WorkPro W004532A User manual

W004532A
SAVE THIS MANUAL FOR FUTURE REFERENCE
Thank you for buying a WORKPRO product. Your cordless drill has been engineered and manufactured to
WORKPRO’s high standard for dependability, ease of operation, and operator safety. When properly cared for, it
will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before
using this product.
OPERATOR'S MANUAL
20V LI-ION CORDLESS DRILL
13
15
17
19
21
RELEASE

2
--------------------------------------------------------------------------------
---------------------------------------------------------------------
Introduction
Caution
General safety rules
Additional Safety Instructions
Additional safety instructions for the charger
Additional safety instructions related to the battery pack and battery safety
When to charge the battery
Unpacking
Symbols
Your product
Specifications
Operating instructions for drill driver
Operation
This tool has many features for making its use more pleasant and enjoyable. Safety, performance,
and dependability have been given top priority in the design of this product making it easy to
maintain and operate.
TABLE OF CONTENTS
INTRODUCTION
2
3
3
4
5
6
6
7
7
8
9
9
10
10
10
10
10
11
11
11
11
11
12
12
12
12
12
------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------------
--------------------------------------------------
--------------
------------------------------------------------------------------------
------------------------------------------------------------------------
--------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------
------------------------------------------------------------
---------------------------------------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
----------------------------------------------------------------
Problem solution
Environmental protection
---------------------------------------------------------------
Maintenance ----------------------------------------------------------------------------
Disposal of an exhausted battery pack --------------------------------------------------
on / off switch (see b)
switch lock
reversible (see c1, c2)
two-speed gear control (see d)
chuck adjustment (see e)
torque adjustment (see f)
automatic spindle lock (see g)
using the led light (see h)
drilling
tool protection system

CAUTION
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
WARNING!
Carefully read through this entire Instruction Manual before using your new Workpro Power Tool. Take special care
to heed the Cautions and Warnings.
Your Workpro power tool has many features that will make your job faster and easier. Safety, performance, and
dependability have given top priority in the development of this tool, making it easy to maintain and operate.
a.
b.
c.
a.
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
WORK AREA SAFETY
1.
2.
a.
b.
c.
d.
e.
a.
b.
c.
d.
e.
GENERAL SAFETY RULES
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodi-
fied plugs and matching outlets will reduce risk of
electric shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
ELECTRICAL SAFETY
b.
c.
d.
e.
f.
g.
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result
in serious personal injury.
PERSONAL SAFETY3.
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it
was designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
Maintain power tools. Check for misalignment or
POWER TOOL USE AND CARE
4.
3
Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will
reduce personal injuries.
Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in
personal injury.
Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.

















6.
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
SERVICE
a.
5.
Ensure the switch is in the off position before
inserting battery pack. Inserting the battery pack
into power tools that have the switch on invites
accidents.
BATTERY TOOL USE AND CARE
f.
g.
h.
i.
If in doubt, do not plug in the tool. Using a power
source with a voltage less than the nameplate rating is
harmful to the motor.
The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual will
be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse. To use this tool
properly, you must observe the safety regulations, the
assembly instructions and the operating instructions to
be found in this Manual. All persons who use and
If possible, always use clamps or a vice to hold your
work piece.
Always switch off before you put the tool down.
Ensure that the lighting is adequate.
Do not put pressure on the tool, such that it slows
the motor down.
Keep the area free of tripping hazards.
Do not let anyone under 18 years to operate this
tool.
Only use accessories in good condition.
Do not touch the blade after operation. It will be very
hot.
Keep your hands away from under the workpiece.
Never use your hands to remove sawdust, chips or
waste close by the blade.
ADDITIONAL SAFETY INSTRUCTIONS
GENERAL SAFETY RULES
Exposure to noise can cause hearing loss.
Loss of control can cause personal injury.
WEAR EAR PROTECTORS.
4
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, and accessories in accordance
with these instructions, taking into account the
working conditions and the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acciden-
tally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from
the battery may cause irritation or burns.
b.
c.
d.
e.
Rags, cloths, cord, string and the like should never
be left around the work area.
Support the work properly.
If you are interrupted when operating the tool,
complete the process and switch off before looking
up.
Periodically check that all nuts, bolts and other
fixings are properly tightened.
When using the tool, use safety equipment including
safety glasses or shield, ear defenders, and
protective clothing including safety gloves. Wear a
dust mask if the cutting or sanding operation creates
dust.

WARNING!








DANGER
If the battery pack is cracked or damaged in any
other way, do not insert it in the charger
Do not plug anything other than your Workpro tool
into the charger, as other objects may touch danger-
ous voltage points or short out parts, which could
result in fire or electric shock.
Do not place the tool or charger on an uneven
surface, as a fall may cause serious damage.
Never place the tool or charger near or over a heat
source such as a radiator or heater.
Do not operate the charger in a cabinet or other
enclosure unless proper ventilation is provided.
Use the battery charger indoors only.



If you wish to charge a second battery pack, unplug
the charger from the mains supply and leave it for at
least 15 minutes. After this time you can charge a
second battery pack.
• Do not allow any liquid to come into contact with
the charger. There is a danger of electric shock.
Do not position the tool or battery charger near
water; for example, near a sink, wash bowl or
toilet.
• Do not spill liquid of any kind on the tool or
charger. Doing so may short out parts, Causing
damage to the product and creating the risk of
fire or electric shock.
• To reduce the risk of an electric shock, unplug the
charger from the power supply before attempting
to clean it. To clean tool or charger, wipe with a
damp cloth. Use of any other cleaners is not
recommended.
• Do not place any object on to, or allow anything
to rest on the charger.
• Make sure that the charger cable is positioned
where it will not be stepped on, tripped over or
otherwise subjected to damage or stress. Keep
the lead away from operating machinery.
• Do not pull on the lead of the charger to discon-
nect it from the mains power socket.
• Do not use an extension cord unless it is
absolutely necessary. The use of an improper
extension cord could cause the risk of fire,
electric shock or electrocution.
• Never attempt to connect two chargers together.
• Do not charge batteries or use the tool and
battery pack in locations where the temperature
may be below 40°F or exceed 104°F such as
alongside sheds or metal structures.
• The battery can be charged or operated at
temperatures between 40°F and 104°F.
ADDITIONAL SAFETY INSTRUCTIONS
ADDITIONAL SAFETY INSTRUCTIONS FOR THE CHARGER
Your WORKPRO tool with Lithium Ion batteries may
only be charged with the specific designed Workpro
Lithium Ion battery charger purchased with the tool.
IT IS DANGEROUS TO USE ANY OTHER BATTERY
CHARGER TO CHARGE YOUR TOOL. Do not
attempt to charge the battery pack with any other
charger than the one supplied.
Before using the charger, read all the instructions,
labels and cautionary markings on the charger and
battery pack as well as the instructions on using the
battery pack.
Do not use the charger if it has been subjected to a
heavy knock, dropped or otherwise damaged in
anyway. Take the charger to an authorised service
centre for a check or repair.
Do not disassemble the charger. Opening or
removing covers may expose you to dangerous
voltages or other risks. Incorrect reassembly can
cause electric shock when you use the tool or
charger again. Take the charger to a power tool
repair centre when service or repair is required.
Incorrect re-assembly may result in the risk of fire,
electric shock or electrocution. To reduce the risk of
electric shock, do not disassemble any part of the
product.
5
service the machine have to be acquainted with this
Manual and must be informed about its potential
hazards.
Children and frail people must not use this tool.
Children should be supervised at all times if they are in
the area in which the tool is being used. It is also
imperative that you observe the accident prevention
regulations in force in your area. The same applies for
general rules of occupational health and safety.
The manufacturer shall not be liable for any changes
made to the tool nor for any damage resulting from
such changes. Even when the tool is used as
prescribed it is not possible to eliminate all residual risk
factors. The following hazards may arise in connection
with the tool’s construction and design:
Damage to the lungs if an effective dust mask is not worn.
Damage to hearing if effective ear defenders are not
worn.
NEVER CHARGE YOU LITHIUM ION BATTERY
BELOW OR ABOVE TEMPERATURES RECOMMEND-
ED OTHERWISE FIRE OR SERIOUS DAMAGE TO THE
BATTERY PACK MAY OCCUR.
The most suitable temperatures to charge the battery
pack are between 68 -77°F.

New batteries are shipped in a low charged condition and
should be fully charged before Use. The battery pack can
be recharged at any time during use, provided the pack is
not overheated. If the battery pack starts to cut out due to
low voltage, or previous tasks undertaken can no longer
be performed, it is suggested to stop using the tool and
recharge the battery. For storage, it is suggested to
recharge the battery between 50% and 75% charge. Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well-ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to filter
out microscopic particles.
Some examples of these chemicals are:
ADDITIONAL SAFETY INSTRUCTIONS RELATED TO
THE BATTERY PACK AND BATTERY SAFETY
NEVER STORE OR LEAVE YOUR LITHIUM ION
BATTERY IN TEMPERATURES OVER THAT RECOM-
MENDED OTHERWISE FIRE MAY OCCUR.
Do not store the Lithium Ion battery anywhere that the
temperature can easily reach higher temperatures than
recommended -this includes garden type sheds, and
Vehicles where the inside temperature can climb to
dangerous levels in the direct sunlight and on high
temperature days.
Some dust created by power sanding, sawing,
grinding, drilling and other construction activities
contains chemicals known to the State of California
to cause cancer, birth defects of other reproductive harm.
WARNING!








