Woxcon WUH4ARC-H2 User manual

WUH4ARC-H2
HDMI2.0 4x1 Switcher
All Rights Reserved
Version: WUH4ARC-H2_2019V1.5
User Manual

HDMI2.0 4x1 Switcher
Preface
Read this user manual carefully before using the product. Pictures are shown in this
manual for reference only. Different models and specifications are subject to real
product.
This manual is only for operation instruction, please contact the local distributor for
maintenance assistance. In the constant effort to improve the product, we reserve the
right to make functions or parameters changes without notice or obligation. Please refer
to the dealers for the latest details.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

HDMI2.0 4x1 Switcher
SAFETY PRECAUTIONS
To ensur e t h e b e s t performance from the pr o d u c t , p l ease read all i n s t r u c t i ons carefully
before using the device. Save this manual for further reference.
l Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
l Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
l Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
l Refer all servicing to qualified service personnel.
l To prev e n t f i re or shock hazard, d o n o t e x p o s e the unit to rain, moisture or install
this product near water.
l Do not put any heavy items on the extension cable in case of extrusion.
l Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
l Install the device in a place with fine ventilation to avoid damage caused by
overheat.
l Keep the module away from liquids.
l Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
l Do not twist or pull by force ends of the optical cable. It can cause malfunction.
l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
l Unplug the power cord when left unused for a long period of time.
l Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

HDMI2.0 4x1 Switcher
Table of Content
1. Product Introduction .................................................................................................... 1
1.1 Features ............................................................................................................. 1
1.2 Package List ....................................................................................................... 2
2. Technical Specifi c a t i o n ................................................................................................ 3
3. Panel Description ........................................................................................................ 4
3.1 Front Panel ......................................................................................................... 4
3.2 Rear Panel ......................................................................................................... 5
4. System Connection ..................................................................................................... 6
4.1 Usage Precaution ............................................................................................... 6
4.2 System Diagram ................................................................................................. 6
5. Source Button Control ................................................................................................. 7
5.1 Manual Switching ............................................................................................... 7
5.2 Automatic Switching ........................................................................................... 7
6. IR Remote Control ....................................................................................................... 8
7. RS232 Control ............................................................................................................. 9
7.1 RS232 Control Software ..................................................................................... 9
7.2 RS232 Command ............................................................................................. 11
7.2.1 Signal Switching ..................................................................................... 11
7.2.2 Source Device Control ........................................................................... 11
7.2.3 Display Device Control ........................................................................... 12
7.2.4 Audio Selection ...................................................................................... 12
7.2.5 System Control ....................................................................................... 14
8. EDID Management .................................................................................................... 15
8.1 Predefined EDID Setting .................................................................................. 15
8.2 User Defined EDID Setting ............................................................................... 16
9. ARC Mode ................................................................................................................. 17
10. Firmware Upgrade ................................................................................................... 18
11. Panel Drawing .......................................................................................................... 18
12. Troubleshooting & Maintenance .............................................................................. 19

HDMI2.0 4x1 Switcher
13. Customer Service .................................................................................................... 20

HDMI2.0 4x1 Switcher
1
1. Product Introduction
The WUH4ARC-H2 is an ultra-thin auto switcher with four HDMI video inputs and one
HDMI output. This switcher supports HDMI video resolution up to 4Kx2K@60Hz 4:4:4
HDR and multichannel audio. Except passing EDID information from the display, there
are multiple built-in EDID settings to simplify an installation. The switcher will de-embed
digital stereo audio to provide an analog audio source for an existing audio system. The
switcher also supports audio return channel (ARC) for transmitting audio back to HDMI
input port from the connected display.
In auto-switch mode, it switches to an HDMI input as soon as a new source is
connected. When the active input is removed, the switcher will select the first source on
the lowest numbered input. The switcher may also be controlled via RS232, IR with the
included remote, or from the source button on the front of the switcher.
1.1 Features
l Switches any one of four HDMI inputs to one HDMI output.
l Supports video resolution up to 4Kx2K@60Hz 4:4:4 HDR.
l 18Gbps high bandwidth.
l Fully compliant with the HDMI 2.0 and HDCP2.3 specifications.
l Supports audio return channel (ARC).
l Advanced EDID management: multiple preset and user defined allowed.
l Controllable via RS232 and IR.
l Supports CEC.
l Provides seven LEDs to indicate the current operating status and to assist
troubleshooting an installation.
l Firmware upgrade by Micro-USB port.

HDMI2.0 4x1 Switcher
2
1.2 Package List
l 1x HDMI2.0 4x1 Switcher
l 2x Mounting Ears
l 4x Mounting Screws
l 4x Plastic Cushions
l 1x RS232 Cable (3.5mm to DB9)
l 1x IR Remote
l 1x IR Receiver
l 1x Power Adapter (5V DC 1A)
l 1x User Manual
Note: Please contact your distributor immediately if any damage or defect in the
components is found.

