Wyse®RclassTM cloud clients
All youneed toknow.Here.Wyse R class: All youneed toknow.Here.
Best power, expandability and display performance

Wyse R50L
High performance,
slim thin client,
SUSE Linux
Enterprise.
Wyse R90L
High performance,
slim thin client,
Microsoft Windows
XP Embedded.
Wyse R90LW
High performance,
slim thin client,
Microsoft Windows
Embedded
Standard.
Wyse R50LE
High performance
thin client,
comprehensive
expansion options,
SUSE Linux
Enterprise.
Wyse R90LE
High performance
thin client,
comprehensive
expansion options,
Microsoft Windows
XP Embedded.
Wyse R90LEW
High performance
thin client,
comprehensive
expansion options,
Microsoft Windows
Embedded Standard.
Wyse R10L
High performance
paired with
simplicity and
security, Wyse
Thin S.
Wyse R00LE
High performance,
comprehensive
expansion options,
cloud PC for
Wyse WSM.
Start Features TechnicalModels Print
Introducing the Wyse R class cloud clients
Wyse R class cloud clients cater for everything your users need from
their desktop PCs. Without the things you don’t. Like moving parts,
wasted energy, insecure hard drives and excessive unnecessary heat.
Instead we’ve built in what matters the most to you: Powerful processors, dual monitor
support, fast graphics and a host of USB ports for those vital everyday peripherals.
Perfect when you need a cloud client desktop capable of voice, data and video.
Wyse R90L7
Harnesses the rich
user experience of
Microsoft Windows
Embedded
Standard 7.
Wyse R00L
High performance,
slim form factor
cloud PC for
Wyse WSM.
Cloud PCs Thin Clients

Features Wyse R class cloud clients
Created with performance and expandability in mind, the new Wyse R class
joins the uniquely integrated range of Wyse Cloud Client Computing
hardware and software. Wyse R class features high performance central and
graphics processors coupled with full support for multiple screens, and the
best PC experience available on a thin computing platform with the Wyse
TCXTM Suite of virtualization software. Wyse Device Manager supports the
Wyse R class with scalable enterprise-wide management including simple
deployment, patching and updates and asset management – all with secure end-
to-end encrypted communications.
Finally, each and every Wyse R class cloud client contributes – quietly and coolly –
to lowering your organization’s carbon footprint, with power usage and emissions
that are a fraction of traditional PC desktops.
Start Features TechnicalModels Print
Green
Performance
L Family
Connectivity
LE Family
Connectivity
Mounting
Options
Cloud PC
Provisioning
Thin Client
Management
Microsoft Windows
XP Embedded
Microsoft Windows
Embedded Standard
ser Experience
Optimization
Wyse Enhanced
S SE Linux
Take a tour of the
Wyse R class range features here
Visit: wyse.com
Learn more:
Simply click the Wyse R class feature icons.
ser Experience
Acceleration
Wyse
WSM
Wyse
WDM
Microsoft Windows
Embedded Standard 7
ThinOS
Wyse
ThinOS

Start Features TechnicalModels Print
Continue tour
By employing the advanced AT 690E chipset from AMD, the Wyse R class
family of cloud clients provides the best graphics performance in their class.
With a maximum resolution of 2560x1600 on a single display (RL-family) or
two displays (RLE-family) these devices will support any high-end graphics
application, with support for dual monitors with standard DV - and DV -D ports.
n addition, Wyse R class includes support for Pixel Shader 2.0 that’s
Windows 7 with Premium Aero GU compliant, which will be a requirement
for running some of the latest and forthcoming technologies from Citrix,
Microsoft and VMware.
Performance High Performing central and graphics processors
AMD ATI 690E
Windows 7 ready
The most powerful and highly optimized
graphics engine in its class.
• Multiple display support
• Built-in support for Full DirectX 9.0
• 3D Acceleration Features
• Support for OpenGL
• Motion Video Acceleration
Features (MPEG-2, MPEG-4
and WMV9)
AMD
Sempron Processor
The advanced technology contained in this
CPU from AMD lowers power consumption
without compromising performance.
• AMD64 Technology
• PowerNow! technology
• HyperTransport technology
• Built to support Microsoft®
Windows®XP Embedded,
as well as Linux.