Use only the WORKPRO batteries supplied with the
WORKPRO Tool or WORKPRO-approved replacements.
Do not use the battery to power any device other
than the WORKPRO tool it was sold with.
Charge the battery only with the WORKPRO charger
supplied with the tool or WORKPRO-approved
replacements and according to the instructions in
the WORKPRO Instruction Manual.
Do not charge the battery in a place where static
electricity is generated nor let the battery touch
something that is statically charged.
The battery can be stored at temperatures between
40°F and 104°F.










NEVER STORE OR LEAVE YOUR LITHIUM ION
BATTERY IN TEMPERATURES OVER THAT RECOM-
MENDED OTHERWISE FIRE MAY OCCUR.
The most suitable temperatures to charge the battery
pack are between 68 -77°F.
The battery can be charged or operated at tempera-
tures between 40°F and 104°F.
Always allow the battery pack to cool down after
charging, do not place it in a hot environment such
as a metal shed or open trailer left in the sun.
Take care where the tool is stored. Do not store in
areas of corrosive fumes, or salt air or similar
conditions. Try and store the tool in the packaging
supplied with the tool.
WHEN TO CHARGE THE BATTERY
Lead from lead-based paints.
Crystalline silica from bricks and cement and other
masonry products, and Arsenic and chromium from
chemically-treated lumber.
6
Do not dispose of the battery in a fire or put the
battery into a microwave oven, conventional oven,
dryer, or high-pressure container. Under these
conditions, the battery may explode.
Never attempt to open the battery pack, puncture
the battery or subject the battery to strong physical
shock.
If the plastic housing of the battery pack breaks
open or cracks, immediately discontinue its use and
do not recharge it. Ensure the battery pack clip is in
good condition and will not allow the pack to fall free
from the tool. If the clip is damaged or for any reason
is not locking the pack in place Do Not continue to
use.
Stop using the battery if it exhibits abnormal heat,
odour, colour, deformation, or is in an abnormal
condition.
If you detect leakage or a foul odour, it is especially
important to keep the battery away from fire. If
battery liquid leaks onto your skin or clothes, wash
well with clean water immediately. If liquid leaking
from the battery gets into your eyes, do not rub your
eyes. Rinse your eyes well (for at least 10 minutes)
with clean water, and consult a doctor immediately.
Do not use a leaking battery.
Handle batteries with care to avoid shorting the
battery with conducting materials, such as nails,
screws, metal watch bands, rings, bracelets, and
keys. The battery may overheat and could burn you.
After the battery has reached the end of its useful
life, we recommend recycling the materials at your
local municipal council recycling centre. DO NOT
attempt to replace the battery cells in the battery
pack, repair or modify any part of the battery pack
assembly.
When recycling, make it nonconductive by applying
insulating tape to the terminals located on the
battery.

UNPACKING
SYMBOLS
The product and the packaging are not children’s
toys! Children must not play with plastic bags,
sheets and small parts! There is a danger of choking
and suffocation!
WARNING!



Unpack all parts and lay them on a flat, stable surface.
Remove all packing materials and shipping devices, if
applicable.
Make sure the delivery contents are complete and free of
any damage. If you find that parts are missing or show
damage do not use the product but contact your dealer.
Using an incomplete or damaged product represents a
hazard to people and property.

On the product, the rating label and within these instructions you will find among others the following
symbols and abbreviations. Familiarize yourself with them to reduce hazards like personal injuries and
damage to property.
Volt, (alternating voltage)
Hertz
Watt
Per minute
Note / Remark.
Read the instructionmanual.
Wear eye protection.
Wear protective gloves.
Do not expose to rain or
water
Do not burn
V~
Hz
W
Millimetre
Kilogram
Decibel (A-rated)
Caution / Warning.
Wear hearing protection.
Wear a dust mask.
Wear protective, slipresis-
tant footwear.
Risk of electric shock
mm
kg
dB(A)
Switch the product off and disconnect it from the power supply before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class II. That means it is equipped with enhanced or
double insulation.
WEEE symbol. Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or local
store for recycling advice.
Do not throw the electronic waste products into the domestic waste refuse. Such
products must be delivered to a recycling centre.
-1
/min or min
7
Ensure that you have all the accessories and tools needed
for assembly and operation. This also includes suitable
personal protective equipment.

