Wyse X50L User manual

Quick-Start Guide
Wyse®X Class Mobile Thin Client, Model Xn0L
Products: X50L, X90L, X90LW, X90Le, X90LeW
http://www.wyse.com/manuals
See accompanying documents in the shipping carton for License Agreement and Warranty information. To find the latest Quick-Start Guide, go to
http://www.wyse.com/manuals and click on the name of your product.
Important: A printed copy of the Wyse Technology End User License Agreement is included in the shipping box and provided for your reference only.
The license at http://www.wyse.com/license as of the purchase date is the controlling licensing agreement. By copying, using, or installing the software or
the product, you agree to be bound by those terms.
Important: If you use Wyse Device Manager Server software for managing your Wyse thin clients, download the latest version to ensure
compatibility at http://www.wyse.com/download.
Caution: Improper connection, mounting, or use of this product could result in component failure and/or flash memory corruption.
Read Caution Statements before setting up and operating your mobile thin client.
Improper connection or use of this product could result in component failure or undesired interference. Read the following caution statements before
setting up and operating your mobile thin client.
Setup
•Do not force a connector into its socket. If any undue resistance is encountered, ensure that the connector is correctly oriented to the receptacle.
•The main unit is not user serviceable; opening or accessing the case may violate your warranty.
•For wireless usage and requirements, refer to the regulatory notices in the mobile thin client’s documentation.
Venting and Care
•Allow sufficient space around your mobile thin client for ventilation; do not place your mobile thin client in any enclosure that restricts airflow around the
device, such as a closed briefcase, while the computer is turned on. Restricting airflow can damage your mobile thin client or cause a fire; do not place
any objects on the device or block the vent holes under the device. Find environmental operating specifications in the mobile thin client’s datasheet
located at http://www.wyse.com/products.
•Do not allow your mobile thin client to rest directly on exposed skin for extended periods of time during operation. The base surface temperature will rise
during normal operation (particularly when AC power is used). Prolonged contact with exposed skin can cause discomfort or a burn.
•To clean your mobile thin client, first disconnect it from the electrical outlet, and then use a soft cloth dampened with water for cleaning. Do not use liquid
or aerosol cleaners.
Power Sources
•To ensure regulatory compliance, use only the power adapter included in the shipping carton, or a Wyse-approved equivalent, with your mobile thin
client. Refer to the regulatory notices in your mobile thin client’s documentation.
•You can connect the power adapter at any time with the mobile thin client turned either on or off.
•Do not hard reset your mobile thin client by holding down the power button during normal operation.
•When turning off your mobile thin client, be sure to perform a complete shutdown (via the user interface). Do not disconnect the AC power cable, DC
power adapter cable, remove the battery, or shut off power at a circuit breaker (including power strips), etc., to turn off the device.
•Surge protectors for electrical devices are recommended in areas of lightning. However, when lightning is occurring, your equipment should be properly
shut down and unplugged from AC power until the storm has passed.
•Dispose of your battery properly when it no longer holds a charge or is damaged. Contact your local waste or environmental agency for instructions.
Battery
•The X class mobile thin clients contain a user-replaceable battery pack that is designed to work with your product. Do not use a battery from other
mobile thin clients or laptop computers. There is a risk of explosion if the battery is replaced by an incorrect type. Replace the battery only with a
compatible battery purchased from Wyse (refer to the Wyse Web site). Always dispose of used batteries according to the instructions accompanying the
battery.
•The X class mobile thin clients contain an internal button cell battery replaceable by Wyse or one of our Authorized Service Centers. For service, visit
http://www.wyse.com/serviceandsupport/service/service.asp. There is a risk of explosion if the battery is replaced by an incorrect type. Always dispose
of used batteries according to the instructions accompanying the battery.
•Perchlorate Materials - Special Handling May Be Required under California Code of Regulations, title 22. (Only required within the U.S.A.)
Caution Statements

