Wyse C10LE User manual

Yourdesktop:
just got bigger.
Wyse C class
™Small size, big performance.
All you need to know. Here.

Learn more:
Simply click the
Wyse C class feature icons opposite:
Introducing the Wyse C class thin clients
Wyse C30LETM
Windows CE 6 -
Microsoft's
componentized
real-time operating
system for small
footprint devices.
Wyse C50LETM
Flexibility and
security in an easy
to manage platform.
Wyse C00LETM
Zero Client with no
local operating
system. Used with
Wyse WSM
provisioning software
for a C experience
on a thin desktop.
Meet the Wyse C class.
Combining small size and
excellent performance, it
sets a new benchmark in
thin computing.
Six models are available featuring:
Wyse ThinOSTM; Microsoft Windows CE; SUSE Linux Enterprise Thin
Client, Microsoft Windows XP Embedded and Microsoft Windows
Embedded Standard operating systems – and a Zero Client model for
Wyse WSM provisioning:
Start Features TechnicalModels Print
Wyse C90LETM
Windows X
Embedded - runs
thousands of
existing Windows
applications and
drivers.
Wyse C90LEWTM
Take advantage of the
power of Microsoft
Windows Embedded
Standard.
Wyse C10LETM
Featuring the
blisteringly fast
Wyse ThinOS
designed for
high security
environments.

Features Wyse C class thin clients
Compact. Clever. Capable.
Creating highly productive, fully functional and compact virtual desktops has never
been easier. Each Wyse C class features full support for the Wyse TCX™suite of
user enhancements - that includes multiple display support, multimedia & Flash
playback, rich audio and USB peripheral connectivity - and Wyse WSM™zero client
provisioning software delivering a C experience on a thin or ‘zero client’.
Cool performance. Cooler workspaces.
Designing these levels of high processing and graphics performance into such a
compact space hasn’t been at the expense of energy consumption and heat
emissions either. Each Wyse C class draws under 7 watts of power – creating cooler
working environments – in every respect.
Learn more: Simply click the Wyse C class feature icons below:
Start Features TechnicalModels Print
Take a tour of the
Wyse C class range features here
Visit: wyse.com
Performance Wyse C class
Connectivity
Mounting
Options Green
Provisioning
Software
Management
Software
Virtualization
Software
Microsoft Windows
XP Embedded
Microsoft Windows
Embedded Standard
Wyse
ThinOS
Wyse
ThinOS
Wyse Enhanced
SUSE Linux
Entreprise
CE
Microsoft
Windows CE
Virtualization
Software

Start Features TechnicalModels Print
VIA C7 1GHz processor
plus advanced best performance per watt
hardware media accelerator
Performance
Continue tour
High performance. Inside out.
Inside every compact, Wyse C class lies a punchy VIA C7 1 GHz
processor and an advanced hardware media accelerator delivering
rich multimedia and video playback up to 1080p HD resolution.
Outside, you’ll find advanced DVI-I display connectivity for one or two
displays, four free USB 2.0 ports, PS/2 ports for keyboard and mouse,
gigabit Ethernet and optional WiFi (b/g/n) support. Wyse C class
supports the Wyse TCX software suite of user-experience
enhancements and Wyse WSM zero-client provisioning software.

Start Features TechnicalModels Print
Well connected
DVI-I Video output
Two S/2 ports for keyboard and mouse
Optional wireless
Kensington lock slot
10/100/1000 Base-T ethernet port
Four available external USB 2.0 ports
(2 front; 2 back)
Audio out: 1/8-inch mini jack, 16 bit stereo
Audio in: 1/8-inch mini jack,
8 bit stereo microphone
Wyse C class family connectivity
Wyse C10LE, C30LE, C50LE, C90LE, C90LEW thin client and C00LE zero client
Continue tour
Content updated 260310

Back of monitor or wall mounting
• An optional VESA mount bracket enables Wyse C class to be
mounted on the back of a monitor (this requires the four industry
standard mounting points to be free). The same bracket can be
used for wall mounting.
Start Features TechnicalModels Print
• Wyse C class clients feature sturdy feet for
simple horizontal desktop installation.
Desktop
Continue tour
Fits around you.
On the desk or out of sight; Wyse C class fits around you.
Every Wyse C class includes a monorail mount that lets
you choose how and where to fit it: horizontally, vertically,
directly to walls, under desks ...and even fitted discretely
to the rear of standard desktop displays.
Mounting options

Going Green
with Wyse thin computing
Every Wyse C class model is EnergyStar certified,
a recognized sign of energy efficiency. Through our
EarthSmart Computing initiative we are committed to
helping organizations implement a greener computing
strategy - one that delivers a more efficient and productive
computing experience for your users with a positive effect
on energy wastage, heat and carbon emissions.
Green Power
Each fanless Wyse C class draws just under 7 watts* of
power and creates very little heat as a result - contributing to
cooler, quieter user work environments, a greatly reduced
carbon footprint and huge savings in energy costs when
compared to equivalent PC desktops.
Learn more
Download carbon calculators, fact sheets and white papers
from here: www.wyse.com/green
*Average power usage with
device connected to 1 keyboard,
1 PS/2 mouse, and 1 monitor.
Start Features TechnicalModels Print
Continue tour
That’s Wyse
EarthSmart
Computing
Desktop computing Without compromise