YOUR PRODUCT
1. 10mm keyless chuck
2. Torque adjustment ring
3. Two-speed gear control
4. Forward/reverse rotation control
5. Belt clip

5
6
7
8
10
1
9
2
3
4
13
15
17
19
21
RELEASE
6. Battery pack
7. Battery pack release button
8. On/off switch
9. Led light
10. Charger
11. 6pc drill bits
12. Extension bit holder
13. 10pc screwdriver bits
1/8 5/32 3/16 1/4 PH1 PH2 PH3 T10 T15 T20
131211
8

SPECIFICATIONS
Charger
Batteries
Charging Time
Drill No Load Speed
Torque Settings
Torque
Drill Chuck Capacity
Max Drilling Capacity Steel / Wood
Weight
Battery
Charger
120V ～60Hz
1.5Ah
3-5H
0-400/0-1500/min-1
21+1
23 N.M.
3/8"(10mm) keyless
8mm / 22mm
0.95Kg(2.09lbs)
0.34Kg(0.75lbs)
WJ-Y112150350W
INTENDED USE
The machine is intended for driving in and loosening
screws as well as for drilling in wood, metal and
plastic.
B) TO REMOVE OR INSTALL BATTERY PACK
(SEE A)
Depress the battery pack release button (7) to release
and slide the battery pack out from your tool. After
recharge, slide it back into your tool. A simple push
with slight pressure will be sufficient.
BEFORE PUTTING INTO OPERATION
A) CHARGING THE BATTERY
The battery charger supplied is matched to the Li-ion
battery installed in the machine. Do not use another
battery charger.The Li-ion battery is protected against
deep discharging. When the battery is empty, the
machine is switched off by means of a protective
circuit: The tool holder no longer rotates.In a warm
environment or after heavy use, the battery pack may
become too hot to permit charging. Allow time for the
battery to cool down before recharging.When the
battery pack is charged for the first time and after
prolonged storage, the battery pack will accept a
100% charge after several charge and discharge
cycles.
OPERATING INSTRUCTIONS FOR DRILL DRIVER
Before using the tool, read the instruction book
carefully.
NOTE:
A
7
9

C2
4
C2
4
Depress the On/Off switch (8) to start and release it to
stop your drill. The on/off switch is fitted with a brake
function which stops your chuck immediately when
you quickly release the switch.It is also a variable
speed switch that delivers higher speed and torque
with increased trigger pressure. Speed is controlled by
the amount of switch trigger pression.
ON / OFF SWITCH (SEE B)1.
The switch trigger can be locked in the OFF position.
This helps to reduce the possibility of accidental
starting when not in use. To lock the switch trigger,
place the rotation control in the center position.
SWITCH LOCK2.
Do not operate for long periods at low speed
because excess heat will be produced internally.
WARNING!
Never change the direction of rotation when the
chuck is rotating, wait until it has stopped!
WARNING!
To prevent gear damage, always allow the chuck to
come to a complete stop before changing the
direction of rotation or the two-speed gear control.
WARNING!
OPERATION

The drill has a two-speed gear control (3) designed for
drilling or driving at LOW (mark is 1) or HIGH (mark is 2)
speeds. A slide switch is located on top of the drill to
select either LOW or HIGH speed. When using the drill
in the LOW speed range, the speed will decrease and
the drill will have greater power and torque. When
using the drill in the HIGH speed range, the speed will
increase and the drill will have less power and torque.
GEAR I
Low speed range: for screw driving or working with
large drilling diameter
GEAR II
High speed range: for working with small drilling
diameter
TWO-SPEED GEAR CONTROL (SEE D)
4.
For drilling and screw driving use forward rotation (4)
marked “ ” (lever is moved to the left). Only use
reverse rotation marked “ ” (lever is moved to the
right) to remove screws or release a jammed drill bit.
REVERSIBLE (SEE C1, C2)3.
13
15
17
19
21
RELEASE
8
B
4
C1
4
13
15
17
19
21
RELEASE
D3
10


