SAFETY AND OPERATING MANUAL

Sonicrafter WX693 WX693.9
3
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1 Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes, radiators,
ranges and refrigerators.There is an increased
risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you
are tired or under the influence of drugs,
alcohol or medication. A moment of inattention
while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the

Sonicrafter WX693 WX693.9
4
working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in
unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do
not charge the battery pack or tool
outside the temperature range specified
in the instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
6) Service
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service
providers.
SAFETY INSTRUCTION FOR
CUTTING
Hold power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring. Cutting accessory contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use, keep
it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery terminals
together may cause burns or a fire.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
the liquid to come into contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts of
water and seek medical advice.
f) Seek medical advice immediately if a cell or
battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean
dry cloth if they become dirty.
i) Battery pack needs to be charged before
use. Always refer to this instruction and use
the correct charging procedure.
j) Do not maintain battery pack on charge
when not in use.
k) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
l) Battery pack gives its best performance
when it is operated at normal room
temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
n) Recharge only with the charger specified
by POSITEC. Do not use any charger other
than that specifically provided for use with
the equipment. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
o) Do not use any battery pack which is not
designed for use with the equipment.
p) Keep battery pack out of the reach of
children.
q) Retain the original product literature for
future reference.
r) Remove the battery from the equipment
when not in use.
s) Dispose of properly.

Sonicrafter WX693 WX693.9
5
SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Do not dispose of batteries.
Return exhausted batteries to
your local collection or recycling
point.
Do not expose to rain or water
Do not burn
Avoid danger of injury from the
sharp edges of the accessories.
Accessories can become very hot
while working, presenting danger
of burns!
Make sure the battery is removed
prior to changing accessories.
Wear protective gloves.
High oscillation frequency
Low oscillation frequency
LED light is a battery capacity
indicator and will flash when
power gets low.
RCM marking
ABN: ABN: Australian Business
Number. By this number,
business information such as
entity type, status, business
location etc. can be found at
website http://abr.business.gov.
au.
ABN of Positec Australia Pty
Limited is 14 101 682 357
- - -
- - -
=
Li-Ion
Li-Ion

Sonicrafter WX693 WX693.9
6
2
3
1
2
1
1
- - -
- - -
=
2
ON
OFF
AB
CD
EF
GH
12
3
4
5
6
7

Sonicrafter WX693 WX693.9
7
2
3
1
2
1
1
- - -
- - -
=
2
ON
OFF
AB
CD
EF
GH

Sonicrafter WX693 WX693.9
8
1. HYPERLOCK™ ACCESSORY CLAMPING
LEVER
2. ON/OFF SWITCH
3. VARIABLE SPEED DIAL
4. VENTING SLOTS
5. UNIVERSAL-FIT ACCESSORY INTERFACE*
6. SMALLER FLANGE (FOR OTHER BRANDS’
SANDING PADS)
7. FLANGE
*Works with other oscillating tool brands’
accessories.
The following compatible brands are trademarks
owned by third parties which may be registered by
their respective owners: Black & Decker®, Bosch®,
Chicago Electric®, Craftsman®, Dremel®, Fein®, Gen-
esis®, Makita®, Mastercraft®, Milwaukee®, Performax®,
Porter Cable®, Ridgid®, Ryobi®, Skil®, andTool Shop®.
Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX693 WX693.9 (6-designation of
machinery, representative of high frequency
oscillation tool)
WX693 WX693.9
Voltage 20V Max**
Oscillations speed 8000-18000 /min
Oscillation angle 4°
Battery capacity 2.0Ah
Charging time 1hr /
Machine weight 1.4 KG 1 KG
Charger 1
(WA3860) /
Battery pack 1
(WA
3551.1 )/
**Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal volt-
age is 18 volts
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The power tool is intended for sawing and
remodeling wooden materials, plastic, plaster,
non-ferrous metals and fasteners (e.g. nails
and clamps) as well as for working on soft wall
tiles and for dry grinding of small surfaces. It is
especially suitable for working close to edges
and for flush cutting
ASSEMBLY AND OPERATION
ACTION FIGURE
Mounting Accessories See Fig. A-C
MountingThe Sanding Sheet See Fig. D
OperatingThe On/Off Switch See Fig. E
UsingThe Variable Speed Dial See Fig. F
Remove Or Install Battery Pack See Fig. G
LED Light See Fig. H
The Variable Speed Dial can be used to set
the optimum oscillating frequency according
to the accessories used and the respective
application.
Oscillation frequency Application
High oscillation
frequency:
Sanding, sawing, rasping
and polishing stone and
metal.
Low oscillation
frequency:
Scraping, polishing
varnishes.

