Angle grinder
Winkelschleifer

Original instructions EN
Übersetzung der Originalanleitung D


1
6 5 4
8
7
9
2 3
10

ABC
D.1 D.2
8
6
9
8
6
9
D.3
E
15°-30°
F

Angle grinder EN
6
1. SPINDLE LOCK BUTTON
2. ON/OFF SWITCH
3. HAND GRIP AREAS
4. AUXILIARY HANDLE
5. WHEEL GUARD FOR GRINDING
6. DISC *
7. SPANNER
8. INNER FLANGE
9. OUTER FLANGE
10. WHEEL GUARD FOR CUTTING*
*Not all the accessories illustrated or described are included in standard delivery.

Angle grinder EN
7
TECHNICAL DATA
Type WX705 WX705.1
(
700-749- designation of machinery, representative of Angle
Grinder
)
Voltage 230-240V~50Hz
Power input 750W
Rated speed 11000/min
Disc size 115mm
Disc bore 22.2mm
Spindle thread M14
Protection class /ll
Machine weight 2.0kg
NOISE INFORMATION
A weighted sound pressure LpA: 78.4dB(A)
A weighted sound power LwA: 89.4dB(A)
KPA&KWA 3.0dB(A)
Wear ear protection when sound pressure is over 80dB(A)
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 60745:
Typical weighted vibration Vibration emission value ah= 6.95m/s2
Uncertainty K = 1.5m/s²
WARNING: The vibration emission value during actual use of the power tool can differ
from the declared value depending on the ways in which the tool is used dependant on the
following examples and other variations on how the tool is used:
How the tool is used and the materials being cut.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration accessories are used.
And the tool is being used as intended by its design and these instructions.

Angle grinder EN
8
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING: To be accurate, an estimation of exposure level in the actual conditions of use
should also take account of all parts of the operating cycle such as the times when the tool
is switched off and when it is running idle but not actually doing the job.This may significantly
reduce the exposure level over the total working period.
Helping to minimise your vibration exposure risk.
Maintain this tool in accordance with these instructions and keep well lubricated (where
appropriate)
If the tool is to be used regularly then invest in anti vibration accessories.
Avoid using tools in temperatures of 100C or less.
Plan your work schedule to spread any high vibration tool use across a number of days.
ACCESSORIES
WX705 WX705.1
Spanner 1 1
Auxiliary handle 1 1
Wheel guard for grinding 1 -
Wheel guard for cutting 1 -
Metal grinding disc - 1
Diamond cutting disc 2 -
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.

Angle grinder EN
9
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR
ANGLE GRINDER
SAFETY WARNINGS COMMON FOR
GRINDING OR ABRASIVE CUTTING-OFF
OPERATIONS:
1. This power tool is intended to
function as a grinder, or cut-off
tool. Read all safety warnings,
instructions, illustrations and
specifications provided with this
power tool. Failure to follow all
instructions listed below may result in
electric shock, fire and/or serious injury.
2. Operations such as sanding,
wire brushing, polishing are not
recommended to be performed with
this power tool. Operations for which
the power tool was not designed may
create a hazard and cause personal injury.
3. Do not use accessories which
are not specifically designed
and recommended by the tool
manufacturer. Just because the
accessory can be attached to your power
tool, it does not assure safe operation.
4. The rated speed of the accessory
must be at least equal to the
maximum speed marked on the
power tool. Accessories running faster
than their rated speed can break and fly
apart.
5. The outside diameter and the
thickness of your accessory must
be within the capacity rating of your
power tool. Incorrectly sized accessories
cannot be adequately guarded or
controlled.
6. The arbour size of wheels, flanges,
backing pads or any other accessory
must properly fit the spindle of the
power tool. Accessories with arbour
holes that do not match the mounting
hardware of the power tool will run out
of balance, vibrate excessively and may
cause loss of control.
7. Do not use a damaged accessory.
Before each use inspect the
accessory such as abrasive wheels
for chips and cracks, backing pad for
cracks, tear or excess wear. If power
tool or accessory is dropped, inspect
for damage or install an undamaged
accessory. After inspecting and
installing an accessory, position
yourself and bystanders away from
the plane of the rotating accessory
and run the power tool at maximum
no-load speed for one minute.
Damaged accessories will normally break
apart during this test time.
8. Wear personal protective equipment.
Depending on application, use face
shield, safety goggles or safety
glasses. As appropriate, wear dust
mask, hearing protectors, gloves
and workshop apron capable of
stopping small abrasive or workpiece
fragments. The eye protection must
be capable of stopping flying debris
generated by various operations. The
dust mask or respirator must be capable
of filtrating particles generated by your
operation. Prolonged exposure to high
intensity noise may cause hearing loss.
9. Keep bystanders a safe distance
away from work area. Anyone
entering the work area must wear
personal protective equipment.
Fragments of workpiece or of a broken
accessory may fly away and cause injury
beyond immediate area of operation.
10.Hold power tool by insulated gripping
surfaces only, when performing
an operation where the cutting
accessory may contact hidden wiring
or its own cord. Cutting accessory
contacting a “live” wire may make
exposed metal parts of the power tool
“live” and shock the operator.
11.Position the cord clear of the
spinning accessory. If you lose control,
the cord may be cut or snagged and
your hand or arm may be pulled into the
spinning accessory.
12.Never lay the power tool down
until the accessory has come to a
complete stop. The spinning accessory
may grab the surface and pull the power

Angle grinder EN
10
tool out of your control.
13.Do not run the power tool while
carrying it at your side. Accidental
contact with the spinning accessory could
snag your clothing, pulling the accessory
into your body.
14.Regularly clean the power tool’s air
vents. The motor’s fan will draw the
dust inside the housing and excessive
accumulation of powdered metal may
cause electrical hazards.
15.Do not operate the power tool near
flammable materials. Sparks could
ignite these materials.
16.Do not use accessories that require
liquid coolants. Using water or other
liquid coolants may result in electrocution
or shock.
17. Your hand must hold on the handle when
you are working. Always use the auxiliary
handles supplied with the tool. Loss of
control can cause personal injury.
FURTHER SAFETY INSTRUCTIONS FOR
ALL OPERATIONS
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or
snagged rotating wheel, backing pad, brush
or any other accessory. Pinching or snagging
causes rapid stalling of the rotating accessory
which in turn causes the uncontrolled power
tool to be forced in the direction opposite of
the accessory’s rotation at the point of the
binding.
For example, if an abrasive wheel is snagged
or pinched by the workpiece, the edge of the
wheel that is entering into the pinch point can
dig into the surface of the material causing
the wheel to climb out or kick out.The wheel
may either jump toward or away from the
operator, depending on direction of the
wheel’s movement at the point of pinching.
Abrasive wheels may also break under these
conditions.
Kickback is the result of power tool misuse
and/or incorrect operating procedures or
conditions and can be avoided by taking
proper precautions as given below.
1. Maintain a firm grip on the power
tool and position your body and
arm to allow you to resist kickback
forces. Always use auxiliary handle, if
provided, for maximum control over
kickback or torque reaction during
start-up. The operator can control torque
reactions or kickback forces, if proper
precautions are taken.
2. Never place your hand near the
rotating accessory. Accessory may
kickback over your hand.
3. Do not position your body in the
area where power tool will move
if kickback occurs. Kickback will
propel the tool in direction opposite to
the wheel’s movement at the point of
snagging.
4. Use special care when working
corners, sharp edges etc. Avoid
bouncing and snagging the
accessory. Corners, sharp edges or
bouncing have a tendency to snag the
rotating accessory and cause loss of
control or kickback.
5. Do not attach a saw chain
woodcarving blade or toothed saw
blade. Such blades create frequent
kickback and loss of control.
ADDITIONAL SAFETY INSTRUCTIONS
FOR GRINDING AND CUTTING-OFF
OPERATIONS
SAFETY WARNINGS SPECIFIC FOR
GRINDING AND ABRASIVE CUTTING-OFF
OPERATIONS:
1. Use only wheel types that are
recommended for your power tool
and the specific guard designed for
the selected wheel. Wheels for which
the power tool was not designed cannot
be adequately guarded and are unsafe.
2. The guard must be securely attached
to the power tool and positioned for
maximum safety, so the least amount
of wheel is exposed towards the
operator. The guard helps to protect
operator from broken wheel fragments
and accidental contact with wheel.
3. Wheels must be used only for
recommended applications. For
example: do not grind with the side