To open the chuck jaws rotate the front section of the
chuck. Insert the drill bit between the chuck jaws and
rotate the front section in the opposite direction.
Ensure the drill bit is in the center of the chuck jaws.
Finally, firmly rotate the front chuck section in the
opposite directions. Your drill bit is now clamped in the
chuck..
CHUCK ADJUSTMENT (SEE E)
5.
(SCREW DRIVING FORCE OF YOUR DRILL DRIVER)
The torque is adjusted by rotating the torque
adjustment ring. The torque is greater when the torque
adjustment ring is set on a higher setting. The torque is
less when the torque adjustment ring is set on a lower
setting.
TORQUE ADJUSTMENT (SEE F)6.
The LED light (9) allows you to keep a clear view under
less illuminated circumstances. To turn on the light
simply press the on/off switch. When you release the
on/off switch, the light will go out.
USING THE LED LIGHT (SEE H)
8.
When drilling into a hard smooth surface, use a center
punch to mark the desired hole location. This will
prevent the drill bit from slipping off center as the hole
is started. Hold the tool firmly and place the tip of the
bit at the point to be drilled. Depress the switch trigger
to start the tool. Move the drill bit into the workpiece,
applying only enough pressure to keep the bit rotating.
Do not force or apply side pressure to elongate a hole.
DRILLING
9.
The automatic spindle lock allows you to use it as a
regular screwdriver. You can give an extra twist to
firmly tighten a screw, loosen a very tight screw or
continue working when the battery energy has expired.
For manual screwdriver purposes, the chuck is
automatically locked when the tool is off.
AUTOMATIC SPINDLE LOCK (SEE G)7.
1 - 4 For driving small screws
5 - 9 For driving screws into soft material
10 - 14 For driving screws into soft and hard material
15 - 19 For driving screws into hard wood
20 - 21 For driving larger screws
For heavy drilling
MAKE THE SETTING AS FOLLOWS:
E
13
15
17
19
21
RELEASE
F
13
15
17
19
21
RELEASE
H
9
G
OPERATION

11

The tool will automatically stop during operation if the
tool and/or battery are placed under one of the
following conditions:
TOOL PROTECTION SYSTEM10.
Overloaded: The tool is operated in a manner that
causes it to draw an abnormally high current. In this
situation, release the Trigger Switch on the tool and
stop the application that caused the tool to become
overloaded. Then pull the Trigger Switch again to
restart.
PROBLEM SOLUTION
1.
2.
3.
WHY DOES THE DRILL NOT TURN ON
WHEN YOU PRESS THE SWITCH?
The forward/reverse rotation control, which is on top
of the trigger, is positioned in the lock function.
Unlock the forward/reverse rotation control by
putting it into the required rotation position. Push
the trigger and the drill will start to rotate. Or if the
LED light flashes at the same time you press the
Switch, please charge the battery.
THE DRILL STOPS BEFORE THE SCREW
IS COMPLETELY TIGHTENED. WHY?
Verify the torque position of the torque adjusting
ring, you can find the torque-adjusting ring between
the chuck and the drill body. Position 1 is the lowest
torque (screw driving force) and position 20 is the
highest torque (screw driving force). Position 21 is
for drill operation. Regulate the torque adjusting ring
to a higher position to reach the best result.
REASONS FOR DIFFERENT BATTERY
PACK WORKING TIMES
Charging time problems, as above, and having not
used a battery pack for aprolonged time will reduce
the battery pack working time. This can be correct-
ed after several charge and discharge operations by
charging & working with your drill. Heavy working
conditions such as large screws into hard wood will
use up the battery pack energy faster than lighter
working conditions. Do not re-charge your battery
pack below 0°C and above 40°C as this will affect
performance.
This product has been marked with a symbol relating to removing electric and electronic waste. This
means that this product shall not be discarded with household waste but that it shall be returned to a
collection system. It will then be recycled or dismantled in order to reduce the impact on the
environment. Electric and electronic equipment can be hazardous for the environment and for human
health since they contain hazardous substances.
ENVIRONMENTAL PROTECTION
DISPOSAL OF AN EXHAUSTED BATTERY PACK



Clean the power tool using a soft, damp cloth. Do
not use detergents or flam-mable products which
may damage the tool.
Your cordless power tool does not require regular
mechanical maintenance such as greasing the
bearings or the rollers.
Check the state of the charger power cable before
each use.
MAINTENANCE
To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack
contains Li-ion batteries. Consult your local waste authority for information regarding available recycling
and/or disposal options. Discharge your battery pack by operating your tool, then remove the battery
pack from the tool housing and cover the battery pack connections with heavy-duty adhesive tape to
prevent short circuit and energy discharge. Do not attempt to open or remove any of the components.

OPERATION

12


Overheated: Under the condition above, if the tool
does not start, the Battery are overheated. In this
situation, let the Tool and Battery cool before pulling
the Trigger Switch again.
Low battery voltage: The remaining Battery capacity
is too low and the tool will not operate. In this
situation, remove and recharge the Battery.