Start Features TechnicalModels Print
Continue tour
R class L-Family connectivity
Wyse R00L cloud PC; R10L, R50L, R90LW and R90L7 thin clients
Well connected
ne DVI-I port
ne DVI-D port
Audio In: 1/8-inch mini,
8 bit stereo microphone
Six available external
USB 2.0 ports
(2 front; 4 back)
Wi-Fi antenna
connector for optional
802.11 b/g/n
Audio out:
1/8-inch mini,
16 bit stereo
Internal mono
speaker
10/100/1000
Base-T Gigabit
ethernet port
Kensington lock
slot
Two serial ports
Two PS/2 ports for keyboard and mouse

Start Features TechnicalModels Print
Continue tour
R class LE-Family connectivity
Wyse R00LE cloud PC; R50LE, R90LE and R90LEW thin clients
Well connected
One parallel port
Two serial ports
Two PS/2 ports for keyboard and mouse
ne DVI-I port
ne DVI-D port
Audio In: 1/8-inch mini, 8 bit stereo microphone
Six available external
USB 2.0 ports (2 front; 4 back)
Wi-Fi antenna
connector for optional
802.11 b/g/n
Kensington lock slot
One PC e 1.1a x4 with
x16 slot
Audio out: 1/8-inch
mini, 16 bit stereo
Internal mono speaker
10/100/1000 Base-T
Gigabit ethernet port

Start Features TechnicalModels Print
Continue tour
Mounting options
Back of monitor or wall mounting
• An optional VESA mount bracket enables
mounting on the back of a monitor or on a wall
(this requires the four industry standard
mounting points to be free). The same bracket
can be used for wall mounting, or in a secure or
ruggedized cabinet if required.
Vertical
• Each Wyse R class is supplied as
standard with feet for vertical use.
Horizontal
• ptional feet enable Wyse R class to be
used horizontally.

Going Green
with Wyse Cloud Client ComputingTM
Many Wyse R class models are EnergyStar certified,
a recognized sign of energy efficiency. Through our
EarthSmart Computing initiative we are committed to
helping organizations implement a greener computing
strategy - one that delivers a more efficient and productive
computing experience for your users with a positive effect
on energy wastage, heat and carbon emissions.
Green Power
Wyse R class cloud clients use between 12 and 15 watts of
power in typical use*. n comparison, a typical PC would use
between 70 and 150 watts. Even in sleep mode Wyse R class
units draw just 2 watts while being fully remotely managed.
Then, when you include additional power requirements in the
data center, a thin computing deployment will deliver power
savings of between 50 and 90%.
Learn more
Download carbon calculators, fact sheets and white papers
from here: www.wyse.com/green
*Average power usage with
device connected to 1 keyboard,
1 PS/2 mouse, and 1 monitor.
Start Features TechnicalModels Print
Continue tour
That’s Wyse
EarthSmart
Computing
Desktop computing Without compromise

