wtw pH 3310 User manual

ba75802e02 12/2008
pH 3310
Operating manual
pH meter
HOLD AR
25.0
6.093
pH
°C
USBoutput
Menu15.11.2008
08:37

pH 3310
ba75802e02 12/2008
Accuracy when
going to press
The use of advanced technology and the high quality standard of our
instruments are the result of a continuous development. This may result in
differences between this operating manual and your meter. Also, we cannot
guarantee that there are absolutely no errors in this manual. Therefore, we
are sure you will understand that we cannot accept any legal claims resulting
from the data, figures or descriptions.
Copyright ©Weilheim 2008, WTW GmbH
Reproduction in whole - or even in part - is prohibited without the express
written permission of WTW GmbH, Weilheim.
Printed in Germany.

pH 3310 Contents
3
ba75802e02 12/2008
pH 3310 - Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Socket field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Authorized use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . 10
3 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Initial commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.1 Inserting the batteries. . . . . . . . . . . . . . . . . . . . . 13
3.2.2 Switching on the meter. . . . . . . . . . . . . . . . . . . . 14
3.2.3 Setting the date and time . . . . . . . . . . . . . . . . . 14
4 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Switching on the meter . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 General operating principles . . . . . . . . . . . . . . . . . . . . . . 16
4.2.1 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2.2 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2.3 Example 1 on navigation: Setting the language. 19
4.2.4 Example 2 on navigation: Setting the date and
time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Sensor-independent settings . . . . . . . . . . . . . . . . . . . . . 24
4.3.1 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3.2 Data storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.3.3 Automatic Stability control . . . . . . . . . . . . . . . . . 26
4.4 pH value / ORP voltage. . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4.1 General information . . . . . . . . . . . . . . . . . . . . . . 27
4.4.2 Measuring the pH value . . . . . . . . . . . . . . . . . . . 28
4.4.3 Measuring the ORP . . . . . . . . . . . . . . . . . . . . . . 30
4.4.4 Settings for pH and ORP measurements. . . . . . 32
4.4.5 pH calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.4.6 Calibration interval . . . . . . . . . . . . . . . . . . . . . . . 39
4.4.7 Carrying out an automatic calibration (AutoCal) 40
4.4.8 Carrying out a manual calibration (ConCal) . . . . 44
4.4.9 Displaying calibration records . . . . . . . . . . . . . . 47
4.4.10 Continuous measurement control (CMC
function) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Contents pH 3310
4ba75802e02 12/2008
4.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.5.1 Manual storage . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.5.2 Automatic storage at intervals . . . . . . . . . . . . 52
4.5.3 Editing the measured value storage . . . . . . . . . . 55
4.5.4 Erasing the measurement data storage . . . . . . . 56
4.6 Transmitting data (USB interface) . . . . . . . . . . . . . . . . . . 57
4.6.1 Options for data transmission . . . . . . . . . . . . . . . 57
4.6.2 Connecting a PC . . . . . . . . . . . . . . . . . . . . . . . . 58
4.7 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.7.1 Resetting the measurement settings . . . . . . . . . 59
4.7.2 Resetting the system settings. . . . . . . . . . . . . . . 60
5 Maintenance, cleaning, disposal . . . . . . . . . . . . . . . . . 61
5.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.1.1 Replacing the batteries. . . . . . . . . . . . . . . . . . . . 61
5.2 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.3 Packing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6 What to do if... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.1 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.2 Measuring ranges, resolution, accuracy . . . . . . . . . . . . . 68
8 Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Appendix: Firmware update. . . . . . . . . . . . . . . . . . . . . 75

pH 3310 Overview
5
ba75802e02 12/2008
1Overview
The compact pH 3310 precision pH meter enables you to perform pH
measurements rapidly and reliably. The pH 3310 provides the
maximum degree of operating comfort, reliability and measuring
certainty for all applications.
The proven calibration procedures and automatic stability control
function (AR) support your work with the pH meter.
The USB interface can be used for data transmission to a PC and for
software updates of the meter.
1Keypad
2Display
3Socket field
HOLD AR
25.0
6.093
pH
°C
USB output
Menu15.11.2008
08:37
1
2
3

Overview pH 3310
6ba75802e02 12/2008
1.1 Keypad
In this operating manual, keys are indicated by brackets <..> .
The key symbol (e.g. <ENTER>) generally indicates a short keystroke
(under 2 sec) in this operating manual. A long keystroke (approx.
2 sec) is indicated by the underscore behind the key symbol (e.g.
<ENTER_>).
ENTER
M
pH 3310
F1 F2
AR
CAL
STO RCL
<F1>:
<F1_>:
<F2>:
<F2_>:
Softkeys providing situation dependent functions, e.g.:
<F1>/[Menu]: Opens the menu for measurement settings
<F1_>/[Menu]: Opens the menu for system settings
<On/Off>: Switches the meter on or off
<M>: Selects the measured parameter
<CAL>:
<CAL_>:
Calls up the calibration procedure
Displays the calibration data
<STO>:
<STO_>:
Stores a measured value manually
Opens the menu for the automatic save function
<RCL>:
<RCL_>:
Displays the manually stored measured values
Displays the automatically stored measured values
<▲>: Increments values, scrolls
<▼>: Decrements values, scrolls
F1
F2
CAL
STO
RCL

pH 3310 Overview
7
ba75802e02 12/2008
1.2 Display
Function display
indicators
<ENTER>:
<ENTER_>:
Opens the menu for measurement settings / confirms
entries
Opens the menu for system settings
<AR> Freezes the measured value (HOLD function)
Switches the AutoRead measurement on or off
ENTER
AR
1Status information
2Measured value (with unit)
3Measured parameter
4Continuous measurement control (CMC function)
5Sensor symbol (calibration evaluation, calibration
interval)
6Measured temperature (with unit)
7Status line
8Softkeys and date + time
HOLD AR
25.0
6.093
pH
°C
4
3
2
5
6
7
8
1
22.09.2008
08:00
Menu Output to USB
AutoCal
e.g. TEC
Calibration with automatic buffer recognition, e.g.
with the buffer set: Technical buffers
ConCal Calibration with any buffers
Error An error occurred during calibration
LoBat Batteries are almost empty
AR Stability control (AutoRead) is active
HOLD Measured value is frozen (<AR> key)

Overview pH 3310
8ba75802e02 12/2008
1.3 Socket field
Caution
Only connect sensors to the meter that cannot return any voltages
or currents that are not allowed (> SELV and > current circuit with
current limiting).
Almost all customary sensors fulfill these conditions.
Connectors:
1pH electrode
2Reference electrode
3Temperature sensor
4USB B (device) interface
5Service interface
51234

pH 3310 Safety
9
ba75802e02 12/2008
2 Safety
This operating manual contains basic instructions that you must follow
during the commissioning, operation and maintenance of the meter.
Consequently, all responsible personnel must read this operating
manual before working with the meter.
The operating manual must always be available within the
vicinity of the meter.
Target group The meter was developed for work in the field and in the laboratory.
Thus, we assume that, as a result of their professional training and
experience, the operators will know the necessary safety precautions
to take when handling chemicals.
Safety instructions Safety instructions in this operating manual are indicated by the
warning symbol (triangle) in the left column. The signal word (e.g.
"Caution") indicates the level of danger:
Warning
indicates instructions that must be followed precisely in order to
avoid possibly great dangers to personnel.
Caution
indicates instructions that must be followed precisely in order to
avoid the possibility of slight injuries or damage to the meter or
the environment.
Further notes
Note
indicates notes that draw your attention to special features.
Note
indicates cross-references to other documents, e.g. operating
manuals.