Sonicrafter WX693 WX693.9
9
APPLICATION
Warning: the sawing teeth are very sharp. Do not touch during mounting and
application.
The workpiece must be clamped tightly before it is cut.
Pic Description Application
Sawing
Universal Metal/Wood End Cut
Blade
Wood, plastic, fiberglass, nails,
non-ferrous metals, thin sheet
metal, hardened fillers
Standard Wood End Cut Blade Wood, plastic, drywall
Precision Wood Cut Blade Wood, soft plastics
HSS Semicircle Saw Blade
Thin wood, plastic, fiberglass,
non-ferrous metals, thin
sheet metal, hardened fillers,
window glazing
Sanding
Sanding Pad (Perforated) Wood, plastic, hardened fillers
Sanding Finger Pad Wood, plastic, hardened fillers
Rasping
Triangular Carbide Grit Rasp Wood, hardened adhesives,
thin set, masonry
Carbide Rasp (Finger Shaped) Wood, hardened adhesives,
thin set, masonry
Removing
grout
Carbide Grit Semicircle Saw
Blade
Grout, porous concrete,
masonry
Diamond-Coated Semicircle
Saw Blade
Ceramic and stone tile, backer
board
Scraping
Rigid Scraper Blade Old paint, hardened adhesives,
caulk, carpet
Flexible Scraper Blade Elastic sealants, paint,
adhesive residues, carpet.

Sonicrafter WX693 WX693.9
10
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
NOTE: When plunging and sawing use a
slight pendulum motion, to allow sufficient
chip removal.
The saw blade lasts longer if the wear is distributed
evenly.To ensure an even distribution, loosen the
saw blade, rotate it and retighten firmly.
Cut/Sand with a constant movement and light pres-
sure.
Heavy pressure does not increase the cut/removal
rate – the accessory merely wears faster.
WORKING HINTS FOR YOUR
TOOL
If your power tool becomes too hot, espe-
cially when used at low speed, set the speed
to maximum and run it with no load for 2-3
minutes to cool the motor. Avoid prolonged
usage at very low speeds. Always keep the
blade sharp.
Always ensure the workpiece is firmly held or
clamped to prevent movement.
Any movement of the material may affect the
quality of the cutting or sanding finish.
Start your tool before working and turn it off
only after you stop working.
Do not start sanding without having the sand-
paper fitted.
Do not allow the sandpaper to wear away , it
will damage the sanding pad.The guarantee
does not cover sanding pad wear and tear.
Use coarse grit paper to sand rough surfaces,
medium grit for smooth surfaces and fine grit
for finishing surfaces. If necessary, first make
a test run on scrap material.
Excessive force will reduce the working ef-
ficiency and cause motor overload. Replacing
the accessory regularly will maintain optimum
working efficiency.
MAINTAIN TOOLS WITH
CARE
Your power tool requires no additional
lubrication or maintenance. There are no
user serviceable parts in your power tool.
Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep
all working controls free of dust.
The ambient temperature range for tool and
battery use and storage is 0 °C -45 °C .
The recommended ambient temperature
range for the charging system during charging
is 0℃-40℃.

Copyright © 2017, Positec. All Rights Reserved.
AR01342000