Continue tour
Cloud PC Provisioning Wyse WSM
Start Features TechnicalModels Print
Approved final 101110.
Enterprise co puting fro the cloud is here.
Whatever you want. Wherever you need it.
That’s the thinking behind Wyse WSM. It’s a dynamic on-demand streamed computing environment
where everyone gets their preferred operating systems, applications,
user data and documents: Wherever they are and whenever they need them.
And Wyse WSM goes beyond the traditional VDI model too - with full support for mobile workers and
remote branch offices. Wyse WSM effectively changes the rules on what’s possible and opens up
the benefits of high performance desktops to enterprise users: Wherever they are.
Better than a PC could ever be.
With Wyse WSM users - such as those in the financial or retail industries - are given a fresh
computer with their chosen PC operating system, applications and files all preloaded and ready-to-
go, every time they sit down and start-up their powerful desktop devices known as Wyse ‘cloud PCs’.
Wyse cloud PCs feature powerful processors that enable them to run full PC operating systems and
applications locally, while keeping their documents and data secure on central Wyse WSM servers.
Enabling existing PC users to continue to use all their familiar operating systems and applications
seamlessly - but with greater reliability and better overall performance than a full PC - with the result
that many users don’t even realize they’re using a cloud PC.
And - better still, Wyse WSM features a highly secure, robust and resilient network design that’s ideal
for remote offices and mission critical deployments such as the defence industry.
With everything anaged, updated, configured re otely
and securely, Wyse WSM is everything a PC pro ises.
Minus the headaches.

Thin Client Management Wyse Device Manager
Start Features TechnicalModels Print
Continue tour
Approved final 101110.
• HTTPS Based Imaging / Updates
• Fully Encrypted Network Traffic
• Delegated Admin Access (MS AD) Support
• Complete Device Imaging / Patc ing / Updates
• Bandwidt T rottling for Efficiency / Reliability
• Software Updates and Add-ons
• Device Healt Status / Reporting
• Remote S adowing / Control
• Default Device Configuration
• Distributed Arc itecture
• Microsoft SQL Database Support
• Multiple Remote Repository Support
• Automated device discovery
• Detailed Hardware Asset information
• Installed Software Asset information.
Security
No-Hassle Deployment
Device Administration
and Monitoring
Scalability
Complete Asset Visibility
At a glance features:
Wyse Device Manager (WDM) addresses ey management requirements
for deploying powerful thin clients. With its centralized management
and administration WDM helps IT departments deliver more effective
remote thin client support while minimizing end user downtime.
Security is assured with HTTPS based imaging, updates and downloads.
WDM delivers organization-wide benefits:
Operations Centralized management.
Collect and organize asset information.
Administration Healt status reports.
Automated client settings.
Update client firmware and add applications.
End User IT Costs Easier more effective remote support.
Create custom scripts and packages.
Minimize downtime Restart or reset t in clients in less t an a minute.
Enforce policies. Minimize user errors.

User Experience Optimization Wyse TCXTM Suite with Collaborative Processing ArchitectureTM
Wyse TCX delivers an amazing ser experience in one software s ite.
Wyse TCX Suite of virtualization software enriches the user experience by removing the limitations previously associate with thin clients.
It enhances, not replaces, key protocols like ICA/HDX an RDP by a ing key features to make each more valuable.
M lti-display
Ensures application
win ows an ialog
boxes are multi-monitor
aware when using more
than one monitor.
Bi-directional so nd
Enables bi- irectional au io in
virtual esktop environments,
enabling solutions such as VOIP,
igital ictation or voice recognition
to be eploye .
Start Feat res TechnicalModels Print
USB Virt alization
Enables plug an play peripheral
support for virtual esktop
environments.
• Re irect an use local USB
evices in virtual esktops.
• Deploy virtual esktops to
knowle ge workers with special
evice access nee s.
• Enable a broa set of USB
peripherals inclu ing webcams
an hea sets.
M ltimedia acceleration
Streamlines the elivery of vi eo an
au io content to the local client for a
rich user experience within a thin client
computing architecture.
• Accelerates Mpeg1, Mpeg2, WMV,
Mpeg4 Part 2, AC3, AAC, MP3, WAV,
WMA me ia types.
• Collaborative Processing Architecture
enhances server scalability, an
network utilization by off-loa ing
multime ia ren ering to the client. Contin e to r
Flash acceleration
Flash acceleration helps thin client
users to experience improve Flash
vi eo performance. While the Flash
player continues to run server-si e, the
resulting images are transco e an
re irecte to the client for fast
ren ering. The technology allows for
greater control of frame rate an
compression an supports enhance
playback of YouTube-style flash vi eos
in Internet Explorer.
Approve final 101110.