2
Refer to the figures and proceed as follows:
1. Install the Battery
With your mobile thin client turned off, insert battery in the
battery compartment located on the underside of the mobile thin
client and secure it by sliding the latches.
Caution: Fully charge the battery for four to eight hours
before first use in battery mode.
To Remove Battery - With your mobile thin client turned off and
disconnected from the power adapter, slide the battery lock to
unlock, and then slide and hold the battery release latch to
gently pull the battery out of the battery compartment.
2. Connect the Power Cable
Plug the power adapter connector to the mobile thin client as
shown. Plug the AC power cable to the power adapter, and then
plug the other end of the power cable to a wall outlet.
Note: You can connect the power adapter at any time with
the computer turned either on or off.
3. Turn On the Mobile Thin Client
Raise and adjust the lid, and press the power on/off button for
two seconds. When you release the power on/off button, the
power icon on the system indicators lights up.
To Turn Off the Mobile Thin Client - Press the power on/off
button, or go to Start | Turn Off Computer and click Turn Off.
After turning on, the mobile thin client initially goes through
several boot sequence procedures before the operating system
loads. Information about setting up your server environment is
available in your product’s operating system administrators guide.
*Zero client not applicable.
Your mobile thin client makes connections through:
•Wired Net/LAN
•Wi-Fi
•Express card provided by data carriers
•Smart card*
•Bluetooth*
*Smart card and Bluetooth are features for X90Le and X90LeW.
Information about connecting your mobile thin client to the Internet
is available in the product’s users guide.
Setting Up Your Mobile Thin Client
Configure
Default User Names and Passwords* (case sensitive)
Enhanced SLE XPe / WES
Administrator
User Name admin Administrator
Password admin Administrator
User
User Name thinuser User
Password thinuser User
Making Connections
1Warning: Listening to audio at high volume levels for extended durations can damage your
hearing.
2Smart card slot is a feature for X90Le and X90LeW; insert with electrical contacts facing
upwards.
3Not all USB devices are supported; check with Wyse or your Wyse representative to find out if a
particular device is supported on your mobile thin client.
*Express card slot accepts either ExpressCard/34 or ExpressCard/54 formats.
Views
Bottom View
1Battery lock
2Battery release latch
3Battery
Front View
1System indicator lights
2Release latch
Back View
1VGA port
2LAN RJ45
Right View
1Line out/Headset out14USB port (3)3
2Microphone in 5Power adapter input
3Smart card slot26Kensington lock slot
Left View
1DVI port 3SD card slot
2USB port 4Express card slot*

3
System Indicator Lights*
*System status indicators light when a particular function of the mobile thin client is active.
Numeric Keypad
The numeric keypad numbers and symbols are printed in blue on
the keypad keys. Press Num to enable or disable the numeric
keypad.
Keyboard Function Keys for System Control
To use the function keys, press and hold the Fn key while pressing
the appropriate function key (F2, F10, and the rest).
*Bluetooth is a feature for X90Le and X90LeW.
Inside View
1Display
2Power on/off button
3Keyboard
4Function key
5System indicator lights
6Touch pad button (2)
7Touch pad
About Your Mobile Thin Client (MTC)
Light Color Description
Power Blue Mobile thin client is turned on
Wireless Blue Wireless signal is enabled
Battery Amber on
Amber flash Battery is charging Battery is low (5% remaining)
Caps lock Green Keyboard caps lock is on
Num Lock Green Keyboard numeric lock is on
Wyse X90L, X90LW, X90Le, and X90LeW Function Keys:
Icon Key Description
Fn Fn Function key
Fn + Esc Volume mute
Fn + F2 Wireless and Bluetooth*- on/off
Fn + F10 Display switch - LCD / LCD+CRT / CRT
Fn + F12 Standby
Scr Fn + Num Scroll lock - on/off
Break Fn + Pause Break
Prt Scr Fn + Insert Print screen
Sys RQ Fn + Delete Sys RQ
Home Fn + PgUp Home
End Fn + PgDn End
Fn + ↓Brightness - decrease
Fn + ↑Brightness - increase
Fn + ←Volume - decrease
Fn + →Volume - increase
Wyse X50L Function Keys:
Icon Key Description
Fn Fn Function key
Fn + F12 Standby
Scr Fn + Num Scroll lock - on/off
Break Fn + Pause Break
Prt Scr Fn + Insert Print screen
Home Fn + PgUp Home
End Fn + PgDn End
Fn + ↓Brightness - decrease
Fn + ↑Brightness - increase
Power Management
Proper power management for your mobile thin client will prolong
battery life and reduce heat dissipation. For information on setting
up power saving modes, refer to your product’s users guide.
Wyse Reference Guides - User, Administrator, and related
documentation is available at:
http://www.wyse.com/manuals
Wyse-Approved Accessories - Information about approved
accessory options are available at:
http://www.wyse.com/products/accessories
Wyse Service and Support - Upgrade software images for
installation on your FTP file server are available at:
http://www.wyse.com/support
Wyse Device Manager - Information about Wyse remote
management software that comes with your mobile thin client is
available at:
http://www.wyse.com/bundle
Wyse WSM - Information about Wyse WSM software is
available at:
http://www.wyse.com/products/software/wsm
Wyse and the Environment - Information about Wyse compliance
with RoHS and with the Waste Electrical and Electronic Equipment
(WEEE) is available at:
http://www.wyse.com/green
Wyse Warranty Registration - Wyse’s warranty registration*
process is available at:
http://www.wyse.com/serviceandsupport/register.asp
*The standard warranty is one year from the date of purchase of the device and six months for the
battery.
Need more information?

©2009 Wyse Technology Inc. All rights reserved. This product and/or associated software are
protected by copyright international treaties, and various patents, including the following U.S.
patents: 6,836,885 and 5,918,039.
883907-01L Rev. C
December 2009