Safety pH 3310
10 ba75802e02 12/2008
2.1 Authorized use
This meter is authorized exclusively for pH and ORP measurements in
a laboratory or field environment.
The technical specifications as given in chapter 7 TECHNICAL DATA must
be observed. Only the operation and running of the meter according to
the instructions given in this operating manual is authorized.
Any other use is considered unauthorized.
2.2 General safety instructions
This meter is constructed and tested in compliance with the IEC 1010
safety regulations for electronic measuring instruments.
It left the factory in a safe and secure technical condition.
Function and
operational safety
The smooth functioning and operational safety of the meter can only be
guaranteed if the generally applicable safety measures and the specific
safety instructions in this operating manual are followed during
operation.
The smooth functioning and operational safety of the meter can only be
guaranteed under the environmental conditions that are specified in
chapter 7 TECHNICAL DATA.
If the meter was transported from a cold environment to a warm
environment, the formation of condensate can lead to the faulty
functioning of the meter. In this event, wait until the temperature of the
meter reaches room temperature before putting the meter back into
operation.
Caution
The meter is only allowed to be opened by authorized personnel.

pH 3310 Safety
11
ba75802e02 12/2008
Safe operation If safe operation is no longer possible, the meter must be taken out of
service and secured against inadvertent operation!
Safe operation is no longer possible if the meter:
zhas been damaged in transport
zhas been stored under adverse conditions for a lengthy period of
time
zis visibly damaged
zno longer operates as described in this manual.
If you are in any doubt, please contact the supplier of the meter.
Obligations of the
purchaser
The purchaser of this meter must ensure that the following laws and
guidelines are observed when using dangerous substances:
zEEC directives for protective labor legislation
zNational protective labor legislation
zSafety regulations
zSafety datasheets of the chemical manufacturers.
Caution
In addition to the safety instructions mentioned here, also follow
the safety instructions of the sensors used.
The operating manuals of the sensors are available on the
supplied CD and on the Internet under www.WTW.com.

Safety pH 3310
12 ba75802e02 12/2008

pH 3310 Commissioning
13
ba75802e02 12/2008
3 Commissioning
3.1 Scope of delivery
zpH meter, pH 3310
z4 batteries 1.5 V Mignon type AA
zShort instructions
zCD-ROM with detailed operating manual
3.2 Initial commissioning
Perform the following activities:
zInsert the supplied batteries
zSwitch on the meter
zSet the date and time
3.2.1 Inserting the batteries
1Unscrew the two screws (1) on the underside of the meter.
2 Open the battery compartment (2) on the underside of the
meter.
3Place four batteries (type Mignon AA) in the battery
compartment.
2
1

Commissioning pH 3310
14 ba75802e02 12/2008
Note
Alternatively, you can also use Ni-MH rechargeable batteries (type
Mignon AA). In order to charge the batteries, an external charging
device is required.
Caution
Make sure that the poles of the batteries are positioned correctly.
The ±signs on the batteries must correspond to the ± signs in the
battery compartment.
3.2.2 Switching on the meter
Note
The meter has an energy saving feature to avoid unnecessary battery
depletion.
The energy saving feature switches off the meter if no key is pressed
during the adjusted interval. (How to set the switch-off interval, see
section 4.3.1).
3.2.3 Setting the date and time
4Close the battery compartment (2) and tighten the screws (1).
1Press the <On/Off> key.
The meter performs a self-test.
The display shows the manufacturer's logo while the self-test
is being performed.
Subsequently, the meter switches to the measuring mode
(measured value display).
2See section 4.2.4

pH 3310 Operation
15
ba75802e02 12/2008
4 Operation
4.1 Switching on the meter
Switching on Press the <On/Off> key.
The meter performs a self-test.
The display shows the manufacturer's logo while the self-test is being
performed.
The measured value display appears.
Switching off Press the <On/Off> key.
Automatic switch-off The instrument has an automatic switch-off function in order to save the
batteries (see section 4.3.1). The automatic switch-off switches off the
meter if no key is pressed for an adjustable period.
The automatic switch-off is not active
zif the communication cable is connected
zif the Autom. saving function is active, or with automatic data
transmission
Display illumination The meter automatically switches off the display illumination if no key
has been pressed for 15 seconds. The illumination is switched on with
the next keystroke again.
You can also generally switch the display illumination on or off (see
section 4.3.1).
pH
6.949
25.0 °C
22.09.2008
08:00
Menu USB output