Removing the barriers of network latency
Wyse Virtual Desktop Accelerator (VDA) enables virtualized desktop and thin
computing environments to be deployed to areas where network latency has, to date,
presented operational barriers. Now, with Wyse VDA, more users can receive the full
benefits of Wyse thin computing – with the best PC experience over virtualized
desktops.
Wyse VDA is a software-only solution for Wyse thin clients
and supported PCs that delivers the best user
experience for the allocated network bandwidth by
neutralizing the effects of network latency and
packet loss. Making thin’ suitable for more
remote-site, branch, or field-based users.
Wyse VDA works with instead of replacing
existing RDP and ICA protocols, accelerating
them by up to 20 times on networks faced with
latencies up to and beyond 300ms, and at
least 768kbps bandwidth.
At a glance features:
• Software-only acceleration of virtual desktops and applications
• Accelerates existing Citrix ICA and Microsoft RDP protocols
• Works on WANs and fat, long pipes’
• Accelerates connections to Citrix XenApp, Citrix XenDesktop, VMware View
and Microsoft Terminal Server and Microsoft Hyper-V VDI
• Enhances Wyse TCX software suite functionality across wide-area networks
• Enables Wyse Collaborative Processing Architecture across
wide-area networks
• Administrator console provides control of maximum bandwidth per
connection
• Leverages built-in security of underlying protocols (128-bit encryption for
RDP and ICA).
Continue tour
Start Features TechnicalModels Print
Virtuali ation Software Wyse Virtual Desktop Accelerator
Generic WVDA approved final 010410

Operatin Systems Wyse ThinOS7
Start Features TechnicalModels Print
Continue tour
Wyse ThinOS is the most secure, mana ement-free solution for
cloud and virtual computin environments with built-in support
for the latest infrastructures includin Citrix, Microsoft, VMware
and other vendors.
Fast. Simple. Secure
This fast, purpose-built thin computing platform boots up in seconds, updates itself
automatically, and provides IT managers with simple, scalable administration to suit their
organization’s needs. Security is assured too as there’s no pubished API – giving you an
environment that’s immune from malware.
Management is simple with time consuming tasks such as software and configuration
updates automated via central file servers (ftp, http, and https) where Wyse thin clients
can check-in for their updates. So, whether you have 10, 100 ...or 1000 devices, rolling
out a new update is as easy as dropping a file onto your file server.
New Zero Launchpad optimizes Virtual Desktop Deployments
By harnessing the power of the new Wyse Zero engine, Wyse ThinOS delivers fast
and secure desktops with user experiences based an individual’s access levels.
Logging on is fast and easy too with no double desktop dramas. There’s just one
screen for inputting their credentials before users are immediately presented with
their assigned desktop(s).
Finally, the new Wyse Zero toolbar gives advanced users the option to switch
between multiple virtual desktops or modify local settings (i.e. display resolution)–
all without leaving their virtual desktop environment.
Wyse ThinOS delivers a wealth of innovative,
user-oriented and productive features:
Instant-on, simple access for users
• New Zero launchpad and Zero toolbar adapt to provide simple and advanced access depending
on user privileges.
• With class-leading boot-up times, users are ready to login in seconds.
Automated Mana ement
• Wyse ThinOS enables simple, scalable device management from day one without the need for basic
management software.
• For more in depth management Wyse ThinOS features complete integration with Wyse Device Manager.
Security
• Featuring an unpublished API and no file system, Wyse ThinOS is inherently secure providing maximum
security from malware and viruses.
• Secure remote access using Citrix Access Gateway (CSG mode) or VMware Security Server, including dual
authentication with RSA SecureID.
Best HDX and RDP in a non-windows client
• Support for latest HDX features including multimedia playback, USB webcam remoting, new audio
codecs for VoIP, dual factor authentication, etc.
• Wyse is the only vendor with an RDP 7 compatible client on non-windows OS - other vendors use
RDESKTOP (based on RDP 5.x)
• ICA and RDP performance outperforms other non-windows clients
by 3x (on comparable hardware).
• Enhance existing protocols further with Wyse TCX
(i.e. Multicasting, high latency support, USB on terminal server, etc)
Approved final 101110.

Operating Systems SUSE Linux Enterprise Thin Client
Start Features TechnicalModels Print
Wyse Enhanced SUSE Linux Enterprise Thin Client (SLETC) is a simple,
secure, and easy to manage plat orm designed or customers looking or
lexibility and support o the latest protocols (ICA, PCoIP, RDP, etc)
without the need or a Windows-based thin client.
Thin-Linux or the Enterprise
Wyse Enhanced SLETC is not a ‘home-brew’ Linux. In fact, it’s the industry’s only
enterprise-quality Linux platform, created by combining the security and flexibility of
ovell’s SUSE Linux with Wyse’s cloud client computing leadership and innovation in
user experience and simplified management.
Additionally, SLETC is the only thin-Linux platform to
protect customers from potential IP infringement suits as
it is jointly indemnified by ovell and Microsoft.
Simple “Hands-O ” Management
Deploying, managing, and updating SLETC is easier than
any other thin-Linux distribution, Period. Utilizing Wyse’s
proven automatic update and configuration approach,
management tasks can be handled centrally and easily
without any management software required.
Updating 1 or 1,000 thin clients is as simple as dragging and dropping a file into a
folder. For customers that desire a little more hands-on approach (such as asset
tracking, reporting, etc) then integration with Wyse Device Manager is built-in.
Security
Wyse Enhanced SLETC is designed with security in mind. IT Managers are able
to provide a locked-down experience, smartcard login to virtual environments,
VP connectivity, and leverage a read-only file system that protects against
data loss, theft and virus attacks.
Flexible, Multi-Protocol Support
Being built from a standard enterprise-quality Linux distribution means SLETC
supports a wide range of protocols and infrastructures straight-out-of-the-box
including Citrix, Microsoft, VMware and even your legacy applications (such as
terminal emulations) - allowing you to mix-and-match connections from a
single SLETC image.
Continue tour
That’s Wyse Enhanced SUSE Linux Enterprise Thin Client
The only enterprise-quality Linux that’s optimized for thin client computing.
Approved final 101110.

Start Features TechnicalModels Print
Running Microsoft Windows XP E bedded on Wyse thin clients
gives IT depart ents the ability to support Citrix ICA, Microsoft
RDP and VMware View environ ents and deploy fully functional
desktops with better anageability and significantly lower total
cost of ownership than personal co puters.
Wyse Enhanced Microsoft Windows XP Embedded-based thin clients
can run 32 bit Microsoft Windows applications, either locally or from
servers located on the network, with inbuilt flexibility to add and
support a host of desktop peripherals with
permission from the IT administrator.
Secure write-protected
thin desktops
This robust and flexible operating system
is further enhanced by the Wyse file-
based Write Filter that enables you to
protect the file system image from
accidental changes or user customization.
n rebooting, the thin client simply returns to the required file system
image state.
Wyse custo ized i age support
Wyse technicians are able to help you customize Windows XP
Embedded to your exact requirements and create bespoke system
images for subsequent enterprise-wide deployment, management
and update through Wyse Device Manager.
Contact your Wyse Partner for further details.
Generic MS XPE overview approved final 181209
Operating Syste s Microsoft Windows XP Embedded
Continue tour

