Worx WX801 User manual

Cordless Angle Grinder
Akku-Winkelschleifer
Meuleuse d’angle sans fil
Smerigliatrice angolare senza filo
Amoladora angular inalámbrica
Draadloze Hoek Slijpmachine
Akumulatorowa szlierka kątowa
Akkus sarokcsiszoló
Mașină de șlefuit unghiulară cu acumulator
Akumulátorová úhlová bruska
Akumulátorová uhlová brúska
Rebarbadora Angular a Bateria
Sladdlös vinkelslip
Akumulatorski kotni brusilnik
P06
P19
P34
P49
P64
P79
P93
P108
P123
P137
P151
P165
P180
P194
EN
D
F
I
ES
NL
PL
HU
RO
CZ
SK
PT
SV
SL
WX801 WX801.9

Original instructions EN
Originalbetriebsanleitung D
Notice originale F
Istruzioni originali I
Manual original ES
Oorspronkelijke gebruiksaanwijzing NL
Instrukcja oryginalna PL
Eredeti használati utasítás HU
Instrucţiuni originale RO
Původní návod k používání CZ
Pôvodný návod na použitie SK
Manual original PT
Bruksanvisning i original SV
Izvirna navodila SL

3 4
12
8
5
6
7
9
10
11
12 13

1
3
2
2
1
2
1
2
1
15o-30
ON OFF
o
2
1OFF
OFF
A1 A2
BC
D1 D2
D3
F
H
G
E
I

1
3
2
2
1
2
1
2
1
15o-30
ON OFF
o
2
1OFF
OFF
A1 A2
BC
D1 D2
D3
F
H
G
E
I

6
EN
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or
battery-operated (cordless) power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on.

7
EN
A wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.

8
EN
6. SERVICE
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
Safety Warnings Common for Grinding or Abrasive Cutting-Off Operations:
a) This power tool is intended to function as a grinder or cut-off tool.
Read all safety warnings, instructions, illustrations and specifications
provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
b) Operations such as sanding, wire brushing, polishing are not
recommended to be performed with this power tool.
Operations for which
the power tool was not designed may create a hazard and cause personal injury.
c) Do not use accessories which are not specifically designed and
recommended by the tool manufacturer.
Just because the accessory can be
attached to your power tool, it does not assure safe operation.
d) The rated speed of the accessory must be at least equal to the
maximum speed marked on the power tool.
Accessories running faster than
their rated speed can break and fly apart.
e) The outside diameter and the thickness of your accessory must be
within the capacity rating of your power tool.
Incorrectly sized accessories
cannot be adequately guarded or controlled.
f) Threaded mounting of accessories must match the grinder spindle
thread. For accessories mounted by flanges, the arbour hole of the
accessory must fit the locating diameter of the flange.
Accessories that
do not match the mounting hardware of the power tool will run out of balance, vibrate
excessively and may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect the
accessory such as abrasive wheels for chips and cracks, backing
pad for cracks, tear or excess wear. If power tool or accessory is
dropped, inspect for damage or install an undamaged accessory.
After inspecting and installing an accessory, position yourself and
bystanders away from the plane of the rotating accessory and run
the power tool at maximum no-load speed for one minute.
Damaged
accessories will normally break apart during this test time.
h) Wear personal protective equipment. Depending on application, use
face shield, safety goggles or safety glasses. As appropriate, wear
dust mask, hearing protectors, gloves and workshop apron capable
of stopping small abrasive or workpiece fragments.
The eye protection
must be capable of stopping flying debris generated by various operations . The dust
mask or respirator must be capable of filtrating particles generated by your operation.
Prolonged exposure to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone
entering the work area must wear personal protective equipment.
Fragments of workpiece or of a broken accessory may fly away and cause injury
beyond immediate area of operation.
j) Hold the power tool by insulated gripping surfaces only, when
performing an operation where the cutting tool may contact hidden
wiring.
Contact with a “live” wire will also make exposed metal parts of the power tool

