Wyrestorm ESSENTIALS EXP-MX-0404-KIT User manual

Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-MX-0404-KIT Quickstart Guide | 200330
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the
installation process.
Basic Wiring Diagram
IMPORTANT! Installation Requirements
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
• While this product supports CEC for the HDMI outputs, WyreStorm cannot
guarantee compatibility with all forms of CEC communication.
In the Box
1x EXP-MX-0404-KIT Matrix
3x EXP-MX-KIT-RX Receivers
1x AC Power Cord with EU pins
1x AC Power Cord with US pins
1x AC Power Cord with UK pins
1x AC Power Cord with AU pins
1x IR Remote (CR2025 Battery not Included)
4x IR Emitters
3x IR Receivers
2x Matrix Mounting Brackets with screws
6x Receiver Mounting Brackets with screws (2 per RX)
1x Quickstart Guide (this document)
EXP-MX-KIT-RX (Receiver)
HDMI to display
IR TXIR RX
HDMI from source
HDMI from source IR TX
IR TX
HDMI to display device
LAN Cat6a/7
AC Mains
Power
Cat6a/7
Cat6a/7
Blu-ray Player
Satellite Box
EXP-MX-KIT-RX (Receiver)
Audio Video Receiver
Projector
Matrix Control Only
IR
Control System
CAB-IR-LINK (Sold Separately)
Wireless Router
EXP-MX-0404-KIT
(Matrix)
Receivers
powered by
KEY
HDMI
HDBaseT / Ethernet
Control
Power
Digital Audio
HDMI to display
IR TXIR RX
4K UHD 4:2:0 60Hz 4x4 HDBaseT™ Matrix Switch
with 3 Receivers & S/PDIF De-Embed
EXP-MX-0404-KIT Quickstart Guide

Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-MX-0404-KIT Quickstart Guide | 200330
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
2 of 4
Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
IMPORTANT! Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and
electrical or environmental interference will have an adverse effect on
signal transmission which may limit performance. Steps should be taken
to minimize or remove these factors completely during installation for best
results.
• WyreStorm recommends the use of shielded category cable to minimize
signal noise and interference.
• WyreStorm recommends using pre-terminated HDMI cables due to the
complexity of these connector types. Using pre-terminated cables will
ensure that these connections are accurate and will not interfere with the
performance of the product.
.
IR TX/RX Guidelines
• Using WyreStorm infrared emitters and receivers is the best way to ensure
that most IR coding formats are transmitted and received by the system.
Other 3rd party emitters and receivers can be used; however, these devices
must operate in the same manner as the WyreStorm devices.
• Due to differences in IR across 3rd party control systems their IR ports
should never be connected directly to a NetworkHD system as an
incompatibility may exist. WyreStorm offers a cable that compensates for
voltage differences as well adjusts for differences in the pins used within the
port. Refer to the CAB-IR-LINK product page for more information.
IR TX Port Pinout
Connection for IR TX (transmit) uses a 3.5mm (1/8in) mono plug.
Tip: Anode
Sleeve: Cathode (IR Signal)
IR RX Port Pinout
Connection for IR RX (receive) uses a 3.5mm (1/8in) stereo jack that outputs
+5V DC to power the included IR receiver.
Tip:
Ring: IR Signal
+5V DC
Sleeve: Ground (GND)
Warranty Information
WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of ve (2) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our limited
product warranty.
Audio Wiring
This matrix contains audio connections for S/PDIF digital.
Tip: Signal (+)
Shield: Ground/Return (-)
RS-232 Wiring
Most control systems and computers are DTE where pin 2 is RX, this can vary from device to device. Refer to the documentation for the connected device for pin
functionally to ensure that the correct connections can be made.
Matrix RS-232 Port
3rd Party Device
Pin 2 TX (Transmit) ---> To ---> RX (Receive)
Pin 3 RX (Receive) ---> To ---> TX (Transmit)
Pin 5 G (Ground) ---> To ---> G (Ground)
WyreStorm Connector
Note: Pins not shown in table have no connection.
Note: Pins not shown in table have no connection.
Receiver (RX) RS-232 Port
3rd Party Device
Pin 1 TX (Transmit) ---> To ---> RX (Receive)
Pin 2 RX (Receive) ---> To ---> TX (Transmit)
Pin 3 G (Ground) ---> To ---> G (Ground)
WyreStorm Connector

Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-MX-0404-KIT Quickstart Guide | 200330
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
3 of 4
Setup and Conguration
EDID Settings
EDIDs can be congured to resolve issues with video output on displays that may not accept the maximum resolution available from the source.
• When set to Smart EDID (default) the matrix will scan all selected displays for the lowest resolution to dynamically adjust the source content to allow output
on 2K and 4K displays sharing the same source.
• When EDID Copy or a direct EDID is being used, SmartEDID is turned Off.
• Ensure that a display is connected and powered On to the selected output before copying EDIDs or the copy will fail. When this occurs, EDID will be set to
4K@30Hz 2ch.
• Power to the matrix must be cycled (Off/On) after changing dip switches in order for the setting to take effect.
EDID Switch Location
Copying EDIDs
1. Set the EDID dipswitch to the Front Panel, Web UI or API EDID Control (all
switches up).
2. Reboot the matrix.
3. Using the front navigation buttons, select the input port for the output.
Example: Input 2 for Output 2
4. Once the output port indicator blinks, press and hold Enter for 5 seconds. OK
indicates that the copy was successful, FAIL indicates that the copy failed.
5. Reboot the matrix
Accessing the Web UI
This matrix is set to a default static IP Address (192.168.11.143). In order to communicate with it initially the PC must be set to a 192.168.11.xxx address with a
subnet of 255.255.0.0. This can be changed back once a static IP is set within a different range.
1. Connect the matrix to the same network as a PC.
2. Open a web browser and enter the IP Address of the matrix.
Default: 192.168.11.143 | Password: admin
IP Address Notes
• When to set to DHCP the IP address of the unit can be displayed by pressing and holding the front panel Enter and Down buttons for 3 seconds. The IP
address will be displayed on the front panel.
• The installer password and general password are the same by default. WyreStorm recommends changing the password for installer login to avoid any
unwanted changes being made to the matrix conguration.
SmartEDID/Front Panel/Web UI 4K UHD 1080p
SmartEDID - Dynamic EDID Based on
Display - 2ch only (default)
4K @30Hz (8bit only) 2ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
1080P @60Hz 2.0ch audio
(SmartEDID OFF, HDCP 1.4 Support)
Front Panel, Web UI, or API Control 4K @30Hz 2ch with HDR (SmartEDID
OFF, HDCP 2.2 Support)
4K@30Hz 5.1ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
4K@30Hz 7.1ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
Reserved
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to the transmitter and receiving device
• Verify that all HDMI and HDBaseT connections are not loose and are
functioning properly
• Verify that the HDBaseT cable is properly terminated following EIA568B
standard
• Verify that the output resolution of the source and display is supported by
this matrix and recevier.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K rated.
No or Intermittent 3rd party Device Control
• Verify that the IR and RS-232 cables are properly terminated following the
Wiring and Connections section.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.

Specications
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-MX-0404-KIT Quickstart Guide | 200330
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
4 of 4
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Matrix Receivers
Audio and Video
Inputs 4x HDMI In: 19-pin type A 1x HDBT In: 8-pin RJ-45 Female
Outputs
4x S/PDIF Out: RCA Female
3x HDBT Out: 8-pin RJ-45 Female
1x HDMI Out: 19-pin type A
1x HDMI Out: 19-pin type A
Output Video Encoding HDBaseT Class B
Encoding Data Rate 9.2Gbps
End to End Latency (Max) 10μs (micro seconds)
Audio Formats S/PDIF: 2ch LPCM | Dolby Digital/DTS up to 5.1ch
HDMI: 2ch LPCM | Multichannel up to Dolby Atmos and DTS-X
Video Resolutions (Max)
Video Resolution HDMI Cat6 Cat6a/7
1920x1080p @60Hz 12bit 15m/49ft 60m/197ft 70m/230ft
1920x1080p @60Hz 16bit 7m/23ft 35m/115ft 40m/131ft
3840x2160p @24Hz 10bit 4:2:0 HDR 3m/10ft 35m/115ft 40m/131ft
3840x2160p @30Hz 8bit 4:4:4 7m/23ft Input
15m/49ft Output 35m/115ft 40m/131ft
3840x2160p @60Hz 8bit 4:2:0 7m/23ft Input
15m/49ft Output 35m/115ft 40m/131ft
Note: WyreStorm recommends the use of shielded category cable to minimize signal noise and interference
Supported Standards DCI (4096x2160) | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock HDBaseT: 340MHz
Communication and Control
HDMI HDMI 2.0 | HDCP 2.2 | EDID | CEC | DVI/D supported with adapter (not included)
HDBaseT HDMI 2.0 | HDCP 2.2 | EDID | CEC | 1-way PoH | Bidirectional IR
Consumer Electronics Control
(CEC) CEC power triggering for connected screens – Requires CEC compatibility
IR
3x IR RX: 3.5mm (1/8in) TRS Stereo
4x IR TX: 3.5mm (1/8in) TS Mono
Bidirectional over HDBaseT
1x IR TX: 3.5mm (1/8in) TS Mono
1x IR RX: 3.5mm (1/8in) TRS Stereo
Bidirectional over HDBaseT
RS-232 1x RS-232: 9-pin DB9 Female (matrix control only) 1x RS-232: 3-pin Terminal Block - 3.5mm (update only)
Ethernet 1x LAN: 8-pin RJ-45 Female NA
Power
Power Supply 100~240V AC 50/60Hz 18V DC (Optional)
PoH 1-way Matrix to Receiver
Max Power Consumption 48.2W 4.5W with External PSU
5W via PoH
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU 164 BTU/hr 15.4 BTU/hr with External PSU
17 BTU/hr via PoH
Dimensions and Weight
Rack Units/Wall Box 1U <1U
Height 43.5mm/1.72in 15.2mm/0.6in
Width 440mm/17.33in 136.4mm/5.38in
Depth 300mm/11.82in 74.2mm/2.93in
Weight 4.06kg/8.93lbs 0.24kg/0.53lbs
Regulatory
Safety and Emission CE | FCC | RoHS | RCM | EAC