Start Feature TechnicalModel Print
Running Window Embedded Standard (WES) on Wy e thin
client give IT department the ability to deploy fully functional
de ktop client with better manageability and ignificantly lower
total co t of owner hip than per onal computer .
Wyse WES 2009-based thin clients can run 32 bit Microso t Windows
applications, either locally or rom servers, with the inbuilt lexibility to
add and support a host o desktop peripherals with permission rom
the IT administrator.
Full support is provided or RDP 7.0, Citrix
ICA 11.2, VMware View 4.0.1 and Internet
Explorer 8.
Secure write-protected
thin client de ktop
This robust and lexible operating system
is urther enhanced by the Wyse ile-based
Write Filter that enables you to protect the
iles, older and/or entire volumes rom
accidental changes or user customization. On rebooting, the thin client
simply returns to its original state thus preventing any possible
damaging modi ication either rom users or malware.
Wy e cu tomized image upport
Wyse technicians are prepared to help you customize Windows
Embedded Standard 2009 to your exact requirements in order to
create custom-built images or subsequent enterprise-wide
deployment, management and update through Wyse Device Manager.
Contact your Wy e Partner for further detail .
Continue tour
Operating Sy tem Microsoft Windows Embedded Standard 2009
Approved inal 101110.

Start Features TechnicaMode s Print
New Windows Embedded Standard 7 (WES 7) de ivers a wea th of
enhanced dep oyment, user experience and management benefits
to Wyse desktops, mobi es and thin c ients dep oyed across an
organization’s virtua ized network.
Richer user experience
Wherever they are - deskbound or mobile - with Microsoft Windows
Embedded Standard 7 your users can benefit from the rich user experience
of the Aero interface and the power, familiarity and reliability of the Windows
7 operating system in a highly customizable
and componentized form.
Full support is provided for Remote Desktop
Protocol (RDP) 7.0 to provide seamless
connectivity to Windows Server 2008 R2 and
virtual desktop infrastructure scenarios. The
Wyse-enhanced WES7 platforms include
additional features supporting the latest Citrix
nline Plug-in and VMware View 4.5 to fit the
needs of your most sophisticated users and
making it an optimum S for organizations
wanting broad support for Cloud computing and desktop virtualization. Citrix
nline Plug-in provides the HDX user experience and View 4.5 provides
localization and Virtual Printing.
The platform also features additional Windows technology innovations to drive rich,
immersive user experiences, including Internet Explorer 8.
There’s full support and inbuilt flexibility too, to add and support a host of desktop
peripherals with permission from the IT administrator.
Easier to manage and dep oy
Now, with WES7, deploying 32-bit capable thin clients is easier and more manageable
than ever before and reflects the direct working relationship between Wyse and Microsoft.
The support for Domain Join and group policies through Active Directory, along with
support for management infrastructures like Microsoft System Center Configuration
Manager (SCCM), help with management and integration of thin clients into existing
desktop management infrastructures.
Wyse Device Manager (WDM) addresses key management requirements for deploying
powerful thin clients. With its centralized management and administration, WDM helps IT
departments deliver more effective remote thin client support while minimizing end user
downtime. While to help IT and Customer Service staff, a simple USB imaging solutions,
Wyse USB Firmware Tool, allows to quickly and easily manage image supported devices.
Enterprise-wide consistency
Wyse Embedded Standard 7 and Wyse provide the ideal, cost effective opportunity to
deploy a consistent, high performance operating system across Wyse cloud clients.
Take the Tour again
Operating Systems Microsoft Windows Embedded Standard 7
Approved final 101110.

Start Features TechnicalModels Print
©2010 The Wyse logo and Wyse are trademarks of Wyse Technology nc. Other product names mentioned herein are for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies. All specifications are subject to change without notice. Whilst we make every effort to ensure the accuracy of the details, specifications, models, images
and benefits featured in this datasheet, we cannot be held responsible for any errors and/or omissions. f you have any queries regarding Wyse products please contact your authorized regional
Wyse Partner or representative for further information and assistance. Some features require support by server operating system and protocol. Approved final 101110.
Wyse offers cloud client computing sales, service
and support expertise around the globe.
Click here for contact details of your regional Wyse office.
Contact Wyse
Wyse Technology Inc.
3471 North First Street, San Jose, CA 95134-1801
Visit our website at:
http://www.wyse.com or send an email to: [email protected]
Wyse Sales
800 GET WYSE (800 438 9973)
nternational customers please dial:
00 1 408 473 1200
Wyse Customer Service Center:
800 800 WYSE (800 800 9973)