Continue tour
Provisioning Software Wyse WSM
Start Features TechnicalModels Print
Wyse WSM Delivers full PC functionality with
all the benefits of centralized management
and maintenance-free ‘Zero Clients’.
Wyse WSM provisions the operating system and applications on-demand to desktop
devices across your network. Even traditional management tasks such as firmware
upgrades, patching or installing new software applications are carried out one-time
only centrally on the server, avoiding the need to visit individual desktops.
Dramatically speeding-up and simplifying deployment in one stroke.
The power of a PC, without the complexity.
Wyse Zero Clients and Wyse WSM provide compact, energy efficient and productive
desktops with all the dynamic user experience of a PC without the day-to-day
complexities and risks associated with one.
Plus, as all Wyse Zero Clients have no moving parts to fail, their service lives
(typically 5-10 years) are extended beyond those of comparable PCs, and the noise
from fans and hard drives is eliminated. Better still, their low power consumption
means low heat output enabling comfortable working environments with a reduced
dependence on costly carbon-heavy air conditioning - often leaving workplace
cooling achievable through natural ventilation.
Generic WSM approved final 100410

Management Software Wyse Device Manager
Thin computing remote management. Made easy.
Wyse Device Manager (WDM) provides comprehensive, enterprise-wide management for Wyse thin clients.
A licence for WDM Workgroup Edition is included and may be upgraded to WDM Enterprise Edition for
an additional charge. Key features include:
Start Features TechnicalModels Print
Continue tour
• HTTPS Based Imaging / Updates
• Fully Encrypted Network Traffic
• Multi-user Admin Access (MS AD) Support
• Complete Device Imaging / Patching / Updates
• Bandwidth Throttling for Efficiency / Reliability
• Software Updates and Add-ons
• Device Health Status / Reporting
• Remote Shadowing / Control
• Default Device Configuration
• Distributed Architecture
• SQL / MSDE Support
• Multiple Remote Repository Support
• Automated Discovery
• Detailed Hardware Asset information
• Installed Software Asset information
Security
No-Hassle Deployment
Device Administration
and Monitoring
Scalability
Complete Asset Visibility
Generic WDM approved final 100410

Virtualization Software Wyse TCXTM Suite with Collaborative rocessing ArchitectureTM
Wyse TCX delivers an amazing user experience in one software suite.
Wyse TCX is our new software suite which enriches the user experience by removing the limitations previously associated with thin clients. It enhances, not replaces,
key protocols like ICA/HDX and RDP adding key features to make each more valuable. With Wyse TCX users receive the best PC experience available on a thin
computing platform.1, 2
Wyse TCX
Multi-display
Ensures application
windows and dialog
boxes are multi-monitor
aware when using more
than one monitor.
Wyse TCX
ich Sound
Enables bi-directional
audio in virtual desktop
environments, enabling
solutions such as VOIP,
digital dictation or voice
recognition to be
deployed.
Start Features TechnicalModels Print
Wyse TCX
USB Virtualizer
Enables plug and play peripheral
support for virtual desktop
environments.
• Redirect and use local USB
devices in virtual desktops.
• Deploy virtual desktops to
knowledge workers with special
device access needs.
• Enable a broad set of USB
peripherals including webcams
and headsets.
Wyse TCX Multimedia
Streamlines the delivery of the
multimedia stream to the local client
for a rich user experience within a
thin computing architecture.
• Accelerates Mpeg1, Mpeg2, WMV,
Mpeg4 Part 2, AC3, AAC, MP3,
WAV, WMA media types.
• Collaborative Processing
Architecture enhances server
scalability, and network utilization
by off-loading multimedia
rendering to the client. Continue tour
Wyse TCX
Flash Acceleration
Wyse TCX Flash Acceleration helps
thin client users to experience
improved Flash video performance.
While the Flash player continues to run
server-side, the resulting images are
transcoded and redirected to the client
for fast rendering. The technology
allows for greater control of frame rate
and compression and supports
enhanced playback of youtube style
flash videos in Internet Explorer.
1 Subject to licence fee.
2 Support is dependant
on host Operating System.
Generic WTCXS approved final 100110

emoving the barriers of network latency
Wyse Virtual Desktop Accelerator (VDA) enables virtualized desktop and thin
computing environments to be deployed to areas where network latency has, to date,
presented operational barriers. Now, with Wyse VDA, more users can receive the full
benefits of Wyse thin computing – with the best PC experience over virtualized
desktops.
Wyse VDA is a software-only solution for Wyse thin clients
and supported PCs that delivers the best user
experience for the allocated network bandwidth by
neutralizing the effects of network latency and
packet loss. Making ‘thin’ suitable for more
remote-site, branch, or field-based users.
Wyse VDA works with instead of replacing
existing RDP and ICA protocols, accelerating
them by up to 20 times on networks faced with
latencies up to and beyond 300ms, and at
least 768kbps bandwidth.
At a glance features:
• Software-only acceleration of virtual desktops and applications
• Accelerates existing Citrix ICA and Microsoft RDP protocols
• Works on WANs and ‘fat, long pipes’
• Accelerates connections to Citrix XenApp, Citrix XenDesktop, VMware View
and Microsoft Terminal Server and Microsoft Hyper-V VDI
• Enhances Wyse TCX software suite functionality across wide-area networks
• Enables Wyse Collaborative Processing Architecture across
wide-area networks
• Administrator console provides control of maximum bandwidth per
connection
• Leverages built-in security of underlying protocols (128-bit encryption for
RDP and ICA).
Continue tour
Start Features TechnicalModels Print
Virtualization Software Wyse Virtual Desktop Accelerator
Generic WVDA approved final 010410