9
EN
“live” and could give the operator an electric shock.
k) Never lay the power tool down until the accessory has come to a
complete stop.
The spinning accessory may grab the surface and pull the power
tool out of your control.
l) Do not run the power tool while carrying it at your side. Accidental
contact with the spinning accessory could snag your clothing, pulling the accessory into
your body.
m) Regularly clean the power tool’s air vents. The motor’s fan will draw the
dust inside the housing and excessive accumulation of powdered metal may cause
electrical hazards.
n) Do not operate the power tool near flammable materials. Sparks could ignite
these materials.
o) Do not use accessories that require liquid coolants. Using water or other
liquid coolants may result in electrocution or shock.
p) Your hand must hold on the handle when you are working. Always use the auxiliary
handles supplied with the tool. Loss of control can cause personal injury.
FURTHER SAFETY INSTRUCTIONS FOR ALL
OPERATIONS
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad,
brush or any other accessory. Pinching or snagging causes rapid stalling of the
rotating accessory which in turn causes the uncontrolled power tool to be forced in
the direction opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the
edge of the wheel that is entering into the pinch point can dig into the surface
of the material causing the wheel to climb out or kick out.The wheel may either
jump toward or away from the operator, depending on direction of the wheel’s
movement at the point of pinching. Abrasive wheels may also break under these
conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below.
a) Maintain a firm grip on the power tool and position your body and arm
to allow you to resist kickback forces. Always use auxiliary handle,
if provided, for maximum control over kickback or torque reaction
during start-up.
The operator can control torque reactions or kickback forces, if proper
precautions are taken.
b) Never place your hand near the rotating accessory. Accessory may kickback
over your hand.
c) Do not position your body in the area where power tool will move if
kickback occurs.
Kickback will propel the tool in direction opposite to the wheel’s
movement at the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid
bouncing and snagging the accessory.
Corners, sharp edges or bouncing have
a tendency to snag the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade.
Such blades create frequent kickback and loss of control.

10
EN
ADDITIONAL SAFETY INSTRUCTIONS FOR GRINDING
AND CUTTING-OFF OPERATIONS
SAFETY WARNINGS SPECIFIC FOR GRINDING AND ABRASIVE CUTTING-
OFF OPERATIONS:
a) Use only wheel types that are recommended for your power tool and
the specific guard designed for the selected wheel.
Wheels for which the
power tool was not designed cannot be adequately guarded and are unsafe.
b) The grinding surface of centre depressed wheels must be mounted
below the plane of the guard lip.
An improperly mounted wheel that projects
through the plane of the guard lip cannot be adequately protected.
c) The guard must be securely attached to the power tool and
positioned for maximum safety, so the least amount of wheel is
exposed towards the operator.
The guard helps to protect the operator from
broken wheel fragments, accidental contact with wheel and sparks that could ignite
clothing.
d) Wheels must be used only for recommended applications. For
example: do not grind with the side of cut-off wheel.
Abrasive cut-off
wheels are intended for peripheral grinding, side forces applied to these wheels may
cause them to shatter.
e) Always use undamaged wheel flanges that are of correct size and
shape for your selected wheel.
Proper wheel flanges support the wheel thus
reducing the possibility of wheel breakage. Flanges for cut-off wheels may be different
from grinding wheel flanges.
f) Do not use worn down wheels from larger power tools. Wheel intended
for larger power tool is not suitable for the higher speed of a smaller tool and may
burst.
ADDITIONAL SAFETY WARNINGS SPECIFIC FOR
ABRASIVE CUTTING-OFF OPERATIONS:
a) Do not “jam” the cut-off wheel or apply excessive pressure. Do not
attempt to make an excessive depth of cut.
Overstressing the wheel
increases the loading and susceptibility to twisting or binding of the wheel in the cut
and the possibility of kickback or wheel breakage.
b) Do not position your body in line with and behind the rotating wheel.
When the wheel, at the point of operation, is moving away from your body, the
possible kickback may propel the spinning wheel and the power tool directly at you.
c) When wheel is binding or when interrupting a cut for any reason,
switch off the power tool and hold the power tool motionless until
the wheel comes to a complete stop. Never attempt to remove the
cut-off wheel from the cut while the wheel is in motion otherwise
kickback may occur.
Investigate and take corrective action to eliminate the cause
of wheel binding.
d) Do not restart the cutting operation in the workpiece. Let the wheel
reach full speed and carefully re-enter the cut.
The wheel may bind, walk
up or kickback if the power tool is restarted in the workpiece.
e) Support panels or any oversized workpiece to minimize the risk of
wheel pinching and kickback.
Large workpieces tend to sag under their own
weight. Supports must be placed under the workpiece near the line of cut and near the
edge of the workpiece on both sides of the wheel.