Wyse Enhanced
S SE Linux Enterprise
Wyse R00L Cloud PC; R10L,
R50L, R90LW and R90L7 thin
clients
Microsoft Windows
Embedded Standard 2009
Microsoft
Windows XP Embedded
Wyse R00LE cloud PC; R50LE,
R90LE and R90LEW thin clients
Technical Wyse R class specifications
Visit: wyse.com
Learn more. Simply click these data sheet icons
The Wyse R class family of cloud clients is available in L and LE
configurations. Choose from versions featuring Wyse Thin S, Wyse Enhanced
SUSE Linux, Microsoft Windows XP Embedded, Windows Embedded Standard
2009 and Windows Embedded Standard 7 (RL Family only). Provisioned
environments are supported with Wyse WSM.
Wyse WSM
Start Features TechnicalModels Print
Wyse
WSM
Microsoft Windows
Embedded Standard 7
Wyse Thin OS
Wyse
ThinOS

Wyse R class L-Family Specifications: R00L Cloud PC; R10L, R50L, R90LW and R90L7 thin clients
Start Features TechnicalModels Print
Processor 1.5 GHz AMD Sempron Processor
Memory R00L 0/1GB or 0 / 2GB RAM
R10L 128MB Flash / 512MB RAM
R50L 1GB Flash / 1GB RAM
R90L 1GB Flash / 1GB RAM
R90LW 2GB Flash / 1GB RAM
R90L7 4GB Flash / 2GB RAM
up to 4GB Flash / 2 GB RAM
I/O peripheral support One DV - Port
One DV -D Port
Two PS/2 ports
Two serial ports
Six external USB 2.0 ports (2 front; 4 back)
One Mic n
One Line Out
Included Optical mouse and PS/2 keyboard
Graphics AMD AT 690E
Microsoft Windows Vista Premium and Windows 7 ready
Networking/Comm 10/100/1000 Base-T Gigabit Ethernet
802.11 b/g/n and Bluetooth 2.0 (optional)
Display VESA monitor support with Display Data Control (DDC) for automatic
setting of resolution and refresh rate
Dual monitor supported*
Single: 2560X1600 32 bpp 60Hz
Dual: 2560X1600 32 bpp 60Hz
Audio Out: 1/8-inch mini, 16 bit stereo. nternal Mono speaker.
n: 1/8-inch mini, 8 bit stereo microphone.
Factory options nternal wireless option 802.B/G/N for R10L and R50L
nternal wireless and bluetooth option 802.B/G/N for R90L, R90LW and R90L7
Fiber Optic-ready Wyse R90LW**
Power Worldwide auto-sensing 100-240 VAC, 50/60 Hz. Energy Star® V.5.0 compliant
power supply. Average power usage with device connected to
1 keyboard with 1 PS/2 mouse and 1 monitor: 14.6 Watts in idle state.
Shipping weight 6.50 lbs. (2.95kg)
Mountings Vertical or Horizontal (optional), VESA mount.
Security Built-in Kensington security slot (cable sold separately)
Dimensions 250mm x 225mm x 53mm (9.8 in. x 8.8 in. x 2.1 in.)
Temperature Range Horizontal position: 50 to 95 F (10 to 35 C)
Vertical position: 50 to 104 F (10 to 40 C)
Humidity 20% to 80%
Hardware Warranty Three-year hardware warranty. Visit our web site for WyseChoice extensions
and upgrades
Certifications German EK - TB 2000, SO 9241-3/-8
cULus 60950, TÜV-GS, EN 60950
FCC Class B, CE, VCC , C-Tick
WEEE, RoHS Compliant
Hardware specifications
* R10L is 1920 x 1200 32 bpp 60Hz (single and dual)
** Fiber ptic Board not included. Please refer to release notes or your Wyse account manager for supported Fiber ptic Board.
