4
FEATURES AND SAFETY PRECAUTIONS
• Quick and easy installation – set up in seconds straight out of
the box.
• Simplied ports - Input: HDMI – Output: Simultaneous HDMI
and integrated RJ45 connectors for a single Cat5e/6/7 UTP
cable to each display point for ease of installation*
* The inclusion of duplicate HDMI ports essentially
doubles the number of outputs (though slaved to the
output channel on the matrix), or allowing connection
to Coax, Fibre or full HDBT extender sets for increased
flexibility and length of distribution.
• Conforms to IEEE-568B standards.
• Each HDMI port also supports DVI signal.
• Enables up to 4 HDMI video/audio devices to be independently
switched through up to 4 HDMI displays or projectors for
uncompressed digital distribution.
• Each output able to show any connected source simultaneously
regardless of whether the input carries HDCP encryption.
• HDCP compliant with constant feed to prevent screen drop-
outs.
• Rened for Custom Install and Home Theatre Installations.
• Reads and copies EDID from connected devices with additional
EDID configuration through customisable DIP switch settings if
necessary.
• The same robust transmission technology as full HDBT that is
far more resistant to electrostatic interference than conventional
TMDS distribution.
• HDMI v1.4 with full 3D compatibility with Frame Packing (Blu-
Ray) and interlaced Stereoscopic (satellite/cable broadcasts).
• Central RS232 control – fully compatible with all market leading
control systems with full integration protocols available for AMX,
Control 4, Crestron, Red Eye, Nevo, RTI, Control FX, Savant, Bit
Wise.
• LAN control – with Control 4 LAN protocols and TELNET
control for all control systems.
• Wide-band, two way discrete IR control between source and
display and vice versa (30 KHz to 56 KHz frequency)
• 2K resolution (compared to 4k resolution with full HDBaseT).
• 36bit Deep Colour (compared to 48bit with Full HDBaseT, and
24bit PRO).
• 6.75 Gbps bandwidth range/signalling rate (compared to
10.2Gbps with full HDBaseT).
• 70m (131ft) distance range of matrix/extenders – (compared to
100m/328ft HDBaseT or 50m/164ft PRO) can be lengthened
by connecting to multiple 70m extender sets or used with any
other Wyrestorm extenders, such as Coax, full HDBT or Fibre
(distances under perfect transmission conditions*)
• Each Output port can be fed to multiple displays (cascaded).
• Supports all high denition resolutions up to and including
1080p and standard video formats.
2. Features • Choose from 6 switching modes – infrared remote control, front
panel buttons, local IR, IR call-back, RS232 and LAN.
• Simple switching remote control included, which can also be
learned into a universal remote handset to allow the control of
multiple devices from one handset.
• 4 x IR 3.5mm mini-jack ports for each output to link IR from
control system to control display.
• Additional infrared extension port for longer IR connections
• Pack comes complete with 1 x MX0404-PP 4x4 matrix unit
with 19”, IR receivers, emitters and a remote control handset.
* Perfect transmissions conditions denote cable run
is within specified distance range of product, no
electrical interference, the use of straight cable runs
with no bends or kinks and no patch panels or wall
outlets used. Please be advised that the presence
of any of these factors in your installation may
compromise bandwidth and signal strength. For longer
transmission distances, LAN control and Ethernet
pass-through, please see our full HDBaseT or HDBT
Lite range of matrices, transmitters, receivers and
extender sets.
NOTE: Wyrestorm reserves the right to make changes to
hardware, packaging and any accompanying documentation
without prior written notice.
3. Safety Precautions
1. Do not expose this apparatus to rain, moisture, sprays,
drips or splashes and ensure that no objects containing
liquids are placed on the apparatus, including cups,
glasses and vases.
2. Do not place this unit in a confined space such as
enclosed shelving, cabinets or bookshelves. Ensure the
unit is adequately ventilated.
3. To prevent the risk of electric shock or fire hazard due to
overheating, do not cover the unit or obstruct ventilation
openings with material, newspaper, cardboard or
anything that may restrict airflow into the unit.
4. Do not install near external heat sources such as
radiators, heat registers, boilers or any device that
produces heat such as amplifiers or computers and do
not place near sources of naked flame.
5. Unplug apparatus from power supply during lightening
storms or when unused for long periods of time.
6. Protect the power cable from being walked on, pinched
or restricted in any way, especially at plug connections.
7. Only use attachments/accessories specified by the
manufacturer.
8. Units contain non-servicable parts - Refer all servicing to
qualified service personnel.
WARNING
To reduce the risk of fire, electric shock
or product damage:
