Wyrestorm MX-0404-KIT User manual

Copyright © 2021 WyreStorm Technologies | wyrestorm.com
Matrix Kits Full Range Quickstart Guide | 210504
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product pages to download the latest rmware, document version, additional documentation, and conguration tools.
• Read through the Wiring and Connections section for important wiring guidelines before creating or choosing premade cables.
• While these products support CEC for the HDMI outputs, WyreStorm cannot guarantee compatibility with all forms of CEC communication.
In the Box (MX-0x0x-KIT)
1x MX-0x0x-KIT Matrix
3/6x MX-KIT-RX Receivers
1x AC Power Cord (US/UK/EU/AU)
1x IR Remote (Battery not Included)
4/8x IR Emitters
3/6x IR Receivers
2x Matrix Mounting Brackets
6/12x Receiver Mounting Brackets (2 per RX)
1x Quickstart Guide (this document)
In the Box (MX-0404-HDBT-H2A-KIT)
1x MX-0404-HDBT-H2A-KIT HDBaseT Matrix Switcher
4x Receivers
1x AC Power Cord (US/UK/EU)
1x IR Remote (Battery not Included)
4x IR Emitters
4x IR Receivers
1x IR Extension Cable
2x Matrix Mounting Brackets
8x Receiver Mounting Brackets (2 per RX)
1x Quickstart Guide (this document)
4K UHD HDBaseT™ Matrix Switchers with
Included Receivers & Audio Breakout
MX-0404-KIT | MX-0808-KIT | MX-0404-HDBT-H2A-KIT Quickstart Guide
Basic Wiring Diagram
KEY
HDMI
Control
Power
Ethernet
Digital Audio
Display Devices
AVR
Projector
4K Satellite Box
Wireless Router
Control System
4K Blu-ray Player
IMPORTANT! The MX-0404-KIT and MX-0808-KIT had the previous model number of EXP-MX-0404-KIT and EXP-MX-0808-KIT.
If you would like to access previous documentation for these models, visit wyrestorm.com

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
IMPORTANT! Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and
electrical or environmental interference will have an adverse effect on
signal transmission which may limit performance. Steps should be taken
to minimize or remove these factors completely during installation for best
results.
• WyreStorm recommends the use of shielded category cable to minimize
signal noise and interference.
• WyreStorm recommends using pre-terminated HDMI cables due to the
complexity of these connector types. Using pre-terminated cables will
ensure that these connections are accurate and will not interfere with the
performance of the product.
.
IR TX/RX Guidelines
• Using WyreStorm infrared emitters and receivers is the best way to ensure
that most IR coding formats are transmitted and received by the system.
Other 3rd party emitters and receivers can be used; however, these devices
must operate in the same manner as the WyreStorm devices.
• Due to differences in IR across 3rd party control systems their IR ports
should never be connected directly to a NetworkHD system as an
incompatibility may exist. WyreStorm offers a cable that compensates for
voltage differences as well adjusts for differences in the pins used within the
port. Refer to the CAB-IR-LINK product page for more information.
IR TX Port Pinout
Connection for IR TX (transmit) uses a 3.5mm (1/8in) mono plug.
Tip: Anode
Sleeve: Cathode (IR Signal)
IR RX Port Pinout
Connection for IR RX (receive) uses a 3.5mm (1/8in) stereo jack that outputs
+5V DC to power the included IR receiver.
Tip:
Ring: IR Signal
+5V DC
Sleeve: Ground (GND)
Audio Wiring
This matrix contains audio connections for S/PDIF digital.
Tip: Signal (+)
Shield: Ground/Return (-)
RS-232 Wiring
Most control systems and computers are DTE where pin 2 is RX, this can vary from device to device. Refer to the documentation for the connected device for
pin functionally to ensure that the correct connections can be made.
Matrix RS-232 Port
3rd Party Device
Pin 2 TX (Transmit) ---> To ---> RX (Receive)
Pin 3 RX (Receive) ---> To ---> TX (Transmit)
Pin 5 G (Ground) ---> To ---> G (Ground)
WyreStorm Connector
Note: Pins not shown in table have no connection.
Note: Pins not shown in table have no connection.
Receiver (RX) RS-232 Port
3rd Party Device
Pin 1 TX (Transmit) ---> To ---> RX (Receive)
Pin 2 RX (Receive) ---> To ---> TX (Transmit)
Pin 3 G (Ground) ---> To ---> G (Ground)
WyreStorm Connector
Copyright © 2021 WyreStorm Technologies | wyrestorm.com
Matrix Kits Full Range Quickstart Guide | 210504
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
2 of 4
Warranty Information
WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of ve (5) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our limited
product warranty.

Accessing the Web UI
This matrix is set to a default static IP Address (192.168.11.143). In order to communicate with it initially the PC must be set to a 192.168.11.xxx address with a
subnet of 255.255.0.0. This can be changed back once a static IP is set within a different range.
1. Connect the matrix to the same network as a PC.
2. Open a web browser and enter the IP Address of the matrix.
Default: 192.168.11.143 | Password: admin
IP Address Notes
• When to set to DHCP the IP address of the unit can be displayed by pressing and holding the front panel Enter and Down buttons for 3 seconds. The IP
address will be displayed on the front panel.
• The installer password and general password are the same by default. WyreStorm recommends changing the password for installer login to avoid any
unwanted changes being made to the matrix conguration.
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to the transmitter and receiving device
• Verify that all HDMI and HDBaseT connections are not loose and are
functioning properly
• Verify that the HDBaseT cable is properly terminated following EIA568B
standard
• Verify that the output resolution of the source and display is supported by
this matrix and recevier.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K rated.
No or Intermittent 3rd party Device Control
• Verify that the IR and RS-232 cables are properly terminated following the
Wiring and Connections section.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
Copyright © 2021 WyreStorm Technologies | wyrestorm.com
Matrix Kits Full Range Quickstart Guide | 210504
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
3 of 4
EDID Settings (MX-0404-KIT/MX-0404-HDBT-H2A-KIT)
EDIDs can be congured to resolve issues with video output on displays that may not accept the maximum resolution available from the source.
• When set to Smart EDID (default) the matrix will scan all selected displays for the lowest resolution to dynamically adjust the source content to
allow output on 2K and 4K displays sharing the same source.
• When EDID Copy or a direct EDID is being used, SmartEDID is turned Off.
• Ensure that a display is connected and powered On to the selected output before copying EDIDs or the copy will fail. When this occurs, EDID will
be set to 4K@30Hz 2ch.
• Power to the matrix must be cycled (Off/On) after changing dip switches in order for the setting to take effect.
EDID Switch Location
Copying EDIDs
1. Set the EDID dipswitch to the Front Panel, Web UI or API EDID Control
(all switches up).
2. Reboot the matrix.
3. Using the front navigation buttons, select the input port for the output.
Example: Input 2 for Output 2
4. Once the output port indicator blinks, press and hold Enter for 5
seconds. OK indicates that the copy was successful, FAIL indicates
that the copy failed.
5. Reboot the matrix
SmartEDID/Front Panel/Web UI 4K UHD 1080p
SmartEDID - Dynamic EDID Based
on Display - 2ch only (default)
4K @30Hz (8bit only) 2ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
1080P @60Hz 2.0ch audio
(SmartEDID OFF, HDCP 1.4 Support)
Front Panel, Web UI, or API Control 4K @30Hz 2ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
4K@30Hz 5.1ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
4K@30Hz 7.1ch with HDR
(SmartEDID OFF, HDCP 2.2 Support)
4K @60Hz 2ch
(MX-0404-HDBT-H2A-KIT)

Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Copyright © 2021 WyreStorm Technologies | wyrestorm.com
Matrix Kits Full Range Quickstart Guide | 210504
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
4 of 4
Specications
MX-0404-KIT MX-0808-KIT
Audio and Video
Inputs 4x HDMI In: 19-pin type A 4x HDMI In: 19-pin type A 8x HDMI In: 19-pin type A
Outputs
1x HDMI In 19-pin type A
4x HDBaseT 8-pin RJ-45 female
4x S/PDIF Out: RCA Female
4x Analog Audio Out: RCA Female
4x S/PDIF Out: RCA Female
3x HDBT Out: 8-pin RJ-45 Female
1x HDMI Out: 19-pin type A
8x Optical Audio Out: Toslink Female
6x HDBT Out: 8-pin RJ-45 Female
2x Switched HDMI Out: 19-pin type A
Output Video Encoding HDBaseT Class B
Encoding Data Rate 9.2Gbps
End to End Latency (Max) 10μs (micro seconds)
Audio Formats
HDMI/HDBaseT: 2ch LPCM | Multichannel up to Dolby Atmos and DTS-X
S/PDIF: 2ch LPCM | Dolby Digital/DTS up to 5.1ch
Analog: 2ch Analog
Supported Standards DCI (4096x2160) | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock HDMI: 600MHz
HDBaseT: 297MHz HDBaseT: 340MHz HDBaseT: 340MHz
Communication and Control
HDMI HDMI 2.0 | HDCP 2.2 | EDID | CEC | DVI/D supported with adapter (not included)
HDBaseT HDMI 2.0 | HDCP 2.2 | EDID | CEC | 1-way PoH | Bidirectional IR
Consumer Electronics Control
(CEC) CEC power triggering for connected screens – Requires CEC compatibility
IR
1x IR Ext 3.5mm (1/8in) TRS Stereo
4x IR TX 3.5mm (1/8in) TS Mono
4x IR RX 3.5mm (1/8in) Stereo
Bidirectional over HDBaseT
3x IR RX: 3.5mm (1/8in) TRS Stereo
4x IR TX: 3.5mm (1/8in) TS Mono
Bidirectional over HDBaseT
6x IR RX: 3.5mm (1/8in) TRS Stereo
8x IR TX: 3.5mm (1/8in) TS Mono
Bidirectional over HDBaseT
RS-232 1x RS-232: 9-pin DB9 Female
(matrix control only)
1x RS-232: 9-pin DB9 Female
(matrix control only)
1x RS-232: 9-pin DB9 Female
(matrix control only)
Ethernet 1x LAN: 8-pin RJ-45 Female 1x LAN: 8-pin RJ-45 Female 1x LAN: 8-pin RJ-45 Female
Power
Power Supply 100~240V AC 50/60Hz 100~240V AC 50/60Hz 100~240V AC 50/60Hz
PoH 1-way Matrix to Receiver
Max Power Consumption 54W 48.2W 109.5W
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU 184.25 BTU/hr 164 BTU/hr 374 BTU/hr
Dimensions and Weight
Rack Units/Wall Box 1U 1U 1U
Height 43.5mm/1.72in 43.5mm/1.72in 43.5mm/1.72in
Width 440mm/17.33in 440mm/17.33in 440mm/17.33in
Depth 300mm/11.82in 300mm/11.82in 300mm/11.82in
Weight 4.06kg/8.93lbs 4.06kg/8.93lbs 4.06kg/8.93lbs
Regulatory
Safety and Emission CE | FCC | RoHS | RCM | EAC
Video Resolutions (Max)
Video Resolution HDMI Cat6 Cat6a/7
1920x1080p @60Hz 12bit 15m/49ft 60m/197ft 70m/230ft
1920x1080p @60Hz 16bit 7m/23ft 35m/115ft 40m/131ft
3840x2160p @24Hz 10bit 4:2:0 HDR 15m/49ft 60m/197ft 70m/230ft
3840x2160p @30Hz 8bit 4:4:4 7m/23ft 35m/115ft 40m/131ft
3840x2160p @60Hz 8bit 4:2:0 7m/23ft 35m/115ft 40m/131ft
Note: WyreStorm recommends the use of shielded category cable to minimize signal noise and interference