HDMI2.0 4x1 Switcher
3
2. Technical Specification
Video Input
Input
(4) HDMI
Input Connector
(4) Female type-A HDMI
HDMI Input Resolution
Up to 4Kx2K@60Hz 4:4:4
HDMI Standard
2.0
HDCP Version
2.3
Video Output
Output
(1) HDMI
Output Connector
(1) Female type-A HDMI
HDMI Output Resolution
Up to 4Kx2K@60Hz 4:4:4
HDMI Standard
2.0
HDCP Version
2.3
Audio
Output
(1) AUDIO
Output Connector
(1) 3.5mm mini stereo audio jack
Audio Format
PCM
Audio Output Impedance
70 Ohms
Frequency Response
20Hz to 20kHz, ±3dB
Control
Control
(1) IR IN; (1) RS232
Control Connector
(2) 3.5mm mini jack
General
Bandwidth
18Gbps
Operation Temperature
-10℃ ~ +55℃
Storage Temperature
-25℃ ~ +70℃
Relative Humility
10%-90%
Power Supply
Input:100V~240V AC; Output: 5V DC 1A
Power Consumption
5W(Max)
Dimension (W*H*D)
194mm x 15mm x 81mm
Net Weight
324g

HDMI2.0 4x1 Switcher
4
Note: Please adopt high-qualified HDMI cable fully compliant with HDMI2.0 for reliable transmission and
connection.
3. Panel Description
3.1 Front Panel
①
Auto/Source Button:
l Press to switch to next input source.
l Press and hold at least three seconds to switch between manual mode and
auto mode.
②
Power LED: The LED illuminates red when power is applied.
③
Audio Mode LED:
l Illuminates green when de-embedding audio.
l Illuminates yellow when in ARC mode.
④
Switching Mode LED:
l Illuminates green in manual switch mode.
l Illuminates yellow in auto-switch mode.
⑤
Input 1~4 LED: The LED illuminates green when there is HDMI input on the
corresponding channel.
⑥
FIRMWARE: Micro-USB port for firmware upgrade.
FIRMWARE
AUTO
SOURCE AUDIO MODE 1 2 3 4
12345 6

HDMI2.0 4x1 Switcher
5
3.2 Rear Panel
①
IN 1~4: Four type-A female HDMI input ports to connect HDMI sources. The input 4
port supports ARC.
②
OUT: Type-A female HDMI output port to connect HDMI display.
③
AUDIO: 3.5mm mini jack for analog audio output.
④
RS232: 3.5mm mini jack to connect control device (e.g. PC).
⑤
IR IN: 3.5mm mini jack to connect the included IR receiver for remote control.
⑥
EDID: 4-pin DIP switch for EDID setting.
⑦
DC 5V: DC port to connect a 5V DC AC power adapter.
Note: Output HDCP compliant status depends on input signal. When the input signal is
with HDCP, then output signal is with HDCP and vice versa.
DC 5VEDIDIR INRS232AUDIOOUT
IN 1 IN 2 IN 3
1234567

HDMI2.0 4x1 Switcher
6
4. System Connection
4.1 Usage Precaution
l Make sure all components and accessories included before installation.
l System should be installed in a clean environment with proper temperature and
humidity.
l All of the power switches, plugs, sockets, and power cords should be insulated and
safe.
l All devices should be connected before power on.
4.2 System Diagram
The following diagram illustrates typical input and output connections that can be
utilized with this switcher:
Game Console Laptop
STB
5 6 7
Receiver Remote
Central Control
System
Ray-Blu DVD
TV Speaker
HDMI:
Control:
Audio:
RS232:

HDMI2.0 4x1 Switcher
7
5. Source Button Control
5.1 Manual Switching
When the switcher is in manual switching mode, the Switching Mode LED will be green,
and please press Auto/Source button to switch to the next input.
5.2 Automatic Switching
To enabl e a u t o m a t i c switching, press a n d h o l d t he Auto/Source button for three
seconds. The Switching Mode LED will turn to yellow.
When in auto-switch mode, the switcher follows the rules in the certain circumstances:
l New Input: Upon detecting a new input, the switcher will automatically select the
new source.
l Reboot: Once power is restored to the switcher, if the last selected source is still
available, the switcher will still output this signal, otherwise, the switcher will switch
to the first available active input starting at HDMI Input 1.
l Source Removed: When an active source is removed, the switcher will switch to the
first available active input starting at HDMI Input 1.

HDMI2.0 4x1 Switcher
8
6. IR Remote Control
Please connect an IR receiver to the IR input port; the IR remote is used for signal
switching and it can also be used to control source and display devices based on CEC
function.
Note:
l Due to the HDMI input 4 port does not support CEC, the source device connected
to this port can not be controlled by IR remote.
l The source and display devices are required to support CEC when the IR remote is
used to control them.
INPUTS:
1~4: Select the corresponding input source.
MANUAL/AUTO: Switch Auto or manual mode.
SOURCE: Control the input source (e.g. DVD).
DISPLAY: Control the display (e.g. HDTV).

HDMI2.0 4x1 Switcher
9
7. RS232 Control
Connect the switcher to the control device (e.g. PC) with RS232 cable and set the
parameters in the right manner, the control device is capable to control this switcher by
RS232 commands.
7.1 RS232 Control Software
Installation: Copy the control software file to the computer connected with this
switcher.
Uninstallation: Delete all the control software files in corresponding file path.
Basic Settings
First of all, please connect all needed input devices and output devices, then to connect
it with a computer which is installed with RS232 control software.
Here take the software CommWatch.exe as example.
Double-click the following icon:

HDMI2.0 4x1 Switcher
10
The interface of the control software is shown as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, then the RS232 commands can be sent in Command Sending Area.
Baud rate: 9600;
Data bit: 8;
Stop bit: 1;
Parity bit: none.
Parameter configuration area
Monitoring area, indicates if
the command sent works.
Command sending area

HDMI2.0 4x1 Switcher
11
7.2 RS232 Command
Note: All commands must be ended with “<CR><LF>”.
7.2.1 Signal Switching
Function
Command
Feedback Example
Switch to HDMI input 1.
>>HDMI1
<<HDMI1
Switch to HDMI input 2.
>>HDMI2
<<HDMI2
Switch to HDMI input 3.
>>HDMI3
<<HDMI3
Switch to HDMI input 4.
>>HDMI4
<<HDMI4
Enable auto-switching mode.
>>AUTO
<<AUTO Switch
Enable manual switching mode.
>>MANUAL
<<MANUAL Switch
7.2.2 Source Device Control
Note:
l The input source device is required to support CEC.
l Due to the HDMI input 4 port does not support CEC, the source device connected
to this port can not be controlled by IR remote.
Function
Command
Feedback Example
Turn on the input source device,
e.g. Blue-ray DVD.
>>SRCOn
<<SRCOn
Turn off the input source device,
e.g. Blue-ray DVD.
>>SRCOff
<<SRCOff
Play
>>SRCPlay
<<SRCPlay
Pause
>>SRCPause
<<SRCPause
Stop
>>SRCStop
<<SRCStop
Fast Forward x1
>>SRCForward
>>SRCForward

HDMI2.0 4x1 Switcher
12
Fast Rewind x1
>>SRCBackward
<<SRCBackward
Next Section
>>SRCSkipForward
>>SRCSkipForward
Previous Section
>>SRCSkipBackward
<<SRCSkipBackward
Open the menu setting
>>SRCMenu
>>SRCMenu
Go back
>>SRCBack
>>SRCBack
Confirm (OK)
>>SRCOk
>>SRCOk
Exit
>>SRCExit
>>SRCExit
Up direction
>>SRCUp
>>SRCUp
Down direction
>>SRCDown
>>SRCDown
Left direction
>>SRCLeft
>>SRCLeft
Right direction
>>SRCRight
<<SRCRight
7.2.3 Display Device Control
Note: The display device is required to support CEC.
Function
Command
Feedback Example
Turn on the display device, e.g.
HDTV.
>>TVOn
>>TVOn
Turn off the display device, e.g.
HDTV.
>>TVOff
>>TVOff
Volume up.
>>TVVOL+
>>TVVOL+
Volume down.
>>TVVOL-
>>TVVOL-
Mute.
>>TVMUTE
>>TVMUTE
Unmute
<<TVUNMUTE
<<TVUNMUTE
7.2.4 Audio Selection
Function
Command
Feedback Example

HDMI2.0 4x1 Switcher
13
Select ARC audio channel.
>>AUDExternal
<<AUDExternal
Select the HDMI audio input
channel.
>>AUDInternal
>>AUDInternal

HDMI2.0 4x1 Switcher
14
7.2.5 System Control
Function
Command
Feedback Example
System reset.
>>RESET
>>RESET
Get system information.
>>SYSInfo
<<AUDExternal
<< WUH4ARC-H2
<< V1.0.0
<< --------
<<HDMI1
<<Auto Switch
<<AUDExternal
<<EDID0

HDMI2.0 4x1 Switcher
15
8. EDID Management
8.1 Predefined EDID Setting
The rear panel boasts a 4-pin DIP switch to set the predefined EDID. The ten types of
embedded EDID and their corresponding switch status are shown in the below list.
When in the lower
position, the switch
represents “ON”,
while putting the
switch in the up
position, it
represents “OFF”.
ID
Switch
Status
Video
Audio
0
0000
Pass though
Pass though
1
0001
1920x1080p@60Hz 4:4:4
RGB 8bit
Stereo
2
0010
1920x1080p@60Hz 4:4:4
RGB 8bit
High Definition
3
0011
1920x1080p@60Hz 4:4:4
RGB 12bit
Stereo
4
0100
1920x1080p@60Hz 4:4:4
RGB 12bit
High Definition
5
0101
3840x2160p@60Hz 4:2:0
RGB 8bit
Stereo
6
0110
3840x2160p@60Hz 4:2:0
RGB 8bit
High Definition
7
0111
3840x2160p@60Hz 4:4:4
RGB 10bit HDR
Stereo
8
1000
3840x2160p@60Hz 4:4:4
RGB 10bit HDR
High Definition
9
1001
1280x800@60Hz
Stereo
10
1010
1920x1200@60Hz
Stereo
