SEALED & OPEN VENT CENTRAL HEATING SYSTEMS WITH 22MM CENTRAL HEATING PIPES
6 720 803 839 (2012/11)

2
CONTENTS
6 720 803 839 (2012/11)
CONTENTS
1 Symbols and safety precautions 2
1.1 Explanation of symbols 2
1.2 Safety precautions 2
2 Standard package 3
3 Installation 4
4Servicing5
5Chemicaldosing6
1SYMBOLSANDSAFETY
PRECAUTIONS
1.1 EXPLANATION OF SYMBOLS
WARNING SYMBOL
Signal words indicate the seriousness of the hazard in terms of
the consequences of not following the safety instructions.
•NOTICE: indicates possible damage to property or
equipment, but where there is no risk of personal injury.
•CAUTION: indicates possible personal injury.
•WARNING: indicates possible severe personal injury.
•DANGER: indicates possible risk to life.
IMPORTANT INFORMATION
ADDITIONAL SYMBOLS
1.2 SAFETY PRECAUTIONS
FITTING AND MODIFICATION
The unit must not be fitted in any way other than described in
the Installation Instructions and any misuse or unauthorised
modifications to the unit or associated components and
systems could invalidate the warranty. The manufacturer
accepts no liability arising from any such actions. This does not
affect your statutory rights.
HEALTH AND SAFETY
The appliance contains no substances that contravene the
COSHH Regulations (Control of Substances Hazardous to
Health regulations 1988).
Spare Parts
Safety instructions in this document are
framed and identified by a warning triangle
which is printed on a grey background.
Electrical hazards are identified by a lightning
symbol surrounded by a warning triangle.
Notes contain important information in cases
where there is no risk of personal injury or
material losses and are identified by the
symbol shown on the left.They are bordered
by horizontal lines above and below the text.
Symbol Meaning
a reference number to identify/refer to a part or
item
1. a numbered step in an action sequence
▶ a step in an action sequence
a reference to a related part in the document or to
other related documents
•alistentry
– a list entry (second level)
Table 1
CAUTION: The system filter contains a strong
magnet.
Table 2
Pre plumbing kit 8 718 689 373 0
Air vent assembly 8 718 686 888 0
Valve assembly 8 718 689 372 0
System filter instructions 6 720 803 839 0
O ring main body seal 8 718 686 329 0
O ring valve 8 718 686 337 0
O ring air vent assembly 8 718 686 333 0
O ring air vent screw 8 718 687 916 0
WB sheath assembly 8 718 686 316 0
Valve screw 8 718 686 889 0
Tool for body 8 718 684 947 0
Tool for cap 8 718 684 950 0
1

3
STANDARD PACKAGE
6 720 803 839 (2012/11)
2 STANDARD PACKAGE
Fig. 1 Standard package
[1] Greenstar system filter
[2] Copper tails and fittings (22mm)
[3] Tool for body
[4] Tool for cap
GENERAL INFORMATION
The Greenstar system filter is suitable for 22mm pipe central
heating systems and can be fitted anywhere on the main
heating circuit. The system should be flushed and a suitable
inhibitor added in accordance with BS7593 before installing
the Greenstar System Filter. Failure to comply with the
guidance will limit the effectiveness of the Greenstar System
Filter in protecting your boiler and central heating system.
However, in order to achieve the best protection for the boiler,
Worcester, Bosch recommend that the filter is fitted between
the last radiator and the boiler on a vertical run of pipework. In
determining a suitable location for installation, it isimportant to
ensure you allow adequate access for servicing.
Fig. 2 Open vented system
Fig. 3 Combi/sealed system
[1] Boiler
[2] Open vent tank
[3] Pump
[4] Radiator
[5] System filter
The following instructions are designed to assist engineers in
the safe and effective installation and servicing of Greenstar
system filter and should be followed at all times. Any queries
arising from either installation or servicing should be directed
to Worcester, Bosch Technical Support.
Fig. 4 Dimensions
6720803839
-01.1Wo
3 4
12
6720803839 -02.1Wo
12
3
4
5
Greenstar system filter should onlybe installed
by a competent person. If in any doubt, consult
a qualified heating engineer.
6720803839
-03.1Wo
14
5
6720803839
-04.1Wo
Ø 139mm
45mm
145mm
35mm

4
INSTALLATION
6 720 803 839 (2012/11)
Fig. 5 Dimensions continued
3 INSTALLATION
▶ Drain the central heating or isolate feed and expansion tank
and release the system pressure.
1. Measure, mark and cut out a 70mm section of pipe.
2. The two copper elbows are different, the shorter elbow is
fitted on the pipe that returns to the boiler. Prepare the
elbows supplied and solder onto the ends of the pipes as
shown in figure 6.
Fig. 6 Pipework preparation
3. Slide the system filter onto the pipework and hand tighten,
following the flow direction indicated on the isolation valves.
Fig. 7 System filter installation
4. Tighten the compression fittings firmly, but do not over
tighten.
Fig. 8 Securing system filter
5. Using a suitable spanner, open the isolation valves.
Fig. 9 Open isolation valves
▶ Refill the heating system.
▶ Run the central heating system and check for leaks.
▶ Attach the self-adhesive label to the boiler in a prominent
position.
6720803839
-05.1Wo
6720803839
-06.1Wo
70mm
1.
2.
6720803839
-07.1Wo
3.
6720803839
-08.1Wo
4.
6720803839
-09.1Wo
5.

5
SERVICING
6 720 803 839 (2012/11)
4SERVICING
1. Turn both isolation valves to the marked OFF position.
2. Loosen the air vent to release the internal pressure.
– Then re- tighten the air vent.
Fig. 10 Close isolating valves
▶ Using the tool for body (larger of the two) steady the system
filter.
3. With the tool for cap gripping the base, loosen the base and
carefully unscrew.
Collect the filter contents in a container placed underneath
the filter.
Fig. 11
4. Remove the base [1] from the system filter, ensuring that
any water or debris is caught within the container.
5. Slide the magnetic cap sheath off the base [2].
▶ Wipe clean the magnetic cap sheath [2} and base [1].
▶ Reassemble the magnetic cap sheath onto the base section
and carefully screw the base section back into canister.
Fig. 12
▶ Using the tool for body (larger of the two) steady the system
filter.
6. Using the tool for cap, grip the base and tighten until sealed,
do not over tighten.
Always service the filter before leaving the
premises. The two large spanners should be
left with the customer.
NOTICE: Before commencing any servicing
work, turn off the electrical supply to the
boiler.
Protect the surface below the system filter
with a suitable container to capture water.
6720803839
-10.1Wo
1.
2.
6720803839
-11.1Wo
3.
6720803839
-12.1Wo
4. 5.
2
1

6
CHEMICAL DOSING
6 720 803 839 (2012/11)
Fig. 13
7. Using a suitable spanner open the isolation valves (If the
filter is used on a sealed system, recharge the system to
correct working pressure).
Fig. 14
5CHEMICALDOSING
1. With a standard radiator key, remove the quick dose air vent
[1].
The built-in, one-way valve will prevent water from
escaping.
Fig. 15
▶ Attach the chemical adaptor and feed in the chemical.
2. Wait five seconds before removing the adaptor.
Fig. 16
3. Replace the quick dose air vent [1].
▶ Allow the system to circulate for 30 seconds.
Fig. 17
The quick dose air vent will accept market-
leading chemical adaptors in either liquid or
concentrate form.
6720803839
-13.1Wo
6.
6720803839
-14.1Wo
7.
1.
6720803839
-15.1Wo
1
6720803839
-16.1Wo
2.
3.
6720803839
-17.1Wo
1

7
CHEMICAL DOSING
6 720 803 839 (2012/11)
SERVICE RECORD
It is recommended that your system filter is serviced regularly and that the appropriate Service Interval Record is completed.
Service Provider
Before completing the appropriate Service Record Below, please ensure you have carried out the service as described in the
servicing section of the manual.
Always use Worcester approved spare parts.
Service 1 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 2 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 3 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 4 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 5 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 6 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 7 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 8 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 9 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
Service 10 Date:
Engineer Name:
Company Name:
Telephone No.
Comments:
Signature:
