Wyrestorm MX-0606-HDBT-H2C User manual

6x6/8x8 HDBaseT 4K Matrix
with ARC and HDCP 2.2 support (70m/230ft)
MX-0606-HDBT-H2C | MX-0808-HDBT-H2C Quickstart Guide
Copyright © 2018 WyreStorm Technologies | wyrestorm.com
MX-xxxx-HDBT-H2C Quickstart Guide | 180413
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation
process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Install the latest rmware to ensure that all features described in this
document are available during and after installation.
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
Recommended Products
To take full advantage of the features of this matrix, WyreStorm recommends
the following products be used within the system.
• RX-70-4K-ARC HDBaseT Receiver – Use this receiver when support for
ARC functions of outputs 5-6 (6x6) and 6-8 (8x8) is required.
• RX-70-4K HDBaseT Receiver – Use this receiver for outputs 1-4 (6x6) and
1-5 (8x8) or when ARC is not required.
• CAB-IR-LINK – Use this cable when using an IR control system for matrix
control of HDBaseT pass-through.
In The Box
1x MX-0606-HDBT-H2C or MX-0808-HDBT-H2C Matrix Switcher
1x IR Remote Handset
1x IR Receiver (38Khz)
6/8x Wide-band IR Receivers (30-50KHz)
6/8x IR Emitters
1x USB to DB9 RS-232 Cable
1x 100~240V AC 50/60Hz Power Cord with US Plug
1x 100~240V AC 50/60Hz Power Cord with UK Plug
1x 100~240V AC 50/60Hz Power Cord with EU Plug
2x Mounting Brackets
1x Quickstart Guide (this document)
Additional Information
This Quickstart Guide provides the basic steps for the common uses of this
product. Detailed installation and conguration information may be found in
the download tab located on the product page.
• WebUI Reference Guide – Setup for advanced Matrix features such as IP
and testing of connections
• H2C Matrix Operation User Guide – Single page document showing the
operation via front panel and included IR remote.
• Drivers and API – Precongured drivers for popular control systems and
API document.
Basic Wiring Diagram
Key
HDMI/Digital Video HDBaseT/Ethernet Digital Audio IR RS-232
MX-0808-HDBT-H2C
RX-70-4K-ARC
RX-70-POH
Router
Multi-channel Audio f
70m/230ft
rom Remote Zone
AV Receiver
70m/230ft
Stereo Audio Breakout of HDBT
Multiroom Amplifier

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in this
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
HDMI/HDBaseT Wiring
IMPORTANT! Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and
electrical or environmental interference will have an adverse effect on HDMI
and Ethernet transmission limiting performance. Steps should be taken to
minimize or remove these factors completely during installation for best
results.
• WyreStorm recommends using high quality HDMI cables such as
WyreStorm Express to ensure the highest content performance available.
• The type of category cable and length used can restrict the available video
resolution. While Cat5e can be used, WyreStorm recommends using Cat6
or higher to ensure the highest content performance available. See Video
Resolutions in the Specications table before determining cable type and
length.
Pin 1
Pin 8
Wire colors shown follow EIA/TIA-568B standard.
Pin 1:
Pin 2:
Pin 3:
Pin 4:
Pin 5:
Pin 6:
Pin 7:
Pin 8:
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
IR TX/RX Wiring
IMPORTANT! IR TX/RX Guidelines
• WyreStorm IR ports function differently than standard IR ports. For this
reason only WyreStorm IR emitters and receivers can be used.
• WyreStorm IR emitter and receiver cables cannot be spliced as cutting
into the cables will short the shield. While an extension cable may be used,
WyreStorm assumes no responsibility for operation using an extension
cable.
• When connecting the IR TX to an IR connecting blocks or control system
with different plugs, a cable must be made following the IR TX Port Pinout
diagram.
• When connecting to an IR control system use the WyreStorm CAB-IR-LINK
cable. This cable compensates for differences between the WyreStorm RX
and the control systems TX connection. Visit the WyreStorm CAB-IR-LINK
product page for details.
IR TX Port Pinout
Tip: Anode
Sleeve: Cathode (IR Signal)
IR RX Port Pinout
Tip:
Ring: IR Signal
+5V DC
Sleeve: Ground (GND)
RS-232 Wiring
Most control systems and computers are DTE where pin 2 is RX, this can vary
from device to device. Refer to the documentation for the connected device for
pin functionally to ensure that the correct connections can be made. 5
9 8 7 6
43 2 1
Outside of DB9 chassis port shown.
Unidnetified pins have no function and should
not be connected.
Pin 3: RX (Receive)
Pin 2: TX (Transmit)
Pin 5: GND (Ground)
Copyright © 2018 WyreStorm Technologies | wyrestorm.com
MX-xxxx-HDBT-H2C Quickstart Guide | 180413
UK: [phone] | North America/ROW: 844.280.WYRE (9973)
[email protected]
2 of 4

Copyright © 2018 WyreStorm Technologies | wyrestorm.com
MX-xxxx-HDBT-H2C Quickstart Guide | 180413
UK: [phone] | North America/ROW: 844.280.WYRE (9973)
[email protected]
3 of 4
EDID Settings
An EDID can be congured to resolve issues with video output on displays that may not accept the maximum resolution available from the source.
• When set to SmartEDID (default) the matrix will scan all selected displays for the lowest resolution to dynamically adjust the source content to allow output
on 2K and 4K displays sharing the same source.
• When EDID Copy or a direct EDID is being used, SmartEDID is turned Off.
• Ensure that a display is connected and powered On to the selected output before copying an EDID or the copy will fail. When this occurs, EDID will be set to
4K@30Hz 2ch.
• Power to the matrix must be cycled (Off/On) after changing dip switches in order for the setting to take effect.
Copying and EDID
1. Set the EDID dipswitch to the Front Panel, Web UI or API EDID Control
(all switches up).
2. Reboot the matrix.
3. Using the front navigation buttons, select the input port for the output.
Example: Input 2 for Output 2
4. Once the output port indicator blinks, press and hold Enter for 5 seconds. An OK message of the display indicates that the copy was successful, an FL-2
indicates that the copy failed.
5. Reboot the matrix.
Note: EDID Copy feature is not available when Matrix in Smart EDID mode.
SmartEDID/Front Panel/ Web UI 4K UHD 1080p Standard Video
SmartEDID
Display Lowest
Resolution - 2ch
only (default)
4K @60Hz 2ch
No HDR
1080p @60Hz
7.1ch
1920x1200
2ch
Front Panel,
Web UI or API
EDID Control
4K @30Hz
5.1ch With HDR
1080p @60Hz
5.1ch
1920x1200 No
Audio
4K @30Hz
7.1ch With HDR
1080p @60Hz
2ch
4K @30Hz 2ch
With HDR
4K @30Hz 8bit
2ch No HDR
Accessing the Web UI
While the matrix will connect to a network out the box, it has a default static IP address that may interfere with other WyreStorm devices on the same network.
WyreStorm recommends changing the IP address of the matrix to one other than the default.
1. Connect the matrix and the PC to the same network.
2. Congure the PC to a 192.168.11.xxx IP address with a subnet of
255.255.0.0.
3. Open a web browser and enter the IP Address of the matrix.
Default: 192.168.11.143 | Password: admin
4. Login to the Installer Section by using the Installer Password
Default: admin
5. Navigate to Advanced Setting> Network.
6. Change the IP Address to match the range of the network and subnet
mask or use DHCP.
7. After updating the IP Address, congure the PC back to a 192.168.1.xxx IP
address with a subnet of 255.255.255.0.
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to devices in the system and that they are
powered on.
• Verify that all source and HDBaseT connections are not loose and are
functioning properly.
• Verify that the HDBaseT cable is properly terminated per the HDMI/HDBaseT
Wiring section.
• Verify that the matrix, receiving device, and display supports the output
resolution of the source. Refer to Video Resolutions in the Specications
table for the max distance based on resolution.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D and/or 4K
rated.
No or Intermittent Matrix or 3rd party Device Control
• Verify that IR cable(s) are properly terminated. See IR TX/RX Wiring.
• Verify that the IR emitter is located near the IR receiver on the device.
Troubleshotting Tips
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
• Use a ashlight to locate the IR receiver behind any tinted panels on the
device being controlled.

Copyright © 2018 WyreStorm Technologies | wyrestorm.com
MX-xxxx-HDBT-H2C Quickstart Guide | 180413
UK: [phone] | North America/ROW: 844.280.WYRE (9973)
[email protected]
4 of 4
Warranty Information
WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of ve (5) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our limited
product warranty.
