Wottan motor STORM-V 125 User manual

Wottan Motor
USER MANUAL
STORM-V125cc


Dear owner: Congratulaons on your choice of a STORM-V 125 model and thank you for your trust in us.
In order to operate your vehicle safely and to keep it in perfect condion at all mes, we recommend that
you carefully read the instrucons in this manual and follow the spulated maintenance procedures. We are
condent that WOTTAN MOTOR will repay the trust you have placed in us.
We would like to remind you that only WOTTAN service technicians are trained and have all the up-to-date
informaon and tools to provide you with excellent service according to the specic needs of your new vehicle.
The enre Woan motor team is constantly working to update and improve the product. Therefore, some of
the informaon in this manual may be altered and modied without prior noce.
The manufacturer declines responsibility for any damage to the unit because of accessories not approved by
the manufacturer.

Page / 3 Wottan Motor
Introducon ........................................................ 4
SECURITY INSTRUCTIONS
Security Check ..................................................... 6
Safe driving recommendaons ............................ 9
Transported cargo ............................................. 13
Running-in ......................................................... 14
VEHICLE IDENTIFICATION
Vehicle idencaon ......................................... 16
View from the right side .................................... 18
View from the le side ...................................... 19
CONTACT LOCK
Instrucons on the remote control ................... 20
Electronic key instrucons ................................. 22
An-the system operaon .............................. 24
DASHBOARD
Elements ........................................................... 28
GENERAL VIEW
Instrumentaon le handgrip ........................... 32
Instrumentaon right handgrip ......................... 32
Overview and operaon .................................... 33
Storage compartments ...................................... 34
Fuel tank cap ..................................................... 35
STANDS
Side stand .......................................................... 36
Center stand ...................................................... 37
DRIVING INSTRUCTIONS
Electric start ...................................................... 38
Braking............................................................... 40
Stop engine........................................................ 41

Maintenance and cleaning ................................ 42
Wheel rims and storage .................................... 44
Technical changes, accessories and spare parts 46
Engine oil ........................................................... 47
Checking steering bearings ................................ 50
Tyre condion .................................................... 52
Air lter ............................................................. 54
Fuses .................................................................. 56
Baery ............................................................... 58
Remove and install baery ................................ 60
TECHNICAL DATA
Engine ................................................................ 62
Trasmission and chassis ..................................... 63
Lubricants and operang uids ......................... 64
Electrical equipment ......................................... 64
Dimensions and weight ..................................... 65

Warranty............................................................ 68
Exclusions .......................................................... 73
Inspecon plan .................................................. 78
Revision table ................................................... 82
TABLE OF CONTENTS

Woan Storm-V 2023 User Manual Page /4
INTRODUCTION
WOTTAN MOTOR has designed, tested and produced this scooter using the most advanced technology in
order to oer you a safe and enjoyable ride.
Your WOTTAN will provide you great moments of fun while being a praccal, safe and economical means of
transport. However, before using it, especially for the rst me, please familiarise yourself with the informaon
on this manual. Also, all the care and maintenance your WOTTAN requires is described in this manual. If you
follow all instrucons carefully, you will ensure a long service life for your motorbike. The Woan Authorised
Dealer and Service Network has experienced technicians capable of giving your motorbike the best possible
service with the necessary tools and knowledge.
All informaon, illustraons, photographs and specicaons contained in this manual are based on the latest
producon informaon. Due to WOTTAN’s policy of connuous product improvement there may be some
dierences between this manual and your scooter. WOTTAN reserves the right to make changes to its products
at any me. Please also note that this Manual refers to all specicaons of a parcular scooter model for any
given country. Some details may vary from one country to another. Therefore, your model may dier from
what is shown in this manual.
COPYRIGHT WOTTAN MOTOR, S.L.
January 2023 Edion

Page / 5 Wottan Motor
This manual includes important instrucons for the safety and handling of your scooter.

The following must be observed:
WARNING
Precauonary measures against the risk of accident, injury and/or death.
RISK OF FIRE
The vehicle is equipped with a catalyc converter that causes extremely high temperatures in the exhaust
system (re risk).
CAUTION
Important instrucons and precauons to avoid damage to the vehicle. Failure to observe these instrucons
may result in the voiding of the warranty.
NOTE
Special instrucons for beer handling during operaon, inspecon adjustments and service acvies.

