WorkSimpli WS323TIB User manual

Item No.: WS323TIB
Installation guide
150KG
580-1230mm
Technical data
Column Stage
Max. Load Capacity
Height range
3
Accessory list
Attention: The drawings below are only for reference which might be slightly
different from the actual object, please in kind prevail. Any tools missing or
installation problems, please contact the customer service firstly.
8
16
12
24
4
6
6
6
1
ImageNo. Spec Qty
M6
M6
M6
M6
M8
St4.2
St4.2
Cable Tie
Allen Key
4x4mm
Allen Key
(with cross)
5x5mm
6
M6
Component list
PartNo. Qty PartNo. Qty
PartNo. Qty PartNo. Qty
PartNo. Qty PartNo. Qty
PartNo. Qty PartNo. Qty
PartNo. Qty PartNo. Qty
PartNo. Qty
Pedestal Lifting Column
Supporting Beam Side Bracket
Left Connecting Plate Right Connecting Plate
Control Box Handset
Handset Screw Switch Cord
Power Plug
Note: There are three angles of installation for this type of desk, 90°, 120°, 180°
STEP 1 Install left and right connecting plates 90° Placement
120° Placement
180° Placement
Connect the two supporting beams (3) to the left and
right connecting plates (5) (6) with screws (C) and (E)
respectively. There are three angles to choose , and
finally tighten them with an allen key (I).
STEP 2 Install Columns
120° Placement
Connect the lifting columns (2) to the supporting beams (3)
with screws (D), the middle column (2) to the left and right
connecting plates (5) (6), and use an allen key (I) to tighten
the screws; the installation methods of 90° and 180°
placements are the same as 120°.
STEP 3-1 Install Pedestals
Assemble the feet (1) and the lifting columns (2) together.
Use a allen key (I) to tighten the screws (C).
90° & 120° Placement

STEP 3-2
180° Placement
Assemble the feet (1) and the lifting columns (2) together.
Use the allen key (I) to tighten the screws(C).
STEP 4
120° Placement
Install Side Brackets
Assemble the left and right side brackets (4) to the supporting
beams (3) with screws (A), connect the middle side bracket (4)
with the left and right connection plates (5) (6), and tighten the
screws with an allen key(I); the installation methods of 90° and
180° placements are the same as 120°.
STEP 5 Wire all Cables to Control Box
120° Placement The wiring of 90°&180° placement are the
same as 120° placement.
Tear off Manage Cable Fix
The cable tie (H) can be glued on the tabletop, and can also
be screwed on the tabletop with screws (G).
Port for
Handset
Power port
Port for cable
connected to the
lifting column
STEP 6-1
STEP 6-2
STEP 6-3
90° Placement
120° Placement
180° Placement
Install Tabletop, Control box and Handset
Loosen
Stretch
Tighten
Loosen
Stretch
Tighten
Loosen
Stretch
Tighten
Fix the control box(7)
under the tabletop
Fix the control box(7)
under the tabletop
Fix the control box(7)
under the tabletop
The stretching distance of the beam
can be adjusted according to the
actual use situation.
Fix the tabletop with screw (J). Install the control box (7)
on the table board with screws (F). Install the handset (8)
with screws (9) and use a pistol drill to tighten.
The stretching distance of the beam can be
adjusted according to the actual use situation,
the adjustment method is the same as step 6-1
The stretching distance of the beam can be
adjusted according to the actual use situation,
the adjustment method is the same as step 6-1
Fix the tabletop with screw (J). Install the control box (7)
on the table board with screws (F). Install the handset (8)
with screws (9) and use a pistol drill to tighten.
Fix the tabletop with screw (J). Install the control box (7)
on the table board with screws (F). Install the handset (8)
with screws (9) and use a pistol drill to tighten.

Method
The desktop could not function
Rising in a low speed
The desk moving downwards
without any operation
Automatically Self-Reset
The following tips will help you detected and eliminate the common fault and
error. If the fault you met is not listed below, please contact with your supplier.
Only the manufacturer and professionals are capable for investigating and
correcting those fault and error.
Fault phenomenon
Go down but not go up or go up
but not go down
The upper and downward
height is not enough
The desk could not lifted
Overwork
(Duty cycle: Max 2min on/18min OFF)
Check if all the cables well
connected;
Check if overloaded,
max loading: 150kg;
Reset;
Restart after suspend for 18mins while
connecting with power.
Attention
1. Power supply: AC100V-240V, 50/60Hz
2. Service Environment: 0-40℃
3. Unplug the power plug before cleaning, wipe the dust on surface with slight wet
dishcloth when cleaning, be careful not to let the drops into the internal parts, not loose
the connector.
4. The electric box contains electronic components, metals, plastics, wires etc., so
dispose of it in accordance with each country's environmental legislation, not the
general household waste.
5. Check carefully to ensure correct and complete assembly before using.
6. Be familiar with all functions and program settings of the product before first use.
7. Children are forbidden to play on the product because of unforeseen action when
playing, so any dangerous consequences caused by this improper action will not be on
manufacturers.
8. Slight noise caused by the V-ribbed belt or brake system due to structure will not
have any effect on the use of the equipment.
9. Corrosive or abrasive materials are forbidden to clean the equipment. Must ensure
that the cleaner used will not pollute the environment.
10. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance.
11. Cleaning and user maintenance shall not be made by children without supervision.
12. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or a similarly qualified person in order to avoid a hazard.
13. Please make sure there is no hazard sources in your operating environment. e.g.,
do not litter the tools around. Always be careful to treat the packaging materials in order
to avoid any possible danger, e.g. plastic bag may lead to choking hazard to children.
14. Keep the original package of the equipment if necessary in case of the future use in
transportation.
This marking indicates that this product should
not be disposed with other household wastes.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