Angle grinder EN
11
of cut-off wheel. Abrasive cut-off wheels
are intended for peripheral grinding, side
forces applied to these wheels may cause
them to shatter.
4. Always use undamaged wheel
flanges that are of correct size and
shape for your selected wheel. Proper
wheel flanges support the wheel thus
reducing the possibility of wheel breakage.
Flanges for cut-off wheels may be different
from grinding wheel flanges.
5. Do not use worn down wheels from
larger power tools. Wheel intended for
larger power tool is not suitable for the
higher speed of a smaller tool and may
burst.
ADDITIONAL SAFETY INSTRUCTIONS
FOR CUTTING-OFF OPERATIONS
ADDITIONAL SAFETY WARNINGS
SPECIFIC FOR ABRASIVE CUTTING-OFF
OPERATIONS:
1. Do not “jam” the cut-off wheel or
apply excessive pressure. Do not
attempt to make an excessive depth
of cut. Overstressing the wheel increases
the loading and susceptibility to twisting
or binding of the wheel in the cut and the
possibility of kickback or wheel breakage.
2. Do not position your body in line with
and behind the rotating wheel. When
the wheel, at the point of operation, is
moving away from your body, the possible
kickback may propel the spinning wheel
and the power tool directly at you.
3. When wheel is binding or when
interrupting a cut for any reason,
switch off the power tool and hold
the power tool motionless until the
wheel comes to a complete stop.
Never attempt to remove the cut-off
wheel from the cut while the wheel
is in motion otherwise kickback may
occur. Investigate and take corrective
action to eliminate the cause of wheel
binding.
4. Do not restart the cutting operation
in the workpiece. Let the wheel reach
full speed and carefully reenter the
cut. The wheel may bind, walk up or
kickback if the power tool is restarted in
the workpiece.
5. Support panels or any oversized
workpiece to minimize the risk of
wheel pinching and kickback. Large
workpieces tend to sag under their own
weight. Supports must be placed under
the workpiece near the line of cut and near
the edge of the workpiece on both sides of
the wheel.
6. Use extra caution when making a
“pocket cut” into existing walls or
other blind areas. The protruding wheel
may cut gas or water pipes, electrical
wiring or objects that can cause kickback.

Angle grinder EN
12
SYMBOLS OpERATION INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for cutting,
roughing and brushing metal and stone
materials without using water. For cutting
metal, a special protection guard for cutting
(accessory) must be used.
1. INSTALLING AUXILIARY HANDLE (See
Fig. A)
You have the option of two working positions
to provide the safest and most comfortable
control of your angle grinder.The handle is
screwed clockwise into either hole on the
sides of the gear case.
2. HAND GRIP AREAS
Always hold your angle grinder firmly with
both hands when operating.
3. GUARD ADJUSTMENT (See Fig. B, C)
Before any work on the machine itself,
pull the mains plug.
For work with grinding or cutting discs,
the wheel guard must be mounted.
Wheel Guard for Grinding
The coded projection on the wheel guard (5)
ensures that only a guard that fits the machine
type can be mounted.
Open the clamping lever. Place the wheel
guard (5) with coded projection into the coded
groove on the spindle of the machine head
and rotate to the required position (working
position).
To fasten the wheel guard (5), close the
clamping lever.
The closed side of the wheel guard (5) must
always point to the operator.
NOTE: With the clamping lever open the
clamp adjusting nut can be adjusted to ensure
the guard is securely clamped after the
clamping lever is finally closed.
Wheel guard for cutting
WARNING! For cutting metal,
always work with the wheel guard for
cutting(10).
The wheel guard for cutting (10) is mounted
To reduce the risk of injury, user
must read instruction manual
Warning
Double insulation
Wear eye protection
Wear ear protection
Wear dust mask
This product has been marked
with a symbol relating to removing
electric and electronic waste.This
means that this product shall not
be discarded with household waste
but that it shall be returned to a
collection system which conforms
to the European Directive 2002/96/
CE. It will then be recycled or
dismantled in order to reduce the
impact on the environment. Electric
and electronic equipment can be
hazardous for the environment
and for human health since they
contain hazardous substances.

Angle grinder EN
13
in the same manner as the wheel guard for
grinding(5) .
4. SPINDLE LOCK BUTTON
Must only be used when changing a disc.
Never press when the disc is rotating!
5. FITTING THE DISCS (See Fig. D)
Put the inner flange onto the tool spindle.
Ensure it is located on the two flats of spindle
(see Fig. D1).
Place the disc on the tool spindle and inner
flange. Ensure it is correctly located. Fit the
threaded outer flange making sure it is facing
in the correct direction for the type of disc
fitted. For grinding discs, the flange is fitted
with the raised portion facing towards the
disc. For cutting discs, the flange is fitted with
the raised portion facing away from the disc
(see Fig. D2).
Press in the spindle lock button and rotate the
spindle by hand until it is locked. Keeping the
lock button pressed in, tighten the outer flange
with the spanner provided. (See Fig. D3)
6. SLIDE ON/OFF SWITCH (See Fig. E)
To start the power tool, push the on/off switch
(2) forward.
To lock the on/off switch (2), press the on/off
switch (2) down at the front until it engages.
To switch off the power tool, release the on/off
switch (2) or, if it is locked, briefly push down
the back of the on/off switch (2) and then
release it.
7. TO USE THE GRINDER (See Fig. F)
ATTENTION: Do not switch the
grinder on whilst the disc is in
contact with the workpiece. Allow the
disc to reach full speed before starting
to grind.
Hold your angle grinder with one hand on the
main handle and other hand firmly around the
auxiliary handle.
Always position the guard so that as much of
the exposed disc as possible is pointing away
from you.
Be prepared for a stream of sparks when the
disc touches the metal.
For best tool control material removal and
minimum overloading, maintain an angle
between the disc and work surface of
approximately 150 -300when grinding.
Use caution when working into corners as
contact with the intersecting surface may
cause the grinder to jump or twist.
When grinding is complete allow the
workpiece to cool. Do not touch the hot
surface.
8. CUTTING
WARNING! For cutting metal, always
work with the wheel guard for cutting.
When cutting, do not press, tilt or oscillate the
machine. Work with moderate feed, adapted to
the material being cut.
Do not reduce the speed of running down
cutting discs by applying sideward pressure.
The direction in which the cutting is performed
is important.
The machine must always work in an up-
grinding motion.Therefore, never move the
machine in the other direction! Otherwise, the
danger exists of it being pushed uncontrolled
out of the cut.
WORKING HINTS FOR YOUR
GRINDER
1. Always start at no load to achieve maximum
speed then start working.
2. Do not force the disc to work faster,
reducing the Disc’s moving speed means
longer working time.
3. Always work with a 15-30 angle between
disc and workpiece. Larger angles will cut
ridges into the workpiece and affect the
surface finish. Move the angle grinder across
and back and forth over the workpiece.
4. When using a cutting disc never change
the cutting angle otherwise you will stall the
disc and angle grinder motor or break the
disc. When cutting, only cut in the opposite
direction to the disc rotation. If you cut in the
same direction as the disc rotation the disc
may push itself out of the cut slot.
5. When cutting very hard material best results
can be achieved with a diamond disc.
6. When using a diamond disc it will become