Woan Storm-V 2023 User Manual Page /6
WARNING

               

Please be advised, of course, that it is neither praccal nor possible to warn you of all the dangers associated
with the operaon, handling or maintenance of your vehicle. You must use your common sense.
SAFETY > SECURITY CHECK

Before driving, perform a safety check using the enclosed checklist.
Take the safety check seriously. Perform proper maintenance before you start your journey. A technically fault
free scooter is a basic requirement for your safety and that of other road users.
Before you start your journey, check the following:
- Handlebars (smooth and easy to handle).
- Engine oil level
- Fuel quanty

Page / 7 Wottan Motor
- Front brake
- Rear brake
- Tyres (contour and pressure)
- Front fork
- Load distribuon
- Lights
- Total weight
- Brake uid level.
In the event of problems or dicules, contact an authorised service point.
WARNING
Do not touch the starng system while the engine is running.
FIRE HAZARD
The vehicle is equipped with a catalyc converter, this causes extremely high temperatures in the exhaust
system (risk of burns). Make sure that you are not in contact with ammable materials while driving or when
staonary or parked!
WARNING
For your safety, only use original accessories or products approved and cered by Woan Motor. Woan
Motor is not responsible for any damage caused by non-approved accessories.

Woan Storm-V 2023 User Manual Page /8
WARNING
For your safety, only use original accessories or products approved and cered by Woan Motor. Woan
Motor is not responsible for any damage caused by non-approved accessories.
NOTE
Our approved products and accessories are available at all authorised points of sale and in our website www.
woanmotor.com.
WARNING
- Do not exceed the maximum permissible weight. 150kg
- Check tyre pressure.
- Check rims.
WARNING
Before any journey, check the operaon of all lighng components of the vehicle.
- Check that the headlights are clean.

Page / 9 Wottan Motor

CAUTION
Safety is also largely determined by driving style.
Therefore:
- Put on an approved safety helmet and fasten it correctly.
- Wear appropriate protecve clothing.
- Use foot rests.
- Do not drive if your driving ability may be compromised (in ice, rain or strong wind).
Your reacons can be severely aected, not only by alcohol, but also by drugs and medicines, do not drive
under the inuence of either.
- Strictly observe all trac regulaons.
- Always adapt your driving speed to the trac and road condions.
On wet roads or in the presence of loose gravel, be aware that your stability and braking power are limited by
the grip of the wheels on the road surface and the distance may be greater.


Woan Storm-V 2023 User Manual Page /10
Fuel consumpon, environmental polluon and wear and tear on the engine, brakes and tyres depend on a
number of factors.
Your personal driving style is a major determinant of fuel consumpon, exhaust and noise generaon.
At idle, the engine needs me to warm up to an opmal operang temperature. However, in the warm-up
phase, pollutant emissions and the level of wear and tear are very high. Therefore, it is best to start driving
immediately aer starng the engine gently and without forcing the engine unl it reaches opmum operang
temperature.

Moderang the use of the accelerator to what is strictly necessary reduces fuel consumpon as well as
polluon and wear levels.

Hard acceleraon and braking cause high fuel consumpon and increased polluon levels.

Washing the scooter or driving through water or rain can delay the braking eect due to wet or (in winter) icy
brake discs or pads.

Page / 11 Wottan Motor
WARNING
Braking distances increase exponenally when the brake discs are wet.
CAUTION
On roads salted by de-icing.
When driving on roads on which salt has been deposited, full braking performance may be compromised.

WARNING
Brake discs and pads must be free of oil and grease!
If the scooter is not to be used for a while, a layer of rust may form on the brakes and thus increase the braking
eect. A thick layer of rust can cause the brakes to lock. When riding aer a period of non-use, carefully
apply the brakes several mes unl they funcon normally. Also, during the rst 500 km of the unit as well as
when changing discs or pads there is an adaptaon period during which the components adjust and gradually
increase their eciency.

Woan Storm-V 2023 User Manual Page /12

When driving in less than opmal road condions (mud, rain, oil, grease, etc.), the braking system’s capacity
may be reduced.
WARNING
In these circumstances use the brakes with cauon unl they are clean, the braking distance may be increased.
Pad wear increases with dirty brakes!
NOTE
Be sure to pracce braking for emergency situaons, but do so in a situaon that will not put yourself or others
at risk.