11
EN
f) Use extra caution when making a “pocket cut” into existing walls or
other blind areas. The protruding wheel may cut gas or water pipes, electrical
wiring or objects that can cause kickback.
SAFETY WARNINGS FOR BATTERY PACK
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs
haphazardly in a box or drawer where they may short-circuit each
other or be short-circuited by conductive materials.
When battery pack
is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
c) Do not expose battery pack to heat or fire. Avoid storage in direct
sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into
contact with the skin or eyes. If contact has been made, wash the
affected area with copious amounts of water and seek medical
advice.
f) Seek medical advice immediately if a cell or battery pack has been
swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if they become
dirty.
i) Battery pack needs to be charged before use. Always refer to this
instruction and use the correct charging procedure.
j) Do not maintain battery pack on charge when not in use.
k) After extended periods of storage, it may be necessary to charge
and discharge the battery pack several times to obtain maximum
performance.
l) Battery pack gives its best performance when it is operated at
normal room temperature
(20°C ± 5°C) .
m) When disposing of battery packs, keep battery packs of different
electrochemical systems separate from each other.
n) Recharge only with the charger specified by WORX. Do not use
any charger other than that specifically provided for use with the
equipment.
A charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
o) Do not use any battery pack which is not designed for use with the
equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future reference.
r) Remove the battery from the equipment when not in use.
s) Dispose of properly.

12
EN
SYMBOLS
To reduce the risk of injury, user must read instruction manual
Wear ear protection
Wear eye protection
Wear dust mask
Warning
Wear protective gloves.
Not permitted for face grinding with abrasive cutting off wheels
Waste electrical products must not be disposed of with household
waste. Please recycle where facilities exist. Check with your local
authorities or retailer for recycling advice
Li-I on
Do not dispose of batteries. Return exhausted batteries to your local
collection or recycling point
Do not burn
Do not expose to rain or water
Make sure the battery is removed prior to changing accessories

13
EN
COMPONENT LIST
1. ON / OFF SWITCH
2. HAND GRIP AREA
3. BATTERY PACK *
4. BATTERY PACK RELEASE BUTTON*
5. SPINDLE LOCK BUTTON
6. SPINDLE
7. WHEEL GUARD FOR GRINDING
8. WHEEL GUARD FOR CUTTING
9. METAL CUTTING DISC
10. CLAMPING BOLT WITH WASHER
11. HEX KEY
12. ABRASIVE CUTTING DISC
13. GRINDING DISC
*Not all the accessories illustrated or described are included in standard
delivery.
TECHNICAL DATA
Type WX801 (80 - designation of machinery, representative of Angle
grinder)
WX801 WX801.9
Rated voltage 20V Max**
Rated speed
19500rpm
Spindle thread M6
Thickness of metal cutting disc 1.2~1.4mm
Thickness of abrasive cutting disc 1.6mm
Thickness of grinding disc 4mm
Disc size 76mm
Disc bore 9.5mm
Machine weight 1.1kg 0.7kg

14
EN
**Voltage measured without workload. Initial battery voltage reaches
maximum of 20 volts. Nominal voltage is 18 volts.
NOISE INFORMATION
A weighted sound pressure LpA=80.9dB(A)
KpA= 3 dB(A)
A weighted sound power LwA=91.9dB(A)
KwA=3 dB(A)
Wear ear protection.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 60745:
surface grinding or abrasive
cutting off
Vibration emission value ah,AG = 3.693 m/s2
Uncertainty K = 1.5m/s²
The declared vibration total value may be used for comparing one tool with
another, and may also be used in a preliminary assessment of exposure.
WARNING: The vibration emission value during actual use of the power tool
can differ from the declared value depending on the ways in which the tool is
used dependant on the following examples and other variations on how the tool is
used:
How the tool is used and the materials being cut.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles and if any anti vibration accessories are
used.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not
adequately managed.
WARNING: To be accurate, an estimation of exposure level in the actual
conditions of use should also take account of all parts of the operating cycle
such as the times when the tool is switched off and when it is running idle but not
actually doing the job.This may significantly reduce the exposure level over the
total working period.
Help to minimize your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.

15
EN
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
If the tool is to be used regularly then invest in anti vibration accessories.
Plan your work schedule to spread any high vibration tool use across a number of
days.
ACCESSORIES
WX801 WX801.9
Metal cutting discs 2 2
Abrasive cutting disc 1 1
Grinding disc 1 1
Hex key 1 1
Charger (WA3860)
1 /
Battery Pack (WA3551.1) 1 /
We recommend that you purchase your accessories from the same store that sold
you the tool. Refer to the accessory packaging for further details. Store personnel
can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
INTENDED USE:
The machine is intended for cutting, roughing and brushing metal and stone
materials without using water. For cutting metal, a special protection guard for
cutting (accessory) must be used.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the Battery Pack See Fig. A1
Charging the Battery Pack See Fig. A2
ASSEMBLY

16
EN
Lock the spindle and assembling metal cutting disc/abrasive
cutting disc /grinding disc
NOTE: Press and hold the spindle lock button to lock
the spindle.
NOTE: Make sure that the metal cutting disc/abrasive
cutting disc /grinding disc is assembled firmly.
WARNING! Before any work on the machine itself,
remove the battery pack.
See Fig. B
Lock the spindle and removing metal cutting disc/abrasive
cutting disc /grinding disc See Fig. C
Adjusting Wheel Guard for grinding/cutting
Note: Remove the battery pack before making any
changes to the tool. For work with grinding or cutting
discs, the protection guard must be mounted. Use the
correct type of disc for your application.
If the power tool is intended to perform any cut-off
operations, a guard specific for this operation must be
installed.
See Fig.
D1,D2,D3
Installing the Battery Pack
WARNING: Before inserting the battery pack, make
sure that the ON/OFF Switch is in OFF position.
WARNING: When replacing the battery pack, do not
insert the battery pack until the metal cutting disc/
abrasive cutting disc /grinding disc comes to a complete
stop!
See Fig. E
OPERATION
Using On/Off Switch
Note: Depress the On/Off switch forward to lock-on
button. Your switch is now locked on for continuous
use.
See Fig. F
Hand grip areas See Fig. G
Rough Grinding
WARNING! Never use a cutting disc for rough
grinding applications. This can cause bodily damaged
by using the tool for wrong applications.
See Fig. H
Cutting See Fig. I

17
EN
WORKING HINTS FOR YOUR ANGLE GRINDER
1. Always start at no load to achieve maximum speed then start working.
2. Do not force the disc to work faster, reducing the Disc’s moving speed means
longer working time.
3. Always work with a 15-30 angle between disc and workpiece when grinding.
Larger angles will cut ridges into the workpiece and affect the surface finish.
Move the angle grinder across and back and forth over the workpiece.
4. When using a cutting disc never change the cutting angle otherwise you will
stall the disc and angle grinder motor or break the disc. When cutting, only cut
in the opposite direction to the disc rotation. If you cut in the same direction as
the disc rotation the disc may push itself out of the cut slot.
5. When cutting very hard material best results can be achieved with a abrasive
cutting disc.
6. When using a abrasive cutting disc it will become very hot. If this happens you
will see a full ring of sparks around the rotating disc. Stop cutting and allow to
cool at no load speed for 2-3 minutes.
7. Always ensure the workpiece is firmly held or clamped to prevent movement.
MAINTENANCE
Remove the battery before carrying out any adjustment, servicing or
maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your
power tool in a dry place. Keep the motor ventilation slots clean. Keep all working
controls free of dust. Occasionally you may see sparks through the ventilation slots.
This is normal and will not damage your power tool. Store the accessories in a dry
place.
TROUBLESHOOTING
Although your new angle grinder is really very simple to operate, if you do
experience problems, please check the following:
1. If your grinder wheel wobbles or vibrates, check that outer flange is tight; check
that the wheel is correctly located on the flange plate.
2. If there is any evidence that the wheel is damaged do not use as the damaged
wheel may disintegrate, remove it and replace with a new wheel. Dispose of old
wheels sensibly.
3. If working on aluminum or a similar soft alloy, the wheel will soon become
clogged and will not grind effectively.
4. When overloaded, the motor comes to a stop. Relieve the load on the machine
immediately and allow cooling for approx. 30 seconds at the highest no-load
speed.
5. When using as intended for the power tool cannot be subject to overload. When
the load is too high or the allowable battery temperature of 75 °C is exceeded,
the electronic control switches off the power tool until the temperature is in the
optimum temperature range again.
6. If machine is blocked, please turn it off and turn it on again after 1~2 seconds.

18
EN
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice.
DECLARATION OF CONFORMITY
We,
Positec Germany GmbH
Grüner Weg 10, 50825 Cologne, Germany
Declare that the product,
Description WORX Angle Grinder
Type WX801 (80-designation of machinery, representative of
Angle grinder )
Function peripheral and lateral grinding and cutting
Complies with the following directives,
2006/42/EC, 2011/65/EU, 2014/30/EU
Standards conform to:
EN 55014-1, EN 55014-2, EN 60745-1, EN 60745-2-3
The person authorized to compile the technical file,
Name Marcel Filz
Address Positec Germany GmbH, Grüner Weg 10, 50825 Cologne,
Germany
2018/09/27
Allen Ding
Deputy Chief Engineer,Testing & Certification
PositecTechnology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

19
D
ALLGEMEINE SICHERHEITSHINWEISE FÜR
ELEKTROWERKZEUGE
WARNUNG! Lesen Sie alle Sicherheitshinweise und Anweisungen.
Versäumnisse bei der Einhaltung der Sicherheitshinweise und Anweisungen
können elektrischen Schlag, Brand und/oder schwere Verletzungen verursachen.
Bewahren Sie alle Sicherheitshinweise und Anweisungen für die Zukunft
auf.
Der in den Sicherheitshinweisen verwendete Begriff „Elektrowerkzeug“ bezieht sich
auf akkubetriebene Elektrowerkzeuge (ohne Netzkabel).
1. ARBEITSPLATZSICHERHEIT
a) Halten Sie Ihren Arbeitsbereich sauber und gut beleuchtet. Unordnung
oder unbeleuchtete Arbeitsbereiche können zu Unfällen führen.
b) Arbeiten Sie mit dem Elektrowerkzeug nicht in explosionsgefährdeter
Umgebung, in der sich brennbare Flüssigkeiten, Gase oder Stäube
befinden. Elektrowerkzeuge erzeugen Funken, die den Staub oder die Dämpfe
entzünden können.
c) Halten Sie Kinder und andere Personen während der Benutzung des
Elektrowerkzeugs fern. Bei Ablenkung können Sie die Kontrolle über das
Gerät verlieren.
2. ELEKTRISCHE SICHERHEIT
a) Der Anschlussstecker des Elektrowerkzeuges muss in die Steckdose
passen. Der Stecker darf in keiner Weise verändert werden.
Verwenden Sie keine Adapterstecker gemeinsam mit schutzgeerdeten
Elektrowerkzeugen. Unveränderte Stecker und passende Steckdosen
verringern das Risiko eines elektrischen Schlages.
b) Vermeiden Sie Körperkontakt mit geerdeten Oberflächen wie von
Rohren, Heizungen, Herden und Kühlschränken. Es besteht ein erhöhtes
Risiko durch elektrischen Schlag, wenn Ihr Körper geerdet ist.
c) Halten Sie Elektrowerkzeuge von Regen oder Nässe fern. Das Eindringen
von Wasser in ein Elektrowerkzeug erhöht das Risiko eines elektrischen
Schlages.
d) Zweckentfremden Sie das Kabel nicht, um das Elektrowerkzeug zu
tragen, aufzuhängen oder um den Stecker aus der Steckdose zu
ziehen. Halten Sie das Kabel fern von Hitze, Öl, scharfen Kanten oder
sich bewegenden Geräteteilen. Beschädigte oder verwickelte Kabel erhöhen
das Risiko eines elektrischen Schlages.
e) Wenn Sie mit einem Elektrowerkzeug im Freien arbeiten, verwenden
Sie nur Verlängerungskabel, die auch für den Außenbereich
geeignet sind. Die Anwendung eines für den Außenbereich geeigneten
Verlängerungskabels verringert das Risiko eines elektrischen Schlages.
f) Wenn der Betrieb des Elektrowerkzeuges in feuchter Umgebung nicht
vermeidbar ist, verwenden Sie einen Fehlerstromschutzschalter.
Der Einsatz eines Fehlerstromschutzschalters vermindert das Risiko eines
elektrischen Schlages.
3. SICHERHEIT VON PERSONEN
a) Seien Sie aufmerksam, achten Sie darauf, was Sie tun, und gehen Sie
mit Vernunft an die Arbeit mit einem Elektrowerkzeug. Benutzen Sie

20
D
kein Elektrowerkzeug, wenn Sie müde sind oder unter dem Einfluss
von Drogen, Alkohol oder Medikamenten stehen. Ein Moment der
Unachtsamkeit beim Gebrauch des Elektrowerkzeuges kann zu ernsthaften
Verletzungen führen.
b) Tragen Sie persönliche Schutzausrüstung und immer eine Schutzbrille.
DasTragen persönlicher Schutzausrüstung, wie Staubmaske, rutschfeste
Sicherheitsschuhe, Schutzhelm oder Gehörschutz, je nach Art und Einsatz des
Elektrowerkzeuges, verringert das Risiko vonVerletzungen.
c) Vermeiden Sie eine unbeabsichtigte Inbetriebnahme. Vergewissern Sie
sich, dass das Elektrowerkzeug ausgeschaltet ist, bevor Sie es an den
Akku anschließen, es aufnehmen oder tragen. Wenn Sie beimTragen des
Elektrowerkzeuges den Finger am Schalter haben oder das Gerät eingeschaltet
an die Stromversorgung anschließen, kann dies zu Unfällen führen.
d) Entfernen Sie Einstellwerkzeuge oder Schraubenschlüssel, bevor Sie
das Elektrowerkzeug einschalten. Ein Werkzeug oder Schlüssel, der sich in
einem drehenden Geräteteil befindet, kann zu Verletzungen führen.
e) Vermeiden Sie eine abnormale Körperhaltung. Sorgen Sie für einen
sicheren Stand und halten Sie jederzeit das Gleichgewicht. Dadurch
können Sie das Elektrowerkzeug in unerwarteten Situationen besser
kontrollieren.
f) Tragen Sie geeignete Kleidung. Tragen Sie keine weite Kleidung oder
Schmuck. Halten Sie Haare, Kleidung und Handschuhe fern von sich
bewegenden Teilen. Lockere Kleidung, Schmuck oder lange Haare können von
sich bewegendenTeilen erfasst werden.
g) Wenn Staubabsaug- und -auffangeinrichtungen montiert werden
können, vergewissern Sie sich, dass diese angeschlossen sind und
richtig verwendet werden. Verwendung einer Staubabsaugung kann
Gefährdungen durch Staub verringern.
4. VERWENDUNG UND BEHANDLUNG DES ELEKTROWERKZEUGES
a) Überlasten Sie das Gerät nicht. Verwenden Sie für Ihre Arbeit das dafür
bestimmte Elektrowerkzeug. Mit dem passenden Elektrowerkzeug arbeiten
Sie besser und sicherer im angegebenen Leistungsbereich.
b) Benutzen Sie kein Elektrowerkzeug, dessen Schalter defekt ist. Ein
Elektrowerkzeug, das sich nicht mehr ein- oder ausschalten lässt, ist gefährlich
und muss repariert werden.
c) Entfernen Sie den Akku, bevor Sie Geräteeinstellungen
vornehmen, Zubehörteile wechseln oder das Gerät weglegen.
Diese Vorsichtsmaßnahme verhindert den unbeabsichtigten Start des
Elektrowerkzeuges.
d) Bewahren Sie unbenutzte Elektrowerkzeuge außerhalb der Reichweite
von Kindern auf. Lassen Sie Personen das Gerät nicht benutzen, die
mit diesem nicht vertraut sind oder diese Anweisungen nicht gelesen
haben. Elektrowerkzeuge sind gefährlich, wenn Sie von unerfahrenen Personen
benutzt werden.
e) Pflegen Sie Elektrowerkzeuge mit Sorgfalt. Kontrollieren Sie, ob
bewegliche Teile einwandfrei funktionieren und nicht klemmen, ob
Teile gebrochen oder so beschädigt sind, dass die Funktion des
Elektrowerkzeuges beeinträchtigt ist. Lassen Sie beschädigte Teile vor
dem Einsatz des Gerätes reparieren. Viele Unfälle haben ihre Ursache in
schlecht gewarteten Elektrowerkzeugen.
f) Halten Sie Schneidwerkzeuge scharf und sauber. Sorgfältig gepflegte