Operating Systems Wyse ThinOS
Start Features TechnicalModels Print
Wyse ThinOS is the most optimized, management-free solution
for Citrix XenApp, Citrix XenDesktop, Microsoft Terminal Server
and VMware View virtual desktop environments.
Wyse ThinOS ensures every Wyse thin client provides flexible and
secure user access as it’s the only thin computing operating system to
feature an unpublished API delivering built-in in protection from the
viruses, malicious software and trojans developed by hackers.
This fast, purpose-built thin computing operating system boots-up in
seconds, updates itself automatically, and delivers IT managers with
simple, scalable adminstration to suit their organization’s needs.
Wyse ThinOS makes time consuming maintenance tasks such as
software and firmware updates as easy as dragging and dropping
them onto a central file server (ftp, http and https).
Image management and configuration can be automated via DHCP
and fileserver for a ‘hands-off’ approach, while Wyse Device Manager
provides complete ‘hands-on’ management of enterprise-wide
devices.
Generic WTOS approved final 100410
Continue tour
Wyse ThinOS delivers a wealth of innovative, user-oriented and productive features:
Easy management
• Wyse ThinOS enables simple, scalable device management from day one.
• Its easy FTP-based configuration and automatic update facility allows for time-saving hands-off
device management.
• In fact it’s so easy, many IT managers find they don’t need dedicated management tool. For those
that do - they’ll benefit from Wyse ThinOS’ complete integration with Wyse Device Manager.
Fast boot-up
• Wyse ThinOS users and managers alike benefit from the class-leading fast boot-up times.
Security
• Featuring an unpublished API and no file system, Wyse ThinOS is inherently secure providing
maximum security from malware and viruses.
Smart card support
• Wyse ThinOS gives organizations the levels of secure access they need with seamless smart-card
roaming between devices.
Full support for Wyse Virtual Desktop Accelerator
• New Wyse Virtual Desktop Accelerator delivers the best user experience for the allocated network
bandwidth and neutralizes the effects of network latency and packet loss, making ‘thin’ suitable for
more remote-site, branch, or field-based users.
• Accelerates RDP and ICA up to 20 times on networks with latencies
up to and exceeding 300ms and at least 768kbps bandwidth.

Wyse-e ha ced Microsoft Wi dows CE is ideal for departme ts a d orga izatio s
that wa t a Microsoft e d-to-e d solutio , a d support for Citrix ICA, Microsoft RDP
a d VMware View as well as a local browser a d termi al emulatio , plus sta dard
co ectio s to peripherals a d add-o s.
Microsoft Windows CE gives you a C-like experience on the desktop, with local terminal
emulation so you can run most legacy applications.
By combining this small and fast operating system with firmware
components, Wyse is able to reduce boot times and increase
protection against viruses, trojan horses, and other malware.
The result is a simply more secure solution that provides the
flexibility to add standard peripherals, from printers to scanners
to USB thumb drives. However these peripherals can only be
connected under access controlled by the IT administrator.
CE
Start Features Tech icalModels Pri t
Operati g Systems Microsoft Windows CE
Co ti ue tour
Generic MSCE overview Approved final 181209

Operating Systems SUSE Linux Enterprise Thin Client
Start Features TechnicalModels Print
Wyse Enhanced SUSE Linux Enterprise Thin Client (SLETC) is a simple,
secure, and easy to manage plat orm designed or customers looking or
lexibility and support o the latest protocols (ICA, PCoIP, RDP, etc)
without the need or a Windows-based client.
Thin-Linux or the Enterprise
Wyse Enhanced SLETC is not a home-brew Linux. In fact, it’s the industry’s only
enterprise-quality Linux platform, created by combining the security and flexibility of
ovell’s SUSE Linux with Wyse’s thin computing leadership and innovation in user
experience and simplified management. Additionally,
SLETC is the only thin-Linux platform to protect
customers from potential IP infringement suits as it is
jointly indemnified by ovell and Microsoft.
Simple “Hands-O ” Management
Deploying, managing, and updating SLETC is easier than
any other thin-Linux distribution, Period. Utilizing Wyse’s
proven automatic update and configuration approach,
management tasks can be handled centrally and easily
without any management software required.
Updating 1 or 1,000 clients is as simple as dragging and dropping a file into a folder.
For customers that desire a little more hands-on approach (such as asset tracking,
reporting, etc) then integration with Wyse Device Manager is built-in.
Security
Wyse Enhanced SLETC is designed with security in mind. IT Managers are able
to provide a locked-down experience, smartcard login to virtual environments,
VP connectivity, and leverage a read-only file system that protects against
data loss, theft and virus attacks.
Flexible, Multi-Protocol Support
Being built from a standard enterprise-quality Linux distribution means SLETC
supports a wide range of protocols and infrastructures straight-out-of-the-box
including Citrix, Microsoft, VMware and even your legacy applications (such as
terminal emulations) - allowing you to mix-and-match connections from a
single SLETC image.
Generic SLETC approved final 100410
Continue tour
That’s Wyse Enhanced SUSE Linux Enterprise Thin Client
The only enterprise-quality Linux that’s optimized for thin computing.

Start Features TechnicalModels Print
Running Microsoft Windows XP E bedded on Wyse thin clients
gives IT depart ents the ability to support Citrix ICA, Microsoft
RDP and VMware View environ ents and deploy fully functional
desktops with better anageability and significantly lower total
cost of ownership than personal co puters.
Wyse Enhanced Microsoft Windows XP Embedded-based thin clients
can run 32 bit Microsoft Windows applications, either locally or from
servers located on the network, with inbuilt flexibility to add and
support a host of desktop peripherals with
permission from the IT administrator.
Secure write-protected
thin desktops
This robust and flexible operating system
is further enhanced by the Wyse file-
based Write Filter that enables you to
protect the file system image from
accidental changes or user customization.
n rebooting, the thin client simply returns to the required file system
image state.
Wyse custo ized i age support
Wyse technicians are able to help you customize Windows XP
Embedded to your exact requirements and create bespoke system
images for subsequent enterprise-wide deployment, management
and update through Wyse Device Manager.
Contact your Wyse Partner for further details.
Generic MS XPE overview approved final 181209
Operating Syste s Microsoft Windows XP Embedded
Continue tour

Start Features Tech icalModels Pri t
Ru i g Wi dows Embedded Sta dard (WES), the latest a d
most adva ced embedded OS from Microsoft, o Wyse thi
clie ts gives IT departme ts the ability to deploy fully fu ctio al
desktop clie ts with better ma ageability a d sig ifica tly lower
total cost of ow ership tha perso al computers.
Wyse WES-based thin clients can run 32 bit Microsoft Windows
applications, either locally or from servers, with the inbuilt flexibility to
add and support a host of desktop peripherals with permission from
the IT administrator.
Full support is provided for RD 7.0,
Citrix ICA 11.2, VMware View 4.0.1 and
Internet Explorer 8.
Secure write-protected
thi desktops
This robust and flexible operating system
is further enhanced by the Wyse file-
based Write Filter that enables you to
protect the files, folder and/or entire volumes from accidental changes
or user customization. On rebooting, the thin client simply returns to
its original state thus preventing any possible damaging modification
either from users or malware.
Wyse customized image support
Wyse technicians are prepared to help you customize Windows
Embedded Standard to your exact requirements in order to create
custom-built images for subsequent enterprise-wide deployment,
management and update through Wyse Device Manager.
Co tact your Wyse Part er for further details.
Generic MWES content Approved final 170410
Take the Tour agai
Operati g Systems Microsoft Windows Embedded Standard

Start Features TechnicalModels Print
©2010 The Wyse logo nd Wyse re tr dem rks of Wyse Technology Inc. Other product n mes mentioned herein re for identific tion purposes only nd m y be tr dem rks nd/or registered
tr dem rks of their respective comp nies. All specific tions re subject to ch nge without notice. Whilst we m ke every effort to ensure the ccur cy of the det ils, specific tions, models, im ges
nd benefits fe tured in this d t sheet, we c nnot be held responsible for ny errors nd/or omissions. If you h ve ny queries reg rding Wyse products ple se cont ct your uthorized region l
Wyse P rtner or represent tive for further inform tion nd ssist nce. Some fe tures require support by server oper ting system nd protocol. Approved fin l 170410.
Wyse offers thin computing sales, service
and support expertise around the globe.
Clic here for contact details of your regional Wyse office.
Contact Wyse
Wyse Technology Inc.
3471 North First Street, S n Jose, CA 95134-1801
Visit our website at:
http://www.wyse.com or send n em il to: s [email protected]
Wyse Sales
800 GET WYSE (800 438 9973)
Wyse Customer Service Center:
800 800 WYSE (800 800 9973)

Start Features TechnicalModels Print
Wyse C class thin clients are available across a variety of operating systems featuring the speed of Wyse ThinOS, the functionality
of Microsoft Windows CE, the security of SUSE Linux Enterprise Thin Client, the versatility of Microsoft Windows X Embedded,
the advanced capabilities of Microsoft Windows Embedded Standard and the provisioning power of Wyse WSM.
Learn more Simply click the data sheets below:
Wyse C10LE, C30LE, C50LE
C90LE, C90LEW thin clients
and C00LE zero clients
Wyse WSM
Microsoft
Windows CE
Microsoft
Windows XPe
Wyse C class family Hardware Specifications
S ar Fea ures TechnicalModels Prin
Processors VIA C7 1GHz
Chipse VIA VX855
Memory C class with Wyse ThinOS (C10LE): 128MB Flash / 512MB RAM DDR2
C class with Windows CE (C30LE): 128MB Flash / 512MB RAM DDR2
C class with SUSE Linux (C50LE): 1GBFlash / 1GBRAM DDR2
C class with Windows XP Embedded (C90LE): 1GB Flash / 1GB RAM DDR2
C class with Windows Embedded Standard (WES) (C90LEW):
2GB Flash / 1GB RAM DDR2
C class for Wyse WSM (C00LE): 0GB Flash / 1GB RAM DDR2
Maximum memory Flash up to 4GB / RAM up to 2GB
Configura ion
I/O peripheral suppor One DVI-I port, DVI to VGA (DB-15) adapter included
Dual-video Support with optional DVI-I to DVI-D plus VGA-monitor
splitter cable (sold separately)
Four USB 2.0 ports (2 on front, 2 on back)
Two PS/2 ports
One Mic In
One Line Out
Enhanced PS/2 Keyboard with Windows Keys (104 keys) and
PS/2 Optical mouse included
Ne working 10/100/1000 Base-T Gigabit Ethernet
Cisco CCX Certified internal 802.11 b/g/n (optional) eliminates theft of external
wireless adapters
Display VESA monitor support with Display Data Control (DDC) for automatic
setting of resolution and refresh rate
Dual monitor supported
Single: 1920x1200@60Hz, Color depth: 8, 15, 16, 24 or 32bpp,
Two independent full resolution frame buffers
Dual: 1920x1200@60Hz, Color Depth: 8, 15, 16, 24 or 32bpp.
Audio Output: 1/8-inch mini jack, full 16 bit stereo
Input: 1/8-inch mini jack, 8 bit microphone
Physical charac eris ics Height: 1.38 inches (34mm)
Width: 6.94 inches (177mm)
Depth: 4.75 inches (121mm)
Shipping Weigh 6 lbs. (2.7kg)
Moun ings Horizontal feet
Optional VESA mounting bracket
Device Securi y Built-in Kensington security slot (cable sold separately)
Power Worldwide auto-sensing 100-240 VAC, 50/60 Hz. Energy Star®V.5.0
compliant power supply
Average power usage with device connected to 1 keyboard with 1 PS/2
mouse and 1 monitor: Under 7 Watts
Temperaure Range Horizontal: 10-35 C (50-95 F), Vertical: 10-40 C (50- 104 F)
Humidi y 20% to 80% condensing
10% to 95% non-condensing
Cer ifica ions German EKI-ITB 2000, ISO 9241-3/-8
cULus 60950, TÜV-GS, E 60950
FCC Class B, CE, VCCI, C-Tick
WEEE, RoHS Compliant
Energy Star®Compliant
Warrany Three-year hardware warranty. Visit our web site for WyseChoice
extensions and upgrades
Wyse C class spec approved final 250310
Wyse WSM Software Specifications
Start Features TechnicalModels Print
Generic WWM pec approved final 170310
Device Hardware
Re uirements
Windows XP Pro
•
Minimum processor speed 800 MHz (1GHz or higher is recommended)
•
Mind. 256 MB (1GB or higher is recommended)
Vista and Windows 7
•
Minimum processor speed 1 GHz (1.5GHz or higher is recommended)
•
Mind. 1 GB (2GB or higher is recommended)
•
Flash size/local storage – none needed. If the device has flash it can be used as a
local cache for offline mode.
Server Re uirements
Network Re uirements
•
Minimum processor speed 1GHz (3GHz or higher is recommended).
•
erver Lan peed = Minimum 100Mbps (1Gbps and up is recommended).
•
erver Operating ystem: Windows XP Pro P3, Windows erver 2003, Windows erver 2008 and 2008 R2
•
Device Lan peed = Minimum 10Mbps (100 Mbps full duplex is recommended)
Operating Systems
Supported
•
Microsoft Windows XP
•
Microsoft Windows Vista.
•
Microsoft Windows 7.
Databases supported
•
Microsoft QL 2005 and 2008 ( erver and Express Editions).
Built-in high Availability
•
Database availability using QL clustering.
•
Built-in server high availability through W M erver Grouping feature.
•
erver to erver Fail-over Capability.
Fast and Easy Installation
•
Installing Wyse W M is simply a matter of running a single, graphical installer.
•
The installer checks for all the prerequisite components before installation.
Web-based Admin Console
•
Allows IT administrators to access Wyse W M from any browser.
•
Control the entire installation from a central location.
•
Dramatically simplifies administration, saving IT time and user downtime.
•
Wizards to guide the user through specific tasks.
Operation System and
Application Imaging Tools
•
Imaging tool simplifies the process of creating an O image for the specific
hardware configuration and an application image for all hardware configurations.
•
All O and application images are ready for deployment once created, no further modifications
needed.
Application Subscription
Management
•
Use flexible application deployment methods: - Auto-subscribed applications are ready for use when user logs in for the first time.
- Manual subscriptions allow users the flexibility to use applications only when needed.
- Mandatory subscriptions that cannot be unsubscribed by users.
Protected System Drive
•
Allows administrators to protect the system drive from enduser initiated updates.
•
Prevents changes to operating system drive except by administrators, helping stop viruses, spyware,
or malware from infecting the device.
Microsof Windows CE 6.0 WFR3 Software Specifications
Firmware fea ures Microsoft Windows CE 6.0 WFR3
Microsoft Internet Explorer 6.0 resident:
HTML, JavaScript, XML, Active X as custom
Citrix ICA 10.x resident
Citrix Web Interface
RD 6.0 resident
VMware View Client Resident
CCID compliant Smart Card Readers support
Ericom owerTerm®Terminal Emulation
provides 30-plus terminal emulation
Jetcet 5.0
Media layer 9.0
Terminal Services Advanced Client (TSAC)
Thin rint ICAVC and Thinprint RD
VNC support in CE 6.0
WinCE 6 eStar B category certification
Server OS Citrix XenApp / Citrix resentation Server
Infras ruc ure Suppor Citrix XenDesktop
VMware View
Microsoft Windows Terminal Server 2003 / 2008
Se -up and Configura ion User interface
Boot from local flash
Pro ocol Suppor TC /I , DNS, DHC , XE, , C/SC and ISO-7816
smart-card support
Managemen Remote management, configuration and upgrades
through Wyse Device Manager
Send messages
Complete image upgrade
Wake terminal remotely (Wake-on LAN)
Terminal configuration (I information, etc)
Remote screen shadowing of entire desktop
(Wyse Remote Shadow)
Reporting
Altiris Deployment via add-on
Wireless suppor 802.11 b/g/n support with internal wireless adapter
IEEE 802.1X
WE , W A, and W A-2 wireless authentication
Internal WiFi default encryptions: MD5, A , TLS
Supports USB wireless adapters from:
Cisco, D-Link, Netgear, US Robotics, Trendware
S ar Fea ures TechnicalModels Prin
Generic MSCE 6.0 WFR3 approved final 100410
Microsoft Windows XP Embedded SP3 Software specifications
Start Feat res TechnicalModels Print
Firmware feat res Microsoft Windows X Embedded S 3
Microsoft Internet Explorer 7.0 resident: HTML, JavaScript, XML, Active X
Sun JRE, Media layer, Citrix Web Interface
RD 6.0.xx resident
Citrix ICA 11 resident
VMware View Client Resident
Ericom owerTerm®Terminal Emulation
provides 30-plus terminal emulations
Windows Media layer 11, .NET 3.0 S 1
Memory 1GB of flash memory and 1GB of RAM
Server OS Citrix XenApp / Citrix resentation Server
Infrastr ct re S pport Citrix XenDesktop
VMware View
Microsoft Windows Terminal Server 2003 & 2008
Set- p and Config ration Boot from local flash
Microsoft Windows X user interface languages: U.S. English, French,
German, Spanish, Optional add-ons
Keyboard langage s pport U.S. English (standard), French, German, Spanish, U.K. English,
40 other languages included
Protocol S pport TC /I , DNS, DHC , XE
Management Remote management, configuration, and upgrades
through Wyse Device Manager
Complete image upgrade
Wake terminal remotely (Wake-on LAN)
Terminal configuration (I information, name, etc.)
Remote screen shadowing of entire desktop
(Wyse Remote Shadow)
Reporting, Asset management
SMS
Altiris
Wireless s pport 802.11 b/g/n support with internal wireless adapter
W A-2, WE , W A wireless authentication
Supports wireless adapters from: Cisco, D-Link, Netgear,
US Robotics, Trendware
Pl g-ins Adobe Flash layer
Adobe Shockwave
Wyse TCX S ite Advanced support for innovative Wyse TCX Suite virtualization software that both
works with and enhancesICA and RD (instead of replacing them) featuring:
• Wyse TCX Multimedia - the power to run rich multimedia files formats ultilizing
Wyse Collaborative rocessing Architecture (C A) that intelligently redirects the
necessary processing tasks between the client and the server.
• Wyse TCX Multi-Display - ensures that windows and dialogue boxes behave the
way users expect when using more than one monitor.
• Wyse TCX USB Virtualizer - makes client attached USB devices visible to virtual
desktops and applications, with full IT control.
• Wyse TCX Rich Sound - enables virtual desktops and applications to receive and
transmit high quality audio without compromise.
• Wyse TCX Flash Acceleration - helps users of thin clients to experience improved
Flash performance.
Generic WX E Spec approved final 100410
Microsof Windows Embedded S andard Software specifications
Firmware feaures Microsoft Windows Embedded Standard (WES)
Microsoft Internet Explorer 7.0 resident: HTML, JavaScript, XML, Active X
Sun JRE, Media Player, Citrix Web Interface
RDP 6.1 resident*
Citrix ICA 11 resident*
Ericom PowerTerm® Terminal Emulation
provides 30-plus terminal emulations
Citrix XenDesktop
Windows Media Player 11, .ET 3.5
Server OS Citrix XenApp / Citrix Presentation Server
Infrasrucure Suppor Citrix XenDesktop
VMware View*
Microsoft Windows Terminal Server 2003 & 2008
Applicaion Framework .et 3.5
Securiy File Based Write Filter (FBWF)
Microsoft Baseline Security Analyzer (MBSA)
Se-up and Configuraion Boot from local flash
Microsoft Windows WES user interface languages: U.S. English, French,
German, Spanish, Optional add-ons
Keyboard language suppor U.S. English (standard), French, German, Spanish, U.K. English,
40 other languages included
Proocol Suppor TCP/IP
, DS, DHCP
, PXE
Managemen Remote management, configuration, and upgrades
through Wyse Device Manager
Complete image upgrade
Wake terminal remotely (Wake-on LA)
Terminal configuration (IP information, name, etc.)
Remote screen shadowing of entire desktop
(Wyse Remote Shadow)
Reporting, Asset management
SMS
Altiris
Wireless suppor 802.11 b/g/n support with external wireless adapter or
internal wireless adapter option
WPA-2, WEP
, WPA wireless authentication
PEAP-GTC wireless authentication protocol with optional
Juniper Odyssey Client
Supports PC-Card wireless adapters from: Cisco, D-Link, etgear,
US Robotics, Trendware
Plug-ins Adobe Flash Player
Adobe Shockwave
Microsoft Silverlight
Wyse TCX Suie Advanced support for innovative Wyse TCX Suite virtualization software that both
works with and enhancesICA and RDP (instead of replacing them) featuring:
• Wyse TCX Multimedia - the power to run rich multimedia files formats ultilizing
Wyse Collaborative Processing Architecture (CPA) that intelligently redirects the
necessary processing tasks between the client and the server.
• Wyse TCX Multi-Display - ensures that windows and dialogue boxes behave the
way users expect when using more than one monitor.
• Wyse TCX USB Virtualizer - makes client attached USB devices visible to virtual
desktops and applications, with full IT control.
• Wyse TCX Rich Sound - enables virtual desktops and applications to receive and
transmit high quality audio without compromise.
• Wyse TCX Flash Acceleration - helps users of thin clients to experience improved
Flash performance.
Generic MWES Spec approved final 100410
S ar Fea ures TechnicalModels Prin
*RDP 7.0, Citrix ICA 11.2 and VMware View 4.0.1 supported as add-ons
Wyse
ThinOS
Wyse Thi OS Software specifications
ICA 11.x Compatible Clie t • HDX Mediastream • Broad USB Support (with Wyse TCX) • Flash Video Support (with TCX)
• HDX ealtime • Progressive Display • Seamless Windows
• HDX IntelliCache • Desktop estart (XenDesktop) • Session eliability
• HDX Broadcast (Branch epeater) • Smartcard authentication and redirection • Access Gateway Support (CSG mode)
RDP 6.x Compatible Clie t • Up to 32-bit color depth connections • ich Multimedia (with Wyse TCX) • Flash Video support (with TCX)
• Dual Monitor Support (hardware dependant) • Broad USB Support (with Wyse TCX) • Disk drive redirection
• Smartcard authentication and redirection • Bidirectional Audio (with Wyse TCX) • WAN Acceleration (with Wyse VDA)
VMware View 4.0 cliet • Smartcard Authentication • SSL Tunneling • SecureID Authentication
• estart VM • Multimedia Support (with TCX) • Broad USB Support (with TCX)
• Bi-directional Audio (with TCX) • Flash Video Support (with TCX) • WAN Acceleration (with VDA)
Roami g smart card ve dor support Enables smart card users to not only roam from station to station but also access the same virtual environment support regardless of which station they are connecting from. Wyse ThinOS
provides ‘out-of-the-box’ smart card support for vendors such as Gemalto .NET, Aladdin, and ActiveIdentity - supported within Citrix, VMware and Microsoft environments. Users benefit from
secure login and roaming desktop support so they can access their environments from any suitably equipped Wyse thin computing environment.
Wyse TCX Advanced support for innovative Wyse TCX virtualization software that both works with and enhancesICA and DP (instead of replacing them) featuring:
• Wyse TCX Multimedia - the power to run rich multimedia files formats ultilizing Wyse Collaborative Processing Architecture (CPA)
that intelligently redirects the necessary processing tasks between the client and the server.
• Wyse TCX Multi-Display - ensures that windows and dialogue boxes behave the way users expect when using more than one monitor.
• Wyse TCX USB Virtualizer - makes client attached USB devices visible to virtual desktops and applications, with full IT control.
• Wyse TCX ich Sound - enables virtual desktops and applications to receive and transmit high quality audio without compromise.
• Wyse TCX Flash Acceleration - helps users of thin clients to experience improved Flash performance.
Wyse Virtual Desktop Accelerator Delivers the best user experience for the allocated network bandwidth. New Wyse Virtual Desktop Accelerator neutralises the effects of network latency and
packet loss, making ‘thin’ more suitable for more remote-site, branch, or field-based users - and boosts DP and ICA up to 20 times on networks with latencies up to and exceeding
300ms and at least 768kbps bandwidth.
Ma ageme t made easy Fast booting, scalable administration includes simple drag and drop placement of firmware, automatic updates via file server and full integration with Wyse Device Manager.
Security built i With no published API Wyse ThinOS is inherently secure from viruses and malware. Wyse ThinOS includes robust wired and wireless 802.1x support, with
secure encrytion for simple installation and management.
Server OS • Citrix XenDesktop • Microsoft Windows Terminal Server 2003 / 2008
I frastructure Support • Citrix XenApp / Citrix Presentation Server • Support for other leading VDI brokers (Quest Software, Leostream, etc) • VMware View
Start Features Tech icalModels Pri t
Generic WTOS Spec approved final 100410
Technical Wyse C class Specifications
Visit: wyse.com
Microsoft Windows
Embedded Standard
Wyse Enhanced SUSE Linux
Enterprise Thin Client
SUSE Linux Enterprise Thin Client 11
Automatic Central Configuration (text-based I I’s)
Automatic Upgrades (FTP, HTTP, HTTPS)
Secure, read-only file system with lockdown abilities
RDESKTOP 1.6 client
Citrix ICA 11 client (w/ HDX Mediastream, Plug-n-Play,
Realtime, etc)
VMware View 4.0 client
Ericom PowerTerm®Terminal Emulation
Cisco, Juniper, ortel, IPSEC VP Support (Add-ons)
Local/Remote Printing support (CUPS, LPR/LPD, Samba,
ThinPrint,etc)
Web-based applications (Firefox, Flash, JAVA,etc)
XDMCP
SSH
Citrix XenApp / Citrix Presentation Server
Citrix XenDesktop
VMware View
VMware View
Microsoft Windows Terminal Server 2003 & 2008
100+ Keyboard Layouts supported locally
(English, German, Spanish, French, Italian, Dutch,
Chinese, Japanese, Turkish)
Firmware features
Server OS
Com atibility/Su ort
Keyboard language
su ort
SUSE Linux Enter rise Thin Client Software specifications
Start Features TechnicalModels Print
Automatic, “hands-off” configuration and upgrading of clients without the need for device management
software. Optionally, administrators can choose to integrate with Wyse Device Manager (WDM) for more
hands-on control:
- Complete image upgrade
- Wake terminal remotely (Wake-on LA )
- Remote screen shadowing of entire desktop (V C)
- Asset management and reporting
WPA Personal, WPA2 Personal, WPA Enterprise, WPA Enterprise Authentication support
PEAP/TLS: PAP/MSCHAP/MSCHAPV2 support
Advanced support for innovative Wyse TCX virtualization software that both works with and enhances ICA and RDP
(instead of replacing them) featuring:
• Wyse TCX Multimedia - the power to run rich multimedia files formats utilizing Wyse Collaborative Processing
Architecture (CPA) that intelligently redirects the necessary processing tasks between the client and the server.
• Wyse TCX Multi-Display - ensures that windows and dialogue boxes behave the way users expect when using more
than one monitor.
• Wyse TCX USB Virtualizer - makes client attached USB devices visible to virtual desktops and applications, with full
IT control.
• Wyse TCX Rich Sound - enables virtual desktops and applications to receive and transmit high quality audio without
compromise.
• Wyse TCX Flash Acceleration - helps users of thin clients to experience improved Flash performance.
Wyse Virtual Desktop Accelerator Delivers the best user experience for the allocated network bandwidth. ew Wyse
Virtual Desktop Accelerator neutralizes the effects of network latency and packet loss, making ‘thin’ more suitable for
more remote-site, branch, or field-based users - and boosts RDP and ICA up to 20 times on networks with latencies
up to and exceeding 300ms and at least 768kbps bandwidth.
Management
made easy
Wireless su ort
Wyse TCX Suite
Wyse Virtual Deskto
Accelerator
Generic SLETC approved final 100410

Wyse C class family Hardware Specifications
Start Features TechnicalModels Print
Processors VIA C7 1GHz
Chipset VIA VX855
Memory C class with Wyse ThinOS (C10LE): 128MB Flash / 512MB RAM DDR2
C class with Windows CE (C30LE): 128MB Flash / 512MB RAM DDR2
C class with SUSE Linux (C50LE): 1GB Flash / 1GB RAM DDR2
C class with Windows XP Embedded (C90LE): 1GB Flash / 1GB RAM DDR2
C class with Windows Embedded Standard (WES) (C90LEW):
2GB Flash / 1GB RAM DDR2
C class for Wyse WSM (C00LE): 0GB Flash / 1GB RAM DDR2
Maximum memory Flash up to 4GB / RAM up to 2GB
Configuration
I/O peripheral support One DVI-I port, DVI to VGA (DB-15) adapter included
Dual-video Support with optional DVI-I to DVI-D plus VGA-monitor
splitter cable (sold separately)
Four USB 2.0 ports (2 on front, 2 on back)
Two PS/2 ports
One Mic In
One Line Out
Enhanced PS/2 Keyboard with Windows Keys (104 keys) and
PS/2 Optical mouse included
Networking 10/100/1000 Base-T Gigabit Ethernet
Cisco CCX Certified internal 802.11 b/g/n (optional) eliminates theft of external
wireless adapters
Display VESA monitor support with Display Data Control (DDC) for automatic
setting of resolution and refresh rate
Dual monitor supported
Single: 1920x1200@60Hz, Color depth: 8, 15, 16, 24 or 32bpp,
Two independent full resolution frame buffers
Dual: 1920x1200@60Hz, Color Depth: 8, 15, 16, 24 or 32bpp.
Audio Output: 1/8-inch mini jack, full 16 bit stereo
Input: 1/8-inch mini jack, 8 bit microphone
Physical characteristics Height: 1.38 inches (34mm)
Width: 6.94 inches (177mm)
Depth: 4.75 inches (121mm)
Shipping Weight 6 lbs. (2.7kg)
Mountings Horizontal feet
Optional VESA mounting bracket
Device Security Built-in Kensington security slot (cable sold separately)
Power Worldwide auto-sensing 100-240 VAC, 50/60 Hz. Energy Star®V.5.0
compliant power supply
Average power usage with device connected to 1 keyboard with 1 PS/2
mouse and 1 monitor: Under 7 Watts
Temperature ange Horizontal: 10-35 C (50-95 F), Vertical: 10-40 C (50- 104 F)
Humidity 20% to 80% condensing
10% to 95% non-condensing
Certifications German EKI-ITB 2000, ISO 9241-3/-8
cULus 60950, TÜV-GS, EN 60950
FCC Class B, CE, VCCI, C-Tick
WEEE, RoHS Compliant
Energy Star®Compliant
Warranty Three-year hardware warranty. Visit our web site for WyseChoice
extensions and upgrades
Wyse C class spec approved final 250310

Wyse Th nOS Software specifications
ICA 11.x Compat ble Cl ent • HDX Mediastream • Broad USB Support (with Wyse TCX) • Flash Video Support (with TCX)
• HDX ealtime • Progressive Display • Seamless Windows
• HDX IntelliCache • Desktop estart (XenDesktop) • Session eliability
• HDX Broadcast (Branch epeater) • Smartcard authentication and redirection • Access Gateway Support (CSG mode)
RDP 6.x Compat ble Cl ent • Up to 32-bit color depth connections • ich Multimedia (with Wyse TCX) • Flash Video support (with TCX)
• Dual Monitor Support (hardware dependant) • Broad USB Support (with Wyse TCX) • Disk drive redirection
• Smartcard authentication and redirection • Bidirectional Audio (with Wyse TCX) • WAN Acceleration (with Wyse VDA)
VMware V ew 4.0 cl ent • Smartcard Authentication • SSL Tunneling • SecureID Authentication
• estart VM • Multimedia Support (with TCX) • Broad USB Support (with TCX)
• Bi-directional Audio (with TCX) • Flash Video Support (with TCX) • WAN Acceleration (with VDA)
Roam ng smart card vendor support Enables smart card users to not only roam from station to station but also access the same virtual environment support regardless of which station they are connecting from. Wyse ThinOS
provides ‘out-of-the-box’ smart card support for vendors such as Gemalto .NET, Aladdin, and ActiveIdentity - supported within Citrix, VMware and Microsoft environments. Users benefit from
secure login and roaming desktop support so they can access their environments from any suitably equipped Wyse thin computing environment.
Wyse TCX Advanced support for innovative Wyse TCX virtualization software that both works with and enhances ICA and DP (instead of replacing them) featuring:
• Wyse TCX Multimedia - the power to run rich multimedia files formats ultilizing Wyse Collaborative Processing Architecture (CPA)
that intelligently redirects the necessary processing tasks between the client and the server.
• Wyse TCX Multi-Display - ensures that windows and dialogue boxes behave the way users expect when using more than one monitor.
• Wyse TCX USB Virtualizer - makes client attached USB devices visible to virtual desktops and applications, with full IT control.
• Wyse TCX ich Sound - enables virtual desktops and applications to receive and transmit high quality audio without compromise.
• Wyse TCX Flash Acceleration - helps users of thin clients to experience improved Flash performance.
Wyse V rtual Desktop Accelerator Delivers the best user experience for the allocated network bandwidth. New Wyse Virtual Desktop Accelerator neutralises the effects of network latency and
packet loss, making ‘thin’ more suitable for more remote-site, branch, or field-based users - and boosts DP and ICA up to 20 times on networks with latencies up to and exceeding
300ms and at least 768kbps bandwidth.
Management made easy Fast booting, scalable administration includes simple drag and drop placement of firmware, automatic updates via file server and full integration with Wyse Device Manager.
Secur ty bu lt n With no published API Wyse ThinOS is inherently secure from viruses and malware. Wyse ThinOS includes robust wired and wireless 802.1x support, with
secure encrytion for simple installation and management.
Server OS • Citrix XenDesktop • Microsoft Windows Terminal Server 2003 / 2008
Infrastructure Support • Citrix XenApp / Citrix Presentation Server • Support for other leading VDI brokers (Quest Software, Leostream, etc) • VMware View
Start Features Techn calModels Pr nt
Generic WTOS Spec approved final 100410