Dierent driving condions aect fuel consumpon. The following are unfavourable for fuel consumpon:
- High trac density, especially in large cies with many stops and trac lights.
- Short, frequent journeys with constant starng and stopping of the engine.
- Driving in trac jams with slow and dense trac.
Plan journeys in advance to avoid heavy trac.
Fuel consumpon is also aected by condions beyond our control, such as poor road condions, steep
gradients and low temperatures.

Page / 13 Wottan Motor
SAFETY > TRANSPORTED CARGO
The performance of the vehicle varies depending on the load being carried and its arrangement. Overloading
aects the stability, steering and safety of the vehicle.
For your safety, do not exceed the specied load limits under any circumstances.
Observe the following points to reduce fuel consumpon:
- Adhere to the unit’s maintenance schedule.
- Regular maintenance by a specialised workshop will ensure not only the connued good performance of the
unit, but also reduced fuel consumpon, low environmental polluon and a long service life.
- Check tyre pressure every two weeks.
Low tyre pressure increases rolling resistance. This increases fuel consumpon and tyre wear and negavely
aects the performance of the unit.
- Connuously monitor fuel consumpon.



Woan Storm-V 2023 User Manual Page /14
SAFETY > RUNNING-IN
Running-in instrucons for engine and transmission.
CAUTION
Excessive engine speed during the running-in period increases engine wear and reduces engine life by up to
50%.
Any engine faults during the running-in period must be reported immediately to an ocial service centre.
Be especially careful when transporng liquids that could spill on the vehicle or damage other vehicles in
trac.
If you use the rear luggage rack, be sure to secure items with strong straps or nets to prevent loss. Remember
that a bulky package is very sensive to wind, causing instability in the handling of the vehicle.
Be especially careful in side winds and when overtaking large vehicles such as trucks and buses.
Do not place any material outside the spaces designed for transport.

Page / 15 Wottan Motor
NOTE
During the running-in period, drive smoothly but vary the engine speed frequently. Select winding roads with
some hills. Constantly avoid driving at very low revs and also avoid accelerang the unit to the limit.
- For the rst 500 km: Use less than half the throle range.
- Aer 1.000 km: Use less than ¾ of the throle range.
CAUTION

You can save delays by making an appointment with an authorised service agent in advance.

CAUTION
New tyres have a smooth surface. Therefore, they should be roughened by rolling them carefully and smoothly
in various inclined posions.
Only then will the surface get its full grip!


Woan Storm-V 2023 User Manual Page /16
VEHICLE IDENTIFICATION
The vehicle has three forms of idencaon: the idencaon plate, the chassis number and the engine
number.
NOTE
The descripon on the right-hand side is seen from the driver’s side.
The idencaon number (1) is located on the rear of the chassis, under the right-hand lower cover.

The chassis number is located on the chassis, behind the cover (2).
WARNING
New brake pads must be used and will not have their full friconal power unl aer 500 km of use.
The eect of reduced braking power can be compensated by increased brake lever pressure.
During this period, avoid unnecessary heavy braking acons.

Page / 17 Wottan Motor
3
2


The engine number (3) is located at the upper rear of the right crankcase.

Woan Storm-V 2023 User Manual Page /18

2
6
7


3

1. Storage box and tool kit
2. Baery box and fuse
3. Ignion block and fork column
4. Brake uid tank for front brake
5. Front brake lever
6. Spark plug
7. Engine oil ller cap

Page / 19 Wottan Motor

8. Rear brake lever
9. Le-hand grip
10. Tank cover
11. Transmission oil ller cap
12. Air lter
13. Side stand
8

9




Woan Storm-V 2023 User Manual Page /20
CONTACT LOCK > FUNCTIONS
WARNING
While driving, do not switch the key from ON to OFF.
NOTE
Keys
With the scooter, you get two sets of ignion keys. Keep the spare key in a safe place.
Keyless is a high-tech system that does not require a key. If the remote control is lost, the keyless ignion
switch cannot be acvated.

1. Keyless ignion
Keyless start range: The remote lock is within 2 metres of an open area without interference.
Press the main switch the indicator light comes on and can be turned to drive.
2. Mechanical emergency lock
Li the black cover on the front lock and insert the key to acvate the system.
NOTES
“O” means that the enre circuit is open and the engine cannot start.