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Specications
Audio and Video
Inputs Up to 8x HDMI In: 19-pin type A
Outputs
All cards: Up to 8x HDBaseT 8-pin RJ-45 female
Plus Up to 8x of the following card dependent connections:
TX-H2-MIR: HDMI 19-pin type A female | TX-H2-ARC: Audio Out Digital coaxial S/PDIF
TX-H2-AUD: Audio Out 3pin Phoenix Connector
Output Video Encoding TX-H2-MIR/ARC/AUD: HDBaseT Class A | TX-H2-CLB: HDBaseT Class B
Encoding Data Rate 9.2Gbps
End to End Latency <1 frame 10μs (micro seconds)
Audio Formats All Cards HDMI/HDBaseT: 2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos | TX-H2-AUD adds 2ch Analog
Output | TX-H2-ARC S/PDIF: 2ch PCM | Multichannel: Up to 5.1 DTS and Dolby Digital
Video Resolutions (Max)
All Cards HDMI
1920x1080p @60Hz 12bit (15m/50ft) | @60Hz 16bit (7m/23ft)
3840x2160p @30Hz 4:4:4 8bit (7m/23ft) | @24Hz 4:2:0 HDR 10bit (3m/9.8ft)
4096x2160p @60Hz 4:2:0 8bit (7m/23ft) | @60Hz 4:4:4 8bit (7m/23ft)
TX-H2-MIR/ARC/AUD TX-H2-CLB
Cat6
1920x1080p @60Hz 12bit (100m/328ft)
1920x1080p @60Hz 16bit (70m/230ft)
3840x2160p @30Hz 4:4:4 8bit (70m/230ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (70m/230ft)
4096x2160p @60Hz 4:2:0 8bit (70m/230ft)
Cat6a/7
1920x1080p @60Hz 12bit (100m/328ft)
3840x2160p @30Hz 4:4:4 8bit (100m/328ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (100m/328ft)
4096x2160p @60Hz 4:2:0 8bit (100m/328ft)
Cat6
1920x1080p @60Hz 12bit (70m/230ft)
1920x1080p @60Hz 16bit (35m/114ft)
3840x2160p @30Hz 4:4:4 8bit (35m/114ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (35m/114ft)
4096x2160p @60Hz 4:2:0 8bit (35m/114ft)
Cat6a/7
1920x1080p @60Hz 12bit (70m/230ft)
1920x1080p @60Hz 16bit (70m/230ft)
3840x2160p @30Hz 4:4:4 8bit (70m/230ft)
3840x2160p @24Hz 4:2:0 HDR 10bit (70m/230ft)
4096x2160p @60Hz 4:2:0 8bit (70m/230ft)
Color Depth 1080p: 16bit | 4K UHD: 8bit | HDR @24p: 10bit BT.2020
Maximum Pixel Clock HDMI: 600mHz | HDBaseT: 297MHz
Communication and Control
HDMI HDMI | HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
HDBaseT HDMI | HDCP 2.2 | 1-way PoH to Receiver | IR RX to Zone | Ethernet to Zone from Chassis (Except CLB)
TX-H2-ARC adds ARC (Audio Return Channel) from Zone
Ethernet 1x 8-pin RJ-45 female 10/100 Mbps auto-negotiating
Web UI | IP Control | Bidirectional over HDBaseT except when using TX-H2-CLB
IR 1x IR Ext - 3.5mm (1/8in) TRS Stereo | Matrix Control
8x IR TX - 3.5mm (1/8in) TS Mono | Up to 8x IR RX - 3.5mm (1/8in) TRS Stereo | Transmits over HDBaseT to receiver
RS-232 1x RS-232: 9-pin DB9 Female | Matrix Control | Firmware Updates
ARC (Audio Return Channel) Up to 8x using TX-H2-ARC only | Returns audio to source location from remote display via HDBaseT
Power
Power Supply Input: 100~240V AC 50/60Hz
PoH 48V 15.4W (each HDBT output)
Max Power Consumption 120W
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU MX-0606-HDBT-H2C: 409.4 BTU/hr | MX-0808-HDBT-H2C: 477.6 BTU/hr
Dimensions and Weight
Rack Units/Wall Box 2U
Height 87.7mm/3.46in
Width 438mm/17.25in
Depth 396mm/15.6in
Weight MX-0606-HDBT-H2C: 8.2kg/18.04lbs | MX-0808-HDBT-H2C: 8.48kg/18.66lbs
Regulatory
Safety and Emission CE | FCC | RoHS