Angle grinder EN
14
very hot. If this happens you will see a full
ring of sparks around the rotating disc. Stop
cutting and allow to cool at no load speed for
2-3 minutes.
7. Always ensure the workpiece is firmly held
or clamped to prevent movement.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
There are no user serviceable parts in your
power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean
with a dry cloth. Always store your power tool
in a dry place. Keep the motor ventilation slots
clean. Keep all working controls free of dust.
Occasionally you may see sparks through the
ventilation slots.This is normal and will not
damage your power tool.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
TROUBLESHOOTING
Although your new angle grinder is really
very simple to operate, if you do experience
problems, please check the following:
1. If your grinder will not operate check the
power at the main plug.
2. If your grinder wheel wobbles or vibrates,
check that outer flange is tight, check that the
wheel is correctly located on the flange plate.
3. If there is any evidence that the wheel is
damaged do not use as the damaged wheel
may disintegrate, remove it and replace with a
new wheel. Dispose of old wheels sensibly.
4. If working on aluminum or a similar soft
alloy, the wheel will soon become clogged
and will not grind effectively.
ENVIRONMENTAL
pROTECTION
This product has been marked with a
symbol relating to removing electric
and electronic waste.This means that
this product shall not be discarded with
household waste but that it shall be returned
to a collection system which conforms to the
European Directive 2002/96/CE. It will then
be recycled or dismantled in order to reduce
the impact on the environment. Electric and
electronic equipment can be hazardous for the
environment and for human health since they
contain hazardous substances.

Angle grinder EN
15
pLUG REpLACEMENT(UK &
IRELAND ONLY)
If you need to replace the fitted plug then
followthe instructions below.
IMPORTANT
The wires in the mains lead are colored in
accordance with the following code:
blue – neutral
brown – live
As the colors of the wires in the mains lead
of thisappliance may not correspond with the
coloured markings identifying the terminals
in your plug,proceed as follows.The wire
which is coloured blue must be connected to
the terminal which is marked with N.The wire
which is coloured brown must be connected
to the terminal which is marked with L.
WARNING: Never connect live or
neutral wires to the earth terminal of the
plug. Only fit an approved BS1363/A plug and
the correct rated fuse.
NOTE: If a moulded plug is fitted and has to
be removed take great care in disposing of the
plug and severed cable, it must be destroyed
to prevent engaging into a socket.
Connect
Blue to N
(neutral)
Outer sleeve
firmly clamped
Cable grip
Brown L (live)
13 Amp fuse approved
to BS1362
DECLARATION OF
CONFORMITY
We,
POSITEC Germany GmbH
Konrad-Adenauer-Ufer 37
50668 Köln
Declare that the product,
Description
WORX Angle grinder
Type WX705 WX705.1 (700-749-
designation of machinery, representative
of Angle Grinder)
Function Peripheral and lateral grinding
Complies with the following Directives,
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive
2004/108/EC
RoHS Directive 2011/65/EU
Standards conform to
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60745-1
EN 60745-2-3
The person authorized to compile the
technical file,
Name Russell Nicholson
Address Positec Power Tools (Europe)
Ltd, PO Box 152, Leeds, LS10 9DS, UK
2013/03/22
LeoYue
POSITEC Quality Manager

Winkelschleifer D
16
1. SPINDELARRETIERUNG
2. EIN/AUS-SCHALTER
3. HANDGRIFFBEREICHE
4. ZUSATZHANDGRIFF
5. SCHLEIF-SCHUTZHAUBE
6. SCHEIBE *
7. SCHLÜSSEL
8. INNENFLANSCH
9. GEGENFLANSCH
10. SCHUTZHAUBE ZUM TRENNEN*
* Abgebildetes oder beschriebenes Zubehör gehört teilweise nicht zum Lieferumfang.

Winkelschleifer D
17
TECHNISCHE DATEN
Typ WX705 WX705.1 (700-749- Bezeichnung der Maschine, repräsentiert die Winkel-
schleifer)
Nennspannung 230-240V~50Hz
Nennleistung 750W
Nenndrehzahl 11000/min
Scheiben 115mm
Scheibenbohrung 22.2mm
Schleifspindelgewinde M14
Schutzklasse /ll
Gewicht 2.0kg
INFORMATIONEN ÜBER LÄRM
Gewichteter Schalldruck LpA: 78.4dB(A)
Gewichtete Schallleistung LwA: 89.4dB(A)
KPA&KWA 3.0dB(A)
Tragen Sie bei einem Schalldruck über einen Gehörschutz 80dB(A)
VIBRATION INFORMATION
Vibrationsgesamtmesswertermittlung gemäß EN 60745:
Typischer gewichteter Vibrationswert Vibrationsemissionswert ah= 4.18m/s2
Unsicherheit K = 1.5m/s²
WARNUNG: Der Vibrationsemissionswert während des tatsächlichen Gebrauchs des
Elektrowerkzeugs kann vom angegebenen Wert abweichen, je nachdem, wie das Werkzeug
gemäß folgender Beispiele und anderweitiger Verwendungsmöglichkeiten eingesetzt wird:
Wie das Werkzeug verwendet wird und Materialen geschnitten .
Das Werkzeug ist in gutem Zustand und gut gepflegt
Verwendung des richtigen Zubehörs für das Werkzeug und Gewährleistung seiner Schärfe und
seines guten Zustands.
Die Festigkeit der Handgriffe und ob Antivibrationszubehör verwendet wird.
Und ob das verwendete Werkzeug dem Design und diesen Anweisungen entsprechend
verwendet wird.

Winkelschleifer D
18
Wird dieses Werkzeug nicht anemessen gehandhabt, kann es ein Hand-Arm-
Vibrationssyndrom erzeugen.
WARNUNG: Um genau zu sein, sollte ein Abschätzung des Belastungsgrades aller
Arbeitsabschnitte während tatsächlicher Verwendung berücksichtigt werden, z.B. die Zeiten,
wenn das Werkzeug ausgeschaltet ist, und wenn es sich im Leerlauf befindet und eigentlich nicht
eingesetzt wird. Auf diese Weise kann der Belastungsgrad während der gesamten Arbeitszeit
wesentlich gemindert werden.
Minimieren Sie Ihr Risiko, dem Sie bei Vibrationen ausgesetzt sind.
Pflegen Sie dieses Werkzeug diesen Anweisungen entsprechend und achten Sie auf eine gute
Einfettung (wo erforderlich).
Bei regelmäßiger Verwendung dieses Werkzeugs sollten Sie in Antivibrationszubehör investieren.
Vermeiden Sie den Einsatz von Werkzeugen beiTemperaturen von 10ºC oder darunter.
Machen Sie einen Arbeitsplan, um die Verwendung von hochvibrierenden Werkzeugen auf
mehrereTage zu verteilen.
ZUBEHÖRTEILE
WX705 WX705.1
Schlüssel 1 1
Zusatzhandgriff 1 1
Schleif-Schutzhaube 1 -
Schutzhaube zumTrennen 1 -
Metall-Schleifscheibe - 1
Diamantplatte 2 -
Wir empfehlen Ihnen, sämtliche Zubehörteile beim selben Fachhändler zu beziehen, bei dem Sie
auch Ihr Elektrowerkzeug gekauft haben. Verwenden Sie nur hochwertige Zubehörteile von nam-
haften Herstellern. Weitere Informationen finden Sie auf der Verpackung der Zubehörteile. Auch
Ihr Fachhändler berät Sie gerne.

Winkelschleifer D
19
ZUSÄTZLICHE
SICHERHEITSHINWEISE
FÜR WINKELSCHLEIFER
GEMEINSAME WARNHINWEISE ZUM
SCHLEIFEN, TRENNSCHLEIFEN:
1. Dieses Elektrowerkzeug ist
zu verwenden als Schleifer,
Trennschleifmaschine. Beachten Sie
alle Warnhinweise, Anweisungen,
Darstellungen und Daten, die Sie
mit dem Gerät erhalten. Wenn Sie
die folgenden Anweisungen nicht
beachten, kann es zu elektrischem Schlag,
Feuer und/oder schweren Verletzungen
kommen.
2. Dieses Elektrowerkzeug ist nicht
geeignet zum Sandpapierschleifen,
Arbeiten mit Drahtbürsten,
Polieren. Verwendungen, für die das
Elektrowerkzeug nicht vorgesehen ist,
können Gefährdungen und Verletzungen
verursachen.
3. Verwenden Sie kein Zubehör, das
vom Hersteller nicht speziell für
dieses Elektrowerkzeug vorgesehen
und empfohlen wurde. Nur weil Sie
das Zubehör an Ihrem Elektrowerkzeug
befestigen können, garantiert das keine
sichere Verwendung.
4. Die zulässige Drehzahl des
Einsatzwerkzeugs muss mindestens
so hoch sein wie die auf dem
Elektrowerkzeug angegebene
Höchstdrehzahl. Zubehör, das sich
schneller als zulässig dreht, kann zerstört
werden.
5. Außendurchmesser und Dicke des
Einsatzwerkzeugs müssen den
Maßangaben Ihres Elektrowerkzeugs
entsprechen. Falsch bemessene
Einsatzwerkzeuge können nicht
ausreichend abgeschirmt oder kontrolliert
werden.
6. Schleifscheiben, Flansche,
Schleifteller oder anderes Zubehöhr
müssen genau auf die Schleifspindel
Ihres Elektrowerkzeugs passen.
Einsatzwerkzeuge, die nicht genau auf
die Schleifspindel des Elektrowerkzeugs
passen, drehen sich ungleichmäßig,
vibrieren sehr stark und können zum
Verlust der Kontrolle führen.
7. Verwenden Sie keine beschädigten
Einsatzwerkzeuge. Kontrollieren
Sie vor jeder Verwendung
Einsatzwerkzeuge wie
Schleifscheiben auf Absplitterungen
und Risse, Schleifteller auf Risse,
Verschleiß oder starke Abnutzung.
Wenn das Elektrowerkzeug oder
das Einsatzwerkzeug herunterfällt,
überprüfen Sie, ob es beschädigt
ist, oder verwenden Sie ein
unbeschädigtes Einsatzwerkzeug.
Wenn Sie das Einsatzwerkzeug
kontrolliert und eingesetzt
haben, halten Sie und in der
Nähe befindliche Personen sich
außerhalb der Ebene des rotierenden
Einsatzwerkzeugs und lassen Sie
das Gerät eine Minute lang mit
Höchstdrehzahl laufen. Beschädigte
Einsatzwerkzeuge brechen meist in dieser
Testzeit.
8. Tragen Sie persönliche
Schutzausrüstung. Verwenden
Sie je nach Anwendung
Vollgesichtsschutz, Augenschutz
oder Schutzbrille. Soweit
angemessen, tragen Sie Staubmaske,
Gehörschutz, Schutzhandschuhe
oder Spezialschürze, die kleine
Schleif- und Materialpartikel von
Ihnen fernhält. Die Augen sollen
vor herumfliegenden Fremdkörpern
geschützt werden, die bei verschiedenen
Anwendungen entstehen. Staub- oder
Atemschutzmaske müssen den bei der
Anwendung entstehenden Staub filtern.
Wenn Sie lange lautem Lärm ausgesetzt
sind, können Sie einen Hörverlust
erleiden.
9. Achten Sie bei anderen Personen
auf sicheren Abstand zu Ihrem
Arbeitsbereich. Jeder, der den
Arbeitsbereich betritt, muss
persönliche Schutzausrüstung
tragen. Bruchstücke des Werkstücks oder
gebrochener Einsatzwerkzeuge können

Winkelschleifer D
20
wegfliegen und Verletzungen auch
außerhalb des direkten Arbeitsbereichs
verursachen.
10. Halten Sie das Gerät nur an den
isolierten Griffflächen, wenn Sie
Arbeiten ausführen, bei denen
das Einsatzwerkzeug verborgene
Stromleitungen oder das eigene
Netzkabel treffen kann. Der Kontakt
mit einer spannungsführenden Leitung
kann auch metallene Geräteteile
unter Spannung setzen und zu einem
elektrischen Schlag führen.
11. Halten Sie das Netzkabel von sich
drehenden Einsatzwerkzeugen
fern. Wenn Sie die Kontrolle über das
Gerät verlieren, kann das Netzkabel
durchtrennt oder erfasst werden und Ihre
Hand oder Ihr Arm in das sich drehende
Einsatzwerkzeug geraten.
12. Legen Sie das Elektrowerkzeug
niemals ab, bevor das
Einsatzwerkzeug völlig zum
Stillstand gekommen ist. Das sich
drehende Einsatzwerkzeug kann in
Kontakt mit der Ablagefläche geraten,
wodurch Sie die Kontrolle über das
Elektrowerkzeug verlieren können.
13. Lassen Sie das Elektrowerkzeug
nicht laufen, während Sie es tragen.
Ihre Kleidung kann durch zufälligen
Kontakt mit dem sich drehenden
Einsatzwerkzeug erfasst werden, und
das Einsatzwerkzeug sich in Ihren Körper
bohren.
14. Reinigen Sie regelmäßig
die Lüftungsschlitze Ihres
Elektrowerkzeugs. Das Motorgebläse
zieht Staub in das Gehäuse, und eine
starke Ansammlung von Metallstaub
kann elektrische Gefahren verursachen.
15. Verwenden Sie das Elektrowerkzeug
nicht in der Nähe brennbarer
Materialien. Funken können diese
Materialien entzünden.
16. Verwenden Sie keine
Einsatzwerkzeuge, die flüssige
Kühlmittel erfordern. Die Verwendung
von Wasser oder anderen flüssigen
Kühlmitteln kann zu einem elektrischen
Schlag führen.
17. Ihre Hand muss den Griff während
der Arbeit festhalten. Verwenden Sie
immer die dem Werkzeug mitgelieferten
Hilfsgriffe. Kontrollverlust kann
Körperverletzungen verursachen.
WEITERE SICHERHEITSHINWEISE FÜR
ALLE ANWENDUNGEN
RÜCKSCHLAG UND ENTSPRECHENDE
WARNHINWEISE
Rückschlag ist die plötzliche Reaktion infolge
eines hakenden oder blockierten drehenden
Einsatzwerkzeugs, wie Schleifscheibe,
Schleifteller, Drahtbürste usw. Verhaken oder
Blockieren führt zu einem abrupten Stopp des
rotierenden Einsatzwerkzeugs. Dadurch wird
ein unkontrolliertes Elektrowerkzeug gegen
dieDrehrichtung des Einsatzwerkzeugs an der
Blockierstelle beschleunigt.
Wenn z. B. eine Schleifscheibe im Werkstück
hakt oder blockiert, kann sich die Kante der
Schleifscheibe, die in das Werkstück eintaucht,
verfangen und dadurch die Schleifscheibe
ausbrechen oder einen Rückschlag
verursachen. Die Schleifscheibe bewegt sich
dann auf die Bedienperson zu oder von ihr
weg, je nach Drehrichtung der Scheibe an der
Blockierstelle. Hierbei können Schleifscheiben
auch brechen.
Ein Rückschlag ist die Folge eines
falschen oder fehlerhaften Gebrauchs des
Elektrowerkzeugs. Er kann durch geeignete
Vorsichtsmaßnahmen, wie nachfolgend
beschrieben, verhindert werden.
1. Halten Sie das Elektrowerkzeug gut
fest und bringen Sie Ihren Körper
und Ihre Arme in eine Position, in der
Sie die Rückschlagkräfte abfangen
können. Verwenden Sie immer
den Zusatzgriff, falls vorhanden,
um die größtmögliche Kontrolle
über Rückschlagkräfte oder
Reaktionsmomente beim Hochlauf
zu haben. Die Bedienperson kann
durch geeignete Vorsichtsmaßnahmen
die Rückschlag- und Reaktionskräfte
beherrschen.
2. Bringen Sie Ihre Hand nie in die Nähe
sich drehender Einsatzwerkzeuge.
This manual suits for next models
1
Table of contents
Languages:
Other Worx Grinder manuals

Worx
Worx WX801 User manual

Worx
Worx WX700 User manual

Worx
Worx WX22AG User manual

Worx
Worx WX701 Installation manual

Worx
Worx WX713 User manual

Worx
Worx WT807 User manual

Worx
Worx BRUSHLESS MOTOR WX812.9 User manual

Worx
Worx MAKER X WX741L Series User manual

Worx
Worx WX800 User manual

Worx
Worx WX710 User manual
Popular Grinder manuals by other brands

KRAUSMANN
KRAUSMANN 8804 Operation manual

Makita
Makita M9000 instruction manual

EINHELL
EINHELL NTS 2000 Directions for use

Chicago Electric
Chicago Electric 95219 Assembly and operation instructions

Ingersoll-Rand
Ingersoll-Rand CD-EU Series instructions

Bosch
Bosch GWS 20-230 Professional Original instructions