Operation pH 3310
16 ba75802e02 12/2008
4.2 General operating principles
This section contains basic information on the operation of the
pH 3310.
Operating elements,
display
An overview of the operating elements and the display is given in
section 1.1 and section 1.2.
Operating modes,
navigation
An overview of the operating modes and navigation of the pH 3310 is
given in section 4.2.1 and section 4.2.2.
4.2.1 Operating modes
The meter has the following operating modes:
zMeasurement
The measurement data of the connected sensor is shown in the
measured value display
zCalibration
The course of a calibration with calibration information, functions
and settings is displayed
zStorage in memory
The meter stores measuring data automatically or manually
zTransmitting data
The meter transmits measuring data and calibration records to the
USB interface automatically or manually.
zSetting
The system menu or a sensor menu with submenus, settings and
functions is displayed

pH 3310 Operation
17
ba75802e02 12/2008
4.2.2 Navigation
Measured value display In the measured value display, you can
zopen the respective measuring menu with <F1> (short keystroke).
zopen the Storage & config menu with the sensor-independent
settings by pressing <F1_>(long keystroke, approx. 2 s on <F1>).
zchange the display in the selected measuring window
(e. g. pH <−> mV) by pressing <M>.
Menus and dialogs The menus for settings and dialogs in procedures contain further
submenus. The selection is made with the <▲><▼>keys. The current
selection is displayed with a frame.
zSubmenus
The name of the submenu is displayed at the upper edge of the
frame. Submenus are opened by confirming with <ENTER>.
Example:
zSettings
Settings are indicated by a colon. The current setting is displayed on
the right-hand side. The setting mode is opened with <ENTER>.
Subsequently, the setting can be changed with <▲><▼>and
<ENTER>. Example:
General
Measurement
Interface
Clock
Service information
Reset
System
22.09.2008
08:00
Back
Language: Deutsch
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
22.09.2008
08:00
Back

Operation pH 3310
18 ba75802e02 12/2008
zFunctions
Functions are designated by the name of the function. They are
immediately carried out by confirming with <ENTER>.
Example: Display the Calibration record function.
Messages Information is marked by the
i symbol. It cannot be selected.
Example:
Note
The principles of navigation are explained in the two following sections
by reference of examples:
zSetting the language (section 4.2.3)
zSetting the date and time (see section 4.2.4).
Calibration record
Buffer:AutoCalTEC
One point calibration:Yes
Calibration interval:7 d
Unit for slope:mV/pH
i 2.00 4.01 7.00 10.01
pH
22.09.2008
08:00
Back
Calibration record
Buffer:AutoCalTEC
One point calibration:Yes
Calibration interval:7 d
Unit for slope:mV/pH
i 2.00 4.01 7.00 10.01
pH
22.09.2008
08:00
Back

pH 3310 Operation
19
ba75802e02 12/2008
4.2.3 Example 1 on navigation: Setting the language
1Press the <On/Off> key.
The measured value display appears.
The instrument is in the measuring mode.
2Using <F1_>/[Menu] open the Storage & config menu.
The instrument is in the setting mode.
3Select the System submenu with <▲><▼>.
The current selection is displayed with a frame.
4 Open the System submenu with <ENTER>.
pH
6.949
25.0 °C
22.09.2008
08:00
Menu USB output
System
Data storage
Storage & config
22.09.2008
08:00
Back

Operation pH 3310
20 ba75802e02 12/2008
5Select the General submenu with <▲><▼>.
The current selection is displayed with a frame.
6 Open the General submenu with <ENTER>.
7Open the setting mode for the Language with <ENTER>.
8Select the required language with <▲><▼>.
General
Measurement
Interface
Clock
Service information
Reset
System
22.09.2008
08:00
Back
Language: Deutsch
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
22.09.2008
08:00
Back
Language: Deutsch
Beep:Off
Illumination:On
Contrast:50 %
Switchoff time:1 h
General
22.09.2008
08:00
Back
